Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 350350 Installation This hob must be installed by qualified personnel, according to the manufacturer’s instructions and to the relevant British Standards.
Page 3
Ensure the control knobs are in the ‘OFF’ position when not in use. When using other electrical appliances, ensure the cable does not come into contact with the hot surfaces of the cooking appliance. Unstable or misshapen pans should not be used on the hob as unstable pans can cause an accident by tipping or spillage.
Contents Instructions for the User Important Safety Information Description of the Hob Operation Maintenance and Cleaning Something Not Working? Service and Spare Parts Customer Care Guarantee Conditions Instructions for the Installer Engineers technical data Important safety requirements Installation Electrical connections Wiring diagram Fault Finding Commissioning...
Description of the Hob Fig. 1 1. Hob Top 2. Semi-rapid burner 3. Auxiliary burner 4. Rapid burner 5. Ultra-rapid burner (triple crown) 6. Control knobs Installation Any gas installation must be carried out by a registered CORGI installer, and in accordance with existing rules and regulations.
Operation Hob burners control knobs The symbols on the knobs mean that : there is no gas supply there is maximum gas supply there is minimum gas supply Lighting the burners For easier lighting, proceed before putting a pan on the pan support. To light a burner, turn the relevant knob anticlockwise to maximum position ( burner.
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. The Hob Top Regularly wipe over the hob top using a soft cloth well wrung out in warm water to which a little...
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Service Force Centre. SYMPTOM There is no spark when lighting the gas The gas ring burns unevenly If after all these checks, your hob still does not operate correctly, contact your local Service Force Centre.
Date of purchase Customer Care For general enquiries concerning your AEG-Electrolux appliance and for further information on AEG-Electrolux products, contact our Customer Care Department by letter or telephone at the address below or visit our website at www.aeg.co.uk calls to this number may be recorded for training purposes.
Standard guarantee conditions We, AEG-Electrolux, undertake that if within 12 months of the date of the purchase this AEG-Electrolux appli- ance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our discretion repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·...
Instruction for the Installer Engineers technical data Overall dimensions Width: Depth: Cut out dimensions Width: Depth: Supply Connections Gas:R 1/2 inch (1/2 inch male) Rear right hand corner Electric: 230 V 50 Hz supply, 3 core flexible cable with non rewireable plug fitted with a 3 amp cartridge fuse.
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). Detailed recommendations are contained in the following British Standards Codes Of Practice: B.S. 6172/ B.S. 5440, Part 2 and B.S.
Installation Important This hob must be installed by qualified personnel to the relevant British Standards. Any gas installation must be carried out by a CORGI registered installer. The manufacturer will not accept liability, should the above instructions or any of the other safety instructions incorporated in this book be ignored.
Cut Out Size The dimensions of the cut-out are given in the diagram. FO 2038 Building In Building over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface.
FO 2563 Building over a kitchen unit with door Proper arrangements must be taken in designing the furniture unit, in order to avoid any contact with the bottom of the hob which can be heated when it is operated. The recommended solution is shown in diagram The panel fitted under the hob ("a") should be easily removable to allow easy access if...
Fitting the Hob into the worktop Carry out the building in of the hob as follows: • put the seals supplied with the hob, on the edges of the cut out: place them exactly on the front and rear edge and at 50 mm.
Electrical connections Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS HOB MUST BE EARTHED. The manufacturer declines any liability should these safety measures not be observed.
Permanent Connection In the case of a permanent connection, it is necessary that you install a double pole switch between the hob and the electricity supply (mains), with a minimum gap of 3 mm. between the switch contacts and of a type suitable for the required load in compliance with the current electric regulations.
Fault Finding Preliminary Electrical Systems Check START Isolate appliance and carry out: A: Earth Continuity check. Has inlet fuse blown? Inlet wiring faulty. Rectify any fault. Isolate appliance and carry out: B: Insulation check. Rectify any fault including replacing fuses as necessary. Carry out: Carry out: D: Resistance to...
Page 20
A. EARTH CONTINUITY CHECK Appliance must be electrically disconnected - meter set on Ω (Ohms) x 1 scale and adjust zero if necessary. — Test leads from any appliance earth point to earth pin on plug. Resistance should be less than 0.1 Ω (Ohm), check all earth wires for continuity and all contacts are clean and tight.
Page 21
Ignition System / Gas Ignition Ignitor does not spark Check plug top fuse and replace if necessary Check polarity and earth continuity of supply point Check earth continuity of appliance Check continuity from 'N' on the mains connector block and "N" on the ignitor unit Check continuity from 'L' on the mains connector block and the...
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. Turn the gas tap to the MAX position and ignite. Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times.
Conversion from Natural Gas to LPG IMPORTANT The replacement/conversion of the gas hob should only be undertaken by a competent person. It is important to note that this model is designed for use with natural gas but can be converted for use with butane or propane gas providing the correct injectors are fitted. The gas rate is adjusted to suit.
