How to Configure Digital Modem PVDM2s
Command or Action
Step 7
no cdp enable
Example:
Router(config-if)#no cdp enable
Step 8
group-range start-range end-range
Example:
Router(config-if)#group-range 0/322 0/345
Configuring the Dialer Interface
The dialer interface is the parent interface that holds the central protocol characteristics for the dialer-rotary
group. To configure the dialer interface, perform the following tasks, beginning in global configuration mode:
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
DETAILED STEPS
Command or Action
Step 1
interface Dialer number
Example:
Router(config)# interface dialer 101
Step 2
ip unnumbered Loopback number
Example:
Router(config-if)# ip unnumbered loopback 0
Step 3
no ip mroute-cache
Example:
Router(config-if)# no ip mroute cache
Cisco IOS Release 12.4(9)T, 12.4(11)XW, and 12.4(20)T
10
Cisco PVDM2-12DM, PVDM2-24DM, and PVDM2-36DM Digital Modem Packet Voice Data Modules
interface Dialer number
ip unnumbered Loopback number
no ip mroute-cache
encapsulation ppp
peer default ip address pool name
dialer in-band
dialer-group number
no fair-queue
no cdp enable
Purpose
Disables Cisco Discovery Protocol on this interface.
Associates one or more interfaces to the group interface so
that all associated interfaces can be configured through the
group interface.
Purpose
Defines a dialer rotary group leader.
Enables IP processing on the loopback interface without
assigning an explicit IP address to the interface.
Disables IP multicast fast switching.
