Acura 2016 MDX User Manual

Table of Contents

Quick Links

The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd., reserves the right,

however, to discontinue or change specifications or design at any time without notice and without incurring any obligation.

Accessories Precautions

The GPS antenna is located in the dashboard. Metallic front or side window tinting can seriously degrade or obstruct GPS reception.

Signal noise from devices such as radar detectors, vehicle tracking devices, remote starters, and additional amplifiers can disrupt the navigation system. If you

install any such item, install it away from the navigation display and antenna.

Important Safety Information

Using the navigation system while driving can take your

attention away from the road, causing a crash in which you

could be seriously injured or killed.

Only operate system controls when the conditions permit you

to safely do so.

Avoid focusing on the screen or manually operating the system controls while driving.

Enter information before you begin driving or when stopped. As you drive, listen to the audible instructions and use voice commands when possible. Pull to the

side of the road if you need more time to look at the screen or operate the controls.

Route guidance may conflict with street closures, road construction, detours, and out-of-date map data.

The system itself may also have limitations. Verify route information by carefully observing roads, signs, and signals. Always use your own judgment and obey

traffic laws.

System Limitations

P. 316

00X31-TZ5-8210

WARNING

2016 MDX Navigation Manual Ver. 2

BNV02434

Table of Contents

Chapters

Table of Contents

Troubleshooting

Summary of Contents for Acura 2016 MDX

Page 1 Route guidance may conflict with street closures, road construction, detours, and out-of-date map data. The system itself may also have limitations. Verify route information by carefully observing roads, signs, and signals. Always use your own judgment and obey traffic laws. System Limitations P. 316 00X31-TZ5-8210 2016 MDX Navigation Manual Ver. 2 BNV02434...
Page 2: Table Of Contents
Contents Quick Reference Guide 2 System Setup P. 21 Start-up 22 Voice Control System 24 Interface Settings 28 Personal Information 40 Routing 55 Guidance 64 Map 71 Data Reset 87 System Setup On Demand Multi-Use Display™ 88 P.21 2 Navigation P. 89 Entering a Destination 90 Calculating the Route 114 Driving to Your Destination 116...
Page 3 Overview—Functions at a Glance Navigation You can select any place/landmark as a destination by using voice control or the Interface Dial. The navigation system gives you turn-by-turn driving directions to your destination. Store home address (P48) Register home address. Store contacts (P41) Store up to contacts in...
Page 4 ® AcuraLink (P258) ® AcuraLink provides you with important information and messages between your vehicle and Acura. Voice Control (P24) Use voice commands for safer system control while driving. You can operate all key functions of ® ® the navigation, audio, Bluetooth HandsFreeLink , and climate control systems.
Page 5: System Controls
System Controls On Demand Multi-Use Display E (Eject) Button PHONE Button (P214) Audio/Information Screen (Power) Button Volume Knob NAV Button BACK Button a (Display Mode) Microphone (P24) Button (P76) Interface Dial/ENTER Button (P7) Left Selector INFO Button Wheel (P150) MENU Button SOURCE Button (P150) SETTINGS Button...
Page 6 On Demand Multi-Use Display™ Basic Operation Audio Source Shortcuts Select to change an audio source. Places (P46) Phone (P224) Audio (P148) You can change the position of icons. * For detail informations about Climate, see your owner's manual. Select Tune. Select and hold a desired number you want to store the station.
Page 7 Voice Control Operation Voice Portal Screen The audio system is muted during voice control mode. a Press and release the d (Talk) button You can use other voice commands on the Voice Portal screen. on the top screen of any mode. Voice Command Index (P330) The system prompts you to say a voice Say d “Voice Help”...
Page 8 Interface Dial/ENTER Button Operation You will see these icons in each chapter. Rotate dial Press ENTER They represent how you can operate the Interface Dial. Changes scale Selects function Press ENTER Selects map icon Map screens Rotate dial Map screens FR ON T AU DIO Move up...
Page 9 How to Enter Information You can enter information (e.g., city names, street names, personal names, and business names comprising letters, numbers, and symbols) when prompted on input screens. Using the Interface Dial Rotate i to highlight a character. Select to display upper/lower case characters. Select to display symbols and accented characters.
Page 10: Map Screen Legend
No icon: Poor/No reception ® AcuraLink Message icon (P14) Map scale (P82) ® AcuraLink signal indicator Landmark icons (P73) Feature areas Acura dealer Airport/Business Park Honda dealer Hospital Water Area Cemetery Shopping Mall School Golf Course University Parking lot Parking garage...
Page 11: Map Screen
During Route Guidance During route guidance, route information is displayed on the map screen and guidance screen. Press the NAV button to toggle between the map and guidance screen. Map Screen Day or Night Mode Press the a (Display mode) button to Tracking dots Calculated route manually switch between day and night...
Page 12: Going Home
Navigation—Home Addresses and Going Home The “Home” feature automatically routes you to your home address from any location simply by selecting Go Home. Storing Your Home Address Going Home e Enter a name. a Press the SETTINGS a From the map screen, SETTINGS button.
Page 13 Navigation—Entering a Destination Enter your destination using one of several methods, then follow route guidance on the map or guidance screen to your destination. e Rotate i to select your destination h Rotate i to select Set as a From the map screen, street from the list.
Page 14: Adding A Waypoint
Navigation—Changing Route or Destination You can alter your route by adding waypoints to visit, adding streets to avoid, or changing your destination during route guidance. Adding a Waypoint Canceling Your Route f Select the icon category and location (“Pit Stop”) to add to the Destination List when a Press the MENU button.
Page 15: Acuralink Messages
® AcuraLink Messages ® AcuraLink provides a direct communication link between you and Acura. It sends and receives several kinds of messages through the Acura server. The following features are available: Vehicle feature guide Operating quick tips Safety and maintenance information...
Page 16: Basic Operation
Rear Entertainment System (P267) The rear passengers can enjoy a wide array of audio/visual sources with the Rear Entertainment System (RES). The rear passengers can use wireless headphones and operate the system with the rear control panel. Overhead Screen and Rear Control Panel Basic Operation Select the audio source.
Page 17 Voice Help This navigation system comes with voice help, which shows you what command to say when using the voice command functions. Command Help Getting Started Tutorial d Say one of the options for a list of available commands by category (e.g., a Press and release the d (Talk) a Move r and rotate i to select d “Find Place commands”).
Page 18: Troubleshooting
Troubleshooting (P297) For more Information How do I turn on the navigation system voice guidance? Why does the vehicle position icon on the map “lag” a short distance behind my actual position, especially at intersections? On the map screen, press u to display the Map Menu. This is normal.
Page 19 How to Use This Manual This section explains different methods on how you can easily find information in this manual. Searching the Table of Contents (P1) Two types of Tables of Contents help you find your desired information. Table of Contents Chapter Contents First, find the general chapter related to This more detailed table of contents...
Page 20: Menu Tree
Entering a Destination Address Book Address Book button Address Book MENU Address Book Select an address stored in your address book to use as the destination. If you have PIN-protected your address book, enter your PIN when prompted. Press u to 1.
Page 22: System Setup
System Setup This section describes the start-up procedure and the navigation and setup functions. Start-up .............. 22 Edit POI Search Radius Along Route....61 Data Reset ............87 Voice Control System ........24 Avoided Area ........... 62 Defaulting All the Settings ....... 87 Guidance ............
Page 23: Start-Up
Start-up Start-up The navigation system starts automatically when you set the power mode to ACCESSORY or ON. At start-up, the following Confirmation screen is displayed. If the navigation system loses power at any time, you may need to press and hold the 9 (Power) 1.
Page 24 Start-up ■ Limitations for Manual Operation Certain manual functions are disabled Disabled option or inoperable while the vehicle is in motion. You cannot select a grayed- out option using the Interface Dial until the vehicle is stopped. Voice commands are still operable while the vehicle is in motion.
Page 25: Voice Control System
Voice Control System d (Talk) Button Your vehicle has a voice control system that allows hands-free operation of most of the navigation system functions. When you press the d (Talk) button, the system The voice control system uses the d (Talk) and J (Hang-Up/Back) buttons on prompts you to say a voice command and gives examples.
Page 26: Voice Recognition
Voice Control System Voice Recognition Voice Recognition Voice Recognition To achieve optimum voice recognition when using the navigation voice control system: The voice control system can only be used from the driver’s seat because the microphone unit • Make sure the correct screen is displayed for the voice command that you are removes noises from the front passenger’s side.
Page 27: Voice Recognition Settings
Voice Control System Voice Recognition Settings Voice Recognition Settings H SETTINGS button System Settings Voice Reco Rotate i to select an item. Press u. The following items are available: • Voice Prompt: Turns the voice prompt on or off. On (factory default): Provides the voice prompts. Off: Disable the feature.
Page 28: Siri Eyes Free
Voice Control System Siri Eyes Free Siri Eyes Free ® When your iPhone is paired and linked to the system via Bluetooth , you can say Siri- Siri Eyes Free related commands. Make sure Siri on your iPhone is turned on. iPhone and Siri are trademarks of Apple, Inc.
Page 29: Interface Settings
Interface Settings Display Settings H SETTINGS button System Settings Display Display Settings Adjusts the screen’s preferences. You can set separate daytime and nighttime 1. Rotate i to select an item. Press settings for Brightness, Contrast, and Black Level. Adjust each setting when the display is in either daytime or nighttime mode.
Page 30: Sound And Beep Settings
Interface Settings Sound and Beep Settings Sound and Beep Settings H SETTINGS button System Settings Sound/Beep Sound and Beep Settings Changes the system sound and beep settings. Guidance Volume Rotate i to select an item. Press u. If you set Guidance Volume to 0, you will not hear route guidance or voice command confirmations.
Page 31: Clock Adjustment
Interface Settings Clock Adjustment Clock Adjustment H SETTINGS button System Settings Clock Clock Adjustment Set the automatic adjustment of the system clock for daylight saving and Auto Time Zone international time zones. If you live and work in two different time zones, Rotate i to select an item.
Page 32: Setting The Clock
Interface Settings Clock Adjustment ■ Setting the Clock Type H SETTINGS button System Settings Clock Clock/Wallpaper Type Clock 1. Rotate i to select an option to change the design. Press u. 2. Move r to select OK. Press u. ■ Setting the Clock H SETTINGS button System Settings...
Page 33 Interface Settings Wallpaper Settings Wallpaper Settings Wallpaper Settings Select, delete, and import wallpaper pictures for display on the screen. • When importing wallpaper files, the image ■ Import wallpaper must be in the USB flash drive’s root directory. Images in a folder cannot be imported. H SETTINGS button System Settings Clock...
Page 34 Interface Settings Wallpaper Settings ■ Select wallpaper Select wallpaper From the pop-up menu, rotate to select Preview H SETTINGS button System Settings Clock Clock/Wallpaper Type and press to see a preview at full-size screen. Wallpaper To go back to the previous screen, press to select 1.
Page 35 Interface Settings Wallpaper Settings ■ Delete wallpaper H SETTINGS button System Settings Clock Clock/Wallpaper Type Wallpaper 1. Rotate i to select a wallpaper that you want to delete. Press u. The preview is displayed on the left side on the screen. The pop-up menu appears on the screen.
Page 36: Unit Settings
Interface Settings Unit Settings Unit Settings H SETTINGS button System Settings Others Units Sets the map units to either miles (factory default) or kilometers (km). Rotate i to select the map unit. Press u.
Page 37: Language Settings
Interface Settings Language Settings Language Settings H SETTINGS button System Settings Others Language Language Settings Set the system language used on all screens. You can choose from three languages: Voice confirmation of cities and streets only occurs when English is the system language. English, Français (French), Español (Spanish).
Page 38: Voice Command Tips
Interface Settings Voice Command Tips Voice Command Tips H SETTINGS button System Settings Others Voice Command Tips Alerts you when manual control of the system is disabled to prevent distraction while driving. Only voice commands are available. Rotate i to select the map unit. Press u.
Page 39 Interface Settings Background Color Background Color H SETTINGS button System Settings Others Background Color Changes the background color of the audio/information screen and the On Demand Multi-Use Display Rotate i to select a desired color. Press u.
Page 40 Interface Settings Header Clock Display Header Clock Display H SETTINGS button System Settings Others Header Clock Display Selects whether the clock display comes on. Rotate i to select an option. Press The following options are available: • On (factory default): The system displays the clock in the audio/information screen. •...
Page 41: Personal Information
Personal Information H SETTINGS button Navi Settings Personal Info Personal Information Use the personal information menu to select and set your address books, home Personal information cannot be backed up or address, and PINs. You can also delete unwanted destinations from the list of moved to another navigation system.
Page 42: Address Book
Personal Information Address Book Address Book H SETTINGS button Navi Settings Personal Info Address Book Address Book Store up to 200 address entries in two address books (Driver 1 and Driver 2). You can Up to 200 addresses can be stored to each add, edit, and delete information in the address books.
Page 43 Personal Information Address Book 2. Rotate i to select an item. Press The following items are available: • Name: Edits the name of the entry. • Address: Edits the address of the entry. • Phone No.: Edits the phone number of the entry. •...
Page 44 Personal Information Address Book The following items are available: Adding an Address Book Entry • Current Position: Select your current location. When you use Place Name or Place Category, • Address: Enter an address on the character input screen when prompted. the phone number is automatically entered.
Page 45 Personal Information Address Book ■ Selecting an Address Book Category Selecting an Address Book Category Up to 100 categories (including “Unfiled”) can H SETTINGS button Navi Settings Personal Info Address Book be stored to each address book of Driver 1 and 1.
Page 46 Personal Information Address Book ■ Deleting an Address Book Entry Deleting an Address Book Entry H SETTINGS button When you transfer the vehicle to a third party, Navi Settings Personal Info Address Book delete all address book entries. 1. Rotate i to select the address to delete.
Page 47 Personal Information Address Book ■ Setting Place Shortcuts You can store up to six addresses previously stored in your Address Book, and a home address for your preset destinations. ■ Storing an address on the Shortcut 1. Select Shortcuts. 2. Select Places. 3.
Page 48 Personal Information Address Book 6. Select an address you want to store as a preset. ■ Deleting a preset address 1. Select Shortcuts. 2. Select Places. 3. Select Edit. 4. Select Delete. 5. Select the preset number with the destination you want to delete.
Page 49: Home Address
Personal Information Home Address Home Address H SETTINGS button Navi Settings Personal Info Edit Go Home Home Addresses Set a home address that you frequently use. If you have PIN-protected your home addresses, enter your PIN when prompted. Press u to 1.
Page 50: Pin Numbers
Personal Information PIN Numbers PIN Numbers H SETTINGS button Navi Settings Personal Info PIN Number PIN Numbers Set a four-digit PIN for protecting personal addresses and your home address. Once you set a PIN, you are prompted to enter it whenever you access a personal address Personal Identification Number (PIN) is a or a home address.
Page 51: Previous Destination
Personal Information Previous Destination Previous Destination H SETTINGS button Navi Settings Personal Info Previous Destination Previous Destinations The navigation system maintains a list of your previously routed destinations as a Up to 50 destinations can be stored. shortcut for entering the same destination in the future. You can delete some or all To cancel the selection of a previous destination, of your previous destinations from the list.
Page 52: Category History
Personal Information Category History Category History H SETTINGS button Navi Settings Personal Info Category History Category History The navigation system maintains a list of your recently used place categories as a Up to 50 categories can be stored. shortcut for selecting the same categories in the future. You can delete some or all To cancel the selection of a category, rotate i of your recently used categories from the list.
Page 53: Download Poi
Personal Information Download POI Download POI Import custom Points of Interest (POI) into the navigation system and set the POI as a destination. You can also add, edit, and delete POIs. ■ Importing POI Categories Importing POI Data H MENU button (on map) For more information about connecting a USB More Search Methods Download POI...
Page 54 Personal Information Download POI 3. Rotate i to select a category to import. Press u. Editing POI Categories ■ Editing POI Categories If you select From AcuraLink, you can edit Alert H SETTINGS button Navi Settings Personal Info Download POI only.
Page 55 Personal Information Download POI 2. Rotate i to select an item. Press The following items are available: • Alert Setting: Alerts you when you approach the places/landmarks in the category. On: Beeps and displays a message when your vehicle gets near the places/ landmarks in the category.
Page 56: Routing
Routing H SETTINGS button Navi Settings Routing Choose various settings that determine the navigation system functionality during route calculation. Rotate i to select an item. Press u. The following items are available: • Route Preference: Changes the route preferences (calculating method). P.
Page 57: Route Preference
Routing Route Preference Route Preference H SETTINGS button Navi Settings Routing Route Preference Route Preference Change the route preference by selecting minimum or maximum driving methods. The calculated route may be the shortest route or 1. Rotate i to select an item. Press the route you would choose.
Page 58 H SETTINGS button Navi Settings Routing Route Preference more information, contact an Acura dealer or You can select desired routes by sorting the route list. The three top routes can be visit owners.acura.com. displayed on the Select a route screen.
Page 59: Unverified Routing
Routing Unverified Routing Unverified Routing H SETTINGS button Navi Settings Routing Unverified Routing Unverified Routing Receive turn-by-turn map and voice guidance in unverified areas. Unverified roads are found in rural areas, and typically include residential streets away from the Rotate i to select On or Off. Press center of a town.
Page 60 Routing Unverified Routing Differences On (factory default) Cautionary Cautionary pop-up screens and Cautionary pop-up screens and messages voice announcements remind you to voice announcements remind you obey all traffic restrictions when to obey all traffic restrictions starting route guidance, when entering an unverified approaching an unverified area, and street.
Page 61: Traffic Rerouting
Routing Traffic Rerouting Traffic Rerouting H SETTINGS button Navi Settings Routing Traffic Rerouting Traffic Rerouting A faster route can be calculated based on continuously updated traffic information. Traffic Rerouting requires an AcuraLink Real- P. 127 Traffic Rerouting™ Time Traffic™ subscription. ®...
Page 62: Edit Poi Search Radius Along Route
Routing Edit POI Search Radius Along Route Edit POI Search Radius Along Route H SETTINGS button Navi Settings Routing Edit POI Search Radius Along Route Select the distance from your highlighted route line (on either side of your route) that the system will search for a waypoint. P.
Page 63: Avoided Area
Routing Avoided Area Avoided Area H SETTINGS button Navi Settings Routing Avoided Area Avoided Area Specify up to five areas to avoid (e.g., road construction, closures), if possible, when The maximum size of an “avoid area” is the system calculates routes to your destination. approximately 1/2 mile.
Page 64 Routing Avoided Area 5. Rotate i to select a method for Avoided Area specifying the area. Press u. Avoid area can be set in the 1/20, 1/8, or 1/4 mile map scales. The following options are available: • Address: Specify the general area by entering an address. P.
Page 65: Guidance
Guidance H SETTINGS button Navi Settings Guidance Choose various settings that determine the navigation system functionality during route guidance. Rotate i to select an item. Press u. The following items are available: • Guidance Mode: Sets whether to display only the map screen or a split map- guidance screen.
Page 66: Guidance Mode
Guidance Guidance Mode Guidance Mode H SETTINGS button Navi Settings Guidance Guidance mode Guidance Mode Select the display mode for the map and guidance screens. The guidance mode can also be selected from Rotate i to select an option. Press the map menu.
Page 67 Guidance Guidance Mode • Direction List: Displays the map and direction list simultaneously on the map screen. When you approach a guidance point, the next guidance point appears. Direction List screen Next Maneuver screen Near the next guidance point Guidance direction list Next guidance point •...
Page 68: Street Name Guidance
Guidance Street Name Guidance Street Name Guidance H SETTINGS button Navi Settings Guidance Street Name Guidance Street Name Guidance The navigation system includes the street names during voice guidance (e.g., “Turn This feature is only available when the system right on Main Street”). language is set to English.
Page 69: Non-Map Screens
Guidance Non-map screens Non-map screens H SETTINGS button Navi Settings Guidance Non-map screens The navigation system temporarily interrupts the screen display to view the guidance screen as you approach a guidance point. Rotate i to select an option. Press The following options are available: •...
Page 70: Guidance Point
Guidance Guidance Point Guidance Point H SETTINGS button Navi Settings Guidance Guidance Point Set the guidance point to display on the map screen. Rotate i to select an option. Press The following options are available: • Destination (factory default): Displays the remaining/arrival time and distance to the destination.
Page 71: Estimated Time
Guidance Estimated Time Estimated Time H SETTINGS button Navi Settings Guidance Estimated Time Select the estimated time to display on the screen. Rotate i to select an option. Press The following options are available: • Arrival: Displays the arrival time to the destination or the next waypoint. •...
Page 72: Map
H SETTINGS button Navi Settings Select the landmark icons to display on the map, change the orientation of the map, display your current location, and learn the meaning of the icons, colors, and symbols displayed on the map. Rotate i to select an item. Press u. The following items are available: •...
Page 73 • Current Location: Displays and saves your current location. P. 80 Current Location • Map Legend: Displays an overview of the map features. P. 81 Map Legend • Display Tracking: Sets whether to display the tracking dots on the map. P.
Page 74: Showing Icons On Map
Showing Icons on Map Showing Icons on Map H SETTINGS button Navi Settings Show Icon on Map Showing Icons on Map Select the icons that are displayed on the map. If you have PIN-protected your address book, enter your PIN when prompted. Move r to 1.
Page 75 Showing Icons on Map ■ Fine-tuning the Icons Icons in some categories can be fine-tuned to display or hide. 1. Rotate i to select the icons to display on the map. Press u. Pressing u toggles the icon display on or off. Repeat the procedure as necessary.
Page 76: Color
Color Color Set separate map colors for Day and Night modes. ■ Color (Day) Color (Day) The factory default is set to Beige. H SETTINGS button Navi Settings Color (Day) Rotate i to select a color for the Day mode. Press u. ■...
Page 77 Color ■ Switching Display Mode Manually Switching Display Mode Manually A visual guide helps you see the difference Set the screen brightness separately for Day and Night modes. Press the a between Day and Night modes. (Display mode) button to cycle through the display modes (Day to Night to Off). 2 Day or Night Mode P.
Page 78 Color Illumination Priority Operation control a button Selects Day, Night, or Off display mode. This button has the highest priority and overrides all other display control adjustments listed below. Remember: Once you press this button, you assume full manual control of the display mode until the power mode is set to VEHICLE OFF (LOCK).
Page 79: View (Map Orientation)
View (Map Orientation) View (Map Orientation) H SETTINGS button Navi Settings View View (Map Orientation) Select the map orientation. The red arrow in the symbol always points North. Rotate i to select an option. Press Heading-up and 3D map view switch to the North-up view on the maximum map scale.
Page 80: 3D Angle Adjustment
3D Angle Adjustment 3D Angle Adjustment H SETTINGS button Navi Settings 3D Angle Adjustment Adjust the viewing angle. Rotate i to adjust the angle. Press Straight Line Guide H SETTINGS button Navi Settings Straight Line Guide Set whether to display a straight guideline to the destination or waypoint Rotate i to select an option.
Page 81: Current Location
Current Location Current Location H SETTINGS button Navi Settings Current Location Current Location Display and save your current location for future use as a destination. The address, If you have PIN-protected your address book, enter your PIN when prompted. Press u to latitude, longitude, and elevation of your current location are displayed.
Page 82: Map Legend
Map Legend Map Legend H SETTINGS button Navi Settings Map Legend Map Legend See an overview of the map lines, areas, routes, traffic information, and navigation A visual guide helps you see the map legend. icons. 2 Map Screen Legend P. 9 Move w or y select an item.
Page 83 Map Legend ■ Map Scale and Functions Map Scale and Functions You can change between miles or kilometers. The functions that are available from the map screen depend on the map scale. 2 Unit Settings P. 35 Map Scale (top: mile, bottom: metric) Function page 1/20 1/8...
Page 84 Map Icons and Functions Map Icons and Functions Icon display control Display or hide all icons on the map screen, with the exception of Honda/Acura Icons that can be displayed or hidden using the Dealer icons which are always shown.
Page 85 Map Legend ■ Traffic icon Traffic Incident When you use the Interface Dial to position the Icon display Icon Icon Type cursor (round red circle) over the traffic incident control selectable searchable icon, you can view the summary of the incident. Traffic incident Press u on the traffic incident icon to view a pop-up message describing the incident in detail.
Page 86: Display Tracking
Display Tracking Display Tracking H SETTINGS button Navi Settings Display Tracking The navigation system can be set to display white tracking dots (“breadcrumbs”) on the map screen. Rotate i to select an option. Press The following options are available: • On: The system displays the white tracking dots. P.
Page 87: Correct Vehicle Position
Correct Vehicle Position Correct Vehicle Position H SETTINGS button Navi Settings Correct Vehicle Position Correct Vehicle Position Manually adjust the current position of the vehicle as displayed on the map screen if An apparent position error can occur where the position appears to be incorrect. buildings, tunnels, and other objects block or reflect the GPS signals, forcing the system to use 1.
Page 88: Data Reset
Data Reset Defaulting All the Settings H SETTINGS button System Settings Factory Data Reset Defaulting All the Settings Reset all the menu and customized settings as the factory defaults. When you transfer the vehicle to a third party, 1. Rotate i to select Yes. Press u. reset all settings to default and delete all personal data.
Page 89: On Demand Multi-Use Display
On Demand Multi-Use Display™ Changing the Screen Settings Adjusts the screen settings of the On Demand Multi-Use Display™. 1. Select More. 2. Select Screen Settings. 3. Use N, B or other icons to adjust the setting. Use the icons to turn the page.
Page 90: Navigation
Navigation This section describes how to enter a destination, select a route to take, and follow the route to your destination. It also describes how to change your route or destination along the way. Entering a Destination ......90 Calculating the Route ......114 Adding Waypoints .......
Page 91: Entering A Destination
Entering a Destination H MENU button (on map) Entering a Destination This section describes how to enter a destination for route guidance. If you press the MENU button when en route, Rotate i to select an item. Press u. the Route Option screen is displayed. 2 Changing Your Route P.
Page 92 Entering a Destination • Go Home: Sets your home address as a destination. P. 11 2 Going Home • Place Category: Sets a destination by selecting a place/landmark. P. 100 2 Place Category • Local Search: Sets a destination by using Local Search. P.
Page 93: Address
Entering a Destination Address Address H MENU button Address Enter an address to use as the destination. The state or province you are currently in is displayed (e.g., California). Rotate i to select an item. Press u. The following items are available: •...
Page 94: Selecting The State Or Province
Entering a Destination Address ■ Selecting the State or Province Selecting the State or Province Move w or y to select the following areas: H MENU button Address Change State • Rotate i to select a state from the USA for the U.S. mainland, Alaska, Hawaii, and Puerto Rico list.
Page 95 Entering a Destination Address 3. Rotate i to select the destination Selecting a City city from the list. Press u. Vehicle position may not be displayed when: Next, you are prompted to enter • The automobile is traveling off-road. a street name. •...
Page 96 Entering a Destination Address 2. Rotate i to select your Selecting a Street destination city from the list. Press When entering the names of major freeways, you can use the following abbreviations. For interstates, use an “I” (e.g., I-10). For U.S. A list of matching hits is freeways, use “US”...
Page 97 Entering a Destination Address 2. Rotate i to select your Selecting a Street destination street from the list. If you did not select a city first and there is more Press u. than one city with the specified street, a list of cities is displayed.
Page 98 Entering a Destination Address ■ Selecting a Street by House Number H MENU button Address House Number 1. Enter the house number. Only a valid house number can be entered. 2. Move r to select OK. Press u. If you did not yet select a street name, enter a street name when you are prompted.
Page 99: Address Book
Entering a Destination Address Book Address Book H MENU button Address Book Address Book Select an address stored in your address book to use as the destination. If you have PIN-protected your address book, enter your PIN when prompted. Press u to 1.
Page 100: Previous Destination
Entering a Destination Previous Destination Previous Destination H MENU button Previous Destination Previous Destination Select an address from a list of your 50 most recent destinations to use as the If Previous Destination is grayed out, there are destination. The list is displayed with the most recent destination at the top. no previous destinations entered.
Page 101: Place Category
Entering a Destination Place Category Place Category H MENU button Place Category Place Category Select the category of a place (e.g., Banking, Lodging, Restaurant) stored in the map This option is convenient if you do not know the database to search for the destination. exact name of a place or if you want to narrow down the number of matches returned for places 1.
Page 102 Entering a Destination Place Category 3. Rotate i to select an item. Press Place Category The straight line distance (as the crow flies, not driving distance) and direction to the destination are shown for the highlighted place. The following items are available: •...
Page 103: Local Search
(e.g., Community). Press u. The screen in this section may differ from the actual ones. Local Search is a subscription service. For more information, contact an Acura dealer or visit owners.acura.com. 2. Rotate i to select a subcategory. Press u.
Page 104 Entering a Destination Local Search 3. Rotate i to select an item. Press The following items are available: • Search nearby: Finds the nearest POI around your vehicle. • Search from Map: Selects a POI by scrolling the Interface Dial on the map screen. •...
Page 105: Place Name
Entering a Destination Place Name Place Name H MENU button Place Name Enter the name of a place (e.g., business, hotel, restaurant) stored in the map database to use as the destination. 1. Enter a place name. 2. Move r to select OK to display a list of matching hits.
Page 106 Entering a Destination Place Name ■ Place Name in Multiple Categories Place Name in Multiple Categories Matching letters are in highlighted. If the place name is in multiple categories in the map database, the following screen is displayed. 1. Rotate i to select a place name. Press u.
Page 107 Entering a Destination Place Name 3. Rotate i to select a place. Press Place Name in Multiple Categories Move r to select Sort by City or Sort by Distance. 4. Set the route to your destination. P. 114 2 Calculating the Route...
Page 108: Place Phone Number
Entering a Destination Place Phone Number Place Phone Number H MENU button More Search Methods Place Phone Number Place Phone Number Select a destination by phone number. Only phone numbers in the database are All 10 digits must be entered. recognized.
Page 109: Download Poi
Entering a Destination Download POI Download POI H MENU button More Search Methods Download POI Download POI Move r and rotate i to select the following Select a place imported into the navigation system as the destination. 1. Rotate i to select a category items: from the list.
Page 110: Scenic Route
Entering a Destination Scenic Route Scenic Route H MENU button More Search Methods Scenic Route Scenic Route Select a scenic road as a destination (U.S. and Canada only). If you select a scenic road that runs through 1. Rotate i to select a state. Press multiple states, only the portion of the road in the selected state is displayed.
Page 111: Intersection
Entering a Destination Intersection Intersection H MENU button More Search Methods Intersection Intersection Select the intersection of two streets as the destination. The state or province for It is usually easier to select Street to find the your current location is displayed at the top of the screen (e.g., California). streets first.
Page 112: Map Input
Entering a Destination Map Input Map Input H MENU button More Search Methods Map Input Use the Interface Dial to manually select an icon or a location on the map screen as the destination. You are prompted to define the map area to display. 1.
Page 113 Entering a Destination Map Input 2. Scroll the map to position the Map Input cursor over your desired Auto Zoom destination, adjusting the map Press u repeatedly on the map to zoom in (to scale as necessary. the scale 1/4 mile) while scrolling the map. If the address is not the desired Information icons are displayed at scales from 1 location, scroll the map to...
Page 114: Coordinate
Entering a Destination Coordinate Coordinate H MENU button More Search Methods Coordinate Coordinate Specify a location using latitude and longitude map coordinates. Latitude and longitude must be entered up to the seconds’ value. 1. Enter the latitude and select OK. 2.
Page 115: Calculating The Route
Calculating the Route Calculating the Route This section describes how to calculate your route. 1. Rotate i to select Set as The straight line distance (as the crow flies, not Destination. Press u. driving distance) and direction to the destination are shown.
Page 116: Viewing The Routes
The travel distance and estimated Sever Routes is a subscription service. For more travel time is displayed for each information, contact an Acura dealer or visit route. owners.acura.com. The system calculates and displays the route line on the map screen.
Page 117: Driving To Your Destination
Driving to Your Destination This section describes how to follow the route guidance to your destination, receive traffic information and choose the icons displayed on the map screen. Viewing the Route Viewing the Route You can change the map scale by rotating i. ■...
Page 118 Driving to Your Destination Viewing the Route ■ Guidance Screen Guidance Screen A visual guide helps you check the guidance The guidance screen offers an alternative way to view your route. screen. 2 Guidance Screen P. 10 The next guidance point is displayed as you approach each Turn-by-Turn Directions guidance point on the route.
Page 119: Route Line
Driving to Your Destination Viewing the Route ■ Route Line Route Line You can set Unverified Routing to Off to When driving on verified streets, the route line is light blue. The route line display follow your own route to the destination. If changes when driving on unverified streets: Unverified Routing is On, be aware that •...
Page 120 Driving to Your Destination Viewing the Route ■ Deviating From the Planned Route If you leave the calculated route, the system automatically recalculates a route to the desired destination based on your current location and direction. P. 56 2 Route Preference Tracking Dots ■...
Page 121: Listening To Voice Guidance
Driving to Your Destination Listening to Voice Guidance Listening to Voice Guidance H ENTER button (on map) Voice Listening to Voice Guidance As you approach each guidance point, a pop-up window is displayed on the map You can turn voice guidance OFF if you prefer. screen with instructions for you to follow.
Page 122: Reaching A Waypoint
Driving to Your Destination Reaching a Waypoint Reaching a Waypoint When you reach a waypoint, a pop-up message is displayed. You can continue or pause the route guidance. Rotate i to select No to pause the route guidance. Press u. Select Yes to continue the guidance.
Page 123: Map Menu
Map Menu Displaying the Map Menu Map Menu Use the Map Menu to control the icons displayed on the screen and to display traffic information and messages. You can also use the Map Menu to find locations or to If you scroll the map while en route, press the cancel the route.
Page 124 Map Menu Displaying the Map Menu • Guidance Volume: Adjusts the navigation system volume level. Map Menu • Map/Guidance: Allows you to select the map and guidance settings (display Directions mode, icons to display on the map, map orientation, map color, and 3D view The system provides freeway exit information only in the U.S.
Page 125: Hide Traffic Flow
Map Menu Hide Traffic Flow Hide Traffic Flow H ENTER button (on map) Hide Traffic Flow Hide the traffic flow indicator on the map screen. Press the ENTER button and select Display Traffic Flow to display the traffic flow indicator on the map screen.
Page 126: Directions
Map Menu Directions Directions H ENTER button (on map) Directions Directions Display a list of the guidance points on your route for your confirmation. Guidance points with exit information are 1. Rotate i to select a guidance indicated by a (freeway exit information) icon.
Page 127 Map Menu Directions ■ Freeway Exit Information Freeway Exit Information H ENTER button (on map) You can scroll the map and select a (freeway Directions Exit Info exit information) icon on the map screen to Display a list of the freeway exits for the route. You can view freeway exit display the freeway exit information.
Page 128: Traffic Rerouting
Traffic™ subscription. 2 AcuraLink Real-Time Traffic™ P. 60 2 Traffic Rerouting AcuraLink Real-Time Traffic™ is a subscription service. For more information, contact an Acura dealer or visit owners.acura.com. Automatic traffic rerouting may not provide a detour route depending on circumstances. ■...
Page 129 Map Menu Traffic Rerouting™ 2. Rotate i to select Avoid. Press Traffic Rerouting™ Manually You can choose to avoid up to 10 traffic incidents. It is not always possible for the system Repeat step 1 to 2 as necessary. to calculate a route that avoids all traffic incidents or specific traffic incidents you select.
Page 130: Changing Your Route
Changing Your Route H MENU button (when en route) Changing Your Route This section describes how to alter your route, add an interim “waypoint” (pit stop), If you press the MENU button when not en choose a different destination, cancel your current destination, and continue your route, the Destination Menu screen is displayed.
Page 131: Pausing The Route
Changing Your Route Pausing the Route • Change Route Preference: Changes the route preferences (calculating method). P. 56 2 Route Preference • Detour: Calculates a detour route. P. 137 2 Taking a Detour • Avoid Streets: Avoids streets along your route. P.
Page 132: Adding Waypoints
Changing Your Route Adding Waypoints Adding Waypoints Adding Waypoints Add up to four waypoints (pit stops) along the route to your destination. Waypoints allow you to stop for gas or food, for Waypoints are displayed on the map example, and then continue on to your screen as small, numbered red flags.
Page 133 Changing Your Route Adding Waypoints ■ Adding Waypoints from the Route Menu Adding Waypoints H MENU button (when en route) Search method Destination List Add New Destination Find Along Route “Search around” method 1. Rotate i to select a search method to add a waypoint.
Page 134 Changing Your Route Adding Waypoints 3. Rotate i to select a place. Press The waypoint is added to the Destination List. 4. Rotate i to select a location and move the order of destinations. Press u. 5. Move r and rotate i to select Start Route.
Page 135 Changing Your Route Adding Waypoints ■ Adding Waypoints from the Navigation Menu Adding Waypoints from the Navigation Menu You can edit the order of waypoints and H MENU button (when en route) Destination List Add New Destination destination. Use Nav Menu 2 Editing the Destination List P.
Page 136: Editing The Destination List
Changing Your Route Editing the Destination List Editing the Destination List ■ Editing the Order of Waypoints Editing the Order of Waypoints Move r to rotate i to select Show All on H MENU button (when en route) Destination List Map to display the destination and waypoints on 1.
Page 137 Changing Your Route Editing the Destination List ■ Deleting Waypoints Deleting Waypoints Move r and rotate i to select Delete All to H MENU button (when en route) Destination List delete the destination and all the waypoints. 1. Rotate i to select a list item to Select Show on Map to display the waypoint on delete.
Page 138: Taking A Detour
Changing Your Route Taking a Detour Taking a Detour H MENU button (when en route) Detour Taking a Detour Calculate a detour route manually. The system attempts to calculate a new route by The detour option is convenient if you encounter avoiding the next 5 miles (while on a freeway) or 1 mile (while on a surface street).
Page 139: Changing Your Destination
Changing Your Destination There are several methods you can use to change the route destination. Find Nearest Place H ENTER button (on map) Search Nearby Search for the nearest place/landmark on the map screen and set it as your destination. 1.
Page 140: Selecting A Destination On The Map
Changing Your Destination Selecting a Destination on the Map Selecting a Destination on the Map Selecting a Destination on the Map Select a new destination when en route by selecting a location on the map. If there is more than one icon or street under the 1.
Page 141: Entering A New Destination
Changing Your Destination Entering a New Destination Entering a New Destination H MENU button (when en route) Destination Enter a new destination using the Destination Menu screen even when you are en route. 1. Rotate i to select a method to enter a new destination.
Page 142: Resuming Your Trip
Resuming Your Trip Stop your vehicle en route (e.g., to rest, stop for gas, etc.), and then continue on Resuming Your Trip your route. The Continue Trip screen has the same options as when you calculate a route. If you did not complete your route, the Continue Trip screen is displayed when you 2 Calculating the Route P.
Page 144: Audio
Audio This section describes how to operate the audio system. You can play music from a wide array of media sources, and control the audio system using the audio buttons, the Interface Dial, or voice control. Audio System ..........144 Audio Menu...........
Page 145: Audio System
Audio System About Your Audio System ® About Your Audio System The audio system features AM/FM radio and the SiriusXM Radio service. It can also play audio CDs, WMA/MP3/AAC files, Hard Disc Drive (HDD) audio, USB flash drives, ® SiriusXM Radio is available on a subscription ®...
Page 146: Usb Port
Audio System USB Port USB Port ® ® Install the iPod or iPhone dock USB Port connector or the USB flash drive to • Do not leave the iPod ® or USB flash drive in the the USB port. vehicle. Direct sunlight and high temperatures may damage it.
Page 147: Auxiliary Input Jack
Audio System Auxiliary Input Jack Auxiliary Input Jack Use the jack to connect standard Auxiliary Input Jack audio devices. You can return to the AUX mode by selecting 1. Open the AUX cover. Change Source on the Audio menu screen or Audio Source on the touchscreen.
Page 148: Audio System Theft Protection
Audio System Audio System Theft Protection Audio System Theft Protection The audio system is disabled when it is disconnected from the power source, such as when the battery is disconnected or goes dead. In certain conditions, the system may display Enter code. If this occurs, reactivate the audio system. ■...
Page 149: Setting Audio Shortcuts
Audio System Setting Audio Shortcuts Setting Audio Shortcuts Setting Audio Shortcuts You can store up to six radio stations, and HDD audio album/play lists when playing ® AM, FM, or SiriusXM radio, or HDD audio. You can also preset a station or song by pressing and holding the preset icon you want to store ■...
Page 150: Customizing Audio Source
Audio System Customizing Audio Source ■ Deleting a preset station or song 1. Select Shortcuts. 2. Select Audio. 3. Select Edit. 4. Select Delete. 5. Select the preset icon with the radio station or a song you want to delete. Customizing Audio Source You can customize order of the source list icons.
Page 151: Audio Remote Controls
Audio Remote Controls Steering Wheel Controls Allows you to operate the audio system while driving. Audio Remote Controls SOURCE Button Left Selector Wheel The CD mode appears only when a CD is loaded. Cycles through the audio modes as follows: ®...
Page 152: Audio Settings
Audio Settings H SETTINGS button Audio Settings 1. Move w or y to select an audio mode you want to set. 2. Rotate i to select an item. Press The following items are available: • Source Select Popup: Selects whether the list of selectable audio sources comes on when the AUDIO button is pressed.
Page 153 Audio Settings • Update Gracenote Album Info (CD or HDD mode): Updates the Gracenote ® ® Album Info (Gracenote Media Database) from CD or from USB. ® P. 183 Updating Gracenote Album Info • DVD Auto Play (DVD mode): Turns the auto play feature on or off. •...
Page 154: Adjusting The Sound
Audio Settings Adjusting the Sound Adjusting the Sound Interface Dial Adjusting the Sound H MENU button Sound The SVC has four modes: Off, Low, Mid, and 1. Rotate i to select the sound High. mode to adjust. Press u. SVC adjusts the volume level based on the 2.
Page 155 Audio Settings Adjusting the Sound On Demand Multi-Use Display Adjusting the Sound 1. Select More. Select Off, Low, Mid or High for the SVC setting. 2. Select Sound. 2 Adjusting the Sound P. 153 3. Use N, B or other icon to adjust You can also adjust the sound to select the setting.
Page 156: Playing Fm/Am Radio
Playing FM/AM Radio Selecting FM/AM Mode Interface Dial Playing FM/AM Radio 1. Press the MENU button. (in AUDIO mode) You can control the AM/FM radio using voice commands. 2. Rotate i to select Change Source. Press u. 2 Voice Control Operation P. 6 3.
Page 157 Playing FM/AM Radio Audio Screen Control Audio Screen Control On Demand Multi-Use Display Select TAG to tag the song if it is played on an Preset screen Tune screen HD Radio station. The iPod/iPhone should be connected to the audio system to store the Select Tune.
Page 158: Audio Menu
Playing FM/AM Radio Audio Menu Audio Menu Interface Dial H MENU button (in FM/AM mode) Rotate i to select an item. Press u. The following items are available: • Sound: Adjusts the settings of the audio speaker’s sound. 2 Adjusting the Sound P. 153 •...
Page 159 Playing FM/AM Radio Audio Menu • Radio Text: Displays the text information broadcast by the current RDS station. Audio Menu • Tag Song: Displays the TAG information saved to the audio system when an HD iTunes Tagging Radio station is selected. “iTunes”...
Page 160 Playing FM/AM Radio Audio Menu On Demand Multi-Use Display 1. Select More. 2. Select a setting item. The following items are available: • Sound: Displays the sound preferences screen. Adjusting the Sound P. 153 • Scan: Scans for stations with a strong signal in the current band and plays a 10- second sample.
Page 161 Playing FM/AM Radio Audio Menu ■ Radio Data System H MENU button (in FM mode) Station List Provides text data information related to your selected RDS-capable FM station. ■ To find an RDS station from Station List Rotate i to select the station. Press ■...
Page 162: Playing Siriusxm ® Radio
® Playing SiriusXM Radio ® Selecting SiriusXM Mode Interface Dial ® Playing SiriusXM Radio 1. Press the MENU button. (in AUDIO mode) ® You can control the SiriusXM radio using voice commands. 2. Rotate i to select Change Source. Press u. 2 Voice Control Operation P.
Page 163 ® Playing SiriusXM Radio Audio Screen Control On Demand Multi-Use Display Preset screen Tune screen Select Tune. Select Presets. Station Number The following items are available: • b n: Select to display and select an SiriusXM ® Radio category. Select and hold to search that station on preset screen.
Page 164: Audio Menu
® Playing SiriusXM Radio Audio Menu Audio Menu Interface Dial H MENU button (in SiriusXM ® mode) Rotate i to select an item. Press u. The following items are available: • Sound: Adjusts the settings of the audio speaker’s sound. P.
Page 165 ® Playing SiriusXM Radio Audio Menu On Demand Multi-Use Display 1. Select More. 2. Select a setting item. The following items are available: • Sound: Displays the sound preferences screen. Adjusting the Sound P. 153 • Save Preset: Stores the station into the preset memory. •...
Page 166: Radio Service
® ® Playing SiriusXM Radio SiriusXM Radio Service ® SiriusXM Radio Service ® Subscribing to SiriusXM Radio ■ ® Subscribing to SiriusXM Radio ® Contact Information for SiriusXM Radio: ® SiriusXM Radio at www.siriusxm.com or (800) 1. You need your radio ID ready before registering for subscription. To see the ID in 852-9696 the display: Operate the On Demand Multi-Use Display until channel 0 appears.
Page 167: Playing A Disc
Playing a Disc Your audio system supports audio CDs, CD-Rs and CD-RWs in either MP3, WMA, or Playing a Disc AAC format. With the CD loaded, select the CD mode. NOTICE Do not use CDs with adhesive labels. The label Selecting Disc Mode can cause the CD to jam in the unit.
Page 168: Audio Screen Control
Playing a Disc Audio Screen Control Audio Screen Control Audio Screen Control Control the audio system through the audio/information screen and On Demand Multi-Use Display On Demand Multi-Use Display Interface Dial • Random: Plays all tracks/files in random order. 1. Rotate i or press u to display •...
Page 169: Audio Menu
Playing a Disc Audio Menu Audio Menu Interface Dial H MENU button (in CD mode) Rotate i select an item. Press u. The following items are available, depending on the type of disc: • Sound: Adjusts the settings of the audio speaker’s sound. 2 Adjusting the Sound P.
Page 170 Playing a Disc Audio Menu • Change Source: Changes the audio source mode. • Rec to HDD: Records a music CD onto the HDD for playback using HDD Audio. P. 174 Recording a Music CD to HDD • Music Search: Selects a file from the Music Search list. How to Select a File from the Music Search List (MP3/WMA/AAC) P.
Page 171 Playing a Disc Audio Menu ■ How to Select a File from the Music Search List (MP3/WMA/AAC) H MENU button (in CD mode) Music Search Rotate i, move w or y to select a file from the Music Search list. Press...
Page 172: Recommended Cds
Playing a Disc Recommended CDs Recommended CDs • Use only high-quality CD-R or CD-RW discs labeled for audio use. Recommended CDs • Use only CD-R or CD-RW discs on which the recordings are closed. A Dual-disc cannot play on this audio unit. If •...
Page 173 Playing a Disc Recommended CDs ■ Protecting CDs Protecting CDs Follow these precautions when handling or storing CDs: NOTICE • Store a CD in its case when it is not being played. Do not insert a damaged CD. It may be stuck •...
Page 174: Playing Hard Disc Drive (Hdd) Audio
Playing Hard Disc Drive (HDD) Audio The Hard Disc Drive (HDD) Audio function plays tracks from music CDs that have Playing Hard Disc Drive (HDD) Audio been recorded onto the built-in HDD. You can arrange the tracks in playlists or play You can control the HDD audio using voice the tracks using various search methods.
Page 175: Recording A Music Cd To Hdd
Playing Hard Disc Drive (HDD) Audio Recording a Music CD to HDD Recording a Music CD to HDD Recording a Music CD to HDD The songs on music CDs are automatically recorded by factory default to the HDD the first time you play each disc. You can then play the songs directly from the HDD. You can add tracks to user playlists, where you can mix and match tracks from other CDs Recording indicator...
Page 176: Audio Screen Control
Playing Hard Disc Drive (HDD) Audio Audio Screen Control Audio Screen Control Audio Screen Control Control the audio system through the audio/information screen and On Demand Multi-Use Display On Demand Multi-Use Display Interface Dial • Repeat: 1. Rotate i or u press to display Repeat Artist: Repeats all tracks in the current artist.
Page 177: Audio Menu
Playing Hard Disc Drive (HDD) Audio Audio Menu Audio Menu Interface Dial H MENU button (in HDD mode) Rotate i to select an item. Press u. The following items are available: • Sound: Adjusts the settings of the audio speaker’s sound. 2 Adjusting the Sound P.
Page 178 Playing Hard Disc Drive (HDD) Audio Audio Menu On Demand Multi-Use Display 1. Select More. 2. Select a setting item. The following items are available: • Sound: Displays the sound preferences screen. P. 153 Adjusting the Sound • Screen Settings: Displays the screen preferences screen. P.
Page 179 Playing Hard Disc Drive (HDD) Audio Audio Menu ■ How to Select a Track from the Music Search List H MENU button (in HDD mode) Music Search 1. Move w or y to select a search category. Press u. 2. Rotate i to select a track from the Music Search list.
Page 180 Playing Hard Disc Drive (HDD) Audio Audio Menu ■ Editing an Album or Playlist Editing an Album or Playlist The maximum number of original playlists is 50 H MENU button (in HDD mode) Edit/Delete with a maximum of 99 songs in each playlist. 1.
Page 181 Playing Hard Disc Drive (HDD) Audio Audio Menu ■ Creating a new Playlist H MENU button (in HDD mode) Edit/Delete Playlists Create New Playlist 1. Enter the playlist name using the interface dial or the On Demand Multi-Use Display 2. Select tracks from the music search list.
Page 182 Playing Hard Disc Drive (HDD) Audio Audio Menu ■ Editing Track Information H MENU button (in HDD mode) Edit/Delete Tracks Change the track title, artist name, genre and composer. You can also delete tracks. Rotate i select a track you want to edit or delete.
Page 183 Playing Hard Disc Drive (HDD) Audio Audio Menu ■ Displaying Music Information H MENU button (in HDD mode) Edit/Delete Music information (album name, artist name, genre) can be acquired by accessing ® the Gracenote Album Info. 1. Rotate i to select Albums. Press 2.
Page 184 ® Update the Gracenote Album Info (Gracenote Media Database) that is included • Visit http://www.navteq.com/gracenote/acura. with the navigation system. Once you perform an update, any information 1. Insert the update disc into the disc you edited before will be overwritten or erased.
Page 185 Playing Hard Disc Drive (HDD) Audio Audio Menu ■ Deleting All HDD Data H SETTINGS button Audio Settings CD/HDD Delete All HDD Data Delete all music data on the HDD. Rotate i to select Yes. Press u.
Page 186: Playing An Ipod
® Playing an iPod ■ ® Connecting an iPod ® Connecting an iPod • Do not connect your iPod ® using a hub. • Do not use a device such as a card reader or hard disk drive, as the device or your tracks may be damaged.
Page 187: Mode
® ® Playing an iPod Selecting iPod Mode ® Selecting iPod Mode ® Playing an iPod ® 1. Connect the iPod to the USB adapter cable in the console compartment. ® You can control an iPod using voice commands. Interface Dial 2 Voice Control Operation P.
Page 188: Audio Screen Control
® Playing an iPod Audio Screen Control Audio Screen Control Audio Screen Control Control the audio system through the audio/information screen and On Demand Multi-Use Display This function may not be available depending on models or versions. Interface Dial Select r to go back to the previous screen. 1.
Page 189 ® Playing an iPod Audio Screen Control On Demand Multi-Use Display Album Image Album Bar Select an album image. Select the album bar. The following items are available: • (Play/Pause): Plays or pauses a song file. • cx: Select the previous or next track. Select and hold to move rapidly within a track.
Page 190: Audio Menu
® Playing an iPod Audio Menu Audio Menu Interface Dial H MENU button (in iPod ® mode) Rotate i to select an item. Press u. The following items are available: • Sound: Adjusts the settings of the audio speaker’s sound. P.
Page 191 ® Playing an iPod Audio Menu On Demand Multi-Use Display 1. Select More. 2. Select a setting item. The following items are available: • Sound: Displays the sound preferences screen. P. 153 Adjusting the Sound • Screen Settings: Displays the screen preferences screen. P.
Page 192 ® Playing an iPod Audio Menu ■ How to Select a Song from the Music Search List H MENU button (in iPod ® mode) Music Search 1. Move w or y to select a search category. Press u. 2. Rotate i to select a file from the Music Search list.
Page 193 ® Playing an iPod Song By Voice (SBV) Song By Voice (SBV) ® Use SBV to search for and play music from your HDD or iPod using voice commands. ■ Settings Song By Voice (SBV) H SETTINGS button System Settings Song by Voice Rotate i to select On or Off.
Page 194: (Sbv)
® Playing an iPod Song By Voice (SBV) ■ Searching for music using Song By Voice (SBV) Searching for music using Song By Voice (SBV) Song By Voice Commands List 1. Set the Song by Voice setting to 2 Song By Voice Commands P. 333 NOTE: 2.
Page 195: Phonetic Modification
® Playing an iPod Song By Voice (SBV) ■ Phonetic Modification Phonetic Modification Phonetic Modification is grayed out when Song H SETTINGS button System Settings Song by Voice Phonetic By Voice is set to Off. Modification You can store up to 2,000 phonetic modification Add phonetic modifications of difficult or foreign words so that it is easier for SBV to items.
Page 196 ® Playing an iPod Song By Voice (SBV) 3. Rotate i to select the item to modify (e.g., Artist). Press u. The list of the selected item appears on the screen. 4. Rotate i to select an entry (e.g., No Name). Press u. The pop-up menu appears on the screen.
Page 197 ® Playing an iPod Song By Voice (SBV) 6. Enter the phonetic spelling you wish to use (e.g., “Artist A”) when prompted. 7. Rotate i to select OK to exit. The artist “No Name” is phonetically modified to “Artist A.” When in the SBV mode, you can press the d (Talk) button and use the voice command “Play ‘Artist A’”...
Page 198: Playing Internet Radio
1. Connect a compatible phone through Bluetooth To find out if your phone is compatible with this Interface Dial feature, visit www.acura.com/handsfreelink, or 2. Press the MENU button. (in AUDIO mode) call 1-888-528-7876. 3. Rotate i to select Change Source. Press u.
Page 199: Menu
® Playing Internet Radio Pandora Menu ® Pandora Menu ® Pandora Menu Interface Dial Rotate i to select an item. Press u. Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered Press MENU button to display the ®...
Page 200 ® Playing Internet Radio Pandora Menu On Demand Multi-Use Display 1. Select b or n to change a station. 2. Select x to skip a song. Select to resume or play a song. Select to evaluate a song. Select More to display the menu item.
Page 201: Radio Menu
2Changing the Screen Settings app must be installed on your phone. Visit P. 88 owners.acura.com/apps for more information. You must have a previously set up Aha account prior to using the service in your vehicle. Visit www.aharadio.com for more information.
Page 202 Playing Internet Radio Radio Menu ■ How to Select a Station from the Station List H MENU button (in Aha mode) Station List Rotate i to select a station form the Station list. Press u.
Page 203: Playing A Usb Flash Drive
Playing a USB Flash Drive ■ Connecting a USB Flash Drive Connecting a USB Flash Drive • Do not connect your USB flash drive using a hub. • Do not use a device such as a card reader or hard disk drive, as the device or your tracks may be damaged.
Page 204: Selecting Usb Mode
Playing a USB Flash Drive Selecting USB Mode Selecting USB Mode Playing a USB Flash Drive 1. Connect the USB flash drive to the USB port in the console compartment. You can control a USB flash drive using voice Interface Dial commands.
Page 205: Audio Screen Control
Playing a USB Flash Drive Audio Screen Control Audio Screen Control Audio Screen Control Control the audio system through the audio/information screen and On Demand Multi-Use Display On Demand Multi-Use Display Interface Dial • Random: 1. Rotate i or press u to display Random in Folder: Plays all files in the current folder in random order.
Page 206: Audio Menu
Playing a USB Flash Drive Audio Menu Audio Menu Interface Dial H MENU button (in USB mode) Rotate i to select an item. Press u. The following items are available: • Sound: Adjusts the settings of the audio speaker’s sound. P.
Page 207 Playing a USB Flash Drive Audio Menu On Demand Multi-Use Display 1. Select More. 2. Select a setting item. The following items are available: • Sound: Displays the sound preferences screen. P. 153 Adjusting the Sound • Screen Settings: Displays the screen preferences screen. P.
Page 208 Playing a USB Flash Drive Audio Menu ■ How to Select a File from the Music Search List H MENU button (in USB mode) Music Search 1. Move w or y to select a search category. Press u. 2. Rotate i to select a file from the Music Search list.
Page 209: Playing Bluetooth ® Audio
® ® P. 212 HandsFreeLink Bluetooth For a list of compatible phones, visit www.acura.com/ handsfreelink, or ® Selecting Bluetooth Audio Mode call 1-888-528-7876. State or local laws may prohibit the operation of 1. Make sure that your phone is on, paired, and linked to HFL.
Page 210: Audio Screen Control
® Playing Bluetooth Audio Audio Screen Control Audio Screen Control Audio Screen Control Control the audio system through the audio/information screen and On Demand Multi-Use Display To play the audio files, you may need to operate your phone. If so, follow the phone maker’s Interface Dial operating instructions.
Page 211 ® Playing Bluetooth Audio Audio Screen Control On Demand Multi-Use Display 1. Select b or n to change folders. 2. Select c or x to change files. Select More to display the menu items, then select a setting item. Select n or h to play or pause a song file.
Page 212: Handsfreelink
® ® HandsFreeLink Bluetooth ® ® This section describes how to operate Bluetooth HandsFreeLink . You can place and receive phone calls using your vehicle’s audio system without handling your cell phone. ® ® Bluetooth HandsFreeLink ....212 Roadside Assistance* ......251 Using HFL ..........212 HFL Menus...........
Page 213: Bluetooth ® Handsfreelink
® To use HFL, you need a Bluetooth -compatible cell phone. For a list of compatible phones, Using HFL pairing procedures, and special feature capabilities: Visit www.acura.com/handsfreelink, or ■ call 1-888-528-7876. HFL Buttons Voice control tips: Volume up • Aim the vents away from the ceiling and close...
Page 214 ® ® Bluetooth HandsFreeLink Using HFL ■ ® ® Bluetooth HandsFreeLink HFL Status Display ® Bluetooth Wireless Technology The audio/information screen notifies you when there is an incoming call. ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Honda Motor ®...
Page 215: Pairing A Phone
® ® Bluetooth HandsFreeLink Pairing a Phone Pairing a Phone H PHONE button Pairing a Phone ® Your Bluetooth -compatible phone must be ® When no Bluetooth -compatible phone is paired, the following screen appears: paired to HFL before you can make and receive 1.
Page 216 ® ® Bluetooth HandsFreeLink Pairing a Phone 4. HFL gives you a pairing code on the Pairing a Phone audio/information screen. Automatic When pairing is completed, an Phone Sync prompt appears. Select if you Confirm if the pairing code on want your call history and phonebook the screen and your phone automatically imported to HFL.
Page 217 ® ® Bluetooth HandsFreeLink Pairing a Phone 3. When your phone appears on the list, select it by pressing u. If your phone does not appear, you can select Refresh to search again. If your phone still does not appear, move r to select Phone not Found? and search ®...
Page 218 ® ® Bluetooth HandsFreeLink Pairing a Phone ■ Changing the Pairing Code Changing the Pairing Code The pairing code may be six or four digits H SETTINGS button System Settings Edit Pairing Code depending on your phone. Rotate i to select Fixed or 0000 The default pairing code is until you...
Page 219 ® ® Bluetooth HandsFreeLink Pairing a Phone ■ Changing the Currently Paired Phone Changing the Currently Paired Phone The replaced phone will keep the same speed H SETTINGS button Phone Settings Bluetooth Device List dial entries, and security PIN information from 1.
Page 220 ® ® Bluetooth HandsFreeLink Pairing a Phone ■ Deleting a Paired Phone H SETTINGS button Phone Settings Bluetooth Device List 1. Rotate i to select a paired phone you want to replace. Press u. 2. Rotate i to select Delete This Device.
Page 221: Importing Phonebook Data
® ® Bluetooth HandsFreeLink Importing Phonebook Data Importing Phonebook Data Importing Phonebook Data When your phone is paired, the contents of its phonebook and call When you select a person from the list in the history are automatically imported to cellular phonebook, you can see up to three category icons.
Page 222: Setting Up Speed Dialing
® ® Bluetooth HandsFreeLink Setting Up Speed Dialing Setting Up Speed Dialing H MENU button (on Phone screen) Speed Dial Setting Up Speed Dialing When a voice tag is stored, press the d button Up to 20 speed dial numbers can be stored per phone. to call the number using the voice tag.
Page 223 ® ® Bluetooth HandsFreeLink Setting Up Speed Dialing ■ Registering a Voice Tag to a Speed Dial Entry Registering a Voice Tag to a Speed Dial Entry H SETTINGS button Avoid using duplicate voice tags. Phone Settings Edit Speed Dial Avoid using ”home“...
Page 224 ® ® Bluetooth HandsFreeLink Setting Up Speed Dialing ■ To delete a voice tag 1. Select an existing speed dial entry. 2. From the pop-up menu, rotate i to select Edit. Press u. 3. Rotate i to select Voice Tag. Press u.
Page 225 ® ® Bluetooth HandsFreeLink Setting Up Speed Dialing ■ Setting Phone Shortcuts Setting Phone Shortcuts Dial icon You can preset five previously stored speed dial entries, and make a call from one of You can make a call using the keyboard on the the preset numbers, or call history when the phone is paired and connected to the On Demand Multi-Use Display™...
Page 226 ® ® Bluetooth HandsFreeLink Setting Up Speed Dialing 6. Select a number you want to store as a shortcut. ■ To make a call from a speed dial entry 1. Select Shortcuts. 2. Select Phone. 3. Select Speed Dial. 4. Select a preset number. Dialing starts automatically.
Page 227 ® ® Bluetooth HandsFreeLink Setting Up Speed Dialing ■ To delete a speed dial 1. Select Shortcuts. 2. Select Phone. 3. Select Speed Dial. 4. Select Edit. 5. Select Delete. 6. Select the preset number with the phone number you want to delete. ■...
Page 228: Phonebook Phonetic Modification
® ® Bluetooth HandsFreeLink Phonebook Phonetic Modification Phonebook Phonetic Modification H SETTINGS button System Settings Phonebook Phonetic Modification Phonebook Phonetic Modification Add phonetic modifications or a new voice tag to the phone's contact name so that You can store up to 20 phonetic modification it is easier for HFL to recognize voice commands.
Page 229 ® ® Bluetooth HandsFreeLink Phonebook Phonetic Modification 3. Move w or y and rotate i to select a contact name. Press u. The pop-up menu appears on the screen. 4. Rotate i to select Modify. Press 5. Using the d button, follow the prompts to complete the voice tag.
Page 230 ® ® Bluetooth HandsFreeLink Phonebook Phonetic Modification ■ To modify a voice tag Phonebook Phonetic Modification 1. Rotate i to select the phone you You can only modify or delete contact names for the currently connected phone. want to add phonetic modification to.
Page 231 ® ® Bluetooth HandsFreeLink Phonebook Phonetic Modification ■ To delete a modified voice tag 1. Rotate i to select the phone you want to delete phonetic modification. Press u. 2. Rotate i to select a contact name you want to delete. Press u. The pop-up menu appears on the screen.
Page 232 ® ® Bluetooth HandsFreeLink Phonebook Phonetic Modification ■ To delete all modified voice tags 1. Rotate i to select the phone you want to delete phonetic modification. Press u. The contact name list appears. 2. Move r and rotate i to select Delete All.
Page 233: Phone Settings
® ® Bluetooth HandsFreeLink Phone Settings Phone Settings H SETTINGS button Phone Settings Set HFL options and features. ■ Editing a Security PIN Editing a Security PIN If the phone is already security PIN protected, you H SETTINGS button Phone Settings Bluetooth Device List need to enter the current security PIN before You can protect each of the six cell phones with a security PIN.
Page 234 ® ® Bluetooth HandsFreeLink Phone Settings ■ Editing User Name Editing User Name You can use the keyboard on the On Demand H SETTINGS button Phone Settings Bluetooth Device List Multi-Use Display™ to input numbers. Edit the user name of a paired phone as follows: 1.
Page 235 ® ® Bluetooth HandsFreeLink Phone Settings ■ Automatic Transferring H SETTINGS button Phone Settings Auto Transfer If you get into the vehicle while you are on the phone, the call can be automatically transferred to HFL. Rotate i to select On. Press u. ■...
Page 236 ® ® Bluetooth HandsFreeLink Phone Settings ■ Ring Tone H SETTINGS button Phone Settings Ring Tone You can change the ring tone setting. Rotate i to select your desired setting item. Press u. The following items are available: • Fixed: The fixed ring tone sounds from the speaker. •...
Page 237 ® ® Bluetooth HandsFreeLink Phone Settings ■ Automatic Phone Sync setting Automatic Phone Sync setting Select On if you want your call history and H SETTINGS button Phone Settings Automatic Phone Sync phonebook automatically imported to HFL. If Rotate i to select On or Off. Press prompted by your phone, please accept the import request.
Page 238: Making A Call
® ® Bluetooth HandsFreeLink Making a Call Making a Call You can make calls by inputting any phone number, or by using the imported Making a Call phonebook, call history, speed dial entries, or redial. Any voice-tagged speed dial entry, phonebook name, or number can be dialed by voice from most screens.
Page 239 ® ® Bluetooth HandsFreeLink Making a Call ■ Using the Phonebook Using the Phonebook H MENU button (on Phone screen) This function is disabled while the vehicle is Phonebook moving. However, you can call a stored voice- tagged speed dial number, phonebook name, or 1.
Page 240 ® ® Bluetooth HandsFreeLink Making a Call ■ Entering a Phone Number Entering a Phone Number This function is disabled while the vehicle is H MENU button (on Phone screen) Dial moving. However, you can call a stored voice- 1. Rotate i to select a number. tagged speed dial number, phonebook name, or Press u.
Page 241 ® ® Bluetooth HandsFreeLink Making a Call ■ Using Call History Using Call History The call history displays the last 20 dialed, H MENU button (on Phone screen) Call History received, or missed calls. Call history is stored by All, Dialed, Received, and Missed. (Appears only when a phone is connected to 1.
Page 242 ® ® Bluetooth HandsFreeLink Making a Call ■ Using Speed Dial Using Speed Dial Move r to select More Speed Dials to view H MENU button (on Phone screen) Speed Dial another paired phone's speed dial list. You can Rotate i to select a number. Press make a call from that list using the currently connected phone.
Page 243: Receiving A Call
® ® Bluetooth HandsFreeLink Receiving a Call Receiving a Call Receiving a Call When there is an incoming call, an audible notification sounds (if activated) and the Incoming call screen appears. Call Waiting Press the h button to put the current call on 1.
Page 244 ® ® Bluetooth HandsFreeLink Receiving a Call ■ Options During a Call Options During a Call Touch Tones : Available on some phones. The available options are shown on the Phone screen. Rotate i to select the option. Press You can select the icons on the On Demand Multi-Use Display The mute icon appears when Mute is selected.
Page 245: Text/E-Mail Message
Text/E-mail Message Setting a Text Message/E-mail ■ To turn on or off the text/E-mail function H SETTINGS button Phone Settings Enable Text/Email Rotate i to select On or Off. Press ■ To turn on or off the text/E-mail notice H SETTINGS button Phone Settings New Text/Email Alert Rotate i to select On or Off.
Page 246: Selecting A Mail Account
Text/E-mail Message Selecting a Mail Account Selecting a Mail Account H SETTINGS button Phone Settings Select Account Selecting a Mail Account If a paired phone has text message or mail accounts, you can select one of them to You can also select a mail account from the be active and receive notifications.
Page 247: Receiving A Text/E-Mail Message
Text/E-mail Message Receiving a Text/E-mail Message Receiving a Text/E-mail Message Receiving a Text/E-mail Message HFL can display newly received text and E-mail messages as well as 20 of the most recently received messages on a linked cell phone. Each received message can be The system does not display any received read aloud and replied to using a fixed common phrase.
Page 248: Displaying Messages
Text/E-mail Message Displaying Messages Displaying Messages Displaying Messages ■ Displaying text messages The icon appears next to an unread message. H MENU button (on Phone screen) Text/Email If you delete a message on the phone, the message is also deleted in the system. If you send 1.
Page 249 Text/E-mail Message Displaying Messages ■ Displaying E-mails Displaying E-mails Received text and E-mail message may appear in H MENU button (on Phone screen) Text/Email the message list screen at the same time. In this 1. Rotate i to select a folder. Press No subject case, text messages are titled 2.
Page 250 Text/E-mail Message Displaying Messages ■ Read or stop reading a message 1. Go to the text or E-mail message screen. The system automatically starts reading the message aloud. P. 247 2 Displaying Messages 2. Press u to stop reading. Press u again to start reading the message from the beginning.
Page 251 Text/E-mail Message Displaying Messages 3. Rotate i to select the reply Reply to a message message. Press u. The available fixed reply messages are as follows: The pop-up menu appears on • Talk to you later, I’m driving. the screen. •...
Page 252: Roadside Assistance
Text/E-mail Message Roadside Assistance* Roadside Assistance* H MENU button (on Phone screen) Roadside Assistance Roadside Assistance* Provides a nationwide service for unexpected incidents. You can call for assistance ® If you are subscribed to a paid AcuraLink ® ® using a phone paired and connected to Bluetooth HandsFreeLink package, you can call the roadside assistance Rotate i to select a phone number.
Page 253: Hfl Menus
Text/E-mail Message HFL Menus HFL Menus HFL Menus The power mode must be in ACCESSORY or ON to use HFL. ® To use HFL, you must first pair your Bluetooth ■ Phone Settings screen compatible cell phone to the system while the vehicle is parked.
Page 254 Text/E-mail Message HFL Menus Delete all the previously stored speed dial numbers. Delete All Enter a phone number to store as a speed Manual Input dial number. Select a phone number from the call Edit Speed Import from New Entry Dial Call History history to store as a speed dial number.
Page 255 Text/E-mail Message HFL Menus ■ Phone screen 1. Press the PHONE button. 2. Press the MENU button to display the menu items. Enter a phone number to dial. Dial Display the paired phone’s phonebook. Phonebook Enter a phone number to store as a speed dial number. Manual Input Select a phone number from the call history to store as a Import from...
Page 256 Text/E-mail Message HFL Menus Redial the last number dialed in the phone’s history. Redial Display the last 20 outgoing, incoming and missed calls. Display the last 20 outgoing calls. Call History Dialed Display the last 20 incoming calls. Received Display the last 20 missed calls. Missed Makes a call to the number for the Roadside Assistance service.
Page 258 ® AcuraLink This section describes how Acura directly communicates important information to you regarding your vehicle. ® AcuraLink ..........258 In Case of Emergency......258 Security Features ........260 Operator Assistance ......261 ® AcuraLink Message......262 ® AcuraLink Subscription Status..... 265...
Page 259: Acuralink
® AcuraLink server. Acura dealer or visit owners.acura.com. In Case of Emergency In Case of Emergency Your vehicle may not be able to connect to the operator if the battery level is low, the line is ■...
Page 260 ® AcuraLink In Case of Emergency ■ Manual operator connection Manual operator connection Do not press the button while driving. When you ® If you need to talk to the AcuraLink need to contact the operator, park the vehicle in operator in an emergency situation, a safe place.
Page 261: Security Features
. If you forget any of the above, ■ Stolen vehicle tracking contact a dealer or go to owners.acura.com. This feature searches and tracks down your vehicle position even if it is on the move. You can also activate the remote door lock/...
Page 262: Operator Assistance
® AcuraLink Operator Assistance Operator Assistance ® Connect to the AcuraLink operator when trying to find a destination or for roadside Operator Assistance assistance. Remain attentive to road conditions and driving 1. Press the LINK button. during operator assistance. Connection to the operator begins.
Page 263: Acuralink Message
Selecting Check Now lets you know if you should see a dealer immediately or later in accordance with the warning severity level. • Scheduled Dealer Appointment: An appointment made through the Acura server or Acura Owners website can be rescheduled or canceled from this option. P. 264 2 Dealer Appointments •...
Page 264: Reading A Message
® ® AcuraLink AcuraLink Message ■ Reading a message Reading a message If there is no message listed on the menu, 1. Press the INFO button, rotate i AcuraLink/Messages is grayed out and cannot to select AcuraLink/Messages, be selected. then press u. The message icon disappears once you read the If your display has changed from message.
Page 265: Acuralink Acuralink
AcuraLink AcuraLink Message • Find Acura Dlr.: Searches for the nearest Acura dealer. • Delete: Deletes the displayed message. • Call Your Dealer: Calls your Acura dealer using HFL. • Schedule Dealer Appointment: Automatically sets an appointment date at your dealer.
Page 266: Acuralink Subscription Status
® ® AcuraLink AcuraLink Subscription Status ® AcuraLink Subscription Status H SETTINGS buttons (in FM mode) Info Settings AcuraLink Subscription Status ® Confirm your AcuraLink subscription Signal strength status. Item Information You can check the signal strength. ® Current Contract The AcuraLink subscription number and subscription level is displayed.
Page 268: Rear Entertainment System
Rear Entertainment System Rear seat passengers can enjoy a completely separate entertainment source than front passengers, including movies, games, and other audio choices. Rear Entertainment System ....268 Front Control Panel Operation .... 282 Auxiliary Console Panel ......268 Selecting the Audio Source using front ®...
Page 269: Rear Entertainment System
Rear Entertainment System The Rear Entertainment System (RES) is operable from both the front control panel Rear Entertainment System and the rear control panel. NOTICE P. 282 2 Front Control Panel Operation This vehicle’s overhead mounted video display, if P. 271 2 Rear Control Panel Operation so equipped, includes mercury-containing components.
Page 270: Hdmi ® Input Jack (Ultrawide Res Only)
® Rear Entertainment System HDMI Input Jack (Ultrawide RES only) ® HDMI Input Jack (Ultrawide RES only) ® HDMI Input Jack (Ultrawide RES only) ® There is an HDMI input jack on the back of the center console compartment. The ®...
Page 271: Playable Discs
Rear Entertainment System Playable Discs Playable Discs The discs that come with these labels can be played in your vehicle’s rear Playable Discs entertainment system. This product incorporates copyright protection technology that is protected by U.S. patents and Also look for the region code of 1 or ALL on the package or jacket on the disc. other intellectual property rights.
Page 272: Rear Control Panel Operation
Rear Control Panel Operation Selecting the Audio Source Rear Control Panel Operation ■ RES In the procedures of this section, “select” means 1. Press the Rear Power button on the front control panel. the following actions: 2. Press the audio source button on the rear control panel. You can also change the audio source by the front control panel.
Page 273: Rear Dvd Menu
Rear Control Panel Operation Rear DVD Menu Rear DVD Menu H MENU button (in the DVD mode) Select an item. Press the ENTER button. The following items are available: • Top Menu: Displays the top menu of the DVD. • Menu: Displays the menu of the DVD. •...
Page 274 Rear Control Panel Operation Rear DVD Menu ■ Setting the Play Mode H MENU button (in the DVD mode) Play Mode 1. Select an item. Press the ENTER button. 2. Select an option. Press the ENTER button. The following items are available: •...
Page 275 Rear Control Panel Operation Rear DVD Menu ■ Searching a Title/Chapter H MENU button (in the DVD mode) Search/NumInput 1. Select an item. Press the ENTER button. 2. Select a number. Press the ENTER button. The following items are available: •...
Page 276: Screen And Surround Settings
Rear Control Panel Operation Screen and Surround Settings Screen and Surround Settings H SETUP button (in the DVD mode) Select an item. Press the ENTER button. The following items are available: • Brightness (Ultrawide RES only): Adjusts the screen’s brightness. Adjust the brightness using the Interface Dial and press the ENTER button.
Page 277 Rear Control Panel Operation Screen and Surround Settings ■ Adjusting the Screen H SETUP button (in the DVD mode) Display Adjust 1. Select an item. Press the ENTER button. 2. Make the adjustment. Press the ENTER button. The following items are available: •...
Page 278 Rear Control Panel Operation Screen and Surround Settings ■ Setting the RES Aspect Ratio H MENU button (in the DVD mode) Aspect Ratio Select an option. Press the ENTER button. ■ Setting the Ultrawide RES Aspect Ratio H MENU button (in the DVD mode) Aspect Ratio 1.
Page 279: Dvd Initial Settings (Res Only)
Rear Control Panel Operation DVD Initial Settings (RES only) DVD Initial Settings (RES only) H MENU button (in the DVD mode) Initial Settings Set the DVD default settings so that you do not have to select the settings each time you play a DVD.
Page 280: Dual Screen Mode
Rear Control Panel Operation Dual Screen Mode (Ultrawide RES only) ■ Selecting the DVD Menu Language Selecting the DVD Menu Language H MENU button (in the DVD mode) When you select Other, enter a 4-digit language Initial Settings Language Settings code.
Page 281 Rear Control Panel Operation Dual Screen Mode (Ultrawide RES only) ■ Single mode to Dual mode Press the DUAL Select the side button. (e.g., “Left”). Select a source (e.g., “AUX- VIDEO”). AUX-VIDEO AUX-VIDEO Press the SWAP button. ■ Dual mode to Single mode AUX-VIDEO Press the Select a source...
Page 282: Replacing The Batteries
Rear Control Panel Operation Replacing the Batteries Replacing the Batteries Replacing the Batteries 1. Remove the rear control panel. 2 Overhead Screen and Rear An improperly disposed of battery can hurt the P. 15 Cover Control Panel environment. Always confirm local regulations for battery disposal.
Page 283: Front Control Panel Operation
Front Control Panel Operation Operate the Rear Entertainment System (RES) from the front control panel. Selecting the Audio Source using front control panel 1. Press the Rear 9 (Power) button on the front control panel. 2. Press the REAR AUDIO button. The rear source is displayed on the front audio/information screen and the On Demand...
Page 284: Rear System Setup
Front Control Panel Operation Rear System Setup Rear System Setup H SETTINGS button Rear Ent Settings 1. Rotate i to select an item. Press 2. Rotate i to select an option. Press u. The following items are available: • Source Select Popup: Selects whether the list of selectable audio sources comes on when the AUDIO button is pressed.
Page 285: Setting The Dvd Menu
Front Control Panel Operation Setting the DVD Menu Setting the DVD Menu Interface Dial H MENU button (in DVD mode) 1. Rotate i to select an item. Press Select Other Function to display additional menu entries. 2. Rotate i to select an option. Press u.
Page 286 Front Control Panel Operation Setting the DVD Menu • Play/Pause: Pauses or resume the playback. • Stop: Stops the playback. • Audio/Subtitle: Selects the language of the DVD audio and the DVD subtitle. • Angle: Selects the angle of a scene shot with multiple cameras. •...
Page 287: Wireless Headphones
Wireless Headphones Using the Wireless Headphones Using the Wireless Headphones Audio for the Rear Entertainment System is sent to the wireless headphones that come with the system. When you remove the headphones, the earpieces automatically pivot inward, and the 1. Pivot the earpieces outward. headphones turn off.
Page 288: Changing The Sound Source (Ultrawide Res Only)
Wireless Headphones Changing the Sound Source (Ultrawide RES only) Changing the Sound Source (Ultrawide RES only) Changing the Sound Source (Ultrawide RES only) ■ Wireless Headphone You can switch the sound source from the setup menu if you connected a set of wired In dual screen mode, you can switch the sound source of the wireless headphones headphones.
Page 289: Replacing The Batteries
Wireless Headphones Replacing the Batteries Replacing the Batteries 1. Insert a coin in the slot and twist it Replacing the Batteries slightly to pry the cover away from The battery is under the cover on the left the earpiece. earpiece. 2.
Page 290: Other Features
Other Features This section describes the useful functions incorporated into the navigation system to help make your journey easier and more enjoyable. Trip Computer ........290 Calendar ..........291 Information Functions ......292 System Device Information ....292 Map Data Update ........ 292 Info Screen Preference ......
Page 291: Trip Computer
Trip Computer H INFO button Trip Computer Trip Computer View the distance traveled and average fuel consumption. Displays the following trip information: Move w or y to select the trip • Instant Fuel: The current estimated instant information. fuel economy. •...
Page 292: Calendar
Calendar H INFO button Calendar View the calendar screen. Move w or y to select the months of the year.
Page 293: Information Functions
Information Functions System Device Information H SETTINGS button Navi Settings System Device Information System Device Information View database, software, device, and vehicle identification information. You will need this information when ordering a map update. 2 Obtaining a Navigation Update P. 319 Map Data Update Map Update Status H SETTINGS button...
Page 294: Info Screen Preference
Information Functions Info Screen Preference Info Screen Preference H SETTINGS button Info Settings Other Info Screen Preference Select the top menu when the INFO button is pressed. Rotate i to select your desired setting item. Press u. The following options are available: •...
Page 295: Multi-View Rear Camera
Multi-view Rear Camera About Your Multi-View Rear Camera The audio/information screen can display your vehicle’s rear view. The display About Your Multi-View Rear Camera automatically changes to the rear view when the shift lever is moved to Reverse. The rear camera view is restricted. You cannot see the corner ends of the bumper or what is ■...
Page 296 Multi-view Rear Camera About Your Multi-View Rear Camera ■ Multi-View Rear Camera Settings H SETTINGS button Camera Settings Rotate i to select an item. Press The following items are available: • Fixed Guideline: On (factory default): Guidelines appear when you shift into Reverse. Off: Guidelines do not appear when the dynamic guideline is off.
Page 298: Troubleshooting
Troubleshooting Troubleshooting ........298 Map, Voice, Entering Destinations ..298 Traffic ..........300 Guidance, Routing ....... 301 Update, Coverage, Map Errors ..... 303 Display, Accessories......303 Miscellaneous Questions ...... 303 Error Messages........304 Navigation System........ 304 CD Player ..........305 Hard Disc Drive (HDD) Audio ....
Page 299: Troubleshooting
Troubleshooting Map, Voice, Entering Destinations Problem Solution The Startup Confirmation screen is displayed every This is normal. The Startup Confirmation screen reminds you and your guest drivers to time I start the car. always operate the navigation system in a safe manner. The Startup Confirmation screen goes off after a certain period of time and the top screen of the last mode is displayed.
Page 300 Troubleshooting Map, Voice, Entering Destinations Problem Solution I cannot select an option using the Interface Dial. To reduce potential driver distraction, certain onscreen functions and features are limited or inoperable while the vehicle is moving. Use voice commands or pull over to proceed.
Page 301: Traffic
LINK button, and connect to the operator. ® 2 AcuraLink P. 258 • There may be a temporary technical problem in your metropolitan area. Call Acura Client Relations to see if there is an outage. 2 Acura Client Relations Contact Information P. 318 •...
Page 302: Guidance, Routing
Troubleshooting Guidance, Routing Guidance, Routing Problem Solution The navigation system does not route me the same The navigation system attempts to generate the optimal route. You can change the way I would go or the same way as other mapping route preferences used when calculating a route.
Page 303 Troubleshooting Guidance, Routing Problem Solution How do I remove the white dots (“breadcrumbs”) Press the SETTINGS button. Select Navi Settings > Map, set Display Tracking to Off from my screen? or select Delete Tracking to remove the white dots from the map. 2 Display Tracking P.
Page 304: Update, Coverage, Map Errors
Troubleshooting Update, Coverage, Map Errors Update, Coverage, Map Errors Problem Solution My city is not part of a fully verified detailed coverage The mapping database is constantly undergoing revision. You can access the most area. recent information on the internet. 2 Map Coverage P.
Page 305: Error Messages
Error Messages Navigation System Error Message Solution The display temperature is too high. For protection, This message appears briefly when the display temperature is too high. The navigation the system will shut off until the display cools down. system turns off until the display cools down. The system turns back on automatically when the display cools down.
Page 306: Cd Player
Error Messages CD Player CD Player If a disc error occurs, you may see the following error messages. Error Message Cause Solution • Current track/file will be skipped. The next supported track/file Unplayable File Track/file format not supported plays automatically. Bad Disc •...
Page 307: Hard Disc Drive (Hdd) Audio
Error Messages Hard Disc Drive (HDD) Audio Hard Disc Drive (HDD) Audio If an error occurs while playing the Hard Disc Drive (HDD) Audio, you may see the following error messages. If you cannot clear the error message, contact a dealer. Error Message Solution HDD access error.
Page 308: Ipod ® /Usb Flash Drive
® Error Messages iPod /USB Flash Drive ® iPod /USB Flash Drive ® If an error occurs while playing an iPod or USB flash drive, you may see the following error messages. If you cannot clear the error message, contact a dealer. Error Message Solution USB Error...
Page 309: Pandora
® Error Messages Pandora ® Pandora ® If an error occurs while playing Pandora , you may see the following error messages. If you cannot clear the error message, contact a dealer. Error Message Cause Solution Incompatible USB Device Appears when an incompatible device is Disconnect the device.
Page 310 ® Error Messages Pandora Cause Solution Error Message ® Cannot connect to PANDORA. The Pandora app failed to start because of • Turn the phone screen on, and make sure When stopped, check your mobile device. the following device errors: it is unlocked.
Page 311 ® Error Messages Pandora Cause Solution Error Message Unable to play PANDORA. Appears when you try to play PANDORA. Try again later. Please try again later. Unable to play PANDORA. Try again later. Music licensing restricts play in this area. Unable to play PANDORA.
Page 312: Aha Tm Radio
Error Messages Radio Radio If an error occurs while playing Aha Radio, you may see the following error messages. If you cannot clear the error message, contact a dealer. Error Message Solution Cannot connect to AcuraLink. When stopped, check your mobile Appears when the Aha app is not activated.
Page 314: Reference Information
GPS System...........316 Legal Information ......... 321 Address Calculation ......316 Copyrights ........... 321 Database ..........316 User Agreements ......... 321 Client Assistance ........318 As required by the FCC ......327 Resolving Problems .......318 Reporting Errors ........318 Acura Client Relations Contact Information .........318...
Page 315: System Initialization
System Initialization Acquiring GPS Information The navigation system must be initialized if 1. Set the power mode to ON, and turn on power to the navigation system is the audio system. interrupted for any reason (e.g., the 2. Press and hold the 9 (Power) button Depending on the length of time the battery was disconnected).
Page 316: Startup Confirmation Screen
System Initialization Startup Confirmation Screen Startup Confirmation Map Matching Screen Map matching is the process of using the acquired GPS information to locate your The Startup Confirmation screen is position on the map screen. If you are on a displayed when initialization has mapped road, the name of the road is successfully completed.
Page 317: System Limitations
System Limitations GPS System Database can cause occasional positioning errors of up to several hundred feet. The signals received from the GPS satellites The digitized map database reflects Address Calculation are extremely weak (less than a millionth conditions as they existed at various points of the strength of a local FM station) and in time before production.
Page 318 System Limitations Database • Pavement characteristics or conditions In addition, the map database contains verified and unverified areas. Unverified Every effort has been made to verify that streets may be missing from the map, in the database is accurate. The number of the wrong location, or have an incorrect inaccuracies you experience increases the name or address range.
Page 319: Client Assistance
P. 318 2 Reporting Errors landmarks, such as changes in business If you have a question that you cannot • Call Acura Client Relations. names. Information about points of resolve using the available help resources, 2 Acura Client Relations Contact interest are constantly being updated.
Page 320: Map Coverage
Client Assistance Map Coverage Map Coverage Obtaining a Navigation Map coverage update information is available from Acura Client Relations or Update online at www.acuranavi.com. The navigation system provides map coverage for the United States, Canada, To find navigation system update Acura is continually expanding the scope Puerto Rico, and Mexico.
Page 321: Traffic Information
All roads displayed on the map screens are To find traffic information: verified roads. Information in this manual 1. Visit www.acura.com/realtimetraffic. relating to “unverified” roads or areas is not applicable. 2. Select Real-Time Traffic on the MDX. 3. Click AcuraLink Real-Time Traffic.
Page 322: Legal Information
Legal Information • The HDD may not be decompiled, Copyrights User Agreements reverse engineered or otherwise disassembled, in whole or in part. • Infogroup-Data: Certain business data ■ Navigation System User • The HDD may not be used in a network provided by Infogroup ©...
Page 323 Legal Information User Agreements • The terms and conditions hereof apply Use, duplication, or disclosure of this HDD IF YOU DO NOT AGREE TO THIS END USER to all subsequent users and owners as by or on behalf of the United States LICENSE AGREEMENT (“EULA”), DO NOT well as to the original purchaser.
Page 324 Legal Information User Agreements • SPEECH RECOGNITION EFFORT (INCLUDING LACK OF If ALPINE provides or makes available NEGLIGENCE) IS WITH YOU. ALSO, to you Supplemental Components If the SOFTWARE includes speech THERE IS NO WARRANTY AGAINST and no other EULA terms are recognition component(s), you should INTERFERENCE WITH YOUR provided along with the...
Page 325 Legal Information User Agreements • UPGRADES • PRODUCT SUPPORT suppliers. The SOFTWARE is licensed, not sold. If the SOFTWARE is provided by ALPINE Product support for the SOFTWARE is separate from the DEVICE on separate You may not copy the printed materials not provided by MS, its parent media or via web download or other accompanying the SOFTWARE.
Page 326 Legal Information User Agreements issued by U.S. and other governments. available at www.honda.com (in U.S.) or ■ Gracenote Music Recognition For additional information on exporting www.honda.ca (in Canada). Service (CDDB) the SOFTWARE, see http:// CD and music-related data from www.microsoft.com/exporting/. Gracenote, Inc., copyright ©...
Page 327 Legal Information User Agreements (collectively, “Gracenote Servers”) and to rights. Under no circumstances will Gracenote Software or Gracenote Servers perform other functions. You may use Gracenote become liable for any payment will be uninterrupted. Gracenote Data only by means of the to you for any information that you Gracenote is not obligated to provide you intended End-User functions or this...
Page 328: As Required By The Fcc
Legal Information As required by the FCC As required by the FCC 1. This device complies with Part 15 of the FCC Rules and Canadian RSS-210/ RSSGen. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
Page 330: Voice Commands
Voice Commands Voice Commands ........330 Voice Portal Screen ......330 Navigation Commands......331 Useful Commands........ 332 Phone Commands........ 332 Audio Commands ........ 333 On Screen Commands ......333 Music Search Commands ..... 333 General Commands ......334 Climate Control Commands....334 List of Categories .........
Page 331: Voice Commands
Voice Commands Voice Portal Screen ■ ■ Phone Call Voice Help This can be only used when the phone is You can see a list of the available connected. When the system recognizes commands on the screen. the Phone call command, the screen will Navigation Commands change the dedicated screen for the voice Useful Commands...
Page 332: Navigation Commands
Emergency room Hospital Find nearest (specify place): iPod Police station Fuel and auto ® Bluetooth Audio Veterinarian Acura dealers Pandora Lodging Honda dealers Bed & breakfast Gas station Hotel Hydrogen station 2 Audio Commands P. 333 Resort Auto parts & electronics Recreation ■...
Page 333: Useful Commands
Voice Commands Useful Commands Useful Commands Performing arts Grocery store Sports complex Home improvement store The system accepts these commands on Tourist attraction Mall the voice portal top screen. Restaurant Office supply store Call <Your Contact Name> American restaurant Pharmacy Call <Phone Number>...
Page 334: Audio Commands
Voice Commands Audio Commands Audio Commands What am I listening to? ■ AUX Commands ■ iPod Commands AUX play The system accepts these commands on the dedicated screen for the voice iPod play On Screen Commands recognition of the audio. iPod play track <1-30>...
Page 335: General Commands
Voice Commands General Commands Climate Control Commands List of Categories ■ Play Commands Play artist <Name> The system accepts these commands on The system accepts these commands (POI Play album <Name> the Climate control screen. category name) on the dedicated screen. Fuel/Auto Play track/song <Name>...
Page 336: Index
3D Angle Adjustment ........ 79 Auxiliary Input Jack ......... 146 Setting Destination........101 Avoid Streets..........137 Clock Adjustment ........30 Avoided Area ..........62 Community (Place Category) ....100 Continue Trip..........141 Acura Client Relations ......318 Contrast ............28 ® AcuraLink ..........258 Coordinate..........113 Address Black Level..........28 Correct Vehicle Position......86...
Page 337 Index Voice Commands List ......333 Fuel/Auto (Place Category)...... 100 Display Tracking .........85 Map (Navi Settings) ........71 Driving ............119 Map Data Update Setting ............85 Checking Version ........292 Download POI Go Home ............ 11 Obtaining Update Data......319 Editing Category ........53 Go Home PIN..........
Page 338 Index Scenic Road Information......292 Scenic Route ..........109 On Demand Multi-Use Display Radio Schedule Basic Operation........... 5 FM/AM ........... 155 Calendar ..........291 ® Customizing Audio Source ...... 149 SiriusXM ..........161 Search Along ..........132 Screen Settings ......... 88 Random Search Around..........132 Shortcuts ........
Page 339 Index Navi Settings ..........60 Travel (Place Category) ......100 Wallpaper Trip Computer ..........290 Deleting, Importing, Setting ...... 32 Troubleshooting.........17, 298 Waypoint Adding ........... 131 Deleting, Ordering ........135 Unit Settings ..........35 Unverified Routing........58 Update System Software Zip Code ............. 93 Finding Update Information.....319 Obtaining Update Data ......319 USB Flash Drive Connecting, Disconnecting....185, 202...

Acura 2016 MDX User Manual

Table of Contents

System Setup

Start-Up

Voice Control System

Interface Settings

Personal Information

Routing

Guidance

Map

Data Reset

On Demand Multi-Use Display

Navigation

Entering a Destination

Calculating the Route

Driving to Your Destination

Map Menu

Changing Your Route

Changing Your Destination

Resuming Your Trip

Audio

Audio System

Audio Remote Controls

Audio Settings

Playing FM/AM Radio

Radio

Playing Siriusxm

Playing a Disc

Playing Hard Disc Drive (HDD) Audio

Playing an Ipod

Playing Internet Radio

Playing a USB Flash Drive

Playing Bluetooth ® Audio

® ®Handsfreelink Bluetooth

Handsfreelink

Bluetooth ® Handsfreelink

Text/E-Mail Message

® Acuralink

Rear Entertainment System

Rear Entertainment System

Rear Control Panel Operation

Front Control Panel Operation

Wireless Headphones

Other Features

Trip Computer

Calendar

Information Functions

Multi-View Rear Camera

Troubleshooting

Troubleshooting

Error Messages

Reference Information

System Initialization

System Limitations

Client Assistance

Troubleshooting

Legal Information

Voice Commands

Index

Quick Links

Chapters

Troubleshooting

Related Manuals for Acura 2016 MDX

Summary of Contents for Acura 2016 MDX
