HP Media Center m200 - Desktop PC Hardware User's Manual

6
TV In
Connect TV signal to computer
Cable or
antenna
Signal
Coaxial cable
8 Remote Sensor
Connect remote control
receiver to computer
9
Power On
Computer to
electrical outlet
Turn on monitor,
computer, and
subwoofer
© 2002, 2003 Hewlett-Packard Development Company, L.P. All rights reserved.
If you use a cable or satellite set-top box,
pass the signal through the box
Cable or
satellite set-top box
IN OUT
FROM TO
ANT TV
or
Signal
Coaxial cable
If you use a cable or satellite
set-top box, pass the signal
through the remote sensor
or
Read your User's Guide
Register your PC
Setup your Internet
Service Provider
HP Support Web site:
http://www.hp.com/support
HP Customer Care Center
1-800-HP-INVENT
Hours: 24 hours, 7 days
HP Registration Web site:
http://register.hp.com
7
TV Out
TV signal from computer to TV
Second coaxial
cable not included
(TV connections are optional)
VIDEO IN
T V
See "Enabling TV
Out Image" in the
Hardware User's Guide
for TV display setup
Composite video cable
Cable or satellite set-top box
Locate IR window
Remote
on set-top box.
sensor Adhere to IR window.
control
cable
Remove
backing tape
