Page 1 Ram Truck 2 0 1 0 O W N E R ’ S M A N U A L...
Page 2: Introduction
TABLE OF CONTENTS SECTION ............3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 4: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 6 INTRODUCTION 5...
Page 7: Van Conversions/Campers
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 8: Vehicle Identification Number
VEHICLE IDENTIFICATION NUMBER The Vehicle Identification Number (VIN) is found on the left front corner of the instrument panel, visible through the windshield. This number also appears on the Auto- mobile Information Disclosure Label affixed to a window on your vehicle, the vehicle registration and title. Vehicle Identification Number NOTE: It is illegal to remove or alter the VIN.
Page 10: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) — If Equipped ......12 Key FOB .
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Open Window Feature — If Equipped ......23 Using The Panic Alarm .
Page 12 Seat Belt Extender ..... 51 Driver And Right Front Passenger Supplemental Restraint System (SRS) – Airbag ......52 Airbag System Components .
Page 13: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Key Fob with Remote Keyless Entry (RKE) — If Equipped Your vehicle uses a keyless ignition system. This system consists of a Key Fob with Remote Keyless Entry (RKE) transmitter and a Wireless Ignition Node (WIN) with integral ignition switch.
Page 14: Key Fob
Wireless Ignition Node (WIN) 1 — OFF 2 — ACC (ACCESSORY) 3 — ON 4 — START THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. It also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob.
Page 15: Removing Key Fob From Ignition
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch at the top of the Key Fob sideways with your thumb and then pull the key out with your other hand. Emergency Key Removal NOTE: You can insert the double-sided emergency key into the lock cylinder with either side up.
Page 16: Key-In-Ignition Reminder
(EVIC)/Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” for further information. WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured.
Page 17 16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system uses a Key Fob with a factory-mated Remote Keyless Entry (RKE) transmitter and Wireless Ignition Node (WIN) to prevent unauthorized vehicle operation. Therefore, only Key Fobs that are programmed to the vehicle can be used to start and operate the vehicle.
Page 18: Replacement Keys
Replacement Keys NOTE: Only Key Fobs that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once a Key Fob is programmed to a vehicle, it cannot be programmed to any other vehicle. CAUTION! Always remove the Sentry Keys from the vehicle and lock all doors when leaving the vehicle unat- tended.
Page 19: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information The Sentry Key system complies with FCC rules Part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •...
Page 20: To Disarm The System
NOTE: If the Vehicle Security Light stays on continu- ously during vehicle operation, have the system checked by an authorized dealer. To Disarm the System Use the RKE transmitter to unlock the door. If something has triggered the system in your absence, the horn will sound three times when you unlock the doors and the Vehicle Security Light will flash for 30 seconds.
Page 21: Remote Keyless Entry (Rke) - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • The front courtesy overhead console and door cour- tesy lights do not turn off if the dimmer control is in the interior lights ON position (extreme right posi- tion). • The illuminated entry system will not operate if the dimmer control is in the extreme left position.
Page 22: To Unlock The Doors
To Unlock the Doors Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door, or twice within five seconds to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on.
Page 23: To Lock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Flash Lamps with Remote Key Lock This feature will cause the turn signal lights to flash when the doors are locked or unlocked with the RKE transmit- ter. This feature can be turned on or turned off. To change the current setting, proceed as follows: •...
Page 24: Remote Open Window Feature - If
Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the RKE transmitter. This feature can be turned on or turned off. To change the current setting, proceed as follows: •...
Page 25: Using The Panic Alarm
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using the Panic Alarm To turn the Panic Alarm feature ON or OFF, press and hold the PANIC button on the RKE transmitter for at least one second and release. When the Panic Alarm is on, the headlights and park lights will flash, the horn will pulse on and off, and the interior lights will turn on.
Page 26: General Information
1. With the RKE transmitter buttons facing down, use a flat blade to pry the two halves of the RKE transmitter apart. Make sure not to damage the seal during removal. 2. Remove and replace the battery. Avoid touching the new battery with your fingers.
Page 27: How To Use Remote Start
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Use Remote Start All of the following conditions must be met before the engine will remote start: • Shift lever in PARK • Doors closed • Hood closed • HAZARD switch off •...
Page 28 • Remote Start Aborted - Hood Ajar • Remote Start Aborted - Fuel Low • Remote Start Aborted - System Fault The EVIC message stays active until the ignition is turned to the ON/RUN position. To Enter Remote Start Mode Press and release the REMOTE START button on the RKE transmitter twice, within five sec- onds.
Page 29: Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Exit Remote Start Mode and Drive the Vehicle Before the end of the 15-minute cycle, press and release the UNLOCK button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm System (if equipped).
Page 30: Power Door Locks - If Equipped
Front doors may be opened with the inside door handle without lifting the lock plunger. Doors locked before closing will remain locked when closed. The emergency key will unlock the driver door lock on your vehicle. WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors when you drive as well as when you park and leave the vehicle.
Page 31 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you press the power door LOCK switch while the Key Fob is in the ignition, and any front door is open, the power locks will not operate. This prevents you from accidentally locking your Key Fob in the vehicle.
Page 32 7. To reactivate this feature, repeat the above steps. 8. If a chime is not heard, program mode was canceled before the feature could be disabled. If necessary, repeat the above procedure. Auto Unlock Doors — If Equipped This feature unlocks all of the doors of the vehicle when either front door is opened.
Page 33: Child Protection Door Lock
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 8. If a chime is not heard, the program mode was canceled before the feature could be changed. If neces- sary, repeat the above procedure. Child Protection Door Lock To provide a safer environment for children riding in the rear seat, the rear doors (if equipped) of your vehicle have the child protection door lock system.
Page 34 To use the system, open each rear door, use a flat blade screwdriver (or emergency key) and rotate the dial to engage and disengage the child protection locks. When the system on a door is engaged, that door can only be opened by using the outside door handle even if the inside door lock is in the unlocked position.
Page 35: Windows
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS Power Windows – If Equipped Power Window Switches 1 – Left Front 3 – Right Rear 2 – Right Front 4 – Left Rear The control on the left front door panel has UP-DOWN switches that give you fingertip control of all power windows.
Page 36: Auto Down
WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured. Don’t leave the key in the ignition. A child could operate power windows, other controls, or move the vehicle.
Page 37 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE rough road conditions may trigger the auto reverse function unexpectedly during auto closure. If this happens, pull the switch lightly to the first detent and hold to close the window manually. • If the Auto-Up function is lost, reset the Auto-Up function by running the window all the way up and then hold the switch in the full up position for two seconds.
Page 38: Wind Buffeting
Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down or in partially open positions. This is a normal occurrence and can be minimized.
Page 39: Lap/Shoulder Belts
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Advanced Front Airbags have a multistage inflator design. This allows the airbag to have different rates of inflation based on the severity and type of collision. Please pay close attention to the information in this section.
Page 40 collision the belt will lock and reduce the risk of you striking the inside of the vehicle or being thrown out. WARNING! • It is dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 41 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. The seat belt latch plate is above the back of the front seat, next to your arm in the rear seat. Grasp the latch plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to allow the belt to go around your lap.
Page 42 WARNING! • A belt buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. • A belt that is too loose will not protect you properly.
Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
Page 44 5. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the belt. 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position.
Page 45 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Regular Cab Front Center Three Point Belt 1. The front center seat belt on the Regular Cab may be disconnected to open up utilization of the storage areas behind the front seats. The black latch plate can be detached from the black keyed seat belt buckle located on the inboard side of the passenger seat.
Page 46 WARNING! • If the black latch and black buckle are not prop- erly connected when the seat belt is used by an occupant, the seat belt will not be able to provide proper restraint and will increase the risk of injury in a collision.
Page 47 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In Use Position WARNING! • If the black latch and black buckle are not prop- erly connected when the seat belt is used by an occupant, the seat belt will not be able to provide proper restraint and will increase the risk of injury in a collision.
Page 48: Adjustable Upper Shoulder Belt Anchorage
Adjustable Upper Shoulder Belt Anchorage In the front row outboard seats, the shoulder belt can be adjusted upward or downward to help position the belt away from your neck. Squeeze the anchorage button lo- cated on the upper belt guide to release the anchorage, and then move it up or down to the position that fits you best.
Page 49: Automatic Locking Retractor (Alr) Mode - If Equipped
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A lap belt worn too loose or too high is dangerous. • A belt worn too loose can allow you to slip down and under the belt in a collision. •...
Page 50: Seat Belts In Passenger Seating Positions
Seat Belts In Passenger Seating Positions The seat belts in the passenger seating positions are equipped with Automatic Locking Retractors (ALR) which are used to secure a child restraint system. For additional information refer to “Installing Child Re- straints Using the Vehicle Seat Belt” under the “Child Restraints”...
Page 51: Enhanced Seat Belt Use Reminder System (Beltalert )
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The pretensioners are triggered by the Occupant Re- straint Controller (ORC). Like the airbags, the pretension- ers are single use items. A deployed pretensioner or a deployed airbag must be replaced immediately. Enhanced Seat Belt Use Reminder System (BeltAlert ) If the driver’s seat belt has not been buckled within...
Page 52: Seat Belts And Pregnant Women
NOTE: Watch for the Seat Belt Reminder Light to turn on while the seat belt retracts and turn off while re- buckling the seat belt. 4. Turn the ignition switch to the LOCK position. A single chime will sound to signify that you have success- fully completed the programming.
Page 53: Driver And Right Front Passenger Supplemental Restraint System (Srs) - Airbag
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use the seat belt extender when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 54: Airbag System Components
The Advanced Front Airbags have a multistage inflator design. This allows the airbag to have different rates of inflation based on the severity and type of collision. This vehicle may be equipped with driver and/or front passenger seat track position sensors that may adjust the inflation rate of the Advanced Front Airbags based upon seat position.
Page 55: Advanced Front Airbag Features
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Supplemental Side Airbag Inflatable Curtains (SABIC) • Front and Side Impact Sensors • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, and Seat Track Position Sensors Advanced Front Airbag Features The Advanced Front Airbag system has multistage driver and front passenger airbags.
Page 56 WARNING! (Continued) • Do not mount any accessories to the knee bolster such as alarm lights, stereos, citizen band radios, etc. Supplemental Side Airbag Inflatable Curtain (SABIC) — If Equipped SABIC airbags may offer side-impact protection to front and rear seat outboard occupants in addition to that provided by the body structure.
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • If your vehicle is equipped with left and right Supplemental Side Airbag Inflatable Curtain (SABIC), do not stack luggage or other cargo up high enough to block the location of the SABIC. The area where the SABIC is located should re- main free from any obstructions.
Page 58 Children that are not big enough to wear the vehicle seat belt properly (see Section on Child Restraints) should be secured in the rear seat in child restraints or belt- positioning booster seats. Older children who do not use child restraints or belt-positioning booster seats should ride properly buckled up in the rear seat.
Page 59: Airbag Deployment Sensors And Controls
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions, the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 60 The Advanced Front Airbags will not deploy in all frontal collisions, including some that may produce substantial vehicle damage — for example, some pole collisions, truck underrides, and angle offset collisions. On the other hand, depending on the type and location of impact, Advanced Front Airbags may deploy in crashes with little vehicle front-end damage but that produce a severe initial deceleration.
Page 61 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE It also includes diagnostics that will illuminate the instru- ment cluster Airbag Warning Light if a malfunction is noted that could affect the airbag system. The diagnostics also record the nature of the malfunction. WARNING! Ignoring the Airbag Warning Light in your instru- ment panel could mean you won’t have the airbags to...
Page 62 A quantity of non-toxic gas is generated to inflate the side curtain airbag. The inflating side curtain airbag pushes the outside edge of the headliner out of the way and covers the window. The airbag inflates in about 30 ms (about one-quarter of the time that it takes to blink your eyes) with enough force to injure you if you are not belted and seated properly, or if items are positioned in the area...
Page 63 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Front and/or side airbags will not deploy in all collisions. This does not mean something is wrong with the airbag system. If you do have a collision which deploys the airbags, any or all of the following may occur: •...
Page 64 Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
Page 65: Event Data Recorder (Edr)
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light You will want to have the airbags ready to inflate for your protection in a collision. While the airbag system is designed to be mainte- nance free, if any of the following occurs, have an authorized dealer service the system immediately.
Page 66 2. Under certain circumstances, EDR data may not be recorded (e.g., loss of battery power). In conjunction with other data gathered during a com- plete accident investigation, the electronic data may be used by Chrysler Group LLC and others to learn more about the possible causes of crashes and associated injuries in order to assess and improve vehicle perfor- mance.
Page 67: Child Restraints
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Requested by police under a legal warrant. 4. Otherwise required by law. Data parameters that are recorded: • Diagnostic trouble code(s) and warning light status for electronically-controlled safety systems, including the airbag system •...
Page 68 There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Use the restraint that is correct for your child. Infants and Small Children • Safety experts recommend rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg).
Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE in the vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system. Refer to “LATCH- Child Seat Anchorage System (Lower Anchors and Tether for Children)”. • The belt-positioning booster seat is for children weigh- ing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly.
Page 70 • Make sure that the child is upright in the seat. • The lap portion should be low on the hips and as snug as possible. • Check belt fit periodically. A child’s squirming or slouching can move the belt out of position. •...
Page 71 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE around, and insert the latch plate into the buckle again. If you still can’t make the child restraint secure, try a different seating position. • Buckle the child into the seat according to the child restraint manufacturer’s directions.
Page 72 Quad Cab /Mega Cab /Crew Cab Rear Outboard Seats Driver Side Child restraint systems having attachments designed to connect to the lower anchorages are now available. Child restraints having tether straps and hooks for connection to the seat back tether anchorage have been available for THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 some time.
Page 73 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE reach. If the buckled seat belt interferes with the child restraint installation, instead of tucking the seat belt behind the child restraint, route the seat belt through the child restraint belt path and then buckle it. This should stow the seat belt out of the reach of an inquisitive child.
Page 74 We urge you to carefully follow the directions of the manufacturer when installing your child restraint. Many, but not all, restraint systems will be equipped with separate straps on each side, with each having a hook or connector, and a means for adjusting the tension in the strap.
Page 75 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE then allow the belt to retract into the retractor. For additional information on ALR, refer to “Automatic Locking Mode”. To install a child restraint, first, pull enough of the seat belt webbing from the retractor to route it through the belt path of the child restraint and slide the latch plate into the buckle.
Page 76 Tether Anchorage Points at the Right and Center Front Seat (Regular Cab - All Seats) 1. Place the child restraint on the seat and adjust the tether strap so that it will reach over the seat back under the head restraint to the tether anchor directly behind the seat.
Page 77 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Multiple Child Restraint Installation Sequence (Quad Cab /Crew Cab/Mega Cab - Rear Seats) Quad Cab /Mega Cab 1. Obtain tether straps by raising the head restraints and reaching between the rear glass and rear seat. The tether strap may be retained with an elastic band.
Page 78 4. Route each tether strap to the anchor behind the center seat, and attach the hooks to the metal ring. 5. Place a child restraint on the center rear seat and adjust the tether strap so that it will reach under the head restraint to the tether anchor directly behind the seat and to the anchor directly behind the right seat.
Page 79 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Crew Cab 1. The tether straps loops are located between the rear glass and the rear seat. There is a tether strap loop located behind each seating position. You can gain access to the center seating position tether strap loop by raising the head restraint and reaching between the rear glass and rear seat.
Page 80: Engine Break-In Recommendations
3. Pass each tether strap hook under the head restraint and through the loop of webbing behind the child seat. 4. Route each tether strap through the tether strap loop behind the center seat, and attach the hooks to the anchor located directly behind the center rear seat located under a plastic cover.
Page 81: Safety Tips
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the recommended viscosity and quality grades refer to “Maintenance Procedures” in “Maintaining Your Ve- hicle”. NON-DETERGENT OR STRAIGHT MINERAL OILS MUST NEVER BE USED. A new engine may consume some oil during its first few thousand miles (kilometers) of operation.
Page 82: Exhaust Gas
Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area.
Page 83: Safety Checks You Should Make Inside The Vehicle
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside the Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
Page 84 WARNING! Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious per- sonal injury. • Always make sure that floor mats are properly attached to the floor mat fasteners. • Never place or install floor mats or other floor coverings in the vehicle that cannot be properly secured to prevent them from moving and inter- fering with the pedals or the ability to control the...
Page 85: Periodic Safety Checks You Should Make Outside The Vehicle
84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside the Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and sidewall for cuts and cracks.
Page 86: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......91 Inside Day/Night Mirror ....91 Automatic Dimming Mirror —...
Page 87 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjustable Head Restraints ... . . 101 Eight-Way Power Seats — If Equipped ..102 Power Lumbar — If Equipped ... 103 Heated Seats —...
Page 88 Multifunction Lever ....118 Windshield Wipers And Washers ..120 Windshield Wipers ....120 Windshield Washers .
Page 89 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Parkview On Or Off — Without Navigation/Multimedia Radio ... 140 Overhead Console — If Equipped ..140 Courtesy/Reading Lights .
Page 90 Power Inverter — If Equipped ... . 156 Cupholders ......158 Front Instrument Panel Cupholders —...
Page 91 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fold Flat Load Floor — If Equipped ..170 Rambox — If Equipped ....172 Rambox Integrated Box Side Storage Bins .
Page 92: Mirrors
MIRRORS Inside Day/Night Mirror Headlight glare can be reduced by moving the small control lever under the mirror to the night position (lever flipped toward the rear of vehicle). Adjusting Rearview Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 The mirror should be adjusted with the lever set in the day position (lever flipped toward the windshield).
Page 93: Automatic Dimming Mirror - If Equipped
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 94: Outside Mirrors Folding Feature
WARNING! Vehicles and other objects seen in a passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the passenger side convex mirror.
Page 95: Power Mirrors - If Equipped
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors — If Equipped The controls for the power mirrors are located on the driver’s door trim panel. Power Mirror Controls The power mirror controls consist of mirror select but- tons and a four-way mirror control switch. Power Mirror Controls 1 —...
Page 96: Heated Mirrors - If Equipped
To adjust a mirror, press the mirror select button for the mirror that you want to adjust. Using the mirror control switch, press on any of the four arrows for the direction that you want the mirror to move. Power Mirror Movement UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Heated Mirrors —...
Page 97: Equipped
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirror — If Equipped Illuminated vanity mirrors are located on each sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights will turn on auto- matically.
Page 98: Trailer Towing Mirrors - If Equipped
Slide-On-Rod Extender Trailer Towing Mirrors — If Equipped These mirrors are designed with an adjustable mirror head to provide a greater vision range when towing extra-wide loads. To change position inboard or out- board, the mirror head should be rotated (flipped in or out).
Page 99: Uconnect™ Phone - If Equipped
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE A small blindspot mirror is located next to main mirror and can be adjusted separately. Blindspot Mirror Uconnect™ Phone — IF EQUIPPED Uconnect™ Phone is a hands-free system that allows you to use voice commands to dial a phone number stored in your cellular phone.
Page 100: Seats
SEATS Seats are a primary part of the Occupant Restraint System of the vehicle. They need to be used properly for safe operation of the vehicle. WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seri- ously injured or killed.
Page 101: Manual Reclining Seats - If Equipped
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust any seat only while the vehicle is parked.
Page 102: Adjustable Head Restraints
WARNING! • Actuating the recliner handle will allow the seat- back to swing (dump) forward on manual recliner seats. Do not stand or lean in front of the seat while actuating the handle. The seatback may swing forward and hit you causing injury. This dump feature allows access to the storage bin behind the seat.
Page 103: Eight-Way Power Seats - If Equipped
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To lower the head restraint, push in the button and then push down on the head restraint. Head Restraints Eight-Way Power Seats — If Equipped The power seat controls are on the outboard side of the front seat cushions.
Page 104: Power Lumbar - If Equipped
CAUTION! Do not put anything under a power seat. It may cause damage to the seat or the seat controls. Power Lumbar — If Equipped The lumbar controls are located on the outboard side of the seat cushion. The lumbar support can be increased by pressing the front of the switch and decreased by press- ing the back of the switch.
Page 105 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After turning the ignition ON, you can choose from High, Low, or Off heat settings. Amber indicator lights in each switch indicate the level of heat in use. Two indicator lights will illuminate for High, one for Low, and none for Off.
Page 106: Ventilated Seats - If Equipped
WARNING! (Continued) • Do not place anything on the seat that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Ventilated Seats — If Equipped Located in the seat cushion and seatback are small fans that draw the air from around the occupant and exhaust it underneath the seat and into the passenger compart- ment.
Page 107: 40-20-40 Front Bench Seat - If Equipped
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 40-20-40 Front Bench Seat — If Equipped The seat is divided into three segments. The outboard seat portions are each 40% of the total width of the seat. The back of the center portion (20%) easily folds down to provide an armrest/center storage compartment (if equipped).
Page 108: Setting Memory Positions And Linking Rke
Keyless Entry (RKE) transmitters can also be pro- grammed to recall the same positions when the UN- LOCK button is pressed. NOTE: The power lumbar option is not programmable with driver memory seats. Your vehicle was delivered with two RKE transmitters. One or both RKE transmitters can be linked to either memory position.
Page 109: Memory Position Recall
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE performed within 10 seconds if you desire to also use a RKE transmitter to recall memory positions. 8. Turn the ignition OFF and remove the key. 9. Press and release the LOCK button on one of the RKE transmitters.
Page 110: To Disable A Rke Transmitter Linked To Memory
NOTE: A chime sound may be heard if setting memory was inhibited for any reason. To Disable a RKE Transmitter Linked to Memory 1. Turn the ignition switch to the OFF position and remove the key. 2. Press and release the memory SET button located on the driver’s seat.
Page 111: Driver Easy Exit And Easy Entry Control
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1 or 2. Continued seat travel beyond the new stored position will indicate the self-limiting control has been reset. Driver Easy Exit and Easy Entry Control This additional feature provides automatic driver’s seat positioning which will enhance driver mobility into and out of the vehicle.
Page 112 Hood Release 2. Reach into the opening beneath the center of the hood and push the safety latch lever from right to left to release it, before raising the hood. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Safety Latch (1500 Series Shown) CAUTION! To prevent possible damage, do not slam the hood to close it.
Page 113: Lights
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.
Page 114: Headlights
To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth. To remove road dirt, wash with a mild soap solution fol- lowed by rinsing. CAUTION! Do not use abrasive cleaning components, solvents, steel wool or other abrasive materials to clean the lenses.
Page 115: Headlight Delay
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 90 seconds after you turn the ignition switch to the OFF position. To turn the automatic headlights off, turn the headlight switch out of the AUTO position. NOTE: The engine must be running before the head- lights will turn on in the Automatic Mode.
Page 116: Interior Lights
Fog Light Switch The fog lights will operate only when the parking lights are on or when the vehicle headlights are on low beam. An indicator light located in the instrument cluster will illuminate when the fog lights are on. The fog lights will UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 turn off when the switch is pushed a second time, when the headlight switch is rotated to the off position, or the...
Page 117 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The brightness of the instrument panel lighting can be regulated by rotating the dimmer control right (brighter) or left (dimmer). When the headlights are on you can supplement the brightness of the odometer, trip odom- eter, radio and overhead console by rotating the control to the right until you hear a click.
Page 118: Cargo Light
Cargo Light The cargo lights are turned on by pressing on the cargo button. Cargo Light Switch The cargo lights will also turn on for approximately 30 seconds when a RKE transmitter UNLOCK button is pressed, as part of the Illuminated Entry feature. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Lights-on Reminder If the headlights, parking lights, or cargo lights are left on...
Page 119: Daytime Running Lights (Drl) (Canada Only And Fleet Vehicles)
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Daytime Running Lights (DRL) (Canada Only and Fleet Vehicles) The headlights on your vehicle will illuminate when the engine is started and the transmission is in any gear except PARK. This provides a constant Lights ON condition until the ignition is turned OFF.
Page 120 NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb. If an indicator fails to light when the lever is moved, it would suggest that the indicator bulb is defective.
Page 121: Windshield Wipers And Washers
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Windshield Wipers The wipers and washers are operated by a switch in the multifunction lever. Turn the end of the handle to select the desired wiper speed. Windshield Wiper/Washer Switch Intermittent Wiper System The intermittent feature of this system was designed for use when weather conditions make a single wiping cycle,...
Page 122: Windshield Washers
Windshield Washers To use the windshield washer, push the washer knob, located on the end of the multifunction lever, inward to the second detent. Washer fluid will be sprayed until the washer knob is released from this position. If the washer knob is depressed while in the delay range, the wiper will operate for several seconds after the washer knob is released.
Page 123: Heated Steering Wheel - If Equipped
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pull the lever toward the steering wheel to unlock the steering column. With one hand firmly on the steering wheel, move the steering column up or down, as desired. Release the lever to lock the steering column firmly in place.
Page 124 The heated steering wheel switch is located on the switch bank below the climate controls. Press the switch to turn on the heated steering wheel. The light on the switch will illuminate to indicate the steering wheel heater is on. Pressing the switch a second time will turn off the heated steering wheel and light indicator.
Page 125: Driver Adjustable Pedals - If Equipped
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE DRIVER ADJUSTABLE PEDALS — IF EQUIPPED The power adjustable accelerator and brake pedals allow the driver to establish a comfortable position relative to the steering wheel and pedals. Adjustment 1. Position the driver’s seat so that you are at least 10 in (25.4 cm) away from the airbag, located in the center of the steering wheel.
Page 126: Electronic Speed Control - If Equipped
CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls. Pedal travel may become lim- ited if movement is stopped by an obstruction in the adjustable pedal’s path.
Page 127: To Activate
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE System can be reactivated by pushing the Electronic Speed Control ON/OFF button and resetting the desired vehicle set speed. To Activate Push the ON/OFF button (located in the end of the lever) once and the cruise indicator light (located in the mes- sage window of the cluster) will illuminate showing that the Electronic Speed Control system is on.
Page 128: To Resume Speed
speed memory. Pushing the ON/OFF button to the OFF position or turning OFF the ignition erases the set speed memory. To Resume Speed To resume a previously set speed, raise the Electronic Speed Control lever (RESUME ACCEL) upwards and release. Resume can be used at any speed above 30 mph (50 km/h).
Page 129: To Accelerate For Passing
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Accelerate for Passing Press the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. NOTE: The Electronic Speed Control system maintains speed up and down hills. A slight speed change on moderate hills is normal.
Page 130: Parksense Sensors
ParkSense will remember the last system state (enabled or disabled) from the last ignition cycle when the ignition is changed to the RUN/ON position. ParkSense can be active only when the shift lever is in REVERSE. If ParkSense is enabled at this shift lever position, the system will be active until the vehicle speed is increased to approximately 11 mph (18 km/h) or above.
Page 131 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The ParkSense Warning Display is located in the instru- ment cluster’s EVIC display. It provides both visual and audible warnings to indicate the distance between the rear bumper and the detected obstacle. Rear ParkSense Display When the vehicle is in REVERSE, the warning display will turn ON indicating the system status.
Page 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Rear Park Assist Disabled Slow Tone ParkSense will indicate a detected obstacle by showing three solid arcs and will produce a ⁄ second tone. As the vehicle moves closer to the object the EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
Page 133 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fast Tone Continuous Tone The vehicle is close to the obstacle when the EVIC display shows one flashing arc and sounds a continuous tone.
Page 134 WARNING DISPLAY DISTANCES DISPLAY MESSAGE REAR CORNERS Park Assist ON Warning Object Detected Warning Object Detected Warning Object Detected 27.5 in (70 cm) Warning Object Detected 25.5 in (65 cm) Warning Object Detected 19.7 in (50 cm) Warning Object Detected 15.7 in (40 cm) Warning Object Detected 11.8 in (30 cm)
Page 135: Enable/Disable Parksense
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Enable/Disable ParkSense ParkSense can be enabled and disabled with a switch located in the switch bank of the instrument panel or through the Customer-Programmable Features section of the EVIC. The available choices are: OFF, Sound Only, or Sound and Display.
Page 136: Service Parksense
and the system is disabled, the EVIC will display the “PARK ASSIST DISABLED” message for as long as the vehicle is in REVERSE. The switch LED will be ON when ParkSense is disabled or defective. The switch LED will be OFF when Park- Sense is enabled.
Page 137 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When you turn ParkSense off, the instrument cluster will display “PARK ASSIST DISABLED.” Further- more, once you turn ParkSense off, it remains off until you turn it on again, even if you cycle the ignition key.
Page 138 CAUTION! • The ParkSense Rear Park Assist system is only a parking aid and it is unable to recognize every obstacle, including small obstacles. Parking curbs might be temporarily detected or not detected at all. Obstacles located above or below the Park- Sense sensors will not be detected when they are in close proximity.
Page 139: Parkview Rear Back Up Camera - If Equipped
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Before using the ParkSense system, it is strongly recommended that the ball mount and hitch ball assembly is disconnected from the vehicle when the vehicle is not used for towing. Failure to do so can result in injury or damage to vehicles or obstacles because the hitch ball will be much closer to the obstacle than the rear bumper when the warning display turns on...
Page 140: Turning Parkview On Or Off - With Navigation/Multimedia Radio
WARNING! Drivers must be careful when backing up even when using the ParkView Rear Back Up Camera. Always check carefully behind your vehicle, and be sure to check for pedestrians, animals, other vehicles, ob- structions, or blind spots before backing up. You are responsible for the safety of your surroundings and must continue to pay attention while backing up.
Page 141: Turning Parkview On Or Off - Without Navigation/Multimedia Radio
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Enable or disable the rear camera feature by selecting “enable rear camera in reverse” soft key. 5. Press the “save” soft key. 6. When the vehicle is shifted into REVERSE, an image of the rear of the vehicle will appear with a caution note to “check entire surroundings”...
Page 142: Courtesy/Reading Lights
Overhead Console Courtesy/Reading Lights Both lights in the overhead console and rear passenger compartment will illuminate as courtesy lights when a door is opened, when the dimmer control is rotated to the courtesy light position (full right position), or when the UNLOCK button is pressed on the Remote Keyless Entry UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 (RKE) transmitter, if equipped.
Page 143: Garage Door Opener - If Equipped
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Passenger Courtesy/Reading Light NOTE: The courtesy/reading lights will remain on until the switch is pressed a second time, so be sure they have been turned off before leaving the vehicle. If the interior lights are left on after the ignition is turned OFF, they will extinguish after 15 minutes.
Page 144 HomeLink Buttons NOTE: HomeLink is disabled when the Vehicle Secu- rity Alarm is active. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 WARNING! • Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people, pets or other objects are in the path of the door or gate.
Page 145: Programming Homelink
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming HomeLink Before You Begin If you have not trained any of the HomeLink buttons, erase all channels before you begin training. To do this, press and hold the two outside buttons for 20 seconds.
Page 146 NOTE: Some gate operators and garage door openers may require you to replace Step 3 with procedures noted in the “Gate Operator/Canadian Programming” section. 4. Press and hold the just-trained HomeLink button. If the channel has been trained, the EVIC display will now state “CHANNEL # TRANSMIT”.
Page 147: Gate Operator/Canadian Programming
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Firmly press and release the LEARN or TRAINING button. The name and color of the button may vary by manufacturer. NOTE: You have 30 seconds in which to initiate the next step after the LEARN button has been pressed. 7.
Page 148: Using Homelink
successfully accepted the frequency signal. The EVIC display will change from “CHANNEL # TRAINING” to “CHANNEL # TRAINED.” If you unplugged the device for training, plug it back in at this time. Then proceed with Step 4 under “Programming HomeLink ” earlier in this section. Using HomeLink To operate, press and release the programmed HomeLink button.
Page 149: Troubleshooting Tips
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Troubleshooting Tips If you are having trouble programming HomeLink , here are some of the most common solutions: • Replace the battery in the original transmitter. • Press the LEARN button on the garage door opener to complete the training for rolling code.
Page 150: Power Sunroof - If Equipped
POWER SUNROOF — IF EQUIPPED The power sunroof switch is located on the overhead console between the courtesy/reading lights. Power Sunroof Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 NOTE: The Power Accessory Delay feature will allow the power sunroof to operate for approximately ten minutes after the ignition is turned OFF or until a front door is opened.
Page 151: Open Sunroof - Express Mode
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not allow small children to operate the sun- roof. Never allow your fingers, other body parts, or any object to project through the sunroof opening. Injury may result. Open Sunroof — Express Mode Momentarily pressing the switch rearward will activate the Express Open Feature, causing the sunroof to open automatically.
Page 152: Venting Sunroof - Express
Venting Sunroof — Express Press and release the Vent button and the sunroof will open to the vent position. This is called “Express Vent”, and will occur regardless of sunroof position. During Express Vent operation, any movement of the switch will stop the sunroof.
Page 153 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE A key symbol indicates that the key must be in the ON/RUN or ACC positions for the outlet to provide power. The battery symbol indicates that the outlet is connected to the battery, and can provide power at all times.
Page 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Power Outlet — Upper Lid Power Outlet — Rear Center Console • Rear of the center console storage compartment — The key symbol indicates that this outlet can supply Quad Cab or Crew Cab. power when the key is in the ON/RUN or ACC posi- tions.
Page 155 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. •...
Page 156: Cigar Lighter And Ash Receiver - If Equipped
CIGAR LIGHTER AND ASH RECEIVER — IF EQUIPPED A removable ash receiver and cigar lighter are available. For vehicles with a bench seat the cupholder tray can be used to hold the ash receiver. Ash Receiver and Cigar Lighter (Bench Seat) 1 —...
Page 157: Power Inverter - If Equipped
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED A 115 Volt (150 Watts Maximum) outlet is located on the center stack of the instrument panel, to the right of the radio. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 Watts.
Page 158 NOTE: • When the power inverter switch is pressed, there will be a delay of approximately one second before the power inverter status indicator turns on. The status indicator of the AC power inverter indicates whether the inverter is producing AC power. •...
Page 159: Cupholders
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Front Instrument Panel Cupholders — (40–20–40 Seats) The cupholders are located in the pull-out tray at the bottom of the center stack. The pull-out tray must be secured when opened. To secure the tray push down until it “clicks”.
Page 160: Front Instrument Panel Cupholders - Floor Mounted Shifter
Front Instrument Panel Cupholders — Floor Mounted Shifter For vehicles equipped with bucket seats and a floor mounted shifter there are two cupholders located in the floor console. Cupholders (Floor Mounted Shifter) UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 Rear Cupholder — Quad Cab Quad Cab vehicles may be equipped with a rear cup- holder that consists of two cup wells for rear passenger convenience.
Page 161: Rear Cupholder - Crew Cab
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Cupholder — Crew Cab Crew Cab vehicles are equipped with rear cupholders located in the center armrest. Crew Cab Rear Armrest Cupholder STORAGE Glove Box Storage The glove box is located on the passenger side of the instrument panel and features both an upper and lower storage area.
Page 162 To open the upper glove box push upward on the handle release. The glove box door will automatically open. Upper Glove Box UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 To open the lower glove box, pull on the handle to release the latch and lower the door.
Page 163: Door Storage
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Door Storage Front Door Storage — If Equipped Storage areas and bottle holders (drivers side only) are located in the door trim panels. Front Door Storage Rear Door Storage — Crew Cab Storage compartments are located in both the driver and passenger door trim panels.
Page 164: Center Storage Compartment - If Equipped
Center Storage Compartment — If Equipped The center storage compartment is located between the driver and passenger seats. The storage compartment provides an armrest and contains both and upper and lower storage area. Center Storage Compartment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 WARNING! •...
Page 165 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pull on the upper handle on the front of the armrest to raise the cover. The upper storage area contains a 12 Volt power outlet that can be used to power small electrical devices, refer to “Electrical Power Outlets”...
Page 166: Second Row In-Floor Storage Bin - If Equipped
Second Row In-Floor Storage Bin — If Equipped In-floor storage bins are located in front of the second row seats and can be used for extra storage. The storage bins have removable liners that can be easily removed for cleaning. In-Floor Storage Bin And Latch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 To open in-floor storage bin, lift upward on the handle of...
Page 167: Seatback Storage
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seatback Storage Located in the back of both the driver and passenger front seats are pockets that can be used for storage. Drivers Side Seatback Storage Storage (Regular Cab) The storage bin is located behind the front seats and runs the length of the cab.
Page 168: Storage And Seats (Crew Cab)
Storage and Seats (Crew Cab) The Crew Cab models provide additional storage under the rear seats. Lift the seats to access the storage com- partment. To open the storage compartments, lift upward on the handle of the latch and open the lid. Crew Cab Storage UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 CAUTION!
Page 169: Plastic Grocery Bag Retainers (Regular Cab Models)
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Plastic Grocery Bag Retainers (Regular Cab Models) Retainer hooks which will hold plastic grocery bag handles are built into the back panel of the cab, behind the rear seat. Grocery Bag Hooks REAR WINDOW FEATURES Rear Window Defroster The rear window defroster button is located on the climate control panel.
Page 170: Power Sliding Rear Window - If Equipped
CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
Page 171: Manual Sliding Rear Window - If Equipped
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Sliding Rear Window — If Equipped A locking device in the center of the window helps to prevent entry from the rear of the vehicle. Squeeze the lock to release the window. FOLD FLAT LOAD FLOOR —...
Page 172 2. Grasp the knob on the load floor and lift the knob until the load floor unfolds into position. Load Floor In Open Position 3. Reverse the procedure to store the load floor. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Positioning the Load Floor for Storage Access Under the Seat 1.
Page 173: Rambox - If Equipped
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not drive with the load floor in the up position. When stopping fast or in an accident, the load floor could move to the down position causing serious injury. Load Floor Securing Straps 4.
Page 174 RamBox Cargo Storage Bins UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 CAUTION! Failure to follow the following items could cause damage to the vehicle: • Assure that all cargo inside the storage bins is properly secured. • Do not exceed cargo weight rating of 150 lb (68 kg) per bin.
Page 175 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To open a storage bin, press and release the button located on the lid. The RamBox lid will open upward to allow hand access. Lift the lid to fully open. RamBox Pushbutton and Lock The interior of the RamBox will automatically illumi- nate when the lid is opened.
Page 176 CAUTION! Leaving the lid open for extended periods of time could cause the vehicle battery to discharge. If the lid is required to stay open for extended periods of time, it is recommended that the bin lights be turned off manually using the on/off switch.
Page 177: Rambox Safety Warning
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE RamBox Safety Warning Carefully follow these warnings to help prevent personal injury or damage to your vehicle: WARNING! • Always close the storage bin covers when your vehicle is unattended. • Do not allow children to have access to the storage bins.
Page 178: Bed Extender - If Equipped
NOTE: In the event of an individual being locked inside the storage bin, the storage bin cover can be opened from inside of the bin by pulling on the glow-in-the-dark lever attached to the storage bin cover latching mechanism. Bed Extender — If Equipped The bed extender has three functional positions: •...
Page 179 178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. With the side gates open, position the extender fully forward in the bed against the front panel. Storage Position 3. Rotate the side gates closed allowing the outboard ends to be positioned in front of the cargo tie down loops. Cargo Tie Down Loop...
Page 180 4. Rotate the center handle horizontally to secure the side gates in the closed position. Side Gates Closed 5. Lock the center handle using the vehicle key to secure the panel into place and assist against theft. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 Divider Position The divider position is intended for managing your cargo and assisting in keeping cargo from moving around the...
Page 181 180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To install the bed extender into a divider position per- form the following: 1. Make sure the center handle is unlocked using the vehicle key and rotate the center handle vertically to release the extender side gates. Center Handle and Lock 1 —...
Page 182 2. With the side gates open, position the extender so the outboard ends align with the intended slots in the sides of the bed. Aligning Gate To Slots 3. Rotate the side gates closed so that the outboard ends are secured into the intended slots of the bed. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 4.
Page 183 182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Extender Position The extender position allows you to load the bed of the truck beyond the tail gate. The bed extender will add an additional 15 in (38 cm) in the back of the truck when additional cargo room is needed.
Page 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Extender Installation Locking Tab 4. Rotate the handles to the horizontal position to secure into place.
Page 185: Bed Rail Tie-Down System
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! To reduce the risk of potential injury or property damage: • Cargo must be secured. • Do not exceed cargo load rating of your vehicle. • Secure all loads to truck utilizing cargo tie downs. •...
Page 186 Adjustable Cleats Each cleat must be located and tightened down in one of the detents, along either rail, in order to keep cargo properly secure. To move the cleat to any position on the rail, turn the nut counterclockwise, approximately three turns. Then pull UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 out on the cleat and slide it to the detent nearest the desired location.
Page 187: Slide-In Campers
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To remove the cleats from the utility rail, remove the end cap by pushing up on the locking tab, located on the bottom of the end cap. Slide the cleat off the end of the rail.
Page 188: Disconnecting The Rear Camera - If Equipped
Disconnecting the Rear Camera — If Equipped 1. Open the tailgate to access the rear camera connector bracket located on the rear sill. Connector Bracket 2. Remove the connector bracket from the sill by press- ing inward in the locking tab. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 Locking Tab 3.
Page 189: Removing The Tailgate
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Connect the tailgate plug (provided in the glove box) to the tailgate wiring harness to ensure that the terminals do not corrode. 6. Tape the tailgate harness and bracket against the forward-facing surface of the tailgate. This will prevent damaging the connector and bracket when storing or reinstalling the tailgate.
Page 190: Locking Tailgate - If Equipped
NOTE: Do not carry the tailgate loose in the truck pickup box. WARNING! To avoid inhaling carbon monoxide, which is deadly, the exhaust system on vehicles equipped with “Cap or Slide-In Campers” should extend beyond the overhanging camper compartment and be free of leaks.
Page 192 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....195 Switch Bank Button Description ... 196 Upper Switch Bank .
Page 193 192 UNDERSTANDING YOUR INSTRUMENT PANEL Customer-Programmable Features (System Setup) ......233 Media Center 730N/430 (RER/REN/RBZ) — AM/FM Stereo Radio And CD/DVD/HDD/ NAV —...
Page 194 Universal Consumer Interface (UCI) 0.5 — If Equipped ......265 Connecting The iPod ....265 Using This Feature .
Page 195 194 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Operation And Cellular Phones ..278 Climate Controls ..... . 278 Manual Heating And Air Conditioning System .
Page 196: Instrument Panel Features
INSTRUMENT PANEL FEATURES 1 — Headlight Switch 2 — Instrument Cluster 3 — Radio 4 — Upper Switch Bank 5 — Upper Glove Compartment 6 — Lower Glove Compartment UNDERSTANDING YOUR INSTRUMENT PANEL 195 7 — 115v Power Inverter Outlet 8 —...
Page 197: Switch Bank Button Description
196 UNDERSTANDING YOUR INSTRUMENT PANEL SWITCH BANK BUTTON DESCRIPTION Upper Switch Bank The upper switch bank is located on the center of the instrument panel. 1. TOW/HAUL Refer to “Starting And Operating” for more information. 2. ESP OFF Refer to “Starting And Operating” for more information. 3.
Page 198 1. HEATED SEATS Refer to “Understanding The Features Of Your Vehicle” for more information. UNDERSTANDING YOUR INSTRUMENT PANEL 197 2. VENTILATED SEATS Refer to “Understanding The Features Of Your Vehicle” for more information. 3. HEATED STEERING WHEEL Refer to “Understanding The Features Of Your Vehicle” for more information.
Page 199: Instrument Cluster - Base
198 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — BASE...
Page 200: Instrument Cluster - Premium
UNDERSTANDING YOUR INSTRUMENT PANEL 199 INSTRUMENT CLUSTER — PREMIUM...
Page 201: Instrument Cluster Descriptions
200 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Tachometer The tachometer indicates engine speed in Revolutions Per Minute (RPM). CAUTION! Do not operate the engine with the tachometer pointer at high RPM for extended periods. Engine damage may occur. 2.
Page 202 CAUTION! Driving with a hot engine cooling system could damage your vehicle. If temperature gauge reads “H” pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range. If the pointer remains on the “H”...
Page 203 202 UNDERSTANDING YOUR INSTRUMENT PANEL rotate at the same speed. Low range provides a greater gear reduction ratio to provide increased torque at the wheels. For further information on four-wheel drive operation and proper use, refer to “Four-Wheel Drive Operation — If Equipped”...
Page 204 9. 4WD Auto Indicator The 4WD auto indicator will be illuminated whenever the four-wheel drive mode is auto- matically engaged. 10. SERV (Service) 4WD The SERV 4WD light monitors the electric shift four-wheel drive system. If the SERV 4WD light stays on or comes on during driving, it means that the four-wheel drive system is not functioning properly and that service is required.
Page 205 204 UNDERSTANDING YOUR INSTRUMENT PANEL 14. Oil Pressure Gauge The pointer should always indicate some oil pressure when the engine is running. A continuous high or low reading under normal driving conditions may indicate a lubrication system malfunction. Immediate service should be obtained from an authorized dealer.
Page 206 The two trip odometers show individual trip mileage. To switch from odometer to trip odometers, press and release the TRIP ODOMETER button. To reset a trip odometer, display the desired trip odom- eter to be reset then push and hold the button for approximately two seconds until the display resets.
Page 207 206 UNDERSTANDING YOUR INSTRUMENT PANEL depending on driving habits and vehicle usage. Press the Odometer / Trip Odometer / ECO (Fuel Saver Indicator) button to change the display from odometer to either of the two trip odometer settings or the “ECO” display. If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a loose gascap indicator...
Page 208 turn off the message temporarily, press and release the Trip Odometer button on the instrument cluster. To reset the oil change indicator system (after performing the scheduled maintenance), refer to the following proce- dure: 1. Turn the ignition switch to the ON position (Do not start the engine).
Page 209 208 UNDERSTANDING YOUR INSTRUMENT PANEL 18. Shift Lever Indicator The Shift Lever Indicator is self-contained within the instrument cluster. It displays the gear position of the automatic transmission. NOTE: In vehicles with 4.7L or 5.7L engines, the highest available transmission gear is displayed in the lower right corner of the Electronic Vehicle Information Center (EVIC) whenever the Electronic Range Select (ERS) fea- ture is active.
Page 210 cycling operation is controlled by the engine control module. Post-heat operation can run for several minutes, and then the electrical system and voltmeter needle will stabilize. 22. Cargo Light The cargo light will illuminate when the cargo light is activated by pressing the cargo light button on the headlight switch.
Page 211 210 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level condi- tions. The vehicle should have service performed, and the brake fluid level checked. If brake failure is indicated, immediate repair is neces- sary.
Page 212 Do not operate the vehicle until the cause is corrected. This light does not indicate how much oil is in the engine. The engine oil level must be checked under the hood. For vehicles equipped with a premium cluster this indi- cator will display in the Electronic Vehicle Information Center (EVIC).
Page 213 212 UNDERSTANDING YOUR INSTRUMENT PANEL Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated.
Page 214 26. Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic (OBDII) system which monitors the emissions and engine control sys- tem. If the vehicle is ready for emissions testing, the light will come on when the ignition is first turned on and remain on, as a bulb check, until the engine is started.
Page 215 214 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal operating conditions. This can cause a fire if you drive slowly or park over flammable substances such as dry plants or wood or cardboard, etc. This could result in death or serious injury to the driver, occu- pants or others.
Page 216 30. Transmission Temperature Warning Light This light indicates that there is excessive trans- mission fluid temperature that might occur with severe usage such as trailer towing. It may also occur when operating the vehicle in a high torque converter slip condition, such as 4-wheel-drive operation (e.g., snow plowing, off- road operation).
Page 217 216 UNDERSTANDING YOUR INSTRUMENT PANEL unbuckled, the seat belt reminder light will flash or remain on continuously. Refer to “Occupant Restraints” in “Things To Know Before Starting Your Vehicle” for further information. 32. Charging System Light This light shows the status of the electrical charg- ing system.
Page 218: Electronic Vehicle Information Center (Evic) - If Equipped
For vehicles equipped with a premium cluster this indi- cator will display in the Electronic Vehicle Information Center (EVIC). Refer to ”Electronic Vehicle Information Center (EVIC) — If Equipped” for further information. WARNING! If a warning light remains on the system may not be working and you will not have the benefit of ESP or BAS.
Page 219 218 UNDERSTANDING YOUR INSTRUMENT PANEL This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel. The EVIC consists of the following: • System Status display • Vehicle information warning message displays •...
Page 220: Evic Displays
Steering wheel EVIC control button, as it appears on the right side of the steering wheel. Press and release the SELECT button for access to main menus, sub menus or to select a personal setting in the system setup menu. Press the BACK button to scroll back to a previous menu or sub menu.
Page 221 220 UNDERSTANDING YOUR INSTRUMENT PANEL • Lights On • Keyfob Battery Low • ECO (Fuel Saver Indicator) — If Equipped • Door(s) Ajar (with a single chime, if vehicle is in motion) • Wrong Key • Damaged Key • Key not programmed •...
Page 222 • Remote start aborted — Fuel low • Remote start disabled — System fault • Remote start disabled — Turn key • Remote start active — Key to Run • Remote Start Disabled — Start Vehicle to Reset • Remote Start Active — Insert Key and Turn to RUN •...
Page 223 222 UNDERSTANDING YOUR INSTRUMENT PANEL Do not operate the vehicle until the cause is corrected. This light does not show how much oil is in the engine. The engine oil level must be checked under the hood. • Charging System Light This light shows the status of the electrical charg- ing system.
Page 224 If the light remains lit with the engine running your vehicle, will usually be drivable, however, see an autho- rized dealer for service as soon as possible. If the light is flashing when the engine is running, immediate service is required and you may experience reduced performance, an elevated/rough idle or engine stall and your vehicle may require towing.
Page 225 224 UNDERSTANDING YOUR INSTRUMENT PANEL with the engine running. If the ESP/BAS Warning Light comes on continuously with the engine running, a mal- function has been detected in either the ESP or the BAS system. If this light remains on after several ignition cycles and the vehicle has been driven several miles at speeds greater than 30 mph (48 km/h), see an authorized dealer as soon as possible.
Page 226 to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the Malfunction Indicator Light (MIL). Oil Change Due Your vehicle is equipped with an engine oil change indicator system.
Page 227: Fuel Economy / Fuel Saver Mode / Distance
226 UNDERSTANDING YOUR INSTRUMENT PANEL Fuel Economy / Fuel Saver Mode / Distance To Empty (DTE) — If Equipped Average Fuel Economy Shows the average fuel economy since the last reset. When the fuel economy is reset, the display will read “0” or show dashes for two seconds.
Page 228: Trip Functions
Distance To Empty (DTE) Distance To Empty (DTE) Shows the estimated distance that can be traveled with the fuel remaining in the tank. This estimated distance is determined by a weighted average of the instantaneous and average fuel economy, according to the current fuel tank level. DTE cannot be reset through the RETURN button.
Page 229: Vehicle Info
228 UNDERSTANDING YOUR INSTRUMENT PANEL • Trip B Shows the total distance traveled for Trip B since the last reset. • Elapsed Time Shows the total elapsed time of travel since the last reset when the ignition switch is in the ACC position. Elapsed time will increment when the ignition switch is in the ON or START position.
Page 230: Tire Psi
• Trailer Brake — If Equipped Displays trailer brake output power and trailer brake status indicator. Tire PSI Press and release the UP or DOWN button until “Tire PSI” displays in the EVIC and press the SELECT button. This will display the Tire Pressure Monitor System (shows the current pressure of all four road tires).
Page 231: Units
230 UNDERSTANDING YOUR INSTRUMENT PANEL to “Tires-General Information/Tire Inflation Pres- sures” in “Starting And Operating” for additional information. • Your system can be set to display pressure units in PSI, kPa, or BAR. Units Press and release the UP or DOWN button until “Units” displays in the EVIC and press the SELECT button.
Page 232 temperature sensor caused by the snowplow. In addi- tion, on vehicles equipped with Automatic Tempera- ture Control (ATC), it is suggested that the interior cabin temperature be manually controlled should the system not perform as desired while in automatic mode. Both the outside temperature display and ATC operation will return to normal when the snowplow is removed.
Page 233 232 UNDERSTANDING YOUR INSTRUMENT PANEL 5. Complete one or more 360–degree turns (in an area free from large metal or metallic objects) until the “CAL” indicator turns off. The compass will now function normally. Compass Variance Compass Variance is the difference between Magnetic North and Geographic North.
Page 234: Customer-Programmable Features
3. Press the DOWN button until the “Compass Variance” message is displayed in the EVIC, then press the SELECT button. The last variance zone number displays in the EVIC. 4. Press and release the SELECT button until the proper variance zone is selected, according to the map. 5.
Page 235 234 UNDERSTANDING YOUR INSTRUMENT PANEL the feature showing the system has been activated or the check-mark is removed, showing the system has been deactivated. Park Assist System The Rear Park Assist system will scan for objects behind the vehicle when the transmission is in the REVERSE and the vehicle speed is less than 11 mph (18 km/h).
Page 236 Press is selected, you must press the RKE transmitter UNLOCK button twice to unlock the passenger’s doors. When Unlock All Doors On 1st Press is selected, all of the doors will unlock on the first press of the RKE transmitter UNLOCK button. To make your selection, scroll up or down until the preferred setting is high- lighted, then press and release the SELECT button until a check-mark appears next to the setting, showing that...
Page 237 236 UNDERSTANDING YOUR INSTRUMENT PANEL SELECT button until a check-mark appears next to the feature showing the system has been activated or the check-mark is removed, showing the system has been deactivated. Horn With Remote Lock When this feature is selected, a short horn sound will occur when the RKE transmitter LOCK button is pressed.
Page 238 your selection, press and release the SELECT button until a check-mark appears next to the feature showing the system has been activated or the check-mark is removed, showing the system has been deactivated. Wiper Mode — If Equipped When this feature is selected, the system will automati- cally activate the windshield wipers if it senses moisture on the windshield.
Page 239 238 UNDERSTANDING YOUR INSTRUMENT PANEL Key-Off Power Delay When this feature is selected, the power window switches, radio, hands-free system (if equipped), DVD video system (if equipped), power sunroof (if equipped), and power outlets will remain active for up to 10 minutes after the ignition switch is turned OFF.
Page 240: Media Center 730N/430 (Rer/Ren/Rbz) - Am/Fm Stereo Radio And Cd/Dvd/Hdd/Nav - If Equipped
Compass Variance Refer to “Compass Display” for more information. Calibrate Compass Refer to “Compass Display” for more information. MEDIA CENTER 730N/430 (RER/REN/RBZ) — AM/FM STEREO RADIO AND CD/DVD/HDD/NAV — IF EQUIPPED NOTE: The sales code is located on the lower right side of the unit’s faceplate.
Page 241 240 UNDERSTANDING YOUR INSTRUMENT PANEL 3. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed.
Page 242: Clock Setting Procedure - Rer/Ren Radio
Changing the Time Zone 1. Turn on the radio. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen.
Page 243 242 UNDERSTANDING YOUR INSTRUMENT PANEL displayed. To move the minute backward, touch the screen where the word “Min” with the arrow pointing downward is displayed. 6. To save the new time setting, touch the screen where the word “Save” is displayed. Changing Daylight Savings Time When selected, this feature will display the time of day in daylight savings time.
Page 244: Media Center 130 (Res) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
3. Touch the screen where “User Clock” is displayed, the clock setting menu will appear on the screen. 4. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen. 5.
Page 245 244 UNDERSTANDING YOUR INSTRUMENT PANEL Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping.
Page 246 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM or FM frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 247: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
246 UNDERSTANDING YOUR INSTRUMENT PANEL SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button. The symbol SET 1 will now show in the display window.
Page 248 • This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up.
Page 249 248 UNDERSTANDING YOUR INSTRUMENT PANEL If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF.
Page 250: Notes On Playing Mp3 Files
Notes on Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions. Supported Media (Disc Types) The MP3 file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
Page 251 250 UNDERSTANDING YOUR INSTRUMENT PANEL Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of multisession for CD audio or MP3 playback may result in longer disc loading times. Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files.
Page 252: Operation Instructions - Auxiliary Mode
Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files. Loading times for playback of MP3 files may be affected by the following: •...
Page 253: Media Center 130 (Res/Rsc) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
252 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 130 (RES/RSC) — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) AND SIRIUS RADIO NOTE: The radio sales code is located on the lower right side of the radio faceplate. Media Center 130 (RES/RSC) Operating Instructions —...
Page 254 to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection. Holding either button will bypass stations without stopping until you release it. Voice Command System (Radio) — If Equipped Refer to “Voice Command”...
Page 255 254 UNDERSTANDING YOUR INSTRUMENT PANEL 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side TUNE/ SCROLL control knob. Press the TUNE/SCROLL control knob to save time change.
Page 256 Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the treble tones.
Page 257 256 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button to select the following format types: 16-Digit Character Program Type No program type or undefined Adult Hits Classical Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies Program Type Personality Display Public...
Page 258 By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station.
Page 259: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
258 UNDERSTANDING YOUR INSTRUMENT PANEL display window. Each button can be set for SET 1 and SET 2 in both AM and FM. This allows a total of 12 AM and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by pressing the pushbutton twice.
Page 260 If you insert a disc with the ignition ON/RUN and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will show the track number, and index time in minutes and seconds.
Page 261: Notes On Playing Mp3 Files
260 UNDERSTANDING YOUR INSTRUMENT PANEL the current selection. Pressing and holding the SEEK button will allow faster scrolling through the tracks in CD and MP3 modes. TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or...
Page 262 Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
Page 263 262 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
Page 264: List Button (Cd Mode For Mp3 Play)
Loading times for playback of MP3 files may be affected by the following: • Media - CD-RW media may take longer to load than CD-R media • Medium formats - Multisession discs may take longer to load than non-multisession discs •...
Page 265: Operating Instructions - Uconnect™ Phone (If Equipped)
264 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack which allows the user to plug in a portable device such as an MP3 player or cassette player and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 266: Universal Consumer Interface (Uci) 0.5 - If Equipped
UNIVERSAL CONSUMER INTERFACE (UCI) 0.5 — IF EQUIPPED NOTE: This section is for sales code RES and REQ/ REL/RET radios only with uconnect™. For sales code RER, RBZ, REN, REP, REW, RB2 or REZ touch-screen radio UCI feature, refer to the separate RER, REN, RBZ, RB2 or REZ User’s Manual.
Page 267: Using This Feature
266 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • It may be necessary to remove the connector pin protection cap from the 16–pin connector port, prior to connecting the cable. • If the iPod battery is completely discharged, it may not communicate with the UCI system until a mini- mum charge is attained.
Page 268 • Turning it counterclockwise (backward) by one click, during the first two seconds of the track, will jump to the previous track in the list. Turning this button at any other time in the track, will jump to the beginning of the current track. •...
Page 269: List Or Browse Mode
268 UNDERSTANDING YOUR INSTRUMENT PANEL During Scan mode, pressing the << SEEK and SEEK >> buttons will select the previous and next tracks. • RND button (available on sales code RES radio only): Pressing this button toggles between Shuffle ON and Shuffle OFF modes for the iPod .
Page 270 • Preset 5 – Audiobooks • Preset 6 – Podcasts • Pressing a PRESET button will display the current list on the top line and the first item in that list on the second line. • To Exit List mode without selecting a track, press the same PRESET button again to go back to Play mode.
Page 271: Uconnect™ Multimedia (Satellite Radio) - If Equipped (Ren/Rer/Rbz/Res Radios Only)
270 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect™ Multimedia (SATELLITE RADIO) — IF EQUIPPED (REN/RER/RBZ/RES RADIOS ONLY) Satellite radio uses direct satellite-to-receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius Satellite Radio. This service offers over 130 channels of music, sports, news, entertainment, and programming for chil- dren, directly from its satellites and broadcasting studios.
Page 272: Selecting Uconnect™ Multimedia (Satellite) Mode
Sirius ID number will display. The Sirius ID number display will time out in two minutes. Press any button on the radio to exit this screen. ESN/SID Access With REN/RER/RBZ Radios While in SAT mode, press the MENU button on the radio faceplate.
Page 273: Operating Instructions - Uconnect
272 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Uconnect™ Multimedia (Satellite) Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. SEEK Buttons Press and release the SEEK buttons to search for the next channel in Satellite mode.
Page 274 MUSIC TYPE Button Pressing this button once will turn on the Music Type mode for five seconds. Pressing the MUSIC TYPE button or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected.
Page 275: Operating Instructions - Uconnect™ Phone (If Equipped)
274 UNDERSTANDING YOUR INSTRUMENT PANEL pushbutton memory. The channels stored in SET 2 memory can be selected by pressing the pushbutton twice. Every time a preset button is used, a corresponding button number will display. Buttons 1 - 6 These buttons tune the radio to the channels that you commit to pushbutton memory (12 Satellite stations).
Page 276 • Nine different medias to choose from in each screen (AM, FM, Sirius Radio, DVD1, DVD2, Hard Disc Drive (HDD), AUX in radio, AUX1, AUX2) The LCD screen is located in the overhead compartment console. Overhead Video Screen UNDERSTANDING YOUR INSTRUMENT PANEL 275 VES™...
Page 277: Remote Sound System Controls - If Equipped
276 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. Remote Sound System Controls (Back View Of Steering Wheel) The right hand control is a rocker type switch with a pushbutton in the center.
Page 278: Cd Player
The button located in the center of the left hand control will tune to the next pre-set station that you have programmed in the radio pre-set pushbuttons. CD Player Pressing the top of the switch once will go to the next track on the CD.
Page 279: Radio Operation And Cellular Phones
278 UNDERSTANDING YOUR INSTRUMENT PANEL oversized, or have protection encoding. Try a known good disc before considering disc player service. RADIO OPERATION AND CELLULAR PHONES Under certain conditions, the operation of a cellular phone in your vehicle can cause erratic or noisy perfor- mance from your radio.
Page 280 1 – Front Blower 4 – DEFROST Mode 2 – Temperature Control 5 – Air Conditioning (A/C) 3 – MODE Control 6 – RECIRCULATION Control UNDERSTANDING YOUR INSTRUMENT PANEL 279 Front Blower Control There are four blower speeds. Use this control to regulate the amount of air forced through the system in any mode you select.
Page 281 280 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control Use this control to regulate the tem- perature of the air inside the passenger compartment. Rotating the knob coun- terclockwise, from top center into the blue area of the scale, indicates cooler temperatures. Rotating the knob clock- wise, into the red area, indicates warmer temperatures.
Page 282 NOTE: There is a difference in temperature (in any conditions other than full cold or full hot), between the upper and lower outlets for added comfort. The warmer air goes to the floor outlets. This feature gives improved comfort during sunny but cool conditions. Floor Mode Air is directed through the floor outlets with a small amount through the defrost and side window...
Page 283 282 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • If the RECIRCULATION button is pressed when the system is in Mix or Defrost mode the Recirculation LED indicator will flash three times and then turn off to indicate Recirculation mode is not allowed. •...
Page 284: Automatic Temperature Control (Atc) - If Equipped
Air Conditioning Operation Push this button to engage the Air Conditioning (A/C). A LED will illu- minate when the A/C system is engaged. MAX A/C For maximum cooling, when MAX A/C is selected the A/C is turned on automatically and the air is recircu- lated.
Page 285 284 UNDERSTANDING YOUR INSTRUMENT PANEL • When occupants in the vehicle select an Auto mode operation, Auto blower operation is set by using rotary knobs on the control unit and a comfort temperature setting by using the temperature up and down but- tons.
Page 286 Automatic Operation 1. Position the MODE control knob to the Auto position on the Automatic Temperature Control (ATC) Panel. 2. Position the BLOWER control knob in the Auto posi- tion on the ATC Panel. 3. Next, adjust the temperature you would like the system to maintain by adjusting the driver and front passenger temperature buttons.
Page 287 286 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Operation This system offers a full complement of manual override features. NOTE: Each of these features operate independently from each other. If any one feature is controlled manually, the temperature doors will continue to operate automati- cally.
Page 288 Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Air comes from the floor, defrost and side window demist outlets. This mode works best in cold or snowy conditions.
Page 289: Summer Operation
288 UNDERSTANDING YOUR INSTRUMENT PANEL Recirculation mode should only be used temporarily. The recirculation LED will illuminate on the blower control knob when this button is selected. Push the button a second time to turn off the Recirculation mode LED and allow outside air into the vehicle.
Page 290: Vacation/Storage
Vacation/Storage Any time you store your vehicle or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in fresh air with the blower setting in high. This will ensure adequate system lubrication to minimize the possibility of compressor damage when the system is started again.
Page 291: Operating Tips
290 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips...
Page 292 STARTING AND OPERATING CONTENTS Starting Procedures ....297 Normal Starting ..... 297 Automatic Transmission .
Page 293 292 STARTING AND OPERATING Transfer Case Position Indicator Light ..320 Electronically Shifted Transfer Case (Four-Position Switch) – If Equipped ..320 Shifting Procedure ....324 Electronically Shifted Transfer Case (Five-Position Switch) –...
Page 294 Off-Road Driving Tips ....357 After Driving Off-Road ....357 Winch Usage (Power Wagon Only) —...
Page 295 294 STARTING AND OPERATING Tire Terminology And Definitions ..401 Tire Loading And Tire Pressure ..402 Tires — General Information ... . . 406 Tire Pressure .
Page 296 Fuel Requirements ..... 428 3.7L And 4.7L Engine ....428 5.7L Engine .
Page 297 296 STARTING AND OPERATING Trailer Towing ......441 Common Towing Definitions ... . 441 Trailer Hitch Classification .
Page 298: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belt. The starter should not be operated for more than 15- second intervals. Waiting a few seconds between such intervals will protect the starter from overheating. WARNING! Never leave children alone in a vehicle.
Page 299: If Engine Fails To Start
298 STARTING AND OPERATING If Engine Fails To Start If the engine fails to start after you have followed the “Normal Starting” procedure, it may be flooded. Push the accelerator pedal all the way to the floor and hold it there while cranking the engine.
Page 300: After Starting
accelerator pedal pushed all the way to the floor. Release the accelerator pedal and the key fob once the engine is running smoothly. If the engine shows no sign of starting after two 15- second periods of cranking with the accelerator pedal held to the floor, the “Normal Starting”...
Page 301: Automatic Transmission
300 STARTING AND OPERATING WARNING! Remember to disconnect the cord before driving. Damage to the 110-115 Volt electrical cord could cause electrocution. AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop.
Page 302: Key Ignition Park Interlock
Key Ignition Park Interlock This vehicle is equipped with a Key Ignition Park Inter- lock which requires the shift lever to be placed in PARK prior to turning the key fob to the LOCK position. The key fob can only be removed from the ignition switch when the ignition is in the LOCK position and once removed the shift lever is locked in PARK.
Page 303 302 STARTING AND OPERATING 5. Using a screwdriver or other suitable tool, press and hold the override tab through the access port (ringed circle) on the bottom of the steering column. Interlock Manual Override 6. Move the shift lever into the NEUTRAL position. 7.
Page 304: Four-Speed Automatic Transmission - If Equipped
Interlock Manual Override 5. Move the shift lever into the NEUTRAL position. 6. The vehicle may then be started in NEUTRAL. 7. Reinstall the override cover. STARTING AND OPERATING 303 Four–Speed Automatic Transmission – If Equipped NOTE: Under extremely cold temperatures (-6°F (-21°C) and when in DRIVE, transmission operation may be briefly limited to only second gear operation.
Page 305 304 STARTING AND OPERATING PARK This range supplements the parking brake by locking the transmission. The engine can be started in this range. Never use PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range. Always apply the parking brake first, then place the shift lever in the PARK position.
Page 306 WARNING! (Continued) • Unintended movement of a vehicle could injure those in and near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running. Before exiting a vehicle, you should always shift the transmission into PARK, remove the key fob from the ignition, and apply the parking brake.
Page 307 306 STARTING AND OPERATING 1 (First) This range is for hard pulling at low speeds in mud, sand, snow, or on steep grades. Begins and stays in low gear with no upshift. Provides engine compression braking at low speeds. Overdrive Operation The Overdrive automatic transmission contains an elec- tronically controlled fourth gear (OVERDRIVE).
Page 308 The transmission will downshift from OVERDRIVE to DRIVE if the accelerator pedal is fully pressed at vehicle speeds above approximately 35 mph (56 km/h). When To Use TOW/HAUL Mode When driving in hilly areas, towing a trailer, carrying a heavy load, etc., and frequent transmission shifting oc- curs, press the TOW/HAUL switch.
Page 309: Five-Speed Automatic Transmission - If Equipped
308 STARTING AND OPERATING Transmission Limp Home Mode Transmission function is monitored for abnormal condi- tions. If a condition is detected that could result in transmission damage, the Transmission Limp Home Mode will be engaged. In this mode, the transmission will operate (when in DRIVE) in second gear only.
Page 310 STARTING AND OPERATING 309 equipped). You must press the brake pedal to move the shift lever out of the PARK position. To drive, move the shift lever from PARK or NEUTRAL to the DRIVE position. Pull the shift lever toward you when shifting into REVERSE or PARK, or when shifting out of PARK.
Page 311 310 STARTING AND OPERATING Console Shift Lever On vehicles equipped with 4.7L or 5.7L engines, use of ERS (or TOW/HAUL mode) also enables an additional underdrive gear which is not normally used during through-gear accelerations. This additional gear im- proves vehicle performance and cooling capability when towing a trailer on certain grades.
Page 312 WARNING! Do not downshift for additional engine braking on a slippery surface. The drive wheels could lose their grip and the vehicle could skid. Screen Display Actual Gear(s) Allowed * Applies to vehicles equipped with 4.7L and 5.7L engines only. NOTE: To select the proper gear position for maximum deceleration (engine braking), hold the shift lever/switch in the (-) position and hold it there.
Page 313 312 STARTING AND OPERATING WARNING! • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage. • Your vehicle could move and injure you and others if it is not completely in PARK.
Page 314 WARNING! (Continued) • Unintended movement of a vehicle could injure those in and near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running. Before exiting a vehicle, you should always shift the transmission into PARK, remove the key fob from the ignition, and apply the parking brake.
Page 315 314 STARTING AND OPERATING • the engine coolant (antifreeze) has reached normal operating temperature; • vehicle speed is above approximately 30 mph (48 km/h); • the TOW/HAUL switch has not been activated; • transmission reached temperature. NOTE: If the vehicle is started in extremely cold tem- peratures, the transmission may not shift into Overdrive and will automatically select the most desirable gear for operation at this temperature.
Page 316 TOW/HAUL Switch Shifts into Overdrive (fourth gear) are allowed during steady cruise (for improved fuel economy) and automatic closed-throttle downshifts to third gear are performed (for improved braking) when driving conditions warrant. The “TOW/HAUL Indicator Light” will illuminate in the instrument cluster to indicate when the switch has been STARTING AND OPERATING 315 activated.
Page 317: Four-Wheel Drive Operation - If Equipped
316 STARTING AND OPERATING torque converter clutch is not engaged, it may seem as if the transmission is not shifting into Overdrive when cold. This is normal. Pressing the TOW/HAUL switch when the transmission is sufficiently warm will dem- onstrate that the transmission is able to shift into and out of Overdrive.
Page 318 moving the shift lever to the desired positions. The 4H and 4L positions are intended for loose, slippery road surfaces only. Driving in the 4H and 4L positions on dry, hard surfaced roads may cause increased tire wear and damage to the driveline components. The “Transfer Case Position Indicator Light”...
Page 319 318 STARTING AND OPERATING WARNING! You or others could be injured if you leave the vehicle unattended with the transfer case in the NEUTRAL position without first fully engaging the parking brake. The transfer case NEUTRAL position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to move regardless of the transmission position.
Page 320: Shifting Procedure - Manually Shifted Transfer Case
Shifting Procedure – Manually Shifted Transfer Case 2H ⇔ 4H Shifting between 2H and 4H can be made with the vehicle stopped or in motion. If the vehicle is in motion, shifts can be made up to 55 mph (88 km/h). With the vehicle in motion, the transfer case will engage/ disengage faster if you momentarily release the accelera- tor pedal after completing the shift.
Page 321: Starting And Operating Transfer Case Position Indicator Light
320 STARTING AND OPERATING Transfer Case Position Indicator Light The “Transfer Case Position Indicator Light” in the instrument cluster is used to alert the driver that the front axle is fully engaged and all four wheels are driving. Electronically Shifted Transfer Case (Four-Position Switch) –...
Page 322 • Neutral (NEUTRAL) This electronically shifted transfer case is designed to be driven in the two-wheel drive position (2WD) for normal street and highway conditions on dry, hard surfaced roads. When additional traction is required, the transfer case 4WD LOCK and 4WD LOW positions can be used to lock the front and rear driveshafts together, forcing the front and rear wheels to rotate at the same speed.
Page 323 322 STARTING AND OPERATING 3. When the shift is complete, the indicator light for the selected position will stop flashing and remain ON. If One Or More Shift Conditions Are Not Met: 1. The indicator light for the current position will remain 2.
Page 324 When operating your vehicle in 4WD LOW, the engine speed is approximately three times that of the 2WD or 4WD LOCK positions at a given road speed. Take care not to overspeed the engine and do not exceed 25 mph (40 km/h).
Page 325: Shifting Procedure
324 STARTING AND OPERATING 4WD LOCK Four-Wheel Drive Lock Range - This range locks the front and rear driveshafts together forcing the front and rear wheels to rotate at the same speed. This range provides additional traction for loose, slippery road surfaces only. 4WD LOW Four-Wheel Drive Low Range - This range provides low speed four-wheel drive.
Page 326 When the shift is complete, the position indicator light for the selected position will stop flashing and remain 2WD⇔ 4WD LOCK Rotate the 4WD control switch to the desired position. Shifts between 2WD and 4WD LOCK can be done with the vehicle stopped or in motion.
Page 327: Electronically Shifted Transfer Case (Five-Position Switch) - If Equipped
326 STARTING AND OPERATING 3. While still rolling, rotate the transfer case control switch to the desired position. 4. After the desired position indicator light is ON (not flashing), shift the transmission back into gear. Alternate Procedure 1. Bring the vehicle to a complete stop. 2.
Page 328 Transfer Case Switch (Five–Position) This electronically shifted transfer case provides five mode positions: • Two-wheel drive high range (2WD) • Four-wheel drive automatic range (4WD AUTO) • Four-wheel drive lock range (4WD LOCK) STARTING AND OPERATING 327 • Four-wheel drive low range (4WD LOW) •...
Page 329 328 STARTING AND OPERATING the front and rear driveshafts together forcing the front and rear wheels to rotate at the same speed. This is accomplished by rotating the 4WD Control Switch to the desired position. Refer to “Shifting Procedure” for spe- cific shifting instructions.
Page 330 2. The newly selected position indicator light will con- tinue to flash. 3. The transfer case will not shift. NOTE: Before retrying a selection, make certain that all the necessary requirements for selecting a new transfer case position have been met. To retry the selection, turn the control knob back to the current position, wait five seconds, and retry selection.
Page 331 330 STARTING AND OPERATING Proper operation of four-wheel drive vehicles depends on tires of equal size, type and circumference on each wheel. Any difference in tire size can cause damage to the transfer case. Because four-wheel drive provides improved traction, there is a tendency to exceed safe turning and stopping speeds.
Page 332: Shifting Procedure
4WD LOW Four-Wheel Drive Low Range - This range provides low speed four-wheel drive. Locks the front and rear drive- shafts together forcing the front and rear wheels to rotate at the same speed. Additional traction and maximum pulling power for loose, slippery road surfaces only. Do not exceed 25 mph (40 km/h).
Page 333 332 STARTING AND OPERATING the vehicle in motion, the transfer case will engage/ disengage faster if you momentarily release the accelera- tor pedal after turning the control switch. If the vehicle is stopped, the ignition switch must be in the ON position with the engine either running or OFF.
Page 334: Axle Locker System (2500 Models Only) - If Equipped
NOTE: If Steps 1 or 2 of either the Preferred or Alternate Procedure are not satisfied prior to attempting the shift or if they no longer are being met while the shift attempt is in process, the desired position indicator light will flash continuously while the original position indicator light is ON, until all requirements have been met.
Page 335 334 STARTING AND OPERATING The locking axles are controlled by the axle locker switch. The switch has three positions, AXLE UNLOCK, REAR LOCK, and FRONT/REAR LOCK. Under normal driv- ing conditions, the switch should be left in the AXLE UNLOCK position. In the AXLE UNLOCK position, the front and rear axles are unlocked.
Page 336: Safe Off-Road Driving - Power Wagon Only
WARNING! Do not use the locked axle position for normal driving. A locked front axle is intended for off-road driving only. Locking the front axle during on-road driving will reduce the steering ability. This could cause an accident and you may be seriously injured. To lock the front axle;...
Page 337 336 STARTING AND OPERATING (ORV) trails or recreation areas. You should always tread lightly and only use established roads, trails or ORV recreational areas. The National Forest Service, Bureau of Land Management or local Department of Natural Re- sources are a wealth of information and usually have maps with marked trails.
Page 338 CAUTION! The door sill height is 25 inches. Water may intrude into the interior of the vehicle at greater depths. Simultaneous Brake And Throttle Operation Many off-road driving conditions require the simulta- neous use of the brake and throttle (two footed driving). When climbing rocks, logs, or other stepped objects, using light brake pressure with light throttle will keep the vehicle from jerking or lurching.
Page 339: Driving In Snow, Mud And Sand
338 STARTING AND OPERATING WARNING! Always wear your seat belt and firmly tie down cargo. Unsecured cargo can become projectiles in an off-road situation. When To Use Low Range When driving off-road, shift into 4L (Low Range) for additional traction or to improve handling and control on slippery or difficult terrain.
Page 340 CAUTION! On icy or slippery roads, do not downshift at high engine RPMs or vehicle speeds because engine brak- ing may cause skidding and loss of control. • Mud – Deep mud creates a great deal of suction around the tires and is very difficult to get through. You should use 4L (Low Range) with a gear low enough to maintain your momentum without shifting.
Page 341: Crossing Obstacles (Rocks And Other High Points)
340 STARTING AND OPERATING CAUTION! Reduced tire pressures may cause tire unseating and total loss of air pressure. To reduce the risk of tire unseating, while at a reduced tire pressure, reduce your speed and avoid sharp turns or abrupt maneu- vers.
Page 342 Crossing Large Rocks When approaching large rocks, choose a path which ensures you drive over the largest with your tires. This will lift your undercarriage over the obstacle. The tread of the tire is tougher and thicker than the side wall and is designed to take the abuse.
Page 343: Hill Climbing
342 STARTING AND OPERATING accelerator to avoid spinning the log out from under your tires. Then ease the vehicle off the log using your brakes. CAUTION! Do not attempt to cross a log with a greater diameter than the running ground clearance or the vehicle will become high centered.
Page 344 the vehicle if something goes wrong? If everything looks good and you feel confident, then change trans- mission into a lower gear, shift the transfer case into 4L (Low) and proceed with caution. You should use first gear and 4L (Low Range) for very steep hills. •...
Page 345 344 STARTING AND OPERATING ability to proceed then make sure you are in 4L (Low Range) with the transmission in first gear (manually select first gear on automatic transmissions) and pro- ceed with caution. Allow engine braking to control the descent and apply your brakes if necessary, but do not allow the tires to lock.
Page 346: Driving Through Water
WARNING! If the engine stalls or you lose headway or cannot make it to the top of a steep hill or grade, never attempt to turn around. To do so may result in tipping and rolling the vehicle, which may result in severe injury.
Page 347 346 STARTING AND OPERATING CAUTION! Water ingestion into the axles, transmission, transfer case, engine or vehicle interior can occur if you drive too fast or through too deep of water. Water can cause permanent damage to engine, driveline or other vehicle components and your brakes will be less effective once wet and/or muddy •...
Page 348: Airing Down For Off-Road Driving
CAUTION! Muddy waters can reduce the cooling system effec- tiveness by depositing debris onto the radiator. • Crossing Ditches, Streams, Shallow Rivers Or Other Flowing Water – Flowing water can be extremely dangerous. Never attempt to cross a fast running stream or river even in shallow water.
Page 349: Vehicle Recovery
348 STARTING AND OPERATING form to the ground contour. Different terrain, tires, and vehicles require different tire pressure. Hard surfaces like rock and heavier vehicles require higher pressures than softer surfaces such as sand and lighter vehicles. You will need to experiment to determine what is right for your situation.
Page 350 vehicle impingement on the surroundings, then using a tow strap to the vehicle tow hooks would be fast and easy. If the vehicle is severely hung up or in a situation where great care needs to be taken during the recovery, then nothing can do the job better than a winch.
Page 351 350 STARTING AND OPERATING CAUTION! Damage can occur when spinning your tires at an excessive high speed. Do not spin your tires faster than an indicated 35 mph (56 km/h). • Using the Tow Hooks With a Tow Strap – Tow straps are a quick and easy way to recover your vehicle from minor situations if you have a secondary vehicle which is not stuck.
Page 352 WARNING! Never use tow straps with end hooks or link two straps with a clevis pin. These heavy metal objects could become projectiles if a strap breaks, which could cause severe injury. Never leave more than two or three feet of slack in the strap. More slack than this greatly increases the risk of injury and vehicle dam- age.
Page 353: After Driving Off-Road
352 STARTING AND OPERATING as you power the winch in. Be careful not to allow slack in the cable as you recover the vehicle. Do not try to guide the cable into the drum. If it starts to bunch up on one end, let it. You can re-spool the cable afterwards.
Page 354: Limited-Slip Differential
• After extended operation in mud, sand, water, or similar dirty conditions, have the radiator, fan, brake rotors, wheels, brake linings, and axle yokes inspected and cleaned as soon as possible. WARNING! Abrasive material in any part of the brakes may cause excessive wear or unpredictable braking.
Page 355: Driving On Slippery Surfaces
354 STARTING AND OPERATING WARNING! On vehicles equipped with a limited-slip differential never run the engine with one rear wheel off the ground since the vehicle may drive through the rear wheel remaining on the ground. You could lose control of the vehicle. Care should be taken to avoid sudden accelerations when both rear wheels are on a slippery surface.
Page 356: Flowing/Rising Water
Flowing/Rising Water WARNING! Do not drive on or across a road or path where water is flowing and/or rising (as in storm run-off). Flow- ing water can wear away the road or path’s surface and cause your vehicle to sink into deeper water. Furthermore, flowing and/or rising water can carry your vehicle away swiftly.
Page 357 356 STARTING AND OPERATING CAUTION! (Continued) • Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission, axle, etc.) for signs of contamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.
Page 358: Off-Road Driving Tips
OFF-ROAD DRIVING TIPS Care should be taken when attempting to climb steep hills or driving diagonally across a hill or slope. If natural obstacles force you to travel diagonally up or down a hill, choose a mild angle and keep as little side tilt as possible. Keep the vehicle moving and make turns slowly and cautiously.
Page 359: Winch Usage (Power Wagon Only) - If Equipped
358 STARTING AND OPERATING • After extended operation in mud, sand, water, or similar dirty conditions, have the radiator, fan, brake rotors, wheels, brake linings, and axle yokes inspected and cleaned as soon as possible. WARNING! Abrasive material in any part of the brakes may cause excessive wear or unpredictable braking.
Page 360 2. Attach the hook to a suitable anchor point. CAUTION! Be certain the anchor will withstand the load re- quired to tension the wire rope. 3. Apply at least 500 lbs (227 kg) of tension to the rope while winding the rope. Always use care to ensure the rope does not pile up on one side of the drum and is neatly wound onto the drum.
Page 361: Understanding The Features Of Your Winch
360 STARTING AND OPERATING Understanding The Features Of Your Winch Winch Components...
Page 362 1. Motor: The winch motor is powered by the vehicle charging system and features a thermal protection switch that automatically stops motor function in the power-in direction if the motor gets too hot. 2. Remote Socket: The remote socket allows the remote control to be attached to the control pack to allow the winch to function.
Page 363: Winch Accessories
362 STARTING AND OPERATING Winch Accessories The following accessories are necessary to attach the winch to anchors, change direction of pull, and for safe winching. Gloves: Wire rope, through use, will develop which can slice skin. It is ex- tremely important to wear protective gloves while oper- ating the winch or handling the wire rope.
Page 364: Operating Your Winch
Clevis/D-Shackles: Operating Your Winch D-Shackle is a safe means of connecting the looped ends of cables, straps and snatch Failure to observe any of these warnings regarding blocks. The shackle’s pin is proper winch usage may result in severe injury. threaded to allow easy re- •...
Page 365 364 STARTING AND OPERATING WARNING! (Continued) • Always stand clear of wire rope and load and keep others away during winching. • Always keep hands and clothing clear of the wire rope, hook and fairlead opening during operation and when spooling. •...
Page 366 2. Always take your time when using a winch. 3. Use the right equipment for the situation. 4. Always wear leather gloves and do not allow the wire rope to slip through your hands when handling the rope. 5. Only the operator should handle the wire rope and remote control.
Page 367 366 STARTING AND OPERATING CAUTION! (Continued) • Always keep remote control lead clear of the drum, wire rope and rigging. • Inspect for cracks, pinches, frayed wires, or loose connections. Replace if damaged. • Be careful not to pull the Winch Cable Collar through the rollers.
Page 368 3. Disengage the clutch to allow free spooling of the winch drum, rotate the clutch lever on the winch to disengage. Freespooling conserves battery power. Free Spool STARTING AND OPERATING 367 4. Free the winch hook and attach the hook strap. Free the winch hook from its anchor point.
Page 369 368 STARTING AND OPERATING 5. Pull the wire to the anchor point. Pull out enough wire rope to reach your anchor point. Be sure to keep a certain amount of tension on the wire as it can become twisted and over-wrapped when slackened, leading to wire rope damage.
Page 370 CAUTION! Always be certain the anchor you select will with- stand the load. NOTE: How to choose an anchor point: A secure anchor is critical to winching operations. An anchor must be strong enough to hold while winching. Natural an- chors include trees, stumps and rocks.
Page 371 370 STARTING AND OPERATING NOTE: Always ensure the clutch is fully engaged or disengaged. 9. Connect the remote control to the winch control box, located behind the front bumper. Be careful not to let the remote control cord dangle in front of the winch. If you choose to control the winch from inside your vehicle, always pass the remote through a window to avoid pinching the cord in the door.
Page 372 11. Check your anchor. Make sure all connections are secured and free of debris before continuing with the winching procedure. STARTING AND OPERATING 371 12. Check wire rope. The wire rope should be neatly wound around the spooling drum. Improper winding can cause damage to the wire rope.
Page 373 372 STARTING AND OPERATING 13. In certain situations you may decide to throw a heavy blanket or similar object over the wire rope. A heavy blan- ket can absorb energy should the wire rope break. Place it on the wire rope midway be- tween the winch and the an- chor point.
Page 374 For additional assistance, the winched vehicle can be slowly driven while being pulled by the winch. Continue pulling until the vehicle is on stable ground. If you are able to drive the vehicle, the winching operation is complete. Using The Remote Control STARTING AND OPERATING 373 NOTE: •...
Page 375 374 STARTING AND OPERATING section of the rope and reposition it to the opposite end of the drum, which will free up space for continued winching. 16. Secure vehicle. Once recovery of the vehicle’s is complete, be sure to secure the vehicle’s brakes and put the transmission in PARK.
Page 376 NOTE: How to spool under no load: Arrange the remote control lead so it cannot be caught in the winch. Arrange the wire rope so it will not kink or tangle when spooled. Be sure any wire rope already on the spooling drum is wound tightly and evenly layered.
Page 377: Rigging Techniques
376 STARTING AND OPERATING Rigging Techniques Various winching situations will require application of other winching techniques. These could range from too little distance to achieve maximum pull using straight line rigging, simply increasing pulling power, or main- taining a straight-line pulling situation. You will have to assess what technique is correct for your situation.
Page 378 will enable you to change your pulling direction while still allowing the wire rope to be at 90° to wind properly onto the spooling drum. Increasing Pulling Power In some cases, you may find yourself needing more pulling power. The use of snatch blocks increases me- chanical advantage and that increases your pulling power.
Page 379: Power Steering
378 STARTING AND OPERATING vehicle’s frame/tow hook and run the wire rope through a snatch block. Disengage the clutch and, using the snatch block, pull out enough wire to reach your anchor point. Do not attach the hook to the mounting kit. Secure to the anchor point with a tree trunk protector or choker chain.
Page 380: Power Steering Fluid Check
CAUTION! Prolonged operation of the steering system at the end of the steering wheel travel will increase the steering fluid temperature and it should be avoided when possible. Damage to the power steering pump may occur. Power Steering Fluid Check Checking the power steering fluid level at a defined service interval is not required.
Page 381: Parking Brake
380 STARTING AND OPERATING If necessary, add fluid to restore to the proper indicated level. With a clean cloth, wipe any spilled fluid from all surfaces. Refer to “Fluids, Lubricants, and Genuine Parts” in “Maintaining Your Vehicle” for further information. PARKING BRAKE The foot-operated parking brake is positioned below the lower left corner of the instrument panel.
Page 382: Brake System
WARNING! • Always fully apply the parking brake when leav- ing your vehicle or it may roll and cause damage or injury. Also be certain to leave the transmission in PARK. Failure to do so may allow the vehicle to roll and cause damage or injury.
Page 383: 3500 Dual Rear Wheel Models Only
382 STARTING AND OPERATING 3500 Dual Rear Wheel Models Only The brake system power assist is provided by a hydro- boost unit which shares fluid with the power steering system. You may experience some clicking or hissing noises from the hydro-boost system during hard braking conditions.
Page 384 The system’s pump motor runs during an ABS stop to provide regulated hydraulic pressure. The pump motor makes a low humming noise during operation. This is normal. The ABS conducts a low-speed selftest at about 10 mph (16 km/h). If you have your foot lightly on the brake while this test is occurring, you may feel slight pedal movement.
Page 385: Electronic Brake Control System
384 STARTING AND OPERATING WARNING! (Continued) • The ABS cannot prevent accidents, including those resulting from excessive speed in turns, following another vehicle too closely, or hydro- planing. Only a safe, attentive, and skillful driver can prevent accidents. • The capabilities of an ABS-equipped vehicle must never be exploited in a reckless or dangerous manner which could jeopardize the user’s safety or the safety of others.
Page 386: Traction Control System (Tcs) - If Equipped
WARNING! • ABS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency beyond that af- forded by the condition of the vehicle brakes and tires or the traction afforded. •...
Page 387: Brake Assist System (Bas) - If Equipped
386 STARTING AND OPERATING Brake Assist System (BAS) – If Equipped The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The BAS detects an emergency braking situation by sensing the rate and amount of brake application and then applies optimum pressure to the brakes.
Page 388: Hill Start Assist (Hsa) - If Equipped
Hill Start Assist (HSA) – If Equipped The HSA system is designed to assist the driver in launching a vehicle on an incline. HSA will maintain the level of brake pressure the driver inputs for a short duration once the driver takes his foot off of the brake pedal.
Page 389 388 STARTING AND OPERATING The system will only work if the intended direction of the vehicle and vehicle gear match. For example, if the intended direction is forward up a hill and the vehicle is in DRIVE and the activation criteria are met, HSA will activate.
Page 390 WARNING! (Continued) • HSA is not a parking brake. If you stop the vehicle on a hill without putting the transmission in PARK or using the parking brake, it will roll down the incline and could cause a collision with an- other vehicle or object.
Page 391: Electronic Stability Program (Esp) - If Equipped
390 STARTING AND OPERATING EVIC Equipped Vehicles HSA is a Customer Programmable Feature on a EVIC equipped vehicle. If you wish to turn off the HSA feature, refer to “Customer Programmable Features/Electronic Vehicle Information Center (EVIC)” in “Understanding Your Instrument Panel” for further information. Electronic Stability Program (ESP) –...
Page 392 • Oversteer - when the vehicle is turning more than appropriate for the steering wheel position. • Understeer - when the vehicle is turning less than appropriate for the steering wheel position. ESP/TCS Indicator Light The “ESP/TCS Indicator Light” located in the instrument cluster, starts to flash as soon as the tires lose traction and the ESP system becomes active.
Page 393 392 STARTING AND OPERATING (2WD/4WD AUTO/4WD NEUTRAL) transfer case. If you have a four-wheel drive vehicle, and want to determine which transfer case is on your vehicle and how to operate it, refer to “Four-Wheel Drive Operation” in “Starting and Operating” for further information.
Page 394 requiring ESP to be switched to the “Partial Off” mode is overcome, turn ESP back on by momentarily pressing the ESP OFF switch. This may be done while the vehicle is in motion. WARNING! In the “Partial Off” mode, the engine torque reduc- tion and stability features are desensitized.
Page 395 394 STARTING AND OPERATING off at low vehicle speeds so that it will not interfere with off-road driving but ESP function returns to provide the stability feature at speeds above 40 mph (64 km/h). The “ESP/TCS Indicator Light” will always be illuminated when ESP is off.
Page 396: Trailer Sway Control (Tsc) - If Equipped
this light remains on after several ignition cycles and the vehicle has been driven several miles/kilometers at speeds greater than 30 mph (48 km/h), see your autho- rized dealer as soon as possible to have the problem diagnosed and corrected. NOTE: •...
Page 397: Tire Safety Information
396 STARTING AND OPERATING TSC is only active in the default “ESP On” mode. TSC can be disabled by pressing the ESP OFF switch and entering “ESP Partial Off” mode. It is not active in the “ESP Partial Off” or “ESP Off” modes. Refer to the ESP portion of this section for an explanation of the different ESP operating modes.
Page 398 NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European-Metric tire sizing is based on European design standards.
Page 399 398 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 400 Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 401: Tire Identification Number (Tin)
400 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
Page 402: Tire Terminology And Definitions
Tire Terminology and Definitions Term B-Pillar Cold Tire Pressure Maximum Inflation Pressure Recommended Inflation Pressure Tire Placard Definition The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof.
Page 403: Tire Loading And Tire Pressure
402 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire Placard Location Tire and Loading Information Placard Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle...
Page 404 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
Page 405 404 STARTING AND OPERATING 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five 150 lb (68 kg) passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 –...
Page 406 STARTING AND OPERATING 405...
Page 407: Tires - General Information
406 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 408: Tire Inflation Pressures
WARNING! (Continued) • Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear patterns to develop across the tire tread.
Page 409: Tire Pressures For High Speed Operation
408 STARTING AND OPERATING CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...
Page 410: Radial Ply Tires
loading may be required for high-speed vehicle opera- tion. Refer to original equipment or an authorized tire dealer for recommended safe operating speeds, loading and cold tire inflation pressures. WARNING! High speed driving with your vehicle under maxi- mum load is dangerous. The added strain on your tires could cause them to fail.
Page 411: Tire Spinning
410 STARTING AND OPERATING original equipped tire on the front or rear axle of your vehicle, but it is not. Installation of this limited-use spare tire affects vehicle handling. Since it is not the same tire, replace (or repair) the original tire and reinstall on the vehicle at the first opportunity.
Page 412: Tread Wear Indicators
Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. 1 — Worn Tire 2 — New Tire STARTING AND OPERATING 411 These indicators are molded into the bottom of the tread grooves.
Page 413: Replacement Tires
412 STARTING AND OPERATING WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident resulting in serious injury or death.
Page 414: Supplemental Tire Pressure Information - If Equipped
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 415: Tire Chains
414 STARTING AND OPERATING TIRE CHAINS Use “Class S” chains, or other traction aids that meet SAE Type “S” specifications. Use “Class U” chains on 2500/3500 model trucks, or other traction aids that meet SAE Type “U” specifica- tions. NOTE: Chains must be the proper size for the vehicle as recommended by the chain manufacturer.
Page 416 CAUTION! (Continued) • Observe the tire chain manufacturer’s instructions on method of installation, operating speed, and conditions for usage. Always use the lower sug- gested operating speed of the chain manufacturer if different than the speed recommended by the manufacturer. These cautions apply to all chain traction devices, includ- ing link and cable (radial) chains.
Page 417: Snow Tires
416 STARTING AND OPERATING CAUTION! Do not use tire chains on 4x4 model trucks equipped with P265/70R17, LT275/70R17, P275/60R20, tires. There may not be adequate clearance for the chains and you are risking structural or body damage to your vehicle. Do not use tire chains on the 4X2 front wheels of 2500/3500 SRW (Single Rear Wheels) equipped with LT245/70R17, LT265/70R17 LT235/ 80R17 tires, or 4X4 front wheels equipped with...
Page 418 STARTING AND OPERATING 417 tires. Rotation will increase tread life, help to maintain mud, snow and wet traction levels and contribute to a smooth, quiet ride. Refer to “Maintenance Schedule” for the proper mainte- nance intervals. More frequent rotation is permissible if desired.
Page 419: Dual Rear Wheels
418 STARTING AND OPERATING Dual Rear Wheels Tire Rotation The tires used on dual wheel assemblies should be matched for wear to prevent overloading one tire in a set. To check if tires are even, lay a straight edge across all four tires.
Page 420: Tire Pressure Monitor System (Tpms)
TIRE PRESSURE MONITOR SYSTEM (TPMS) The Tire Pressure Monitoring System (TPMS) will warn the driver of a low tire pressure based on the vehicle recommended cold tire inflation placard pressure. The placard pressure is defined on the Tire and Loading Information label.
Page 421 420 STARTING AND OPERATING have been received. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) to receive this information. As an example, assume your vehicle has a recommended cold tire inflation placard pressure (parked for more than 3 hours) of 35 psi (241 kPa).
Page 422: Tire Pressure Monitor System Components
NOTE: • The TPMS is not intended to replace normal tire care and maintenance, nor to provide warning of a tire failure or condition. • The TPMS should not be used as a tire pressure gauge while adjusting your tire pressure. •...
Page 423 422 STARTING AND OPERATING Tire Pressure Monitoring Low Pressure Warnings The Tire Pressure Monitoring Telltale Lamp will illuminate in the instrument cluster, and an au- dible chime will be activated when one or more of the four active road tire pressures are low. Should this occur, you should stop as soon as possible, check the inflation pressure of each tire on your vehicle and inflate each tire to the vehicle’s recommended cold placard...
Page 424 1. This spare tire does not have a tire pressure monitor- ing sensor. Therefore, the TPMS will not monitor the tire pressure in the spare tire. 2. If you install the full size spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition switch cycle, a chime will sound and the “TPM Telltale Light”...
Page 425: Tire Pressure Monitor System (Tpms) Tire Light Load Inflation Switch Description (2500 Models) - If Equipped
424 STARTING AND OPERATING Tire Pressure Monitor System (TPMS) Tire Light Load Inflation Switch Description (2500 Models) – If Equipped WARNING! Never operate your vehicle with the TPMS and tire pressures set to the Light Load Inflation Pressure settings if carrying more than two occupants (150 lbs [68 kg] each) plus 200 pounds (91 kg) of cargo.
Page 426 Tire Light Load Inflation Switch STARTING AND OPERATING 425 Tire Light Load Inflation Switch Operation – If Equipped • This vehicle may have different recommended tire pressure values between the front and rear tires as shown in both the Tire Loading Information Label and the Supplemental Tire Pressure Information Label.
Page 427 426 STARTING AND OPERATING • The tire light load inflation switch will allow the driver to change between the max load inflation pressure (cold) low pressure warning threshold and the light load inflation pressure (cold) low pressure warning threshold depending on the vehicle’s load condition. Refer to the “Supplemental Tire Pressure Information”...
Page 428 the driver door. Use an accurate tire gauge to check the tire pressures when lowering all four tire pressures. After all four tire pressures have been lowered to the Light Load inflation pressures, press the tire light load inflation switch. If the tire light load inflation switch’s amber colored LED turns ON, the TPMS is using the light load inflation pressure (cold) low pressure warning thresh- olds.
Page 429: General Information
428 STARTING AND OPERATING the tire light load inflation switch, and tire pressures are below the max load inflation pressure (cold) low pressure warning thresholds, the TPMS low pressure warning telltale light (located in the instrument cluster) will turn ON and a chime will sound. The tire pressures are now required to be inflated to the max load inflation pressure (cold) values described on the Tire and Loading Informa- tion label.
Page 430: 5.7L Engine
5.7L Engine The 5.7L engine is designed to meet all emissions regulations and provide satisfac- tory fuel economy and performance when using high quality unleaded gasoline hav- ing an octane range of 87 to 89. The manu- facturer recommends the use of 89 octane for optimum performance.
Page 431: Gasoline/Oxygenate Blends
430 STARTING AND OPERATING Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE and ETBE. Oxygen- ates are required in some areas of the country during the winter months to reduce carbon monoxide emissions. Fuels blended with these oxygenates may be used in your vehicle.
Page 432: Mmt In Gasoline
• disconnect and reconnect the battery to reset the engine controller memory More extensive repairs will be required for prolonged exposure to E-85 fuel. MMT In Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase octane. Gasoline blended with MMT provides no performance advantage beyond gasoline of the same octane number without MMT.
Page 433: Carbon Monoxide Warnings
432 STARTING AND OPERATING CAUTION! (Continued) • An out-of-tune engine or certain fuel or ignition malfunctions can cause the catalytic converter to overheat. If you notice a pungent burning odor or some light smoke, your engine may be out of tune or malfunctioning and may require immediate service.
Page 434: Flexible Fuel (4.7L Engine Only) - If Equipped
WARNING! (Continued) • Guard against carbon monoxide with proper maintenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnor- mal conditions repaired promptly. Until repaired, drive with all side windows fully open. FLEXIBLE FUEL (4.7L ENGINE ONLY) — IF EQUIPPED E85 General Information The information in this section is for Flexible Fuel Ve-...
Page 435: Ethanol Fuel (E85)
434 STARTING AND OPERATING CAUTION! Only vehicles with the E85 fuel filler door label can operate on E85. E85 Badge Ethanol Fuel (E85) E85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline. WARNING! Ethanol vapors are extremely flammable and could cause serious personal injury.
Page 436: Selection Of Engine Oil For Flexible Fuel Vehicles (E85) And Gasoline Vehicles
For best results, a refueling pattern that avoids alternat- ing between E85 and unleaded gasoline is recom- mended. When you do switch fuel types, it is recommended that: • you do not add less than 5 gal (19 L) when refueling •...
Page 437: Starting
436 STARTING AND OPERATING Starting The characteristics of E85 fuel make it unsuitable for use when ambient temperatures fall below 0°F (-18°C). In the range of 0°F (-18°C) to 32°F (0°C), you may experience an increase in the time it takes for your engine to start, and a deterioration in driveability (sags and/or hesitations) until the engine is fully warmed up.
Page 438: Adding Fuel
ADDING FUEL The fuel filler cap (gas cap) is located behind the fuel filler door, on the left side of the vehicle. Open the fuel door and remove the fuel cap by turning it counter- clockwise. Fuel Filler Cap STARTING AND OPERATING 437 NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler door.
Page 439: Loose Fuel Filler Cap Message
438 STARTING AND OPERATING WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank filled. • Never add fuel to the vehicle when the engine is running. • A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.
Page 440: Vehicle Loading
VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration regulations, your vehicle has a certification label affixed to the driver’s side door or pillar. This label contains the month and year of manufacture, Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front and rear, and Vehicle Identification Number (VIN).
Page 441: Starting And Operating
440 STARTING AND OPERATING Rim Size This is the rim size that is appropriate for the tire size listed. Inflation Pressure This is the cold tire inflation pressure for your vehicle for all loading conditions up to full GAWR. Curb Weight The curb weight of a vehicle is defined as the total weight of the vehicle with all fluids, including vehicle fuel, at full capacity conditions, and with no occupants or cargo...
Page 442: Trailer Towing
CAUTION! Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR. If you do, parts on your vehicle can break, or it can change the way your vehicle handles. This could cause you to lose control.
Page 443 442 STARTING AND OPERATING Gross Combination Weight Rating (GCWR) The GCWR is the total permissible weight of your vehicle and trailer when weighed in combination. NOTE: The GCWR rating includes a 150 lbs (68 kg) allowance for the presence of a driver. Gross Axle Weight Rating (GAWR) The GAWR is the maximum capacity of the front and rear axles.
Page 444 Trailer Sway Control The trailer sway control is a telescoping link that can be installed between the hitch receiver and the trailer tongue that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling. Weight-Carrying Hitch A weight-carrying hitch supports the trailer tongue weight, just as if it were luggage located at a hitch ball or...
Page 445 444 STARTING AND OPERATING WARNING! (Continued) • Weight distributing systems may not be compat- ible with surge brake couplers. Consult with your hitch and trailer manufacturer or a reputable Rec- reational Vehicle dealer additional information. EXAMPLE — With Weight-Distributing Hitch (Correct) EXAMPLE —...
Page 446: Trailer Hitch Classification
EXAMPLE — Improper Adjustment of Weight- Distributing Hitch (Incorrect) Fifth-Wheel Hitch The fifth-wheel hitch is a special high platform with a coupling that mounts over the rear axle of the tow vehicle in the truck bed. It connects a vehicle and fifth-wheel trailer with a coupling king pin.
Page 447: Trailer Towing Weights (Maximum Trailer Weight Ratings)
• http:// www.dodge.com/bodybuilder. • http:// www.dodge.ca (Canada). Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in (4540 kg) the front of the trailer.
Page 448: Towing Requirements
Consider the following items when computing the weight on the rear axle of the vehicle: • The tongue weight of the trailer • The weight of any other type of cargo or equipment put in or on your vehicle • The weight of the driver and all passengers. STARTING AND OPERATING 447 NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle.
Page 449 448 STARTING AND OPERATING CAUTION! (Continued) • Then, during the first 500 miles (805 km) that a trailer is towed, do not drive over 50 mph (80 km/h) and do not make starts at full throttle. This helps the engine and other parts of the vehicle wear in at the heavier loads.
Page 450 WARNING! (Continued) • Vehicles with trailers should not be parked on a grade. When parking, apply the parking brake on the tow vehicle. Put the tow vehicle transmission in PARK. For four-wheel drive vehicles, make sure the transfer case is not in NEUTRAL. Always, block or chock the trailer wheels.
Page 451 450 STARTING AND OPERATING • Check for signs of tire wear or visible tire damage before towing a trailer. Refer to “Tires – General Information” in “Starting and Operating” for the proper inspection procedure. • When replacing tires, refer to “Tires – General Infor- mation”...
Page 452 WARNING! • Do not connect trailer brakes to your vehicle’s hydraulic brake lines. It can overload your brake system and cause it to fail. You might not have brakes when you need them and could have an accident. • Towing any trailer will increase your stopping distance.
Page 453 452 STARTING AND OPERATING The user interface consists of the following: GAIN/ Brake Output Power Display Shows the current GAIN setting. This display may also be used to display diagnostic information, if needed. • SC — Short Circuit to Ground •...
Page 454 GAIN Adjustment Buttons (+/-) Pressing these buttons will adjust the brake control power output to the trailer brakes in 0.5 increments. The GAIN setting can be increased to a maximum of 10 or decreased to a minimum of 0 (no trailer braking). GAIN The GAIN setting is used to set the trailer brake control for the specific towing condition and should be changed...
Page 455 454 STARTING AND OPERATING Repeat Steps 5 and 6 until the GAIN setting is at a point just below trailer wheel lockup. If towing a heavier trailer, trailer wheel lockup may not be attainable even with the maximum GAIN setting of 10. EVIC Display Messages The trailer brake control interacts with the Electronic Vehicle Information Center (EVIC).
Page 456 NOTE: • An aftermarket controller may be available for use with trailers with air or electric-over-hydraulic trailer brake systems. To determine the type of brakes on your trailer and the availability of controllers, check with your trailer manufacturer or dealer. •...
Page 457 456 STARTING AND OPERATING The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. Four-Pin Connector 1 — Female Pins 4 — Park 2 — Male Pin 5 —...
Page 458: Towing Tips
WARNING! Any work done to the vehicle’s electrical system or wiring should be performed by a qualified automo- tive technician. If done improperly it may cause damage to the electrical system wiring and could result in serious or fatal injury. Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer up in an area away from heavy...
Page 459: Snowplow
458 STARTING AND OPERATING Electronic Speed Control – If Equipped − Do not use in hilly terrain or with heavy loads. − When using the speed control, if you experience speed drops greater than 10 mph (16 km/h), disengage until you can get back to cruising speed.
Page 460: 2500/3500 Models Only
STARTING AND OPERATING 459 Dodge Body Builders Guide. See your authorized dealer, installer or snowplow manufacturer for this information. There are unique electrical systems that must be con- nected to properly assure operator safety and prevent overloading vehicle systems.
Page 461 • Check that snowplow lighting is connected and func- tioning properly. Snowplow Prep Package Model Availability For Information about snowplow applications visit www.dodge.com or refer to the current Dodge Body Builders Guide. 1. The maximum number of occupants in the truck should not exceed two.
Page 462 if necessary at the beginning and end of the snowplow season. This will help prevent uneven tire wear. The blade should be lowered whenever the vehicle is parked. Maintain and operate your vehicle and snowplow equip- ment following the recommendations provided by the specific snowplow manufacturer.
Page 463: Recreational Towing (Behind Motorhome, Etc.)
462 STARTING AND OPERATING General Maintenance Snowplows should be maintained in accordance with the plow manufacturer’s instructions. Keep all snowplow electrical connections and battery terminals clean and free of corrosion. When plowing snow, to avoid transmission and drive- train damage, the following precautions should be ob- served.
Page 464: Recreational Towing - Four-Wheel Drive Models
CAUTION! Do not disconnect the rear driveshaft because fluid will leak from the transmission and damage the internal parts. Recreational Towing – Four-Wheel Drive Models CAUTION! Failure to follow these requirements can cause severe damage to the transmission and/or transfer case. NOTE: Both the manual shift and electronic shift trans- fer cases must be shifted into NEUTRAL for recreational towing.
Page 465 464 STARTING AND OPERATING CAUTION! It is necessary to follow these steps to be certain that the transfer case is fully in NEUTRAL before recre- ational towing to prevent damage to internal parts. 1. Bring the vehicle to a complete stop. 2.
Page 466 Returning to Normal Operation – Manual Shift Transfer Case Use the following procedure to prepare your vehicle for normal usage: 1. Bring the vehicle to a complete stop, leaving it con- nected to the tow vehicle. 2. Firmly apply the parking brake. 3.
Page 467 466 STARTING AND OPERATING CAUTION! • Do not use a bumper-mounted clamp-on tow bar on your vehicle. The bumper face bar will be damaged. • Do not disconnect the rear driveshaft because fluid will leak from the transfer case and damage the internal parts.
Page 468 1. Bring the vehicle to a complete stop. 2. Turn OFF the engine. 3. Turn the ignition switch to the ON position, but do not start the engine. 4. Press and hold the brake pedal. 5. Shift the transmission into NEUTRAL. 6.
Page 469 468 STARTING AND OPERATING 17. Release the parking brake. NOTE: • The transfer case cannot be shifted into NEUTRAL from the 4WD AUTO (if equipped) position. • Steps 1 through 5 are requirements that must be met prior to pressing the NEUTRAL button, and must continue to be met until the four seconds elapses and the shift has been completed.
Page 470 7. After the NEUTRAL indicator light turns off, release the NEUTRAL button. 8. After the NEUTRAL button has been released, the transfer case will shift to the position identified by the selector switch. 9. Shift the transmission into PARK. 10. Release the brake pedal. 11.
Page 471: Equipment Identification Plate
470 STARTING AND OPERATING WARNING! You or others could be injured if you leave the vehicle unattended with the transfer case in the NEUTRAL position without first fully engaging the parking brake. The transfer case NEUTRAL position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to move, even if the transmission is in PARK.
Page 472: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....472 Jacking And Tire Changing ....472 Jack Location .
Page 473: Hazard Warning Flasher
472 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is located on the upper switch bank just below the radio. Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 474: Jack Location
WHAT TO DO IN EMERGENCIES 473 Jack Location The jack and jack tools are stored under the front passenger seat. Removal To access the jack and jack tools you must remove the plastic access cover, located on the side of the seat. To remove the cover, pull the front part of the cover (closest to the front of the seat) toward you to release a locking tab.
Page 475 474 WHAT TO DO IN EMERGENCIES Remove the jack and tools by removing the wing bolt and sliding the assembly from under the seat. Jack and Tools (2500/3500 Series) Jack and Tools (1500 Series)
Page 476 WARNING! After using the jack and tools, always reinstall them in the original carrier and location. While driving you may experience abrupt stopping, rapid accelera- tion or sharp turns. A loose jack, tools, bracket or other objects in the vehicle may move around with force, resulting in serious injury.
Page 477 476 WHAT TO DO IN EMERGENCIES 3. Fold the flap and roll the jack tool kit into a cylindrical package (in direction of arrows) and tie to the jack using the tie straps. Tying Bag to Jack with Straps Folding Flap and Rolling Bag...
Page 478 WHAT TO DO IN EMERGENCIES 477 Jack and Tools Tied Jack and Tools (1500 Series) 4. Place the jack and tools in the storage position holding the jack by the jack turn-screw, slip the jack and tools under the seat so that the bottom slot engages into the fastener on the floor, and then secure to the floor pan using the wing bolt.
Page 479: Removing The Spare Tire
478 WHAT TO DO IN EMERGENCIES Jack and Tools (2500/3500 Series) Removing The Spare Tire Remove the spare tire before attempting to jack up the truck. Attach the wheel wrench to the jack extension tube. Insert the tube through the access hole between the lower tailgate and the top of the bumper and into the winch mechanism tube.
Page 480: Preparations
Removing the Spare Tire 1 — Wheel Wrench 2 — Spare Tire It is recommended that you stow the flat or spare to avoid tangling the loose cable. WHAT TO DO IN EMERGENCIES 479 NOTE: The winch mechanism is designed for use with the jack extension tube only.
Page 481: Instructions
480 WHAT TO DO IN EMERGENCIES 4. Turn the ignition OFF. 5. Turn on the Hazard Warning flasher. 6. Block both the front and rear of the wheel diagonally opposite the jacking position. For example, if the right front wheel is being changed, block the left rear wheel.
Page 482 WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a jack. • Do not get under the vehicle when it is on a jack. • Only use the jack in the positions indicated and for lifting this vehicle during a tire change.
Page 483 482 WHAT TO DO IN EMERGENCIES • 1500 Series Trucks When changing a front wheel, place the scissors jack under the rear portion of the lower control arm as shown below. 4X2 Jacking Location 4X4 Jacking Location Operate the jack using the jack drive tube and the wheel wrench.
Page 484 For 4x2 and 4x4 trucks, when changing a rear wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the axle between the wheel and the shock bracket with the drive tubes extending to the rear.
Page 485 484 WHAT TO DO IN EMERGENCIES • 2500/3500 Series Trucks For 2500/3500 4x2 series trucks, when changing a front wheel, place the bottle jack under the frame rail behind the wheel. Locate the jack as far forward as possible on the straight part of the frame.
Page 486 WHAT TO DO IN EMERGENCIES 485 4x4 Jacking Location Rear Jacking Location (All) For 4x2 and 4x4 trucks, when changing a rear wheel, Connect the jack tube extension and wheel wrench. assemble the jack drive tube to the jack and connect the drive tube to the extension tube.
Page 487 486 WHAT TO DO IN EMERGENCIES CAUTION! Before raising the wheel off the ground, make sure that the jack will not damage surrounding truck parts and adjust the jack position as required. NOTE: If the bottle jack will not lower by turning the dial (thumbwheel) by hand, it may be necessary to use the jack drive tube in order to lower the jack.
Page 488: Hub Caps/Wheel Covers - If Equipped
WARNING! A loose tire or jack thrown forward in a collision or hard stop could injure someone in the vehicle. Al- ways stow the jack parts and the extra tire and wheel in the places provided. 7. Install the wheel center cap and remove the wheel blocks.
Page 489: Wheel Nuts
488 WHAT TO DO IN EMERGENCIES CAUTION! • Use a back-and-forth motion to remove the hub cap. Do not use a twisting motion when removing the hub cap, damage to the hub cap finish may occur. • The rear hub caps on the dual rear wheel has two pry-off notches.
Page 490 Disc Type Nut Stud Size Torque Wheels Ft. Lbs. Cone 9/16-18 120-150 Flanged 9/16-18 130-160 8-Stud — Dual Rear Wheels Dual wheels are flat-mounted and center-piloted. The lug nuts are a two-piece assembly. When the tires are being rotated or replaced, clean these lug nuts and add two drops of oil at the interface between the hex and the washer.
Page 491 490 WHAT TO DO IN EMERGENCIES Dual wheel models require a special heavy-duty lug nut tightening adapter (included with the vehicle) to cor- rectly tighten the lug nuts. Also, when it is necessary to remove and install dual rear wheels, use a proper vehicle lifting device.
Page 492: To Stow The Flat Or Spare
second time to verify that specific torque has been achieved. Retighten to specifications at 100 miles (160 km) and after 500 miles (800 km). It is recommended that wheel stud nuts be kept torqued to specifications at all times. Torque wheel stud nuts to specifications at each lubrication interval.
Page 493: Hoisting
492 WHAT TO DO IN EMERGENCIES HOISTING A conventional floor jack may be used at the jacking locations. Refer to the graphics that show jacking loca- tions. However, a floor jack or frame hoist must never be used on any other parts or the underbody. CAUTION! Never use a floor jack directly under the differential housing of a loaded truck or damage to your vehicle...
Page 494 NOTE: The positive battery post is covered with a protective cap. Lift up on the cap to gain access to the positive battery post. Positive Battery Post WHAT TO DO IN EMERGENCIES 493 WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised.
Page 495: Jump-Starting Procedure
494 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. WARNING! Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result.
Page 496 WARNING! Do not connect the cable to the negative post (-) of the discharged battery. The resulting electrical spark could cause the battery to explode and could result in personal injury. 5. Start the engine in the vehicle that has the booster battery, let the engine idle a few minutes, and then start the engine in the vehicle with the discharged battery.
Page 497: Freeing A Stuck Vehicle
496 WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE If the vehicle becomes stuck in snow, sand or mud, it can often be moved by a rocking motion. Move the shift lever rhythmically between DRIVE and REVERSE while ap- plying slight pressure to the accelerator.
Page 498: Emergency Tow Hooks - If Equipped
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause damage, or even failure, of the axle and tires. A tire could explode and injure someone. Do not spin your vehi- cle’s wheels faster than 30 mph (48 km/h) or for longer than 30 seconds continuously without stop- ping when you are stuck and do not let anyone near a spinning wheel, no matter what the speed.
Page 499: Towing A Disabled Vehicle
498 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE Proper towing or lifting equipment is required to prevent damage to your vehicle. Use only tow bars and other equipment designed for the purpose, following equip- ment manufacturer’s instructions. Use of safety chains is mandatory.
Page 500 CAUTION! Towing faster than 30 mph (48 km/h) or farther than 15 miles (24 km) can cause severe damage to the transmission. Such damage is not covered by the New Vehicle Limited Warranty. If the vehicle will be towed faster than 30 mph (48 km/h) or farther than 15 miles (24 km) the vehicle must be towed with the rear wheels OFF the ground.
Page 502: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.7L ... . . 504 Engine Compartment — 4.7L ... . . 505 Engine Compartment —...
Page 503 502 MAINTAINING YOUR VEHICLE Body Lubrication ....517 Windshield Wiper Blades ....518 Adding Washer Fluid .
Page 504 Fluid Capacities ..... . 555 Fluids, Lubricants And Genuine Parts ..557 MAINTAINING YOUR VEHICLE 503 Engine .
Page 505: Engine Compartment - 3.7L
504 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.7L 1 — Air Cleaner Filter 2 — Automatic Transmission Dipstick (If Equipped) 3 — Engine Oil Dipstick 4 — Brake Fluid Reservoir 5 — Battery 6 — Integrated Power Module 7 — Washer Fluid Reservoir 8 —...
Page 506: Engine Compartment - 4.7L
ENGINE COMPARTMENT — 4.7L 1 — Air Cleaner Filter 2 — Automatic Transmission Dipstick 3 — Engine Oil Dipstick 4 — Brake Fluid Reservoir 5 — Battery 6 — Integrated Power Module MAINTAINING YOUR VEHICLE 505 7 — Washer Fluid Reservoir 8 —...
Page 507: Engine Compartment - 5.7L
506 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 5.7L 1 — Air Cleaner Filter 2 — Automatic Transmission Dipstick 3 — Engine Oil Fill 4 — Engine Oil Dipstick 5 — Brake Fluid Reservoir 6 — Battery 7 — Washer Fluid Reservoir 8 —...
Page 508: Onboard Diagnostic System (Obd Ii)
ONBOARD DIAGNOSTIC SYSTEM (OBD II) Your vehicle is equipped with a sophisticated onboard diagnostic system called OBDII. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 509: Emissions Inspection And Maintenance Programs
508 MAINTAINING YOUR VEHICLE the SELECT button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the Malfunction Indicator Light (MIL). EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass...
Page 510: Replacement Parts
4. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 511: Maintenance Procedures
510 MAINTAINING YOUR VEHICLE your vehicle. Refer to these manuals before attempting any procedure yourself. NOTE: Intentional tampering with emissions control systems may void your warranty and could result in civil penalties being assessed against you. WARNING! You can be badly injured working on or around a motor vehicle.
Page 512: Engine Oil
CAUTION! (Continued) • Your vehicle has been built with improved fluids that protect the performance and durability of your vehicle and also allow extended maintenance intervals. Do not use chemical flushes in these components as the chemicals can damage your engine, transmission, power steering or air condi- tioning.
Page 513 512 MAINTAINING YOUR VEHICLE NOTE: Under no circumstances should oil change intervals exceed 6,000 miles (10 000 km) or six months, whichever occurs first. Engine Oil Selection For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends engine oils that are API Certified and meet the requirements of Chrysler Material Standard MS-6395.
Page 514: Engine Oil Filter
Lubricants which do not have both the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used. NOTE: For 2500/3500 trucks with a 5.7L engine oper- ating under a gross combined weight rating of 14,000 lbs (6 350 kg) or greater, SAE 5W-30 engine oil is recom- mended for all operating temperatures.
Page 515: Engine Air Cleaner Filter
514 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter Refer to “Maintenance Schedule” for further information. WARNING! The air induction system (air cleaner, hoses, etc.) can provide a measure of protection in the case of engine backfire. Do not remove the air induction system (air cleaner, hoses, etc.) unless such removal is necessary for repair or maintenance.
Page 516 WARNING! (Continued) • Battery gas is flammable and explosive. Keep flame or sparks away from the battery. Do not use a booster battery or any other booster source with an output greater than 12 Volts. Do not allow cable clamps to touch each other. •...
Page 517: Air Conditioner Maintenance
516 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test.
Page 518: Front Driveshaft Lubrication - 2500/3500
Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency (EPA) and is an ozone-saving product. However, the manufacturer recommends that air condi- tioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.
Page 519: Windshield Wiper Blades
518 MAINTAINING YOUR VEHICLE Windshield Wiper Blades Clean the rubber edges of the wiper blades and the windshield periodically with a sponge or soft cloth and a mild nonabrasive cleaner. This will remove accumula- tions of salt or road film. Operation of the wipers on dry glass for long periods may cause deterioration of the wiper blades.
Page 520: Exhaust System
WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. After the engine has warmed up, operate the defroster for a few minutes to reduce the possibility of smearing or freezing the fluid on the cold windshield.
Page 521 520 MAINTAINING YOUR VEHICLE WARNING! • Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing CO, refer to “Safety Tips/Exhaust Gas” in “Things To Know Before Starting Your Vehicle”...
Page 522 Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage. NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you.
Page 523: Cooling System
522 MAINTAINING YOUR VEHICLE Cooling System WARNING! You or others can be badly burned by hot coolant or steam from your radiator. If you see or hear steam coming from under the hood, do not open the hood until the radiator has had time to cool. Never try to open a cooling system pressure cap when the radiator is hot.
Page 524 Refer to “Maintenance Schedule” for further information. Selection Of Coolant Use only the manufacturer’s recommended engine cool- ant (antifreeze). Refer to “Fluids, Lubricants, and Genu- ine Parts” in “Maintaining Your Vehicle” for further information. CAUTION! • Mixing of engine coolant (antifreeze) other than specified HOAT engine coolant (antifreeze), may result in engine damage and may decrease corro- sion protection.
Page 525 524 MAINTAINING YOUR VEHICLE replacement. To prevent reducing this extended mainte- nance period, it is important that you use the same engine coolant (antifreeze) throughout the life of your vehicle. Please review these recommendations for using Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze).
Page 526 WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add engine coolant (antifreeze) when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine. Heat causes pressure to build up in the cooling system.
Page 527 526 MAINTAINING YOUR VEHICLE of this. As long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month. When additional engine coolant (antifreeze) is needed to maintain the proper level, it should be added to the coolant bottle.
Page 528: Brake System
• Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the condenser clean, also. • Do not change the thermostat for Summer or Winter operation. If replacement is ever necessary, install ONLY the correct type thermostat.
Page 529 528 MAINTAINING YOUR VEHICLE With disc brakes the fluid level can be expected to fall as the brake linings wear. However, an unexpected drop in fluid level may be caused by a leak and a system check should be conducted. Use only the manufacturer’s recommended brake fluid.
Page 530: Rear Axle And 4X4 Front Driving Axle Fluid Level
WARNING! (Continued) • To avoid contamination from foreign matter or moisture, use only new brake fluid or fluid that has been in a tightly closed container. Keep the master cylinder reservoir cap secured at all times. Brake fluid in a open container absorbs moisture from the air resulting in a lower boiling point.
Page 531: Transfer Case
530 MAINTAINING YOUR VEHICLE axles. The fluid level should be 5/8 in (16 mm) below the fill hole on 9 1/4 in manufacturer’s rear axles. For all 2500/3500 Model axles, the fluid level should be 1/4” ± 1/4 in (6.4 mm ± 6.4 mm) below the fill hole on the 9.25 in front and 3/4 in ±...
Page 532: Automatic Transmission
Fluid Level Check This fluid level can be checked by removing the filler plug. The fluid level should be to the bottom edge of the filler plug hole with the vehicle in a level position. Automatic Transmission Selection Of Lubricant It is important that the proper lubricant is used in the transmission to assure optimum transmission perfor- mance.
Page 533 532 MAINTAINING YOUR VEHICLE should not be tampered with. Your authorized dealer has the proper tools to ensure that the fluid level is set properly. The fluid level should be checked when the engine is fully warmed up and the fluid in the transmis- sion is at normal operating temperature.
Page 534 NOTE: If it is necessary to check the transmission below the operating temperature, the fluid level should be between the two “COLD” (lower) holes on the dipstick with the fluid at approximately 70°F (21°C) (room tem- perature). If the fluid level is correctly established at room temperature, it should be between the “HOT”...
Page 535: Appearance Care And Protection From Corrosion
534 MAINTAINING YOUR VEHICLE Special Additives Automatic Transmission Fluid (ATF) is an engineered product and its performance may be impaired by supple- mental additives. Therefore, do not add any fluid addi- tives to the transmission. The only exception to this policy is the use of special dyes to aid in detecting fluid leaks.
Page 536 Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using MOPAR Car Wash or equiva- lent, or a mild car wash soap and rinse the panels completely with clear water. • If insects, tar or other similar deposits have accumu- lated on your vehicle, use MOPAR Super Kleen Bug and Tar Remover or equivalent to remove.
Page 537 536 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, touch them up immediately. The cost of such repairs is considered the responsibility of the owner. • If your vehicle is damaged due to an accident or similar cause which destroys the paint and protective coating, have your vehicle repaired as soon as pos- sible.
Page 538 • Blot any remaining stain with a clean, damp towel. • For tough stains, apply MOPAR equivalent, or a mild soap solution to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. • For grease stains, apply MOPAR Cleaner or equivalent to a clean, damp cloth and remove stain.
Page 539 538 MAINTAINING YOUR VEHICLE Cleaning Headlights Your vehicle is equipped with plastic headlights and fog lights (if equipped) that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed.
Page 540: Fuses
Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. If the belts need cleaning, use a mild soap solution or lukewarm water.
Page 541 540 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 30 Amp Pink 30 Amp Pink 25 Amp Natural 40 Amp Green 30 Amp Pink 30 Amp Pink 25 Amp Natural 30 Amp Pink Description Cavity Cartridge Bat – Presafe #1/ CM2200 Bat –...
Page 542 Cavity Cartridge Mini Fuse Fuse 25 Amp Bat – Sunroof/ Natural Skylight 25 Amp TCM/Trans Range Natural 5 Amp Ign R/ACC – Sunroof/Window Sw Illum 25 Amp Frt Wiper Natural 25 Amp Door Locks Natural 20 Amp Fuel Pump Yellow 20 Amp Bat –...
Page 543 542 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 15 Amp Blue 15 Amp Blue 20 Amp Yellow 20 Amp Yellow 10 Amp 20 Amp Yellow 30 Amp Green 25 Amp Natural Description Cavity Cartridge Bat – NGC/EATX/ Bat – CCN/Interior Light/SCM/Sw Bank Htd Seat/Htd Str Wheel/Rear Htd Seat...
Page 544 Cavity Cartridge Mini Fuse Fuse 20 Amp IGN R/ACC-Pwr Yellow Outlet #2 20 Amp IGN R/ACC/Bat-Pwr Yellow Outlet #3 25 Amp ASD #1, #2 Natural 20 Amp ASD #3 Yellow 10 Amp IGN R/S-SWAY/ TCASE/DTCM/ FAD/TRLR BRAKE MOD. 15 Amp IGN R/S-MFSW/ Blue CNN/SCM/TPM/RR...
Page 545: Vehicle Storage
544 MAINTAINING YOUR VEHICLE VEHICLE STORAGE If you are storing your vehicle for more than 21 days, we recommend that you take the following steps to mini- mize the drain on your vehicle’s battery: • Disconnect the Ignition-Off Draw (IOD) fuse located in the Integrated Power Module, located in the engine compartment.
Page 546: Replacement Bulbs
REPLACEMENT BULBS LIGHT BULBS – Interior Overhead Console Lamps ....TS 212-2 Dome Lamp ......7679 NOTE: For lighted switches, see your authorized dealer for replacement instructions.
Page 547 546 MAINTAINING YOUR VEHICLE 4. Remove the two plastic push-in rivets that secure the upper radiator seal to the radiator. 5. Remove the upper radiator seal from the vehicle. 6. Remove the two headlamp assembly attachment screws. 7. Reach into the front wheel house ahead of the front wheel, remove the fastener, and lift the cover over the access hole in the front of the wheel house splash shield.
Page 548 9. Remove the headlamp assembly. Grasp the outboard edge of the lamp and pull it straight forward to disen- gage the ball stud from the plastic grommet. 10. Disconnect the wiring harness connectors from the bulb socket. 11. Replace bulb(s) as necessary. MAINTAINING YOUR VEHICLE 547 CAUTION! •...
Page 549: Fog Lamps
548 MAINTAINING YOUR VEHICLE Fog Lamps 1. Reach under and behind the front bumper to access the back of the front fog lamp housing. 2. Disconnect the fog lamp wiring harness connector from the fog lamp bulb. 3. Rotate the bulb counterclockwise bulb from the housing.
Page 550 2. Pull the outboard side of the lamp rearward far enough to unsnap the two receptacles on the outboard side of the lamp housing from the two plastic snap post retainers in the outer box side panel. 3. Disconnect the wiring harness connectors from the bulb socket.
Page 551: Center High-Mounted Stoplamp (Chmsl) With Cargo Lamp
550 MAINTAINING YOUR VEHICLE Center High-Mounted Stoplamp (CHMSL) With Cargo Lamp 1. Remove the two screws holding the housing/lens to the body as shown. 2. Separate the connector holding the housing and wir- ing harness to the body. 3. Turn the desired bulb socket socket and bulb from housing.
Page 552: Cab Top Clearance Lamps - If Equipped
CAUTION! Do not contaminate the bulb glass by touching it with your fingers or by allowing it to contact other oily surfaces. Shortened bulb life will result. • Outside Bulbs: Cargo Lamps MAINTAINING YOUR VEHICLE 551 • Inside Bulb: Center High-Mounted Stop Lamp 5.
Page 553 552 MAINTAINING YOUR VEHICLE 2. Rotate the socket ⁄ turn and pull it from the lamp assembly. 3. Pull the bulb straight from it’s socket and replace.
Page 554: Rear Lamp Bar Id Marker (Dual Rear Wheels) - If Equipped
Rear Lamp Bar ID Marker (Dual Rear Wheels) — If Equipped 1. Loosen the two screws and the housing to gain access to the bulb sockets. MAINTAINING YOUR VEHICLE 553 2. Turn the socket ⁄ turn counterclockwise to access the bulb.
Page 555: Side Marker Lamps (Dual Rear Wheels) - If Equipped
554 MAINTAINING YOUR VEHICLE Side Marker Lamps (Dual Rear Wheels) — If Equipped 1. Push rearward on the side marker lamp assembly. 2. Pull the entire assembly from the fender. 3. Turn the socket ⁄ turn counterclockwise and remove from assembly to access the bulb. 4.
Page 556: Fluid Capacities
FLUID CAPACITIES Fuel (Approximate) 1500 Regular Cab Shortbed/Crew Quad Cab Models 1500 Regular Cab Longbed/Crew Quad Cab Models (Optional) 2500/3500 Shortbed Models 2500/3500 Longbed Models Engine Oil with Filter 3.7L Engine (SAE 5W-20, API Certified) 4.7L Engine (SAE 5W-20, API Certified) 5.7L Engine (SAE 5W-20, API Certified) 5.7L Engine (SAE 5W-30, API Certified).
Page 557 556 MAINTAINING YOUR VEHICLE Cooling System 3.7L Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula or equivalent) 4.7L Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula or equivalent) 5.7L Engine — 1500 Models (MOPAR Antifreeze/ Coolant 5 Year/100,000 Mile Formula or equivalent) 5.7L Engine —...
Page 558: Engine
FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil – For 2500/3500 trucks operat- ing under a gross combined weight rating greater than 14,000 lbs/(6,350 kg.) Engine Oil Filter Spark Plugs – 3.7L Engine Spark Plugs – 4.7L Engine Spark Plugs –...
Page 559: Chassis
558 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Transfer Case Transfer Case – NVG 246 Only Front Axle – 1500 Four-Wheel Drive Models Rear Axle – 1500 Models Front and Rear Axle – 2500/3500 Models Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product.
Page 560 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..560 Maintenance Schedule ....560 Required Maintenance Intervals ..562...
Page 561 560 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 562 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicle’s oil if it has been six months since your last oil change even if the oil change indicator message is NOT illuminated.
Page 563 562 MAINTENANCE SCHEDULES Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of the coolant reservoir, brake master cylinder, and transmission and add as needed. •...
Page 564 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only). ❏ Inspect exhaust system (including isolators). Odometer Reading Date Repair Order #...
Page 565: Service Schedule
564 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only). ❏ Inspect the front and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road, snow plowing or frequent trailer towing.
Page 566 30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs (3.7L and 5.7L Engines). ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only).
Page 567 566 MAINTENANCE SCHEDULES 42,000 Miles (70,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only). ❏ Inspect exhaust system (including isolators).
Page 568 54,000 Miles (90,000 km) or 54 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only). ❏ Inspect the front and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road, snow plowing or frequent trailer towing.
Page 569 568 MAINTENANCE SCHEDULES 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Replace the engine air cleaner filter. ❏ Replace the ignition cables (3.7L Engine). ❏...
Page 570 66,000 Miles (110,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only). ❏ Inspect exhaust system (including isolators). Odometer Reading Date Repair Order #...
Page 571 570 MAINTENANCE SCHEDULES 78,000 Miles (130,000 km) or 78 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only). ❏ Inspect exhaust system (including isolators).
Page 572 90,000 Miles (150,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs (3.7L and 5.7L Engines). ❏ Inspect and replace PCV valve if necessary. † ❏...
Page 573 572 MAINTENANCE SCHEDULES 96,000 Miles (160,000 km) or 96 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter;...
Page 574 108,000 Miles (180,000 km) or 108 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. ❏...
Page 575 574 MAINTENANCE SCHEDULES 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Replace the engine air cleaner filter. ❏ Replace the ignition cables (3.7L Engine). ❏...
Page 576 126,000 Miles (210,000 km) or 126 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only). ❏ Inspect the front and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road, snow plowing or frequent trailer towing.
Page 577 576 MAINTENANCE SCHEDULES 138,000 Miles (230,000 km) or 138 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only). ❏ Inspect exhaust system (including isolators).
Page 578 150,000 Miles (250,000 km) or 150 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs (3.7L and 5.7L Engines). ❏ Lube the front drive shaft fitting (2500/3500 (4x4) models only).
Page 580: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......581 Prepare For The Appointment .
Page 581 580 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....585 Department Of Transportation Uniform Tire Quality Grades ......586 Treadwear .
Page 582: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 583: Chrysler Group Llc Customer Center
582 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 584: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 585: Warranty Information
584 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment when you purchased the vehicle. An authorized dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with the ownership experience.
Page 586: In Canada
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.
Page 587: Department Of Transportation Uniform Tire
586 IF YOU NEED CONSUMER ASSISTANCE vehicle, system, and/or components is written in straightforward language with illustrations, diagrams, and charts. • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 588: Treadwear
in each category is shown on the sidewall of the tires on your vehicle. All passenger car tires must conform to Federal safety requirements in addition to these grades. Treadwear The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 589 588 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 590 INDEX...
Page 591 590 INDEX Adding Engine Coolant (Antifreeze) ..523 Adding Fuel ......437 Adjustable Pedals .
Page 592 Fluid Level Check ....531,532 Fluid Type ......531,558 Gear Ranges .
Page 593 592 INDEX Power Steering ......379 Radiator (Coolant Pressure) ....524 Car Washes .
Page 594 Coolant Level ..... . 522,525 Disposal of Used Coolant ....525 Drain, Flush, and Refill .
Page 595 594 INDEX Electronic Brake Control System ... . . 384 Anti-Lock Brake System ....384 Brake Assist System .
Page 596 Exterior Lighting ......113 Exterior Lights ......84 Filters Air Cleaner .
Page 597 596 INDEX Octane Rating ..... . 428,557 Requirements ..... . 428,555 Saver Mode .
Page 598 Automatic ......113 Cleaning ......538 High Beam .
Page 599 598 INDEX Jack Location ......472 Jump Starting ......492 Key, Programming .
Page 600 Hazard Warning Flasher ....472 Headlights ......113 High Beam .
Page 601 600 INDEX Manual, Service ......585 Manual Transmission Fluid Level Check ..... 531 Lubricant Selection .
Page 602 Filter ......513,557 Filter Disposal ......513 Identification Logo .
Page 603 602 INDEX Sunroof ......149 Windows ......34 Power Steering Fluid .
Page 604 Restraints, Occupant ..... . 37 Rotation, Tires ......416 Safety Checks Inside Vehicle .
Page 605 604 INDEX Service Manuals ......585 Setting the Clock ....239,241,244,253 Settings, Personal .
Page 606 Sway Control, Trailer ..... 395 Synthetic Engine Oil ..... . 513 System, Remote Starting .
Page 607 606 INDEX Tow Hooks, Emergency ....497 Towing ....... 441 Disabled Vehicle .
Page 608 Uniform Tire Quality Grades ....586 Universal Consumer Interface (UCI) Connector . . . 265 Universal Transmitter ..... 142 Utility Rails, Rear Cargo Area .
Page 609 608 INDEX Windshield Defroster ..... . 82 Windshield Washers ....120,121,518 Fluid .
Page 610 Chrysler Group LLC 10D241-126-AC Printed in U.S.A. 3rd Edition...

Dodge 2010 Ram Truck Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

STARTING and OPERATING Transfer Case Position Indicator Light

Starting and Operating

Starting and Operating

Quick Links

Chapters

Related Manuals for Dodge 2010 Ram Truck

Summary of Contents for Dodge 2010 Ram Truck
