KitchenAid KUDC20FVBL - ARCHITECT Series II Parts List page 9

W10304967
UPPER WASH AND RINSE PARTS
For Models: KUDC20FVBL3, KUDC20FVWH3, KUDC20FVSS3
(Black)
Illus. Part
No. No.
1 W10077863 Feed Tube
2 8533889 Screw
3 8557720 Spinner, 3rd
4 W10118464 Fastener, Push−In
5 W10082867 Mount
6 W10082949 Manifold
7 W10082832 Hanger
8 8268433 Seal, Sprayarm
9 W10082831 Nozzle−Feed
10 W10082841 Sprayarm
(White) (Stainless)
DESCRIPTION
Assembly
(Also Includes
Item 3)
Level
9
