Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
THIS CATALOG SUPERCEDED
PUBLICATION #5995522561.
Product No.
Color
Volts
Wiring Diagram
Owner's Guide
Market
Service Data Sheet 241957100
W241899001B.eps S241899001B.eps
E24WC75HPS0
stainless
115
241899001
241957000
North America
Publication No.
5995531844
09/01/21
(EN/SERVICE/KHB)
390
Copyright
WINE COOLER
Model No.
E24WC75H
©
2009 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Electrolux E24WC75H
Summary of Contents for Electrolux E24WC75H
-
Page 1: Wine Cooler
PUBLICATION #5995522561. Product No. E24WC75HPS0 Color stainless Volts Wiring Diagram 241899001 Owner's Guide 241957000 Market North America Service Data Sheet 241957100 Publication No. 5995531844 09/01/21 (EN/SERVICE/KHB) Copyright WINE COOLER Model No. E24WC75H © 2009 Electrolux Home Products, Inc. All rights reserved. - Page 2 Publication No: 5995531844 01/09 E24WC75HPS0 DOOR U05DIAAAA0...
- Page 3 POS. NO PART NO. 7241867201 7241879203 7241958501 7241953401 7241603101 7241866601 7241866602 7241954602 7241637915 7241866801 7241866802 7240383408 7241906101 7241918201 7241904601 21D* 7241947201 7241866401 7241866402 7241866501 7241866502 7241897403 7215503203 7241866101 # Functional Parts * Non-Illustrated Parts E24WC75HPS0 DOOR DESCRIPTION Gasket-door, black Door Assembly, glass, w/framing Harness-wiring, door Plug button, black Label, nameplate, elux/icon...
- Page 4 Publication No: 5995531844 01/09 E24WC75HPS0 CABINET U05BIABBA0...
- Page 5 POS. NO PART NO. 15 # 7241904201 7241906101 7241947301 7241500304 7241882201 7241882202 7241904601 7241904301 7241882401 7241882402 7241882301 7241882302 7241881801 7241881802 7241710601 7241911501 7241908401 7241898002 7241904501 7241909201 7241903801 7241900701 # Functional Parts * Non-Illustrated Parts E24WC75HPS0 CABINET DESCRIPTION Light Assembly, LED, (4) Screw-#10 x 3/4 TEK Screw Screw, hex washer head, 8-18AB x 0.625...
- Page 6 Publication No: 5995531844 01/09 E24WC75HPS0 SHELVES U05SWIAAA0...
- Page 7 POS. NO PART NO. 7241902602 7241904701 7241905202 # Functional Parts * Non-Illustrated Parts E24WC75HPS0 SHELVES DESCRIPTION Shelf-Wine Rack, lower Screw, 8-18 X 1-1/4 Shelf-Wine Rack, lower Publication No: 5995531844 01/09...
- Page 8 Publication No: 5995531844 01/09 E24WC75HPS0 SYSTEM U05CWADAD1...
- Page 9 POS. NO PART NO. 7241931201 75304406721 7241890001 7241890002 7241931901 7218944002 7241516901 7241932501 7241932601 7241932701 6* # 7241900201 6* # 7241900501 6* # 7241900701 7241890201 7241890503 7241933201 13 # 7241781901 7215503203 15 # 7241891801 7241889801 7241888101 7218252201 7218513300 7241812301 7216056401 7241889901 29 # 75303918368 30 #...
-
Page 10: Wiring Schematic
Publication No: 5995531844 E24WC75HPS0 WIRING SCHEMATIC 01/09... -
Page 11: Wiring Diagram
WINE COOLER EVAPORATOR FANS USER INTERFACE DISPLAY (U.I.) BEVERAGE COOLER EVAPORATOR FAN NTC THERMISTOR COOLER COMPARTMENT LEDs # Functional Parts * Non-Illustrated Parts E24WC75HPS0 WIRING DIAGRAM SERVICE CORD RIBBED LT BLUE GRN/YEL GRN/YEL NON-RIBBED GRN/YEL GRN/YEL GRN/YEL WHITE NOT USED NOT USED NTC THERMISTOR EVAPORATOR COIL...
