Set the IP address using the printer operator panel

A simple way to set the IP address, netmask and gateway inside the print server is to use the
printer operator panel. You need to be standing at the printer to use this method.
1
On the printer operator panel, choose Parallel Menu, STD Parallel, Network 0 Setup,
TCP/IP, Set IP Address. Press Menu> until you see the correct menu item, and then
press Select.
2
When the current IP address is displayed, use the buttons to change the address.
Note: Pressing Select advances you to the next segment in the address. Menu>
increases the number by one. <Menu decreases the number by one.
3
When you finish setting the IP address, press Select until the word SAVED appears
briefly.
4
Set the IP netmask and gateway in a similar way.
5
Print a network setup page to verify the parameters are set as you intended.
