Asus M2N68 PLUS User Manual page 10

M2N68 PLUS specifications summary
Back panel I/O ports
Internal I/O connectors
BIOS
Accessories
Form Factor
Support DVD
*Specifications are subject to change without notice.
x
1 x PS/2 Keyboard port
1 x PS/2 Mouse port
1 x LAN (RJ45) port
4 x USB 2.0/1.1 ports
6-channel Audio ports
1 x LPT port
1 x COM port
3 x USB 2.0/1.1 connectors support additional
6 USB 2.0/1.1 ports
1 x IDE connector
1 x High Definition Front panel audio connector
4 x SATA connectors
1 x CD audio-in connector
1 x Speaker connector
1 x S/PDIF Out connector
1 x CPU Fan connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
1 x system panel connector
8Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0,
ACPI2.0a, SM BIOS2.5
1 x Serial ATA cable
1 x UltraDMA 133/100/66 cable
1x I/O Shield
User manual
ATX form factor: 12'' x 8'' (30.5cm x 20.3cm)
Drivers
ASUS LiveUpdateUtility
ASUS PC Probe II
Anti-Virus software (OEM version)
