SERIAL FUNCTIONAL SPECIFICATION

7.48. Auto PC Adj. Command

Command
Detail
Response

7.49. Presentation Timer Command

Command
Detail
Response
7.50. Keystone Up Command
Command
Detail
Response
7.51. Keystone Down Command
Command
Detail
Response
"C89" [CR]
Execute Auto PC Adj. command
This command works the same as a Remote control's "AUTO PC " button.
While Auto PC Adj. is working and a computer issues another command, Auto
PC Adj. stops.
Acceptable [ACK] [CR]
Unacceptable "?" [CR]
"C8A" [CR]
Set a presentation timer to active.
This command works the same as the Remote control's "P-TIMER" button.
Acceptable [ACK] [CR]
Unacceptable "?" [CR]
"C8E" [CR]
Adjust keystone. Make the screen image length at the top edge shorter.
Acceptable [ACK] [CR]
Unacceptable "?" [CR]
"C8F" [CR]
Adjust keystone. Make the screen image length at the bottom edge shorter.
Acceptable [ACK] [CR]
Unacceptable "?" [CR]
Page 14 of 18
