Intel Desktop Board D945PVS Technical Product Specification

1.1 Overview

1.1.1 Feature Summary

Table 1 summarizes the major features of the board.
Table 1.

Feature Summary

Form Factor
Processor
Memory
Chipset
Video
Audio
Legacy I/O Control
USB
IEEE-1394a
Interface
Peripheral
Interfaces
SATA RAID
LAN Support
BIOS
Expansion
Capabilities
10
ATX (12.00 inches by 9.60 inches [304.80 millimeters by 243.84 millimeters])
®
Support for an Intel Pentium
or 533 MHz system bus
• Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR2 667, DDR2 533, or DDR2 400 MHz DIMMs
• Support for up to 4 GB of system memory
®
Intel 945P Chipset, consisting of:
• Intel
® 82945P Memory Controller Hub (MCH)
• Intel
®
82801GR I/O Controller Hub (ICH7-R)
One PCI Express* x16 bus add-in card connector
8-channel (7.1) audio subsystem with five analog audio outputs and one S/PDIF
optical digital audio output using the Sigmatel* 9223 audio codec
Legacy I/O controller for diskette drive, serial, parallel, and PS/2* ports
Support for USB 2.0 devices
IEEE-1394a controller and three IEEE-1394a connectors (one back panel
connector, two front-panel connectors)
• Eight USB ports
• One serial port
• One parallel port
• Four Serial ATA interfaces
• One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support
• One diskette drive interface
• PS/2 keyboard and mouse ports
Intel 82801GR I/O Controller Hub (ICH7-R) for RAID support (levels 0,1, 0+1,
and 5) on the SATA interface
Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the
®
Intel 82573E/82573V/82574V Gigabit Ethernet Controller
• Intel
®
BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
• Four PCI Conventional* bus connectors
• Two PCI Express x1 bus add-in card connectors
• One PCI Express x16 bus add-in card connector
®
4 processor in an LGA775 socket with a 1066, 800,
continued
