2.2.1.3 Local User Interface Setup Menus

Access to Network Configuration Menu:
Phase 1: bootROM
Phase 2: application
Phone network configuration parameters may be edited by means of a main menu and
two sub-menus: DHCP Menu and Server Menu.
Use the soft keys, the arrow keys, the Sel/ , and the Del/X keys to make changes.
Parameters that cannot be changed are read-only due to the value of other parameters.
For example, if the DHCP Client parameter is enabled, the Phone IP Addr and Subnet
Mask parameters are dimmed or not visible since these are guaranteed to be supplied
by the DHCP server (mandatory DHCP parameters) and the statically assigned IP
address and subnet mask will never be used in this configuration.
2.2.1.3.1 Main Menu
Configuration parameters that may be edited on the main setup menu are described in
the table below:
Name
DHCP Client
DHCP Menu
Phone IP Address
Subnet Mask
IP Gateway
Server Menu
® ®
IP / SoundStation IP
The network configuration menu is accessible during the auto-boot
countdown of the bootROM phase of operation. Press the
soft key to launch the main menu.
The network configuration menu is accessible from the main menu.
Navigate to Menu>Settings>Advanced>Admin Settings>Network
Configuration. Advanced Settings locked by default. Enter the
administrator password to unlock. (Factory default password: 456)
a
Possible Values
Enabled, Disabled
dotted-decimal IP
address
dotted-decimal subnet
mask
dotted-decimal IP
address
Copyright © 2005 Polycom, Inc.
Installation and Operation
Description
If enabled, DHCP will be used to obtain the
parameters discussed in 2.2.1.1 DHCP or Man-
ual TCP/IP Setup on page 5.
See 2.2.1.3.2 DHCP Menu on page 8.
Note: Disabled when DHCP client is disabled.
Phone's IP address.
Note: Disabled when DHCP client is enabled.
Phone's subnet mask.
Note: Disabled when DHCP client is enabled.
Phone's default router.
See 2.2.1.3.3 Server Menu on page 10.
