Specifications - Dell Latitude E6430 ATG Setup And Features Information

Figure 11. RF Pass Connector
NOTE: It is recommended that you turn on and shut down your computer at least
once before you install any cards or connect the computer to a docking device or
other external device, such as a printer.

Specifications

NOTE: Offerings may vary by region. The following specifications are only those
required by law to ship with your computer. For more information regarding the
configuration of your computer, click Start → Help and Support and select the
option to view information about your computer.
Power
AC Adapter
Latitude E6430, Latitude E6530, and
Latitude E6430 ATG
Input voltage
Coin-cell battery
Physical
Latitude E6430
Height
Width
Depth
Weight (Discrete unit with 6 cell)
65 W and 90 W
NOTE: 65 W AC adapter is available only
for computers with integrated video card.
100 VAC to 240 VAC
3 V CR2032 lithium coin cell
26.90 mm to 32.40 mm (1.06 inches to 1.27
inches)
352.00 mm (13.86 inches)
241.00 mm (9.49 inches)
2.62 kg (5.78 lb)
9
