HP StorageWorks 2405 - Disk System User Manual page 9

Figure 1 Disk System Front View 14
Figure 2 Disk System Back View 14
Figure 3 Disk Module 18
Figure 4 LCC 19
Figure 5 Power Supply/Fan Module 21
Figure 6 Single Initiator Basic Configuration 24
Figure 7 Single Host PV Links Configuration 25
Figure 8 Two Host High Availability Configuration 26
Figure 9 Four Host Hub Configuration 27
Figure 10 PDRU Placement in 1.6-Meter Rack 35
Figure 11 PDRU Placement in a 2.0-Meter Rack 36
Figure 12 Disk System Accessories 39
Figure 13 Disk System Contents 40
Figure 14 HP Rack System/E Rail Kit Contents 41
Figure 15 HP Rack System/E Installation Overview 42
Figure 16 Locating the site for the device installation in a System/E
rack 44
Figure 17 Installing clipnuts for an HP Rack System/E 44
Figure 18 Installing rails in an HP Rack System/E 45
Figure 19 Installing the enclosure clipnut in an HP Rack System/E 46
Figure 20 Installing the storage device in the Rack System/E 47
Figure 21 Installing enclosure rail clamps in an HP Rack
System/E 48
Figure 22 HP Computer Cabinet Rail Kit Contents 49
Figure 23 HP Computer Cabinet Installation Overview 50
Figure 24 Locating the site for the device installation in an HP
Computer Cabinet 51
Figure 25 Installing rail clip nuts in the HP Computer Cabinet 51
Figure 26 Installing rails in the HP Computer Cabinet 52
Figure 27 Installing enclosure retention clipnuts in an HP Computer
Cabinet 53
Figure 28 Installing the storage device in an HP Computer
Cabinet 54
figures
9
