NOTES
•
To fill in the source IP or MAC, you can:
a)
Enter a specific IP address, such as "192.168.122.1".
b)
Enter IP addresses within one subnet or within the same IP
pool, such as "192.168.123.*", or "192.168.*.*"
c)
Enter all IP addresses as "*.*.*.*" or leave the field blank.
d)
The format for the MAC address is six groups of two
hexadecimal digits, separated by colons (:), in transmission
order (e.g. 12:34:56:aa:bc:ef)
•
For source or destination port range, you can either:
a)
Enter a specific port, such as "95".
b)
Enter ports within a range, such as "103:315", ">100", or
"<65535".
The Transferred column contains information about the upstream
•
and downstream traffic (outgoing and incoming network traffic) for
one section. In this column, you can set the network traffic limit (in
KB) for a specific service to generate specific priorities for the service
assigned to a specific port. For example, if two network clients, PC
1 and PC 2, are both accessing the Internet (set at port 80), but PC 1
exceeds the network traffic limit due to some downloading tasks, PC
1 will have a lower priority. If you do not want to set the traffic limit,
leave it blank.
5. On the User-defined Priority page, you can prioritize the
network applications or devices into five levels from the user-
defined QoS rules' dropdown list. Based on priority level, you
can use the following methods to send data packets:
• Change the order of upstream network packets that are sent
