Operating Instructions

LCD Television
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and retain
them for future reference.
The images shown in this manual are for illustrative purposes only.
English
UK and Ireland model
Model No.
TX-L32E30B
TX-L37E30B
TX-L42E30B
TQB0E2096
