Getting Started
Map Screen Legend
Map Orientation
(see page 63)
"North Up"
"Heading Up"
GPS Signal Strength
: Best Reception
: Good Reception
Missing: Poor/No Reception
Traffic Status Indicator
(see page 23)
"Breadcrumbs"
(see Off-road Tracking
on page 70)
Vehicle Position
(see page 71)
(Use voice command
"Display the current location," or
use the Interface Dial to show
current location.)
Current Street
(see page 6)
Current Map Scale
(see page 62)
Map Scale Adjustment
(Mile or km per half-inch appears only when you
zoom in or out by rotating the Interface Dial knob.)
NOTE:
See Map Legend on the INFO screen (Other) for further explanation.
20
Navigation System
One-Way Traffic Icon
(1/20 mile scale only) (see page 64)
Streets
(see Map Overview on page 6)
Interstates or Freeways
Verified Streets
Unverified Streets
Weather Icon
(see page 65)
Map Menu
(see page 58)
(Push in on the Interface Dial to view.)
Message Icon (see page 79)
Indicates that you have a message. View
messages by pushing in on the Interface Dial.
Warning Icon
Indicates that there are weather warnings.
To check the warning list, see page 83.
Landmark Icon - Generic (see page 64)
Honda Dealer
Acura Dealer
Hospital
School
Grocery Store
Restaurant
Gas Station
ATM
Hotel/Lodging
Parking Lot
Parking Garage
Post Office
Freeway Exit Information
Map Features
: Park
: Water Area
: Hospital
: Cemetery
: Shopping Mall
: University
: Golf Course
: Indian Reservation
: Airport/Stadium/Business
NOTE:
If you move the Interface Dial over an
area (map features shown above), the
name is displayed on the screen.
