- Page 1 HP NetVectra HP NetPC HP Small PC Accessories Guide...
- Page 2 Notice The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Important Safety Information
Who this Manual is For This manual is for anyone who wants to install accessories in their HP NetVectra Net PC or Small PC. Important Ergonomic Information It is strongly recommended that you read the ergonomic information before using your Net PC. To view this information you can connect to HP’s ergonomic web site at... - Page 4 Net PC, or to HP so they can either be recycled or disposed of in a sound way. Returned used batteries will be accepted free of charge. If your Net PC is multimedia or if you add a sound card to your Net PC: Always turn the volume down before connecting headphones or speakers, to avoid discomfort from unexpected noise or static.
-
Page 5: Table Of Contents
Contents Accessories You Can Install ........8 Removing and Replacing the Cover . - Page 6 English...
- Page 7 Accessories Guide...
-
Page 8: Accessories You Can Install
Accessories Guide Accessories You Can Install Accessories You Can Install You can install the following accessories in the HP NetVectra Net PC and Small PC: Main memory modules • PCI or ISA accessory boards • A hard disk drive (replacing the one already installed) •... -
Page 9: Removing And Replacing The Cover
Accessories Guide Removing and Replacing the Cover Removing and Replacing the Cover WARNING For your safety, never remove the Net PC’s cover without first removing the power cord from the power outlet and any connection to a telecommunication network. Always replace the cover before switching the Net PC on again. -
Page 10: Replacing The Cover
Accessories Guide Removing and Replacing the Cover 5 Pull the sides outward and lift off the cover. Replacing the Cover 1 Ensure that you have installed all your accessories and that all internal cables are properly connected and safely routed. 2 Pulling out the sides, lower the cover onto the Net PC as shown. - Page 11 Accessories Guide Removing and Replacing the Cover 3 Slide the cover forward into place. 4 Replace the three rear screws. 5 Reconnect all the power cables. English...
-
Page 12: Removing The Front Chassis
Accessories Guide Removing the Front Chassis Removing the Front Chassis 1 Remove the cover (described on page 9). 2 Remove the two screws at the top of the chassis. 3 Carefully slide the front chassis forward until it is free of the main chassis, then place it upside down on the main chassis. - Page 13 4 On the system board, remove the front panel connector and the floppy disk connector (if you have one). 5 Remove the connectors from the hard disk drive. 6 Remove the connector from the CD-ROM drive (if you have one). 7 Lift off the front chassis and place it on a flat work surface.
-
Page 14: Installing Memory
Accessories Guide Installing Memory Installing Memory CAUTION Static electricity can damage electronic components. Turn all equipment OFF. Don’t let your clothes touch the accessory. To equalize the static electricity, rest the accessory bag on top of the Net PC while you are removing the accessory from the bag. Handle the accessory as little as possible and with care. - Page 15 To install a main memory module: 1 Disconnect the computer’s power supply cord and any connection to a telecommunication network. 2 Remove the computer’s cover (described on page 9). 3 Remove the front chassis and place it upside down on the rear of the Net PC (described in the section "Removing the Front Chassis", on page 12).
-
Page 16: Which Connectors To Use For Mass Storage Devices
Accessories Guide Which Connectors to Use for Mass Storage Devices Which Connectors to Use for Mass Storage Devices When you install a hard disk drive, a CD-ROM drive, or a floppy disk drive, ensure that you use the correct internal connectors: Slim Floppy Disk Drive Connector Slim CD-ROM Drive Connector English... -
Page 17: Replacing The Hard Disk Drive
Accessories Guide Replacing the Hard Disk Drive Replacing the Hard Disk Drive Your Net PC has one hard disk drive installed. You can replace the installed disk drive with a larger disk drive. CAUTION Handle the hard disk drive with care. Avoid shocks and violent movement as this can cause damage to the hard disk drive’s internal components. - Page 18 Accessories Guide Replacing the Hard Disk Drive 5 Remove the screws securing the hard disk drive. 6 Carefully remove the hard disk drive from the front chassis. English...
-
Page 19: Installing The Hard Disk Drive
Installing the Hard Disk Drive 1 Carefully slide the hard disk drive into the shelf, then secure the drive with the screws. 2 Place the front chassis upside down on the rear of the Net PC. 3 Connect the power and data cables to the rear of the drive. The connectors are shaped to go in one way only. -
Page 20: Installing A Slim Cd-Rom Drive
Accessories Guide Installing a Slim CD-ROM Drive Installing a Slim CD-ROM Drive WARNING To avoid electrical shock and harm to your eyes by laser light, do not open the laser module. The laser module should be serviced by service personnel only. Do not attempt to make any adjustment to the laser unit. - Page 21 Accessories Guide Installing a Slim CD-ROM Drive 7 Fasten the four screws to secure the CD-ROM drive. 8 Attach the CD-ROM data adaptor to the back of the CD-ROM drive. 9 Replace the hard disk drive (described on page 19). 10 Place the front chassis upside down on the rear of the Net PC.
- Page 22 Accessories Guide Installing a Slim CD-ROM Drive 11 Connect the data cable to the CD-ROM drive and the system board. 12 Reconnect the hard disk drive cables, the front panel cable, and the floppy disk drive cable (if you have a floppy disk drive). 13 Replace the front chassis, ensuring that all cables are properly routed as you slide it carefully into place.
-
Page 23: Installing A Slim Floppy Disk Drive
Installing a Slim Floppy Disk Drive 1 Switch off the display and computer, and disconnect the power supply cables and any telecommunication cables. 2 Remove the computer’s cover (described on page 9). 3 Remove the front chassis (described on page 12). 4 For improved access, remove the hard disk drive (described on page 17). - Page 24 Accessories Guide Installing a Slim Floppy Disk Drive 8 Slide the floppy drive into the front chassis as shown and secure it with the three screws. 9 Replace the hard disk drive (described on page 19). 10 Place the front chassis upside down on the rear of the Net PC. 11 Connect the ribbon cable provided to the floppy drive and the system board.
-
Page 25: Installing Accessory Boards
Installing Accessory Boards CAUTION Static electricity can damage electronic components. Turn all equipment off. Don’t let your clothes touch the accessory. To equalize the static electricity, rest the accessory bag on top of the computer while you are removing the accessory from the bag. Handle the accessory as little as possible and with care. -
Page 26: Installing The Board
Accessories Guide Installing Accessory Boards Installing the Board 1 Switch off the display and computer, and disconnect the power supply cables and any telecommunication cables. 2 Remove the computer’s cover (described on page 9). 3 Select a free accessory board slot. 4 If you are installing an ISA accessory board, you may need to slide the front chassis forward to allow access. - Page 27 7 Align the board’s connector with the slot’s socket. Firmly press the board into the socket. Ensure that the board’s connector engages completely with the socket. 8 Close the retaining bracket and fasten the screw. 9 If you moved the front chassis, slide it back into place and replace the two screws.
-
Page 28: Installing A Security Cable
2 Turn the key to lock the cable to the Net PC. 3 Remove the key and store it in a safe place. NOTE The Kensington ordered from HP. Contact your reseller for more information. English security cable, you can: security cable is not an HP accessory. It cannot be... -
Page 30: Troubleshooting Guide
HP NetVecta Net PC and Small PC Documentation User’s Guide The paper manual that came with your Net PC. Also available on HP’s web site at Describes how to set up and use your Net PC for the first time.
