SuperStack II Baseline Switch
The 3Com SuperStack II Baseline
switch delivers the power of Ethernet
switching at an affordable price, and
includes two switched 10/100 Mbps
ports as standard. Designed to meet
your immediate performance demands,
the Baseline switch is an ideal solution
when bandwidth is constrained and
users need a cost-effective solution to
speed up the network.
The Baseline switch has 12 or 24
10BASE-T switched ports and two
10/100BASE-TX (Ethernet or Fast
Ethernet) switched ports that automati-
cally detect the speed of connected
devices, optimizing network perfor-
mance to 100BASE-TX, where
applicable. These are ideal for use as
high-speed connections to servers or as
downlink ports to the rest of the net-
work where traffic is highest and
bandwidth is at a premium. The
SuperStack II Baseline switch is unman-
aged and works straight out of the box.
12 or 24 RJ-45 10BASE-T
switched connections.
Two RJ-45 10BASE-T/100BASE-
TX auto-sensing uplink ports
provide high-speed connections
to network servers or a backbone
connection.
Autonegotiating full-/half-duplex
operation on each port doubles the
speed of each network connection
to 20 Mbps (for 10BASE-T ports)
or up to 200 Mbps (for 100BASE-
TX ports).
MAC addresses support up to
2,000 network devices on your
local area network.*
Two MDI/MDIX switchable
ports (one 10 Mbps port and one
10/100 Mbps port) let you cascade
hubs and switches and add high-
speed downlink connections
without using crossover cable.
19" size for easy installation in a
wiring closet. A rackmounting kit
is supplied. The product can also
be used free-standing.
Diagnostic LEDs indicate network
traffic, port status, speed
+
full-/half-duplex
10/100 Mbps ports, making it
easy to spot-check faults and
check individual port status.
* 750 MAC addresses supported by 12-port version
+ Only available on 24-port version
6
SuperStack II Baseline Switch
Front View
Back View
Advanced RPS connector
3Com lifetime limited warranty
Connection for the SuperStack II
Advanced Redundant Power
System provides ultimate protec-
tion against network downtime.
The SuperStack II Advanced
Redundant Power System
and Uninterruptible Power System
are available as options from 3Com.
SuperStack II
The 3Com SuperStack II system gives you a
flexible, cost-effective connectivity solution
for local, wide area, and SNA networks. You
can combine diverse technologies and network
services in one stacked system, strengthen it
with uninterruptible and redundant power
systems, and manage it all with Transcend
network management solutions.
As an important part of the 3Com Transcend
Networking framework, SuperStack II systems
will meet your evolving network needs—
futureproofing your network investment.
A single SuperStack II system provides
connections for a range of network environments
and protocols: Ethernet, Fast Ethernet, Layer 3
Switching, Gigabit Ethernet, Token Ring, FDDI,
ISDN, X.25, Frame Relay, and ATM. Depending
on your needs, you can build SuperStack II
systems for virtually any network environment.
+
and
Capabilities include:
operation of the
Hubs for flexible workgroup connectivity that
feature SNMP, RMON and Web-based manage-
ment
Industry-leading physical layer support for
Token Ring networks, including Token Ring
switching
12 or 24 RJ-45 ports
(60 W Type 1)
®
LEDs for link status
and network traffic
MDI/MDIX
LEDs to indicate 10/100 Mbps
switch
speed and full/half duplex
2 RJ-45 ports for
MDI/MDIX
10/100 Mbps connections
switch
Backbone
WAN/SNA Host
Transcend Network
Management Architecture
Full SNMP, RMON, and Web-based management
for Ethernet, Fast Ethernet, Gigabit Ethernet, as
well as a dedicated RMON/RMON-2 probe
Full range of switches to increase performance
in high-speed client/server LANs
Full, multiprotocol network access for telecom-
muters or users at other off-site locations
Routing between central site and branch
offices using innovative Boundary Routing
architecture or conventional routing software
for multiple WAN choices, including ISDN
SNA-to-LAN conversion linking local and
remote offices to an SNA host system
Choice of power systems to ensure
uninterrupted network operation
For smaller offices with fewer than 20 users,
®
our OfficeConnect
products can be used
to complement SuperStack II systems.
Hubs
Switches
Routers
SDLC Converters
Access Servers
RMON-2 Probes
Open Hub
Power Systems
®
