  • Page 1 Wall-Mounting your HP TouchSmart User Guide...
  • Page 2 The only warranties for Hewlett-Packard products and services are set forth in the express statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Table of contents 1 Preparing your HP TouchSmart PC for wall-mounting ............1 What you need ........................1 Safety information ........................1 Before removing the stand ......................2 Removing the computer stand ....................2 Installing the VESA adapter plate ....................7 2 Reinstalling the stand on your HP TouchSmart PC ............
  • Page 4 Wall-Mounting your HP TouchSmart...

  • Page 5: Preparing Your Hp Touchsmart Pc For Wall-Mounting

    Preparing your HP TouchSmart PC for wall-mounting This document provides instructions for computer wall-mounting preparation. The VESA adapter plate is attached to bottom of the stand on the HP TouchSmart PC. This adapter assembly attaches to a wall- mounting device (sold separately). Should you decide to switch your computer back from a wall-mounted unit to desktop unit, instructions are also included for reinstalling the stand on the computer.

  • Page 6: Before Removing The Stand

    Before removing the stand To avoid injury and equipment damage when opening the HP TouchSmart PC, always complete the following steps in order: Remove any media and external devices (such as any CD, DVD, memory cards, USB devices, or external hard disk drives) from the HP TouchSmart PC. CAUTION: Static electricity can damage the electronic components of the HP TouchSmart PC or optional equipment.
  • Page 7 Insert your finger, or a flathead screwdriver, into the slot on the stand cover to pry it off of the computer stand. Remove the stand cover from the computer stand. Removing the computer stand Wall-Mounting your HP TouchSmart...
  • Page 8 Use a Phillips screwdriver to tighten the recessed two brake screws (for the rails) on the computer. It should take about 5–10 turns of the screwdriver to secure the screws. Take care not to overtighten the screws. NOTE: The tightened brake screws will hold the VESA adapter plate in the locked position, so that the computer does not slide down once it is mounted on a wall.
  • Page 9 Remove the VESA adapter plate from the bottom of the computer stand. Use a flathead screwdriver to remove the four screws attaching the computer stand to the back of the computer. Removing the computer stand Wall-Mounting your HP TouchSmart...
  • Page 10 Lift the computer stand away from the computer. Save the computer stand, stand cover, and four screws, so that you can convert your HP TouchSmart PC back to a desktop unit in the future. NOTE: If the computer stand is ever replaced on the computer, the VESA adapter plate must be replaced on the bottom of the computer stand in order to properly support the computer.

  • Page 11: Installing The Vesa Adapter Plate

    Installing the VESA adapter plate Place the VESA adapter plate over the rails on the back of the computer, matching the cutouts on the each side of the plate with the screw holes and the hooks on the rails. Attach the VESA adapter plate to the back of the computer, using a Phillips screwdriver to tighten the four screws.
  • Page 12 Slide the VESA adapter plate upward until it locks into place. You will hear a click when the VESA adapter plate is locked in place. NOTE: If you do not hear the click or the plate does not lock in place, it means the two brake screws were not sufficiently tightened when the computer stand was removed.
  • Page 13 Attach the wall-mounting hardware (purchased separately) to the VESA adapter plate, according to the manufacturer's instructions, using either the 100 mm x 100 mm screw holes or the 100 mm x 200 mm screw holes. Mount the computer on the wall. CAUTION: The computer is heavy and may require two people to mount it to the wall.

  • Page 14: Reinstalling The Stand On Your Hp Touchsmart Pc

    Reinstalling the stand on your HP TouchSmart PC You may decide to convert your HP TouchSmart PC from a wall-mounted unit back to a desktop unit. You will need to install the computer stand back on to your HP TouchSmart PC. The VESA adapter plate must be replaced on the bottom of the computer stand, in order to properly support the computer.

  • Page 15: Removing The Wall-Mounting Hardware

    Removing the wall-mounting hardware Prepare your HP TouchSmart PC for removal from the wall-mounting device. Remove any media and external devices (such as any CD, DVD, memory cards, USB devices, or external hard disk drives) from the HP TouchSmart PC. CAUTION: Static electricity can damage the electronic components of the HP TouchSmart PC or optional equipment.

  • Page 16: Replacing The Computer Stand

    Replacing the computer stand Replace the computer stand on your HP TouchSmart PC. Once the computer stand is on the computer, replace the VESA adapter plate on the bottom of the computer stand. This stabilizes the computer stand so that it supports the weight of your HP TouchSmart PC. Use a Phillips screwdriver to remove the four screws from the VESA adapter plate at the back of the HP TouchSmart PC.
  • Page 17 Tilt the base of the computer stand so that you can position it over the rails on the back of the computer, and align the four screw holes. Use a flathead screwdriver to replace the four screws attaching the computer stand to the computer.
  • Page 18 Use a Phillips screwdriver to loosen the brake screws, turning to the left 5–6 times. NOTE: The brake screws are not removable and only need to be loosened to move the computer stand. Grasp the computer stand and move it slightly upward to release the lock. You will hear a click. Then slowly move the computer stand down to the bottom of the computer.
  • Page 19 Position the VESA adapter plate over the bottom of the computer stand, aligning the round cutout with the raised circle, and align the four screw holes. Use a Phillips screwdriver to tighten all four screws attaching the VESA adapter plate to the bottom of the computer stand.
  • Page 20 Align the stand cover to the computer stand and snap it back into place. Make sure that there are no gaps between the computer stand and the stand cover. Place the HP TouchSmart PC in an upright position. Adjust the vertical position and tilt of the display. Connect the power cord.
