Vigor N61

Wireless Adapter

User's Guide
Version: 1.01
Date: 2008/02/19
Copyright 2008 All rights reserved.
This publication contains information that is protected by copyright. No part may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language without written permission from the copyright
holders. The scope of delivery and other details are subject to change without prior notice.
Microsoft is a registered trademark of Microsoft Corp.
Windows, Windows 95, 98, Me, NT, 2000, XP and Explorer are trademarks of Microsoft Corp.
Apple and Mac OS are registered trademarks of Apple Computer Inc.
Other products may be trademarks or registered trademarks of their respective manufacturers.
Please visit www.draytek.com to get the newly updated manual at any time.

Advertisement

Table of Contents
loading

Related Manuals for Draytek VIGOR N61

Summary of Contents for Draytek VIGOR N61

  • Page 1: Wireless Adapter

    Windows, Windows 95, 98, Me, NT, 2000, XP and Explorer are trademarks of Microsoft Corp. Apple and Mac OS are registered trademarks of Apple Computer Inc. Other products may be trademarks or registered trademarks of their respective manufacturers. Please visit www.draytek.com to get the newly updated manual at any time.

  • Page 2: Regulatory Information

    Product: Vigor N61Wireless Adapter DrayTek Corp. declares that Vigor N61Wireless Adapter are in compliance with the following essential requirements and other relevant provisions of R&TTE Directive 1999/5/EEC. The product conforms to the requirements of Low Voltage (LVD) Directive 2006/95/EC by complying with the requirements set forth in EN60950.

  • Page 3: Table Of Contents

    Installation Overview...7 Introduction ... 7 Installation Procedure ... 7 Uninstalling USB Driver... 12 Configuration ...15 Wireless USB Adapter Utility... 15 Configuration... 16 Status ... 24 Option... 25 About ... 27 Miscellaneous ...29 Windows Zero Configuration... 29 Vigor N61 User’s Guide...
  • Page 4 This page is left blank. Vigor N61 User’s Guide...

  • Page 5: Preface

    Compatibility with IEEE 802.11n future version is not guaranteed. Compatibility with IEEE 802.11n draft devices from other manufacturer is not guaranteed. Vigor N61 User’s Guide...
  • Page 6 This page is left blank. Vigor N61 User’s Guide...

  • Page 7: Installation Overview

    Before installing Vigor N61, make sure that there is already an Access Point existed on the wireless network. It is needed in case of Infrastructure network mode. Here are some steps you will perform in establishing your wireless network connection: Install the USB Driver for Vigor N61 by using the Install CD.
  • Page 8 The setup wizard will appear as follows. Please click Next. Now, you can insert Vigor N61 to the USB port of your computer. Then click Next. Connect with USB cable Connect directly Vigor N61 User’s Guide...
  • Page 9 There are two types of setup that you have to choose, Complete or Install Driver Only. If you do not know which one is proper, simply choose Complete and click Next. Vigor N61 User’s Guide...
  • Page 10 The default destination folder will be specified in this page. Also, you can click Browse... to choose another folder for storing the driver. Click Next. A default program folder will be offered by the setup program. If you do not want to change it, simply click Next. Vigor N61 User’s Guide...
  • Page 11 When it locates, a message will be shown on the system tray. 11. Now, you can find the N61 utility icon in the system tray. Double click it to open the configuration window of Vigor N61 wireless adapter. Vigor N61 User’s Guide...

  • Page 12: Uninstalling Usb Driver

    If you want to remove the driver for this wireless card, please do the following: Run Start >> Programs>> Vigor N61 802.11n Wireless USB Adapter Utility>>Uninstall. The Preparing Setup will appear. When the following screen appears, please click OK. Now, the system starts to remove the corresponding files.
  • Page 13 When the following dialog appears, please click Finish. Vigor N61 User’s Guide...
  • Page 14 This page is left blank Vigor N61 User’s Guide...

  • Page 15: Configuration

    The Wireless USB Adapter Utility window will appear as the following. Basically, the software will scan and display available wireless AP automatically. This chapter will introduce each tab in detail. Also, an example of configuration will be provided for your reference. Vigor N61 User’s Guide...

  • Page 16: Configuration

    It can re-search available APs on wireless network whenever the user clicks it. By the way, the whole list will be refreshed in a certain time automatically. It starts to build a connection between the station (client) and the AP. Vigor N61 User’s Guide...
  • Page 17 In the field of Profile Group Control, you can see: Rename Delete Select Vigor N61 User’s Guide It allows you to add a new profile to group several APs. Click New to open the following dialog box. Type a new name in the box and click OK.
  • Page 18 AP. When you want to import such profile, you have to type the correct password for that AWP file. It allows you to select one of the existed profiles for applying with current connected Access Point. Vigor N61 User’s Guide...
  • Page 19 Wireless network name (SSID) Authentication Mode Data Encryption Vigor N61 User’s Guide Please type the name for the AP or wireless router you want to connect. There are six modes provided for you to choose for data encryption in connection.
  • Page 20 It will be available when you choose Open System. Such button will be available after you check Enable 802.1X. You have to type the same parameters as set in the connected AP. Otherwise the connection will not be successful. Vigor N61 User’s Guide...
  • Page 21 Remove – For the CA server which is useless, please select that one from Trust CA List and click this button to delete it. IP & Proxy Setting This setting allows you to set IP and proxy. Please click this button to open the following window. Vigor N61 User’s Guide...
  • Page 22 Alternate DNS server – Type the address for secondary DNS server. Primary WINS - Type the IP address for primary WINS. Secondary WINS - Type the IP address for secondary WINS. To set proxy setting, click ProxySetting tab to display the following window: Vigor N61 User’s Guide...
  • Page 23 Socks/Port - Type proxy IP and port number for Socks. Do not use proxy server for address beginning with - Type the heading of IP address that you do not want to use as a proxy server. Vigor N61 User’s Guide...

  • Page 24: Status

    It displays the MAC address for AP or wireless router that station connected. It displays Regulatory Domain for different areas. For example, it will display ETSI (CH1~CH13) for nations in Europe, display FCC(CH1~CH11) for USA, etc. It displays On or Off status for this wireless card. Vigor N61 User’s Guide...

  • Page 25: Option

    Automatically connect to non-preferred networks Disable Radio Vigor N61 User’s Guide Check this button to launch the wireless connection when Windows starts up. If you do not check this box, you can launch wireless connection manually. Remember and fix the position of mini status dialog.
  • Page 26 Disable – The power will not be saved. However, the wireless signal will be better. Such function can increase the data transmission rate within a short time. Choose Enable to activate the function, otherwise, choose Disable to close the function. Vigor N61 User’s Guide...

  • Page 27: About

    This page provides software information such as utility version and driver versions. Simply click About tab on the Wireless USB Adapter window. Utility Version Driver Version Vigor N61 User’s Guide It displays the version number of this utility. It displays the driver version of this wireless card.
  • Page 28 This page is left blank Vigor N61 User’s Guide...

  • Page 29: Miscellaneous

    Locate Wireless Zero Configuration. If you find that the status of WZC is not enabled, please click the wireless monitor utility icon and choose Enable Windows Zero Configuration (WZC) to activate it. Then follow the steps below to configure WZC. 1. Double click the wireless connection icon on the system tray. Vigor N61 User’s Guide...
  • Page 30 2. Next, the following window will appear. 3. Click Change Advanced Settings and the following window will be shown. Press the Wireless Networks tab. Vigor N61 User’s Guide...
  • Page 31 WPA-PSK as the Network Authentication and TKIP as the Data encryption. Then, type the encryption key characters. The type for Network Authentication, Data encryption and key must be the same values as configured in the AP that you want to connect. Vigor N61 User’s Guide...
  • Page 32 5. Press the Authentication tab. Choose the EAP type which is the same as configured in the 6. After click OK, the wireless station can associate with the AP. 7. Open Wireless Connection window. Please choose “Tom” (as an example) and click Connect. Vigor N61 User’s Guide...
  • Page 33 8. The wireless connection starts. Please wait for it completes. 9. The wireless connection has been established. Vigor N61 User’s Guide...
