Page 3: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 5: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by a Warranty Information Booklet and various customer-oriented documents. You are urged to read these publications carefully.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
The Vehicle Identification Number (VIN) is on the left front corner of the instrument panel. The VIN is visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information VIN Location Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove the VIN.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) ... . 12 Fob With Integrated Key .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using The Panic Alarm ....22 Programming Additional Transmitters ..23 RKE Transmitter Battery Service .
Page 13 Event Data Recorder (EDR) ....61 Child Restraints ..... . 63 Engine Break-In Recommendations .
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Fob with Integrated Key and a Wireless Ignition Node (WIN) with integral ignition switch. You can insert the double-sided integrated key into the igni- tion switch with either side up.
Page 15: Fob With Integrated Key
Fob with Integrated Key The Fob with Integrated Key (FOBIK) operates the igni- tion switch. It also contains the Remote Keyless Entry (RKE) transmitter and a valet key, which stores in the rear of the Fob. The valet key allows for entry into the vehicle should the battery in the vehicle or the Fob go dead.
Page 16: Ignition Key Removal
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Ignition Key Removal Place the shift lever in PARK. Turn the key to the LOCK position and then remove the key. NOTE: The power window switches, radio, power sunroof (if equipped), and power outlets will remain active for up to 60 minutes after the ignition switch is turned to the LOCK position.
Page 17: Sentry Key Immobilizer System
NOTE: The Key-In-Ignition reminder only sounds when the ignition key is placed in the LOCK or ACC position. SENTRY KEY IMMOBILIZER SYSTEM The Sentry Key Immobilizer system prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exxon/Mobil Speedpass™, additional RKE transmit- ters, or any other transponder-equipped components on the same key chain will not cause a fault unless the additional part is physically held against the RKE transmitter being used to start the vehicle. Cell phones, pagers, or other Radio Frequency (RF) elec- tronics will not cause interference with this system.
Page 19: Customer Key Programming
Customer Key Programming If you have two valid RKE transmitters with integrated keys, you can program new RKE transmitters to the system by performing the following procedure: 1. Insert the first valid integrated key into the ignition switch and turn the ignition switch to the ON position for at least three seconds, but no longer than 15 seconds.
Page 20: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information The Sentry Key system complies with FCC rules Part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: This device may not cause harmful interference. This device must accept any interference that may be received, including interference that may cause undes- ired operation.
Page 21: To Disarm The System
To Disarm the System Either press the UNLOCK button on the RKE transmitter or insert a valid ignition key into the ignition switch and turn the key to the ON position. NOTE: The driver’s door key cylinder and the trunk button on the RKE transmitter cannot arm or disarm the system.
Page 22: Illuminated Entry System
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ILLUMINATED ENTRY SYSTEM The courtesy lights will turn on when you use the Remote Keyless Entry (RKE) transmitter or open any door. The lights will fade to off after about 30 seconds or they will immediately fade to off once the ignition switch is turned ON from the LOCK position.
Page 23: To Unlock The Doors
RKE Transmitter with Integrated Key To Unlock the Doors Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door, or twice within five seconds to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on.
Page 24: To Lock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Turn Headlights On with Remote Key Unlock This feature activates the headlights for up to 90 seconds when the doors are unlocked with the RKE transmitter. The time for this feature is programmable. Refer to “Turn Headlights On with Remote Key Unlock,”...
Page 25: Programming Additional Transmitters
NOTE: The interior lights will turn off if you turn the ignition switch to the ACC or ON position while the Panic Alarm is activated. However, the exterior lights and horn will remain on. You may need to be less than 35 ft (11 m) from the vehicle when using the transmitter to turn off the Panic Alarm due to the radio frequency noises emitted by the system.
Page 26: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Battery access is through a door located on the rear of the fob. Insert a small, flat blade screwdriver into the slot and gently pry open the access door. Battery Replacement 1—...
Page 27: Remote Starting System - If Equipped
If your transmitter fails to operate from a normal dis- tance, check for these two conditions: 1. A weak battery in the transmitter. The expected life of the battery is a minimum of three years. 2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios.
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Enter Remote Start Mode Press and release the REMOTE START button on the RKE transmitter twice, within five sec- onds. The parking lights will flash and the horn will honk twice (if programmed). Then, the engine will start and the vehicle will remain in the Remote Start mode for a 15-minute cycle.
Page 29: Door Locks
To Turn Off the Engine While in Remote Start Mode Press and release the REMOTE START button one time. NOTE: To avoid inadvertent shut downs, the system will disable the one time press of the REMOTE START button for two seconds after receiving a valid Remote Start request.
Page 30: Power Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! For personal security and safety in the event of an accident, lock the vehicle doors before you drive as well as when you park and leave the vehicle. When leaving the vehicle, always remove the key from the ignition and lock your vehicle.
Page 31 If you press the power door lock switch while the key is in the ignition, and any front door is open, the power locks will not operate. This prevents you from acciden- tally locking the key in the vehicle. Removing the key or closing the door will allow the locks to operate.
Page 32: Child Protection Door Lock
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. The transmission was in gear and the vehicle speed returned to 0 mph (0 km/h). 3. The transmission is in NEUTRAL or PARK. 4. The driver door is opened. 5. The doors were not previously unlocked, and 6.
Page 33 Child Lock Control 3. Repeat Steps 1 and 2 for the opposite rear door. NOTE: When the Child Protection Door Lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked position.
Page 34: Windows
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Disengage the Child Protection Door Lock System 1. Open the rear door. 2. Insert the tip of the valet key (or alike) into the child lock control and pull it downward. Child Lock Control 3.
Page 35 Power Window Switches There are single window controls on each passenger door trim panel, which operate the passenger door windows. The window controls will operate only when the ignition switch is in the ON or ACC position. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 WARNING! Never leave children in a vehicle with the key in the ignition switch.
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To stop the window from going all the way down during the AUTO-down operation, pull up on the switch briefly. The power window switches will remain active for up to 60 minutes after the ignition switch is turned OFF. Opening either front door will cancel this feature.
Page 37 Any impact due to rough road conditions may trigger the auto-reverse function unexpectedly during auto- closure. If this happens, pull the switch lightly to the first detent and hold to close the window manually. WARNING! There is no anti-pinch protection when the window is almost closed.
Page 38: Wind Buffeting
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Reset Anytime the vehicle battery is disconnected or goes dead, the AUTO-up function will be disabled. To reactivate the AUTO-up feature, perform the following procedure after vehicle power is restored: 1. Pull the window switch up to close window com- pletely and continue to hold the switch up for an additional two seconds after the window is closed.
Page 39: Trunk Lock And Release
TRUNK LOCK AND RELEASE The trunk lid can be released from inside the vehicle by pressing the TRUNK RELEASE button located on the instrument panel to the left of the steering wheel. NOTE: The transmission must be in PARK before the switch will operate.
Page 40: Trunk Safety Warning
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE TRUNK SAFETY WARNING WARNING! Do not allow children to have access to the trunk, either by climbing into the trunk from outside, or through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended.
Page 41: Lap/Shoulder Belts
and passengers seated next to a window, and the optional supplemental front seat-mounted side airbags. If you will be carrying children too small for adult-size belts, your seat belts also can be used to hold infant and child restraint systems. Please pay close attention to the information in this section.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE normal conditions. However, in a collision, the belt will lock and reduce your risk of striking the inside of the vehicle or being thrown out. WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the front seat. 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt.
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Inserting Latch Plate into Buckle WARNING! A belt that is buckled into the wrong buckle will not protect you properly.
Page 45 WARNING! (Continued) A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen.
Page 47: Lap/Shoulder Belt Untwisting Procedure
NOTE: When the shoulder belt is adjusted to the full downward position, it will not be at the bottom of the slot in the Trim Panel. This is normal and the intended lowest position. Adjusting Upper Shoulder Belt THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 As a guide, if you are shorter than average you will prefer a lower position, and if you are taller than average you will prefer a higher position.
Page 48: Seat Belt Pretensioners
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Slide the latch plate upward over the folded webbing. The folded webbing must enter the slot at the top of the latch plate. 4. Continue to slide the latch plate up until it clears the folded webbing.
Page 49 BeltAlert Programming The BeltAlert can be enabled or disabled by your authorized dealer or by performing the following steps: NOTE: Chrysler LLC does not recommend deactivating the BeltAlert . 1. With all doors closed, and the ignition switch in any position except ON or START, buckle the driver’s seat belt.
Page 50: Automatic Locking Mode - If Equipped
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Locking Mode — If Equipped In this mode, the shoulder belt is automatically pre- locked. However, the belt will still retract to remove slack in the shoulder belt. Use the Automatic Locking mode any time a child safety seat is installed in a seating position that has a seat belt with this feature.
Page 51: Driver And Front Passenger Supplemental Restraint System (Srs) - Airbag
dealer can provide you with a seat belt extender. This extender should be used only if the existing belt is not long enough. When it is not required, remove the ex- tender and store it. WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment. The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity.
Page 53 Window Airbag NOTE: Airbag covers may not be obvious in the interior trim, but they will open to allow airbag deployment. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 If the vehicle is equipped with supplemental front seat- mounted side airbags, they are marked with an SRS label sewn into the outboard side of the seat.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! If your vehicle is equipped with supplemental front seat-mounted side airbags, do not use acces- sory seat covers or place objects between you and the seat airbags; the performance could be ad- versely affected and/or objects could be pushed into you, causing serious injury.
Page 55 Along with the seat belts, front airbags work with the instrument panel knee bolsters to provide improved protection for the driver and front passenger. Side curtain and seat airbags also work with seat belts to improve occupant protection. While the seat belts are designed to protect you in many types of collisions, the front airbags will deploy in moderate to severe frontal collisions.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. If a child from 1 to 12 years old must ride in the front passenger seat because the vehicle is crowded, move the seat as far back as possible and use the proper child restraint. (Refer to information on Child Restraints in this section.) 5.
Page 57 Airbag System Components The airbag system consists of the following: Occupant Restraint Controller (ORC) Side Remote Acceleration Sensors (if equipped) Airbag Warning Light Driver Airbag Front Passenger Airbag Supplemental Side Curtain Airbags above Side Win- dows (if equipped) Supplemental Front Seat-Mounted Side Airbags (if equipped) Steering Wheel and Column Instrument Panel...
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The ORC also monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or ON positions. These include all of the items listed above except the knee bolster, the instru- ment panel, and the steering wheel and column.
Page 59 their full size. The bags fully inflate in about 50 to 70 ms. This is about half of the time that it takes to blink your eyes. The bags then quickly deflate while helping to restrain the driver and front passenger. The driver’s front airbag gas is vented through vent holes in the sides of the airbag.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE between the occupant and the door. The airbag inflates at a very high speed and with enough force to injure you if you are not belted and seated properly, or if items are positioned in the area where the front seat-mounted side airbag inflates.
Page 61 If a Deployment Occurs The airbag system is designed to deploy when the ORC detects a moderate to severe collision to help restrain the driver and front passenger and then to immediately deflate. NOTE: A frontal collision that is not severe enough to need airbag protection will not activate the system.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Deployed airbags can’t protect you in another colli- sion. Have the airbags replaced by an authorized dealer as soon as possible. Enhanced Accident Response System In the event of an impact that causes airbag deployment, with the vehicle stopped, and the vehicle communication network intact, and the power intact, the Enhanced Accident Response System performs the following func-...
Page 63: Event Data Recorder (Edr)
WARNING! (Continued) You need proper knee impact protection in a collision. Do not mount or locate any aftermarket equipment on or behind the knee impact bolster. It is dangerous to try to repair any part of the airbag system yourself. Be sure to tell anyone who works on your vehicle that it has airbags.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: 1. A near-deployment event occurs when the airbag sensor detects severe vehicle deceleration usually indica- tive of a crash, but not severe enough to warrant airbag deployment. 2. Under certain circumstances, EDR data may not be recorded (e.g., loss of battery power).
Page 65: Child Restraints
2. Used in defense of litigation involving a Chrysler LLC product. 3. Requested by police under a legal warrant. 4. Otherwise required by law. Data parameters that may be recorded: Diagnostic trouble code(s) and warning light status for electronically-controlled safety systems, including the airbag system Airbag disable light status (if equipped) Time of airbag deployment (in terms of ignition...
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children 12 years and younger should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front. WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle.
Page 67 infant carriers do, so they can be used rearward-facing by children who weigh more than 20 lbs (9 kg) but are less than one year old. Both types of child restraints are held in the vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children Too Large for Booster Seats Children who are large enough to wear the shoulder belt comfortably and whose legs are long enough to bend over the front of the seat when their back is against the seatback should use the lap/shoulder belt in a rear seat.
Page 69 Here are some tips on getting the most out of your child restraint: Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards. We also recommend that you make sure that you can install the child restraint in the vehicle where you will use it before you buy it.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE connection to the top tether anchorages have been avail- able for some time. For some older child restraints, many child restraint manufacturers offer add-on tether strap kits or retrofit kits. You are urged to take advantage of all the available attachments provided with your child re- straint in any vehicle.
Page 71 Again, carefully follow the installation instructions that are provided with the child restraint system. The rear seat lower anchorages are round bars located at the rear of the seat cushion where it meets the seatback and are just visible when you lean into the rear seat to install the child restraint.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Ensure that the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap. When using the LATCH attaching system to install a child restraint, please ensure that all seat belts not being used for occupant restraints are stowed and out of reach of children.
Page 73 Seat belts with an automatic locking retractor have a distinctive label on the seat belt webbing. The seat belt must be in the Automatic Locking mode in order to enable a child restraint to be tightly installed. Refer to “Automatic Locking Mode” in this section. A locking clip should not be necessary once the automatic locking feature is enabled.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To attach a child restraint tether strap: 1. Rotate the cover over the anchor directly behind the seat where you are placing the child restraint. Tether Strap Mounting 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.
Page 75: Engine Break-In Recommendations
Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.
Page 76: Safety Tips
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SAFETY TIPS Transporting Passengers NEVER TRANSPORT PASSENGERS IN THE CARGO AREA. WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seri- ously injured or killed.
Page 77: Safety Checks You Should Make Inside The Vehicle
If it is necessary to sit in a parked vehicle with the engine running, adjust your heating or cooling controls to force outside air into the vehicle. Set the blower at high speed. If you are required to drive with the trunk open, make sure that all windows are closed and the climate control BLOWER switch is set at high speed.
Page 78: Periodic Safety Checks You Should Make Outside The Vehicle
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE authorized dealer. If the light stays on, flickers, or comes on while driving, have the system checked by an autho- rized dealer. Defroster Check operation by selecting the defrost mode and place the blower control on high speed.
Page 79 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......81 Inside Day/Night Mirror ....81 Automatic Dimming Inside Mirror —...
Page 80 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information ....113 Voice Recognition System (VR) — If Equipped ......113 Voice Recognition System (VR) Operation .
Page 81 Windshield Wipers And Washers ..132 Intermittent Wiper System ....132 Mist Feature ......133 Windshield Washers .
Page 82 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Sunroof — If Equipped ... . 147 Opening Sunroof - Express ... . . 148 Closing Sunroof - Express .
Page 83: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 84: Automatic Dimming Inside Mirror
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Inside Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 85: Outside Mirrors Folding Feature - If Equipped
WARNING! Vehicles and other objects seen in the passenger-side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger-side convex mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the passenger-side convex mirror.
Page 86: Power Mirrors
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors The power mirror switch is located on the drivers door trim panel next to the power door lock switch. A rotary knob selects the left mirror, right mirror or off position. Power Mirror Control After selecting a mirror, move the knob in the same direction you want the mirror to move.
Page 87: Illuminated Vanity Mirrors - If Equipped
Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is located on the sun visor. To use the mirror, rotate the sun visor downward and swing the mirror cover upward. The light turns on automatically. Closing the mirror cover turns off the light. Illuminated Vanity Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 HANDS-FREE COMMUNICATION (UConnect ) —...
Page 88 For UConnect customer support, visit the NOTE: following websites: www.chrysler.com/uconnect www.dodge.com/uconnect www.jeep.com/uconnect or call 1–877–855–8400 UConnect allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone for private conversation.
Page 89: Operation
Voice Recognition Button Actual button location may vary with radio. The individual buttons are described in the “Operation” section. The UConnect system can be used with any Hands-Free Profile certified Bluetooth cellular phone. See the UConnect website for supported phones. If your cellu- lar phone supports a different profile (e.g., Headset Profile) you may not be able to use any UConnect features.
Page 90 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For each feature explanation in this section, only the combined form of the voice command is given. You can also break the commands into parts and say each part of the command when you are asked for it. For example, you can use the combined form voice com- mand Phonebook New Entry, or you can break the combined form command into two voice commands:...
Page 91 The following are general phone to UConnect system pairing instructions: Press the PHONE button to begin. After the Ready prompt and the following beep, say Setup Phone Pairing. When prompted, after the beep, say Pair a Phone and follow the audible prompts. You will be asked to say a four-digit Personal Identi- fication Number (PIN), which you will later need to enter into your cellular phone.
Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The system will prompt you to say the number you want to call. For example, you can say 234-567-8901 . The UConnect system will confirm the phone num- ber and then dial. The number will appear in the display of certain radios.
Page 93 When prompted, enter the number designation (e.g., Home, Work, Mobile, or Pager ). This will allow you to store multiple numbers for each phonebook entry, if desired. When prompted, recite the phone number for the phonebook entry that you are adding. After you are finished adding an entry into the phone- book, you will be given the opportunity to add more phone numbers to the current entry or to return to the...
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Depending on the maximum number of entries down- loaded, there may be a short delay before the latest downloaded names can be used. Until then, if available, previous downloaded phonebook is available for use. Only the phonebook of the currently connected mobile phone is accessible.
Page 95 If the phonebook entry is longer than 24 characters, it will only use the first 24 characters. Edit UConnect Phonebook Entries NOTE: Editing names in the phonebook is recommended when the vehicle is not in motion. Automatic downloaded phonebook entries cannot be deleted or edited.
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After the Ready prompt and the following beep, say Phonebook Delete. After you enter the Phonebook Delete menu, you will then be asked for the name of the entry that you wish to delete. You can either say the name of a phonebook entry that you wish to delete or you can say List Names to hear a list of the entries in the phonebook from which you choose.
Page 97: Phone Call Features
List All Names in the UConnect Phonebook Press the PHONE button to begin. After the Ready prompt and the following beep, say Phonebook List Names. The UConnect system will play the names of all the phonebook entries, including the downloaded phone- book entries, if available.
Page 98 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Answer or Reject an Incoming Call - Call Currently in Progress If a call is currently in progress and you have another incoming call, you will hear the same network tones for call waiting that you normally hear when using your cell phone.
Page 99 Three-Way Calling To initiate three-way calling, press the “Voice Recogni- tion” button while a call is in progress, and make a second phone call, as described under Making a Second Call While Current Call in Progress. After the second call has established, press and hold the PHONE button until you hear a double beep, indicating that the two calls have been joined into one conference call.
Page 100: Uconnect System Features
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After the ignition key is switched to OFF, a call can continue on the UConnect system for a certain dura- tion, after which the call is automatically transferred from the UConnect system to the mobile phone. An active call is automatically transferred to the mobile phone after the ignition key is switched to OFF.
Page 101 After the Ready prompt and the following beep, say Emergency and the UConnect system will instruct the paired cellular phone to call the emergency num- ber. This feature is supported in the U.S., Canada, and Mexico. NOTE: The emergency number dialed is based on the country where the vehicle is purchased (911 for the U.S.
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The Towing Assistance number dialed is based on the country where the vehicle is purchased (1-800-528- 2069 for the U.S., 1-877-213-4525 for Canada, 55-14- 3454 for Mexico City and 1-800-712-3040 for outside Mexico City in Mexico).
Page 103 numbers, followed by Send, is also to be used for navigating through an automated customer service cen- ter menu structure, and to leave a number on a pager. You can also send stored UConnect phonebook entries as tones for fast and easy access to voice mail and pager entries.
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone and Network Status Indicators If available on the radio and/or on a premium display such as the instrument panel cluster, and supported by your cell phone, the UConnect notification to inform you of your phone and network status when you are attempting to make a phone call using UConnect .
Page 105: Advanced Phone Connectivity
Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect system allows ongoing calls to be trans- ferred from your cellular phone to the UConnect system without terminating the call. To transfer an ongoing call from your UConnect paired cellular phone to the UConnect system or vice versa, press the “Voice Recog- nition”...
Page 106: Things You Should Know About Your Uconnect System
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Select Another Cellular Phone This feature allows you to select and start using another phone paired with the UConnect system. Press the PHONE button to begin. After the Ready prompt and the following beep, say Setup Select Phone and follow the prompts.
Page 107 Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the UConnect system Voice Training feature may be used. To enter this training mode, follow one of the two following proce- dures: From outside the UConnect mode (e.g., from radio mode): Press and hold the “Voice Recognition”...
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Performance is maximized under: low-to-medium blower setting, low-to-medium vehicle speed, low road noise, smooth road surface, fully closed windows, dry weather condition. Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some.
Page 109 Far End Audio Performance Audio quality is maximized under: low-to-medium blower setting, low-to-medium vehicle speed, low road noise, smooth road surface, fully closed windows, dry weather conditions, and operation from the driver’s seat. Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the UConnect system.
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109...
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 113 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again Voice Commands Primary Alternate(s) redial return to main menu return or main menu select phone...
Page 115: Understanding The Features Of Your Vehicle 113
General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When you press the VR hard-key, you will hear a beep. The beep is your signal to give a command. NOTE: If you do not say a command within a few seconds, the system will present you with a list of options.
Page 117: Commands
Commands The Voice Recognition System understands two types of commands. Universal commands are available at all times. Local commands are available if the supported radio mode is active. Changing the Volume 1. Start a dialogue by pressing the VR hard-key. 2.
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio FM To switch to the FM band say FM or RADIO FM. In this mode, you may say the following commands: FREQUENCY (to change the frequency) NEXT STATION (to select the next station) PREVIOUS STATION (to select the previous station) RADIO MENU (to switch to the radio menu) MAIN MENU (to switch to the main menu)
Page 119 Memo To switch to the voice recorder mode say MEMO. In this mode, you may say the following commands: NEW MEMO (to record a new memo) — During the recording you may press the VR hard-key to stop recording. You proceed by saying one of the following commands: −...
Page 120: Voice Training
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the UConnect system Voice Training feature may be used. 1. Press the VR hard-key, speak “System Setup” and once you are in that menu then speak “Voice Training.”...
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.
Page 122: Power Reclining Seats
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Reclining Seats The recliner control is located on the outboard side of the seat. Power Seat Recline Switch WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured.
Page 123: Head Restraints
Lumbar Support Control Lever Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear. Adjust the restraint so that the upper edge is as high as practical. To raise it, pull UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 upward on the head restraint.
Page 124: Heated Seats
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats This feature heats the front driver, passenger, and second row seats. The controls for each heater are located near the bottom center of the instrument panel. Front Heated Seat Switch After turning the ignition ON, Press the switch once to select High level heating.
Page 125: Folding Rear Seat
WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, ex- haustion, or other physical conditions must exer- cise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods.
Page 126: To Open And Close The Hood
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious injury.
Page 127: Lights
2. Move to the outside of the vehicle and push the safety catch to the left. The safety catch is located under the center front edge of the hood. Hood Safety Catch Use the hood prop rod (if equipped) to secure the hood in the open position.
Page 128: Automatic Headlights - If Equipped
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ment panel lights, instrument panel light dimming, inte- rior lights and fog lights. Headlight Switch Rotate the headlight switch clockwise to the first detent for parking light and instrument panel light operation. Rotate the headlight switch to the second detent for headlight, park light, and instrument panel light operation.
Page 129: Headlight Time Delay
The Headlights On with Wipers feature can be enabled or disabled. Refer to ”Headlights On with Wipers,” under “Personal Settings (Customer-Programmable Features)” under “Electronic Vehicle Information Center” in Section 4. Headlight Time Delay This feature provides the safety of headlight illumination for up to 90 seconds (programmable) when leaving your vehicle in an unlit area.
Page 130: Fog Lights
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fog Lights The front fog light switch is built into the head- light switch. To activate the front fog lights, turn on the parking lights or the low beam headlights and press the headlight switch. To turn off the front fog lights, either press headlight switch again or turn off the headlight switch.
Page 131 Turn Signals Move the multifunction lever up or down and the corresponding turn signal indicator in the instrument cluster flashes to show proper operation of the front and rear turn signal lights. You can also signal a lane change by moving the lever partially up or down without moving beyond the detent.
Page 132: Overhead Console Map/Reading Lights
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Overhead Console Map/Reading Lights These lights are mounted between the sun visors on the overhead console. Each light is turned on by pressing the lens. Press the lens a second time to turn off the light. These lights also turn on when a door is opened, or when the UNLOCK button on the Remote Keyless Entry (RKE) transmitter is pressed, or when the dimmer control is...
Page 133: Interior Lights
Interior Lights The interior lights come on when a door is opened. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position. This will occur if the interior lights were switched on manually or are on because a door is open.
Page 134: Windshield Wipers And Washers
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS The multifunction lever operates the windshield wipers and washer when the ignition switch is in the ON position. The multifunction lever is lo- cated on the left side of the steering column. Windshield Wiper/Washer Control Rotate the end of the multifunction lever to the first detent past the intermittent settings for low speed wiper...
Page 135: Mist Feature
regulate the wipe interval from a minimum of one cycle every second to a maximum of approximately 23 seconds between cycles. WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with the defroster before and during windshield washer use.
Page 136: Tilt/Telescoping Steering Column
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE addition, the headlights will turn off when the wipers are turned off if they were turned on by this feature. The Headlights On with Wipers feature can be enabled or disabled. Refer to ”Headlights On with Wipers,” under “Personal Settings (Customer-Programmable Features)”...
Page 137: Adjustable Pedals - If Equipped
WARNING! Do not adjust the steering wheel while driving. The telescoping adjustment must be locked while driv- ing. Adjusting the steering wheel while driving or driving without the telescoping adjustment locked could cause the driver to lose control of the vehicle. ADJUSTABLE PEDALS —...
Page 138: Electronic Speed Control
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The pedals can be adjusted while driving. The pedals cannot be adjusted when the transmission is in REVERSE or when the speed control is on. CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls.
Page 139: To Activate
To Activate Push and release the ON/OFF button located on the end of the Electronic Speed Control lever. The indicator light in the instrument cluster will illuminate to show that the speed control system is on. To turn the system off, push and release the ON/OFF button again.
Page 140: To Deactivate
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Deactivate The system will disable Electronic Speed Control without erasing the memory if you: Softly tap the brake pedal, Depress the brake pedal, or Pull the Electronic Speed Control lever toward you to CANCEL.
Page 141: To Accelerate For Passing
Tapping the Electronic Speed Control lever to SET DE- CEL once will result in a 1 mph (1.6 km/h) speed decrease. Each time the Electronic Speed Control lever is tapped, speed decreases. To Accelerate For Passing Depress the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed.
Page 142: Overhead Console
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE OVERHEAD CONSOLE The overhead console contains courtesy/reading lights, an optional universal garage door opener (HomeLink ), storage for sunglasses, and an optional power sunroof switch. Overhead Console Courtesy/Reading Lights At the forward end of the console are two courtesy/ reading lights.
Page 143: Garage Door Opener - If Equipped
GARAGE DOOR OPENER — IF EQUIPPED HomeLink replaces up to three remote controls (hand- held transmitters) that operate devices such as garage door openers, motorized gates, lighting, or home security systems. The HomeLink unit operates off your vehicle’s battery. The HomeLink buttons are located in the overhead console, and contain one, two, or three dots/lines desig- nating the different HomeLink channels.
Page 144: Programming Homelink
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. Only use this trans- ceiver with a garage door opener that has a “stop and reverse”...
Page 145 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) from the HomeLink buttons while keeping the EVIC display in view. For optimal training, point the battery end of the hand- held transmitter away from the HomeLink . 3.
Page 146 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This can usually be found where the hanging antenna wire is attached to the garage door opener motor (it is NOT the button normally used to open and close the door). 1 — Garage Door Opener 2 —...
Page 147: Gate Operator/Canadian Programming
Gate Operator/Canadian Programming Canadian radio-frequency laws require transmitter sig- nals to “time-out” (or quit) after several seconds of transmission – which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U.S. gate operators are designed to “time-out”...
Page 148: Reprogramming A Single Homelink Button
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reprogramming A Single HomeLink Button To reprogram a channel that has been previously trained, follow these steps: 1. Turn the ignition switch to the ON/RUN position. 2. Press and hold the desired HomeLink button for 20 seconds until the EVIC display states “CHANNEL # TRAINING.”...
Page 149: General Information
General Information This device complies with FCC rules Part 15 and Industry Canada RSS-210. Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference that may be received including interference that may cause undesired operation NOTE: The transmitter has been tested and it complies...
Page 150: Opening Sunroof - Express
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death.
Page 151: Pinch Protect Override
sunroof will automatically retract. Remove the obstruc- tion if this occurs. Next, press the power sunroof switch forward and release to Express Close. Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing, press the power sunroof switch forward and hold for two seconds after the reversal occurs.
Page 152: Sunroof Maintenance
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunroof Maintenance Use only a nonabrasive cleaner and a soft cloth to clean the glass panel. Ignition Off Operation The power sunroof switch will remain active for up to 60 minutes after the ignition switch is turned OFF. Opening either front door will cancel this feature.
Page 153 NOTE: If desired, the power outlet next to the ash receiver tray (if equipped) can be converted by your authorized dealer to provide power with the ignition switch in the LOCK position. Front Power Outlet UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 The center console outlet is powered directly from the battery (power available at all times).
Page 154: Electrical Outlet Use With Engine Off
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Electrical Outlet Use With Engine Off CAUTION! Many accessories that can be plugged in draw power from the vehicle’s battery even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent engine starting.
Page 155: Cupholders
CUPHOLDERS Front Seat Cupholders The cupholders are located in the forward edge of the center console. Front Seat Cupholders UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Rear Seat Cupholders The rear seat cupholders are located in the center armrest between the rear seats. The cupholders are positioned forward in the armrest and side-by-side to provide convenient access to beverage cans or bottles while maintaining a resting place for the rear occupants elbows.
Page 156: Storage
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Console Features The center console contains two shift bezel cubby bins with rubber mats for holding small items. For vehicles not equipped with navigation radio, the console also contains an extra storage bin located below the climate control, which holds up to four CD jewel cases.
Page 157: Cargo Area - Vehicles Equipped With 60/40
The top compartment holds small items, such as a pen and note pad, while the larger bottom compartment will hold CDs and alike. The bottom compartment also con- tains a 12 Volt power outlet and a molded-in coin holder (designed to hold various size coins). A slot in the left and right side of the top compartment provides clearance for power cords to pass conveniently out of the bin with the lid closed.
Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious injury.
Page 159: Rear Window Features
REAR WINDOW FEATURES Electric Rear Window Defroster The Electric Rear Window Defroster button is located on the climate control. Press this button to turn on the rear window defroster and the heated outside rearview mirrors (if equipped). An indicator in the button will illuminate when the rear window defroster is on.
Page 161 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....163 Premium Instrument Cluster ... . . 164 Instrument Cluster Descriptions .
Page 162 160 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - (Disc Mode For CD And MP3/WMA Audio Play, DVD-Video) . . . 199 Notes On Playing MP3/WMA Files ..201 List Button (Disc Mode For MP3/WMA Play) .
Page 163 List Button (CD Mode For MP3 Play) ..228 Info Button (CD Mode For MP3 Play) ..229 Universal Consumer Interface (UCI) — If Equipped ......230 Connecting The iPod .
Page 164 162 UNDERSTANDING YOUR INSTRUMENT PANEL Sirius Backseat TV™ — If Equipped ..241 Video Entertainment System (VES)™ — If Equipped ......242 Kicker Mobile Surround (KMS1) –...
Page 165: Instrument Panel Features
INSTRUMENT PANEL FEATURES 1 - Air Outlet 2 - Instrument Cluster 3 - HAZARD Switch 4 - Electronic Stability Program OFF Button* 5 - Glove Compartment 6 - Radio UNDERSTANDING YOUR INSTRUMENT PANEL 163 7 - Climate Control 8 - HEATED SEAT Switch* 9 - Power Outlet 10 - Ash Tray* 11 - Storage Compartment*...
Page 166: Premium Instrument Cluster
164 UNDERSTANDING YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER...
Page 167: Instrument Cluster Descriptions
INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when the ignition switch is in the ON position. 2. Trip Odometer Button Press this button to change the display from odometer to either of two trip odometer settings.
Page 168 166 UNDERSTANDING YOUR INSTRUMENT PANEL 7. Electronic Throttle Control (ETC) Light This light will turn on briefly as a bulb check when the ignition switch is turned ON. This light will also turn on while the engine is running if there is a problem with the Elec- tronic Throttle Control (ETC) system.
Page 169 CAUTION! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads 240°F (116°C) or greater, pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range 200– 230°F (93–110°C).
Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL 11. Engine Temperature Warning Light This light will turn on and a single chime will sound to warn of an overheated engine condition. When this light turns on, the engine temperature is critically hot. The vehicle should be turned OFF immediately and serviced as soon as possible.
Page 171 15. High Beam Light This light will turn on when the high beam headlights are ON. Push the multifunction lever away from the steering wheel to switch the headlights to high beam. 16. Seat Belt Reminder Light This light will turn on for five to eight seconds as a bulb check when the ignition switch is first turned ON.
Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL 20. Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on, it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the anti-lock brake system reservoir.
Page 173 WARNING! Driving a vehicle with the brake light on is danger- ous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have an accident. Have the vehicle checked immediately. Vehicles equipped with the Anti-Lock Brake System (ABS), are also equipped with Electronic Brake Force Distribution (EBD).
Page 174 172 UNDERSTANDING YOUR INSTRUMENT PANEL As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under-inflated. Accordingly, when the low tire pressure telltale illumi- nates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure.
Page 175 CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system opera- tion or sensor damage may result when using re- placement equipment that is not of the same size, type, and/or style.
Page 176: Electronic Vehicle Information Center (Evic)
174 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD. The OBD system monitors engine and automatic transmission control systems. The MIL will turn on when the key is in the ON position before engine start.
Page 177 This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel. The EVIC consists of the following: System status Vehicle information warning message displays Tire Pressure Monitor System Personal settings (customer programmable features) Compass display Outside temperature display Trip computer functions,...
Page 178: Electronic Vehicle Information Center (Evic) Displays
176 UNDERSTANDING YOUR INSTRUMENT PANEL Press the FUNCTION SELECT button to accept a selection. The FUNCTION SELECT button also functions as a remote sound system con- trol. Refer to “Remote Sound System Controls” FUNC- in this section. TION SELECT Button Press the SCROLL button to scroll through Trip Functions, Performance Pages (if equipped), Navigation (if equipped), System Status Mes-...
Page 179 Right Front Turn Signal Light Out (with a single chime) Right Rear Turn Signal Light Out (with a single chime) RKE Battery Low (with a single chime) Personal Settings Not Available – Vehicle Not in PARK Left/Right Front Door Ajar (one or more, with a single chime if speed is above 1 mph [1.6 km/h]) Left/Right Rear Door Ajar (one or more, with a single chime if speed is above 1 mph [1.6 km/h])
Page 180: Trip Functions
178 UNDERSTANDING YOUR INSTRUMENT PANEL Check TPM System (with a single chime). Refer to “Starting And Operating, Tire Section” Check Gascap (refer to “Adding Fuel” in Section 5) Insert Key/Turn To Run (refer to “Remote Starting System” in Section 2) Upshift Stereo (if equipped with Driver-Selectable Surround Sound [DSS])
Page 181 Trip B Elapsed Time Display Units of Measure in Press the SCROLL button to cycle through all the Trip Computer functions. The Trip Functions mode displays the following. Average Fuel Economy Shows the average fuel economy since the last reset. When the fuel economy is reset, the display will read “RESET”...
Page 182: Performance Pages - If Equipped
180 UNDERSTANDING YOUR INSTRUMENT PANEL Trip B Shows the total distance traveled for Trip B since the last reset. Elapsed Time Shows the total elapsed time of travel since the last reset when the ignition switch is in the ACC position. Elapsed time will increment when the ignition switch is in the ON or START position.
Page 183 The Performance Pages include the following features: 0-60 mph (0-100 km/h) Braking Distance 1/8 Mile 1/4 Mile Instantaneous G-Force Peak G-Force Digital Speedometer To access, press and release the MENU button until Performance Pages displays in the EVIC. Press the SCROLL button to cycle through the features.
Page 184 182 UNDERSTANDING YOUR INSTRUMENT PANEL Braking Distance When selected, this screen displays the vehicle’s braking distance and the speed at which the brake pedal was depressed. This feature will only function when applying the brakes at speeds above 30 mph (48 km/h). Engaging the parking brake will disable this feature.
Page 185 The time and speed will continue to display until the FUNCTION SELECT button is pressed. Pressing the FUNCTION SELECT button will clear the current run and display the vehicle’s best 1/8 mile (1/4 mile) run. To clear the vehicle’s best 1/8 mile (1/4 mile) run, press and hold the FUNCTION SELECT button for five seconds.
Page 186: Compass Display
184 UNDERSTANDING YOUR INSTRUMENT PANEL Compass Display The compass readings indicate the direction the vehicle is facing. Press and release the COMPASS button to display one of eight com- pass readings and the outside temperature. COM- PASS Button Automatic Compass Calibration This compass is self-calibrating, which eliminates the need to set the compass manually.
Page 187 Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences, the variance should be set for the zone where the vehicle is driven, per the zone map. Once properly set, the compass will automatically compensate for the differences, and provide the most accurate compass heading.
Page 188: Navigation - If Equipped
186 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Press and release the FUNCTION SELECT button until the proper variance zone is selected, according to the map. 5. Press and release the compass button to exit. Navigation — If Equipped Navigation Display Control Press and release the MENU button until Navigation displays in the EVIC.
Page 189: System Warnings (Customer Information Features)
Audio Surround While in the Surround Sound menu, press the FUNC- TION SELECT button to change surround modes. The Video Surround Mode will only be available for video media sources (DVDs, Video CDs, or other video media supported by the radio). System Warnings (Customer Information Features) Press and release the MENU button until “SYSTEM...
Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL select English, Espanol, Deutsch, Italiano, or Francais. Then, as you continue, the information will display in the selected language. NOTE: The EVIC will not change the UConnect lan- guage selection. Refer to “Language Selection” under “Hands-Free Communication (UConnect )”...
Page 191 “Flash Lights with Remote Key Lock” When ON is selected, the front and rear turn signals will flash when the doors are locked or unlocked with the RKE transmitter. This feature may be selected with or without the sound horn on lock feature selected. To make your selection, press and release the FUNCTION SE- LECT button until “ON”...
Page 192 190 UNDERSTANDING YOUR INSTRUMENT PANEL “Delay Power Off to Accessories Until Exit” When this feature is selected, the power WINDOW switches, radio, hands-free system (if equipped), DVD video system (if equipped), power sunroof (if equipped), and power outlets will remain active for up to 60 minutes after the ignition switch is turned OFF.
Page 193: Sales Code Req - Am/Fm Stereo Radio And 6-Disc Cd/Dvd Changer (Mp3/Wma Aux Jack)
SALES CODE REQ — AM/FM STEREO RADIO AND 6–DISC CD/DVD CHANGER (MP3/WMA AUX JACK) NOTE: The radio sales code is located on the lower right side of the radio faceplate. REQ Radio UNDERSTANDING YOUR INSTRUMENT PANEL 191 Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 194 192 UNDERSTANDING YOUR INSTRUMENT PANEL to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection. Holding either button will bypass stations without stopping until you release it. SCAN Button Pressing the SCAN button causes the tuner to search for the next listenable station, in AM, FM or Satellite (if...
Page 195 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side TUNE/ SCROLL control knob. Press the TUNE/SCROLL control knob to save the time change. 5.
Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the treble tones. Push the rotary TUNE/SCROLL control knob a fourth time and BALANCE will display.
Page 197 16-Digit Character Program Type Jazz News Nostalgia Nostalga Oldies Personality Public Rhythm and Blues Religious Music Rel Musc Religious Talk Rock Soft Soft Rock Soft Rck Soft Rhythm and Blues Soft R & B UNDERSTANDING YOUR INSTRUMENT PANEL 195 Program Type Display Jazz Sports...
Page 198 196 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button Pressing the SETUP button allows you to select between the following items: NOTE: Turn the TUNE/SCROLL control knob to scroll through the entries. Push the AUDIO/SELECT button to select an entry and make changes. DVD Enter - When the disc is in DVD Menu mode, selecting DVD Enter will allow you to play the current highlighted selection.
Page 199 VES™ Power - Allows you to turn VES™ ON and OFF (if equipped). VES™ Lock - Locks out rear VES™ remote controls (if equipped). VES™ CH1/CH2 - Allows the user to change the mode of either the IR1 or IR2, wireless headphones by pressing the AUDIO/SELECT button (if equipped).
Page 200 198 UNDERSTANDING YOUR INSTRUMENT PANEL Subtitle Language — If Equipped Selecting this item allows you to choose a default subtitle language (effective only if the language is supported by the disc). You can select a language not listed by scrolling down and selecting other.
Page 201: Understanding Your Instrument Panel 199
and press and release that button. If a button is not selected within five seconds after pressing the SET but- ton, the station will continue to play but will not be stored into pushbutton memory. You may add a second station to each pushbutton by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window.
Page 202 200 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! The radio may shut down during extremely hot conditions. When this occurs, the radio will indicate “Disc Hot” and shut off until a safe temperature is reached. This shutdown is necessary to protect the optics of the DVD player and other radio internal components.
Page 203: Notes On Playing Mp3/Wma Files
SEEK Button (CD MODE) Press the right SEEK button for the next selection on the CD. Press the left SEEK button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first second of the current selection.
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
Page 205 frequencies in the following table are supported. In addition, variable bit rates (VBR) are also supported. The majority of MP3/WMA files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates. MPEG Sampling Fre- Specification quency (kHz) MPEG-1 Audio...
Page 206: List Button (Disc Mode For Mp3/Wma Play)
204 UNDERSTANDING YOUR INSTRUMENT PANEL Number of files and folders - Loading times will increase with more files and folders To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once”...
Page 207 Pressing the AUX button will change the mode to auxil- iary device if the AUX jack is connected. NOTE: The AUX device must be turned on and the device’s volume set to the proper level. If the AUX audio is not loud enough, turn the device’s volume up. If the AUX audio sounds distorted, turn the device’s volume down.
Page 208: Am/Fm/Cd/Dvd Multimedia System Radio (Rer/Ren) - If Equipped
206 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Hands-Free Phone (UConnect ) (If Equipped) Refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions - Satellite Radio Mode (If Equipped) Refer to “Satellite Radio” in this section. Operating Instructions - Video Entertainment System (VES)™...
Page 209: Operating Instructions - Voice Recognition System (Vr) - If Equipped
(HDD). Sirius Satellite Radio is optional. The 6.5 in (16.5 cm) touch screen allows for easy menu selection. The RER radio also contains a Global Positioning System (GPS)-based Navigation system. Refer to your Multimedia system (REN) or Navigation (RER) user’s manual for detailed operating instructions. Operating Instructions —...
Page 210 208 UNDERSTANDING YOUR INSTRUMENT PANEL 4. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed.
Page 211: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
Changing the Time Zone 1. Turn on the multimedia system. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen.
Page 212: Operating Instructions - Radio Mode
210 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the On/Volume control knob to turn on the radio. Push the On/Volume control knob a second time to turn off the radio.
Page 213 4. Adjust the minutes using the right side Tune/Scroll control knob. Press the Tune/Scroll control knob to save time change. 5. To exit, press any button/knob, or wait five seconds. RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows.
Page 214: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
212 UNDERSTANDING YOUR INSTRUMENT PANEL AM/FM Button Press the buttons to select either AM or FM mode. SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button.
Page 215 This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up.
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF.
Page 217: Notes On Playing Mp3 Files
Press the RND button a second time to stop Random Play. Notes on Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions.
Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal CD audio tracks and computer files (including MP3 files). Discs created with an option such as keep disc open after writing are most likely multisession discs.
Page 219: Operation Instructions - Auxiliary Mode
Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files. Loading times for playback of MP3 files may be affected by the following: Media - CD-RW media may take longer to load than...
Page 220: Sales Code Res/Rsc - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
218 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RES/RSC — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) AND SIRIUS RADIO NOTE: The radio sales code is located on the lower right side of the radio faceplate. RES/RSC Radio Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 221 SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL 3. After adjusting the hours, press the right side Tune/ Scroll control knob to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side Tune/Scroll control knob. Press the Tune/Scroll control knob to save time change.
Page 223 Push the rotary Tune/Scroll control knob a second time and MID will display. Turn the Tune/Scroll control knob to the right or left to increase or decrease the mid-range tones. Push the rotary Tune/Scroll control knob a third time and TREBLE will display.
Page 224 222 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type Foreign Language Information Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Religious Music Religious Talk Rock Soft Soft Rock 16-Digit Character Display Language Soft Rhythm and Blues Inform Jazz News Nostalga Oldies By pressing the SEEK button when the Music Type icon Persnlty is displayed, the radio will be tuned to the next frequency...
Page 225 SETUP Button Pressing the SETUP button allows you to select between the following items: Set Clock — Pressing the SELECT button will allow you to set the clock. Turn the Tune/Scroll control knob to adjust the hours and then press and turn the Tune/Scroll control knob to adjust the minutes.
Page 226: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
224 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions — CD MODE for CD and MP3 Audio Play NOTE: The ignition switch must be in the ON or ACC position to operate the radio. This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks.
Page 227 EJECT Button - Ejecting a CD Press the EJECT button to eject the CD. If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF.
Page 228: Notes On Playing Mp3 Files
226 UNDERSTANDING YOUR INSTRUMENT PANEL SET/RND Button (Random Play Button) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace. Press the right SEEK button to move to the next ran- domly selected track.
Page 229 Maximum number of characters in file/folder names: Level 1: 12 (including a separator . and a three- character extension) Level 2: 31 (including a separator . and a three- character extension) Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal CD audio tracks and computer files (including MP3 files).
Page 230: List Button (Cd Mode For Mp3 Play)
228 UNDERSTANDING YOUR INSTRUMENT PANEL ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios. Playlist files are not supported. MP3 Pro files are not supported.
Page 231: Info Button (Cd Mode For Mp3 Play)
INFO Button (CD Mode for MP3 Play) Pressing the INFO button repeatedly will scroll through the following TAG information: Song Title, Artist, File Name, and Folder Name (if available). Press the INFO button once more to return to elapsed time priority mode. Press and hold the INFO button for three seconds or more and the radio will display song titles for each file.
Page 232: Universal Consumer Interface (Uci) - If Equipped
230 UNDERSTANDING YOUR INSTRUMENT PANEL UNIVERSAL CONSUMER INTERFACE (UCI) — IF EQUIPPED NOTE: This section is for sales code RES and REQ/ REL/RET radios only with UConnect . For sales code RER, REN and REZ touch-screen radio UCI feature, refer to the separate RER, REN or REZ User’s Manual.
Page 233: Using This Feature
If the iPod battery is completely discharged, it may not communicate with the UCI system until a mini- mum charge is attained. Leaving the iPod connected to the UCI system may charge it to the required level. Using This Feature By using the optional connection cable to connect an iPod to the vehicle’s UCI 16–pin connector port: The iPod audio can be played on the vehicle’s sound...
Page 234 232 UNDERSTANDING YOUR INSTRUMENT PANEL Jump backward in the current track by pressing and holding the << RW button. Holding the << RW button long enough will take you to the beginning of the current track. Jump forward in the current track by pressing and holding the FF >>...
Page 235: List Or Browse Mode
RND button (available on sales code RES radio only): Pressing this button toggles between Shuffle ON and Shuffle OFF modes for the iPod . If the RND icon is showing on the radio display, then the shuffle mode is List Or Browse Mode During Play mode, pressing any of the buttons described below, takes you to List mode.
Page 236 234 UNDERSTANDING YOUR INSTRUMENT PANEL Pressing a PRESET button, will display the current list on the top line and the first item in that list on the second line. To Exit List mode without selecting a track, press the same PRESET button again to go back to Play mode.
Page 237: Satellite Radio - If Equipped (Ren/Req/Rer/Res/Reu Radios Only)
SATELLITE RADIO — IF EQUIPPED (REN/REQ/RER/RES/REU RADIOS ONLY) Satellite radio uses direct satellite-to-receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius Satellite Radio. This service offers over 130 channels of music, sports, news, entertainment, and programming for chil- dren, directly from its satellites and broadcasting studios.
Page 238: Selecting Satellite Mode
236 UNDERSTANDING YOUR INSTRUMENT PANEL Sirius ID number will display. The Sirius ID number display will time out in two minutes. Press any button on the radio to exit this screen. ESN/SID Access With REN/RER Radios While in SAT mode, press the MENU button on the radio faceplate.
Page 239: Operating Instructions - Satellite Mode
Dense tree coverage may interrupt reception in the form of short audio mutes. Driving under wide bridges or along tall buildings can cause intermittent reception. Placing objects over or too close to the antenna can cause signal blockage. Operating Instructions — Satellite Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 240 238 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next channel in the direction of the arrows. TUNE Control (Rotary) Turn the rotary Tune/Scroll control knob clockwise to increase or counterclockwise to decrease the channel.
Page 241 SETUP Button Pressing the SETUP button allows you to select the following items: Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription. SET Button –...
Page 242: Operating Instructions - Hands-Free Phone (If Equipped)
240 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Hands-Free Phone (If Equipped) Refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions — Video Entertainment System (VES)™ (If Equipped) Refer to separate “Video Entertainment System (VES)™ Guide.” KICKER HIGH PERFORMANCE SOUND SYSTEM WITH DRIVER-SELECTABLE SURROUND (DSS) –...
Page 243: Sirius Backseat Tv™ - If Equipped
“Audio Surround” is optimized for front seat passengers for any audio source. This surround effect is available for audio from any source – AM/FM/CD/ Satellite Radio or AUX – and is activated through the Electronic Vehicle Information Center (EVIC). Refer to “Driver-Selectable Surround Sound (DSS)”...
Page 244: Video Entertainment System (Ves)™ - If Equipped
242 UNDERSTANDING YOUR INSTRUMENT PANEL VIDEO ENTERTAINMENT SYSTEM (VES)™ — IF EQUIPPED The optional Video Entertainment System (VES)™ in- cludes the following components for rear seat entertain- ment: A diagonal 7 in (17.8 cm) Liquid Crystal Display (LCD) screen integrated into the center console armrest. The screen features brightness control for optimum day- time and nighttime viewing.
Page 245 The LCD screen swings up from the rear of the armrest to allow the rear seat passenger(s) to view the display. VES™ Video Screen NOTE: Close the armrest after the LCD screen has been raised to its viewing position. UNDERSTANDING YOUR INSTRUMENT PANEL 243 The touch screen radio and DVD player controls allow front seat operation for easy setup in the case of younger rear seat passengers.
Page 246: Kicker Mobile Surround (Kms1) - If Equipped
244 UNDERSTANDING YOUR INSTRUMENT PANEL Two wireless infrared headsets allow rear seat passen- gers to listen to the same or individual audio sources. Audio/Video RCA Jacks (AUX Jacks) on the rear of the center console enable the monitor to display video directly from a video camera, connect video games for display on the screen, or play music directly from an MP3...
Page 247: Remote Sound System Controls
REMOTE SOUND SYSTEM CONTROLS The remote sound system controls are located on the surface of the steering wheel at the three and nine o’clock positions. Remote Sound System Controls UNDERSTANDING YOUR INSTRUMENT PANEL 245 The remote sound system controls are located on the surface of the steering wheel at the three and nine o’clock positions.
Page 248: Cd/Dvd Maintenance
246 UNDERSTANDING YOUR INSTRUMENT PANEL Press the AUDIO MODE button to select the Compass/Temp/Audio screen. This screen displays radio and media mode information depending on which radio is in the vehicle. AUDIO MODE Button If the Compass/Temp/Audio screen is already displayed when the AUDIO MODE button is pressed, then the mode will change (i.e., from AM to FM, to Media mode, etc., depending on which radio is in the vehicle).
Page 249: Radio Operation And Cellular Phones
5. Store the disc in its case after playing. 6. Do not expose the disc to direct sunlight. 7. Do not store the disc where temperatures may become too high. NOTE: If you experience difficulty in playing a particu- lar disc, it may be damaged (i.e. scratched, reflective coating removed, a hair, moisture or dew on the disc) oversized, or have theft protection encoding.
Page 250: Automatic Temperature Control
248 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control Automatic Temperature Controls Automatic Operation The Infrared Dual-Zone Climate Control System auto- matically maintains the climate in the cabin of the vehicle at the comfort levels desired by the driver and passenger. To accomplish this, the system gathers information from the controls on the climate control, from a dual sun- sensor located in the top of the instrument panel, from an...
Page 251 or HI AUTO. The LO AUTO position should be used for front seat occupants only. The HI AUTO position should be used when more airflow is desired, or when rear seat occupants are present. Then, dial in the temperature you would like the system to maintain by rotating the driver or passenger temperature control knob.
Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The surface of the climate control panel and the top center of the instrument panel should be kept free of debris due to the location of the climate control sensors. Mud on the windshield may also cause poor operation of this system.
Page 253 UNDERSTANDING YOUR INSTRUMENT PANEL 251...
Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL The operator can override the AUTO mode setting to change airflow distribution by rotating the mode control knob (on the right) to one of the following positions. Defrost Air is directed to the windshield through the outlets at the base of the windshield.
Page 255: Operating Tips
conditioning. An indicator in the button illuminates when manual compressor operation is selected. NOTE: To control the air conditioning manually, the mode selector must be moved out of the AUTO position. Recirculation Control This button can be used to block out smoke, odors, dust, high humidity, or if rapid cooling is desired.
Page 256 254 UNDERSTANDING YOUR INSTRUMENT PANEL Winter Operation Use of the air Recirculation mode during Winter months is not recommended because it may cause window fogging. Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in the fresh air and high blower setting.
Page 257 UNDERSTANDING YOUR INSTRUMENT PANEL 255 Control Setting Suggestions for Various Weather Conditions...
Page 259: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....260 Automatic Transmission ....260 Normal Starting (Tip Start) .
Page 260 258 STARTING AND OPERATING Power Steering ..... . . 276 Power Steering Fluid Check ... . . 277 Parking Brake .
Page 261 Tire Rotation Recommendations ... 305 Tire Rotation — Standard Tires ..306 Tire Rotation — All Season Tires ..306 Tire Pressure Monitor System (TPMS) .
Page 262: Starting Procedures
260 STARTING AND OPERATING STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.
Page 263: Normal Starting (Tip Start)
CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: Shift into PARK only after the vehicle has come to a complete stop. Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
Page 264 262 STARTING AND OPERATING If Engine Fails To Start WARNING! Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle. This could result in a flash fire causing serious personal injury. Do not attempt to push or tow your vehicle to get it started.
Page 265: Engine Block Heater - If Equipped
ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms the engine, and permits quicker starts in cold weather. Connect the cord to a standard 110-115 Volt AC electrical outlet with a grounded, three-wire extension cord. The engine block heater cord is routed under the hood on the driver side of the vehicle.
Page 266: General Information
264 STARTING AND OPERATING WARNING! It is dangerous to move the shift lever out of PARK or NEUTRAL if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse.
Page 267 The electronically-controlled transmission provides a precise shift schedule. The transmission electronics are self-calibrating. Therefore, the first few shifts on a new vehicle may be somewhat abrupt or soft until after the break-in period. This is a normal condition, and pre- cision shifts will develop within a few shift cycles.
Page 268: Brake/Transmission Shift Interlock System
266 STARTING AND OPERATING during normal operation in DRIVE position. After the transmission cools down, it will return to normal operation. Brake/Transmission Shift Interlock System This vehicle is equipped with a Brake Transmission Shift Interlock (BTSI) system that holds the shift lever in the PARK position when the ignition switch is in the LOCK position.
Page 269: 5-Speed Automatic Transmission
5-Speed Automatic Transmission Shifting from DRIVE to PARK or REVERSE should be done only after the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake pedal when moving the shift lever between these gears. Shift Lever STARTING AND OPERATING 267 Gear Ranges...
Page 270 268 STARTING AND OPERATING WARNING! Never use PARK position on an automatic transmis- sion as a substitute for the parking brake. Always apply parking brake fully when parked to guard against vehicle movement and possible injury or damage. The following indicators should be used to ensure that you have engaged the shift lever in the PARK position: When shifting into PARK, move the shift lever all the way forward and left until it stops and is fully seated.
Page 271 CAUTION! Coasting the vehicle or driving for any other reason with the shift lever in NEUTRAL can result in transmission damage. WARNING! Do not coast in NEUTRAL and never turn off the ignition to coast down a hill. These are unsafe practices that limit your response to changing traffic or road conditions.
Page 272 270 STARTING AND OPERATING Temporary Transmission Limp Home Mode The transmission is monitored for abnormal conditions. If a condition is detected that could result in transmission damage, the transmission will engage Limp Home Mode. If vehicle acceleration worsens, or the transmission no longer shifts, the transmission is most likely operating in the Limp Home Mode.
Page 273: Autostick
Permanent Transmission Limp Home Mode Permanent Limp Home Mode will be activated if the transmission enters temporary Limp Home Mode three times. Follow the reset procedure described under “Tem- porary Transmission Limp Home Mode” in this section. In Permanent Limp Home Mode, PARK, REVERSE, and NEUTRAL will continue to operate.
Page 274: Autostick General Information
272 STARTING AND OPERATING You can shift in or out of the Autostick mode at any time without taking your foot off the accelerator pedal. When you wish to engage Autostick , simply move the shift lever to the right (D+) or left (D-) while in the DRIVE position.
Page 275: Traction
WARNING! Rapid acceleration on slippery surfaces is dangerous. Unequal traction can cause sudden pulling of the rear wheels. You could lose control of the vehicle and possibly have an accident. Accelerate slowly and carefully whenever there is likely to be poor traction (ice, snow, wet mud, loose sand, etc.).
Page 276: Flowing/Rising Water
274 STARTING AND OPERATING Flowing/Rising Water WARNING! Do not drive on, or cross, a road or a path where water is flowing and/or rising (as in storm run-off). Flowing water can wear away the road or path’s surface and cause your vehicle to sink into deeper water.
Page 277 CAUTION! (Continued) Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission/transaxle, axle, etc.) for signs of con- tamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.
Page 278: Power Steering
276 STARTING AND OPERATING POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason the power assist is interrupted, it will still be possible to steer your vehicle.
Page 279: Power Steering Fluid Check
Power Steering Fluid Check Checking the power steering fluid level at a defined service interval is not required. The fluid should only be checked if a leak is suspected, abnormal noises are apparent, and/or the system is not functioning as antici- pated.
Page 280 278 STARTING AND OPERATING When parking on a hill, it is important to apply the parking brake before placing the shift lever in PARK, otherwise the load on the transmission locking mecha- nism may make it difficult to move the shift lever out of PARK.
Page 281: Brake System
WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Do not leave the key in the ignition. A child could operate power win- dows, other controls, or move the vehicle.
Page 282 280 STARTING AND OPERATING When the vehicle is driven over 7 mph (11 km/h), you may also hear a slight clicking sound as well as some related motor noises. These noises are the system per- forming its self check cycle to ensure that the ABS system is working properly.
Page 283 WARNING! (Continued) Anti-lock system (ABS) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded. The ABS cannot prevent accidents, including those resulting from excessive speed in turns, following another vehicle too closely, or hydro-...
Page 284: Electronic Brake Control System
282 STARTING AND OPERATING ELECTRONIC BRAKE CONTROL SYSTEM Your vehicle is equipped with an advanced electronic brake control system commonly referred to as ESP. This system includes the ABS (Anti-Lock Brake System), the TCS (Traction Control System), the BAS (Brake Assist System), and the ESP (Electronic Stability Program).
Page 285: Bas (Brake Assist System)
BAS (Brake Assist System) This system complements the ABS by optimizing the vehicle braking capability during emergency braking maneuvers. This system detects an emergency braking situation by sensing the rate and amount of brake appli- cation and then applies optimum pressure to the brakes. This can help reduce braking distances.
Page 286 284 STARTING AND OPERATING power may also be reduced to assist in counteracting the condition of oversteer or understeer and help the vehicle maintain the desired path. The ESP uses sensors in the vehicle to determine the path that the driver intends to steer the vehicle and compares it to the actual path of the vehicle.
Page 287 The ESP system has three available operating modes: ESP On This is the normal operating mode for the ESP. Whenever the vehicle is started, the ESP system will be in this mode. This mode should be used for most driving situations. The ESP should only be turned OFF for specific reasons as noted in the following paragraphs.
Page 288 286 STARTING AND OPERATING illuminate, and the ESP OFF message will display in the vehicle odometer. Press and release the TRIP ODOM- ETER button located on the instrument cluster to clear this message. The “ESP OFF” message may appear in the Electronic Vehicle Information Center (EVIC).
Page 289: Synchronizing Esp
WARNING! With the ESP switched OFF, the enhanced vehicle stability offered by ESP is unavailable. In an emer- gency evasive maneuver, the ESP system will not engage to assist in maintaining stability. The “Full Off” ESP mode is intended for off-highway or off- road only.
Page 290: Tire Safety Information
288 STARTING AND OPERATING NOTE: The ESP/TCS Indicator Light and the ESP/BAS Mal- function Indicator Light will turn on momentarily each time the ignition switch is turned ON. Each time the ignition is turned ON, the ESP System will be ON even if it was turned OFF previously. The ESP Control System will make buzzing or clicking sounds when it is active.
Page 291 NOTE: P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. European-Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width.
Page 292 290 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger Car tire size based on U.S. design standards ...blank... = Passenger Car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 293 Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 294: Tire Identification Number (Tin)
292 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
Page 295: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. STARTING AND OPERATING 293 Tire and Loading Information Placard Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle...
Page 296 294 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
Page 297 available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs [295 kg]). 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4.
Page 298 296 STARTING AND OPERATING...
Page 299: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 300: Tire Inflation Pressures
298 STARTING AND OPERATING WARNING! (Continued) Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear pat- terns to develop across the tire tread.
Page 301: Tire Pressures For High Speed Operation
CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...
Page 302: Radial Ply Tires
300 STARTING AND OPERATING loading may be required for high-speed vehicle opera- tion. Refer to original equipment or an authorized tire dealer for recommended safe operating speeds, loading and cold tire inflation pressures. WARNING! High speed driving with your vehicle under maxi- mum load is dangerous.
Page 303: Tread Wear Indicators
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. Do not spin your vehicle’s wheels faster than 30 mph (48 km/h) or for more than 30 seconds continuously when you are stuck, and do not let anyone near a spinning wheel, no matter what the speed.
Page 304: Life Of Tire
302 STARTING AND OPERATING Many states have laws requiring tire replacement at this point. Life of Tire The service life of a tire is dependent upon varying factors including, but not limited to: Driving style Tire pressure Distance driven WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread.
Page 305: Tire Chains
WARNING! Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 306 304 STARTING AND OPERATING CAUTION! To avoid damage to your vehicle or tires, observe the following precautions: Because of restricted chain clearance between tires and other suspension components, it is important that only chains in good condition are used. Bro- ken chains can cause serious damage.
Page 307: Snow Tires
Always use the lower suggested operating speed if both the chain manufacturer and vehicle manufacturer sug- gest a maximum speed. This notice applies to all chain traction devices, including link and cable (radial) chains. SNOW TIRES Some areas of the country require the use of snow tires during the winter.
Page 308: Tire Rotation - Standard Tires
306 STARTING AND OPERATING Tire Rotation — Standard Tires The suggested rotation method is the “side-to-side” as shown in the following diagram. Tire Rotation — All Season Tires The suggested rotation method for vehicles equipped with all season tires is the “forward-cross” as shown in the following diagram.
Page 309 will decrease. Tire pressure should always be set based on cold inflation tire pressure. This is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1 km) after a three hour period.
Page 310 308 STARTING AND OPERATING TPM Telltale Light will still be ON. In this situation, the TPM Telltale Light will turn OFF only after the tires are inflated to the vehicle’s recommended cold placard pres- sure value. CAUTION! The TPMS has been optimized for the original equipment tires and wheels.
Page 311: Base System
The TPMS is not a substitute for proper tire mainte- nance, and it is the driver’s responsibility to maintain correct tire pressure using an accurate tire pressure gauge, even if under-inflation has not reached the level to trigger illumination of the TPM Telltale Light. Seasonal temperature changes will affect tire pressure, and the TPMS will monitor the actual tire pressure in the tire.
Page 312 310 STARTING AND OPERATING possible, check the inflation pressure of each tire on your vehicle, and inflate each tire to the vehicle’s recom- mended cold placard pressure value. Once the system receives the updated tire pressures, the system will automatically update and the TPM Telltale Light will turn off.
Page 313 2. If you install the full size spare in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, a chime will sound and the TPM Telltale Light will turn ON. 3.
Page 314: Premium System - If Equipped
312 STARTING AND OPERATING Premium System — If Equipped The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levels. Sensors mounted to each wheel as part of the valve stem transmit tire pressure readings to the receiver module.
Page 315 Tire Pressure Monitoring Low Pressure Warnings The TPM Telltale Light will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires. In addition, the EVIC will display one or more low pressure messages (Left Front, Left Rear, Right Front, Right Rear) for three seconds and a graphic showing the pressure values of each tire with the low tire...
Page 316 314 STARTING AND OPERATING turn off. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. Check TPMS Warning If a system fault is detected, the TPM Telltale Light will flash on and off for 75 seconds and then remain on solid.
Page 317 1. Signal interference due to electronic devices or driving next to facilities emitting the same radio frequencies as the TPM sensors. 2. Installing aftermarket window tinting that contains materials that may block radio wave signals. 3. Accumulation of snow or ice around the wheels or wheel housings.
Page 318: General Information
316 STARTING AND OPERATING 3. After driving the vehicle for up to 20 minutes above 15 mph (25 km/h), the TPM Telltale Light will flash on and off for 75 seconds and then remain on solid. In addition, the EVIC will display a CHECK TPM SYS- TEM message for three seconds and then display dashes (- -) in place of the pressure value.
Page 319: Fuel Requirements
FUEL REQUIREMENTS 6.1L Engine The 6.1L engine is designed to meet all emissions regulations and provide excel- lent fuel economy and performance when using high-quality premium unleaded gasoline with an octane rating of 91 or higher. Light spark knock at low engine speeds is not harmful to your engine.
Page 320: Gasoline/Oxygenate Blends
318 STARTING AND OPERATING Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE. Oxygen- ates are required in some areas of the country during the winter months to reduce carbon monoxide emissions. Fuels blended with these oxygenates may be used in your vehicle.
Page 321: Mmt In Gasoline
To fix a Non-FFV vehicle inadvertently fueled once with E-85 perform the following: drain the fuel tank (see your authorized dealer) change the engine oil and oil filter disconnect and reconnect the battery to reset the engine controller memory More extensive repairs will be required for prolonged exposure to E-85 fuel.
Page 322: Fuel System Cautions
320 STARTING AND OPERATING Fuel System Cautions CAUTION! Follow these guidelines to maintain your vehicle’s performance: The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine performance and damage the emissions control system. An out-of-tune engine or certain fuel or ignition mal- functions can cause the catalytic converter to overheat.
Page 323: Adding Fuel
stopped in an open area with the engine running for more than a short period, adjust the ventilation system to force fresh, outside air into the vehicle. Guard against carbon monoxide with proper mainte- nance. Have the exhaust system inspected every time the vehicle is raised.
Page 324 322 STARTING AND OPERATING CAUTION! Damage to the fuel system or emissions control system could result from using an improper fuel tank filler tube cap (gas cap). A poorly fitting gas cap could let impurities into the fuel system. A poorly fitting gas cap may cause the Malfunc- tion Indicator Light (MIL) to turn on.
Page 325: Loose Fuel Filler Cap Message
Loose Fuel Filler Cap Message If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “Check Gascap” message will display in the Electronic Vehicle Information Center (EVIC) (if equipped). If this occurs, tighten the fuel filler cap properly and press the TRIP ODOMETER button to turn off the message.
Page 326: Gross Vehicle Weight Rating (Gvwr)
324 STARTING AND OPERATING Gross Axle Weight Rating (GAWR) rear Vehicle Identification Number (VIN) Type of Vehicle Month Day and Hour of Manufacture (MDH) The bar code allows a computer scanner to read the VIN. Gross Vehicle Weight Rating (GVWR) The GVWR is the total allowable weight of your vehicle.
Page 327: Loading
Figure out the weight on the front and rear of the vehicle separately. It is important that you distribute the load evenly over the front and rear axles. Overloading can cause potential safety hazards and shorten useful service life. Heavier axles or suspension components do not necessarily increase the vehicle’s GVWR.
Page 329: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....328 If Your Engine Overheats ....328 TIREFIT Kit .
Page 330: Hazard Warning Flasher
328 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning Flasher switch is located in the switch bank near the top center of the instrument panel. Press the switch to turn on the Hazard Warning Flashers. When the Hazard Warning Flasher switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of...
Page 331: Tirefit Kit
the fan control to high. This allows the heater core to act as a supplement to the radiator and aids in removing heat from the engine cooling system. CAUTION! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads 240°F (116°C) or greater pull over and stop the vehicle.
Page 332 330 WHAT TO DO IN EMERGENCIES The TIREFIT system is located under an access panel in the trunk. TIREFIT Location Tirefit Kit 1. Air pump hose 2. Power plug and cable 3. AIR PUMP switch 4. Pressure gauge 5. TIREFIT sealant bottle 6.
Page 333 WARNING! Do not attempt to repair a tire on the side of the vehicle close to traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or repairing a tire. Cuts or punctures larger than approximately 0.16 in (4 mm), tire damage caused by driving with extremely low tire pressure or on a flat tire, or a damaged wheel can pose a hazard while driving.
Page 334 332 WHAT TO DO IN EMERGENCIES Sealing tire with TIREFIT 1. Turn on the hazard warning flashers. 2. Move the shift lever to the PARK position, turn OFF the engine, and set the parking brake. 3. Remove the TIREFIT kit from the trunk. 4.
Page 335 15. Disconnect the air pump hose 1 from the underside of the sealant bottle 5 by flipping the hose valve open. 16. Connect the air pump hose valve to the tire valve and flip the hose valve closed. 17. Leave the parking brake set and the shift lever in PARK and start the engine.
Page 336 334 WHAT TO DO IN EMERGENCIES 26. Leave the parking brake set and the shift lever in PARK and start the engine. 27. Inflate the tire to the pressure indicated on the tire pressure label on the driver-side latch pillar by pressing the switch 3 on the air pump to I (ON) and watching the pressure gauge.
Page 337: Jump-Starting Procedures
JUMP-STARTING PROCEDURES WARNING! Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is ON. You can be hurt by the fan. Do not attempt to push or tow your vehicle to get it started.
Page 338 336 WHAT TO DO IN EMERGENCIES NOTE: The battery is stored under an access cover in the trunk. Remote battery terminals are located in the engine compartment for jump-starting. 1. Wear eye protection and remove any metal jewelry such as watchbands or bracelets that might make an inadvertent electrical contact.
Page 339 6. Connect the other cable, first to the negative terminal of the booster battery and then to the engine ground (-) of the vehicle with the discharged battery. Make sure you have a good contact on the engine ground. Refer to the following illustration for jump-starting connections.
Page 340: Freeing A Stuck Vehicle
338 WHAT TO DO IN EMERGENCIES NOTE: Refer to Synchronizing ESP under Electronic Stability Program in Section 5 if the ESP/BAS light (in the instrument cluster) remains on continuously after starting the engine of the vehicle with the discharged battery. 8.
Page 341: Towing A Disabled Vehicle
CAUTION! When “rocking” a stuck vehicle by moving be- tween 1st and REVERSE, do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. Racing the engine or spinning the wheels too fast may lead to transmission overheating and failure. It can also damage the tires.
Page 342: Towing This Vehicle Behind Another Vehicle With A Tow Dolly
340 WHAT TO DO IN EMERGENCIES gear failure. If the transmission is not operative or if the vehicle is to be towed more than 30 miles (48 km), the vehicle must be transported using a flatbed truck. CAUTION! Do not attempt to tow this vehicle from the front with sling type towing equipment.
Page 343: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 6.1L ... . . 343 Onboard Diagnostic System — OBD II ..344 Loose Fuel Filler Cap ....344 Emissions Inspection And Maintenance Programs .
Page 344 342 MAINTAINING YOUR VEHICLE Cooling System ..... 358 Brake System ..... . . 364 Automatic Transmission .
Page 345: Engine Compartment - 6.1L
ENGINE COMPARTMENT — 6.1L 1 — Remote Jump-Start Positive Battery Post 2 — Integrated Power Module 3 — Coolant Pressure Cap 4 — Brake Fluid Reservoir Access Cover 5 — Engine Coolant Reservoir MAINTAINING YOUR VEHICLE 343 6 — Power Steering Fluid Reservoir 7 —...
Page 346: Onboard Diagnostic System - Obd Ii
344 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 347: Emissions Inspection And Maintenance Programs
TRIP ODOMETER button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the MIL. EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system.
Page 348: Replacement Parts
346 MAINTAINING YOUR VEHICLE 5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 349: Dealer Service
DEALER SERVICE Your authorized dealer has the qualified service person- nel, special tools, and equipment to perform all service operations in an expert manner. Service Manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
Page 350 348 MAINTAINING YOUR VEHICLE The best time to check the engine oil level is about five minutes after a fully warmed engine is shut off or before starting the engine after it has sat overnight. Checking the oil while the vehicle is on level ground will improve the accuracy of the oil level readings.
Page 351 the following recommendation and be within the oper- ating temperature shown in the engine oil viscosity chart. The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil filler cap location, refer to “Engine Compart- ment”...
Page 352: Engine Oil Filter
350 MAINTAINING YOUR VEHICLE Engine Oil Filter The engine oil filter should be replaced at every engine oil change. Engine Oil Filter Selection This manufacturer’s engines have a full-flow type oil filter. Use a filter of this type for replacement. The quality of replacement filters varies considerably.
Page 353: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 351 Maintenance-Free Battery The top of the maintenance-free battery is permanently sealed. You will never have to add water, nor is periodic maintenance required. NOTE: The battery is stored under an access cover in the trunk. Remote battery terminals are located in the engine compartment for jump-starting.
Page 354: Air Conditioner Maintenance
352 MAINTAINING YOUR VEHICLE WARNING! Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing. Do not lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 355: A/C Air Filter
include cleaning of the condenser fins and a performance test. Drive belt tension should also be checked at this time. WARNING! Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you.
Page 356: Body Lubrication
354 MAINTAINING YOUR VEHICLE filter. Install the new filter with arrows pointing in the direction of airflow, which is toward the rear of the vehicle (text and arrows on the filter indicate this). Refer to the “Maintenance Schedule” in Section 8 for proper maintenance intervals.
Page 357: Windshield Washers
Avoid using the wiper blades to remove frost or ice from the windshield. Keep the blade rubber out of contact with petroleum products such as engine oil, gasoline, etc. Windshield Washers The windshield washer fluid reservoir is located in the front of the engine compartment.
Page 358 356 MAINTAINING YOUR VEHICLE damaged, have a competent mechanic inspect the com- plete exhaust system and adjacent body areas for broken, damaged, deteriorated, or mispositioned parts. Open seams or loose connections could permit exhaust fumes to seep into the passenger compartment. In addition, inspect the exhaust system each time the vehicle is raised for lubrication or oil change.
Page 359 NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you. WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your exhaust system.
Page 360: Cooling System
358 MAINTAINING YOUR VEHICLE Cooling System WARNING! When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the LOCK position. The fan is tempera- ture controlled and can start at any time the ignition switch is in the ON position.
Page 361 Cooling System — Drain, Flush, and Refill If the engine coolant (antifreeze) is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner. Follow with a thorough rinsing to remove all deposits and chemicals. Properly dispose of the old engine coolant (antifreeze) solution.
Page 362 360 MAINTAINING YOUR VEHICLE Adding Coolant Your vehicle has been built with an improved engine coolant (antifreeze) coolant that allows extended mainte- nance intervals. This engine coolant (antifreeze) can be used up to five years or 102,000 miles (170 000 km) before replacement.
Page 363 Cooling System Pressure Cap The cap must be fully tightened to prevent loss of engine coolant (antifreeze), and to ensure that engine coolant (antifreeze) will return to the radiator from the coolant recovery bottle. The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces.
Page 364 362 MAINTAINING YOUR VEHICLE Disposal of Used Coolant Used ethylene glycol-based engine coolant (antifreeze) is a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal rules for your community. To prevent ingestion by ani- mals or children, do not store ethylene glycol-based engine coolant (antifreeze) in open containers or allow it to remain in puddles on the ground.
Page 365 If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be safely driven. The vapor will soon dissipate. Do not overfill the coolant recovery bottle. Check engine coolant (antifreeze) freeze point in the radiator and in the coolant recovery bottle.
Page 366: Brake System
364 MAINTAINING YOUR VEHICLE Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Refer to the “Maintenance Schedule” in Section 8 for proper maintenance intervals. WARNING! Riding the brakes can lead to brake failure and possibly an accident.
Page 367: Automatic Transmission
WARNING! Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire. Use of a brake fluid that may have a lower initial boiling point, or is unidentified as to specification, may result in sudden brake failure during hard prolonged braking.
Page 368 366 MAINTAINING YOUR VEHICLE CAUTION! (Continued) The fluid level is preset at the factory and it does not require adjustment under normal operating conditions. If a transmission fluid leak occurs, visit your authorized dealer immediately. Severe damage to the transmission may occur. Your au- thorized dealer has the proper tools to adjust the fluid level accurately.
Page 369: Appearance Care And Protection From Corrosion
Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and chemicals that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
Page 370 368 MAINTAINING YOUR VEHICLE Use MOPAR Cleaner Wax to remove road film, stains and to protect your paint finish. Take care never to scratch the paint. Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish.
Page 371 Use MOPAR Touch Up Paint or equivalent on scratches as soon as possible. Your authorized dealer has touch up paint to match the color of your vehicle. Wheel and Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion.
Page 372 370 MAINTAINING YOUR VEHICLE WARNING! Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in closed areas they may cause respiratory harm. Cleaning Headlights Your vehicle has plastic headlights that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed.
Page 373 Cleaning Plastic Instrument Cluster Lenses The lenses in front of the instruments in this vehicle are molded in clear plastic. When cleaning the lenses, care must be taken to avoid scratching the plastic. 1. Clean with a wet soft rag or micro-fiber towel. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners.
Page 374: Fuses
372 MAINTAINING YOUR VEHICLE FUSES Integrated Power Module The Integrated Power Module (IPM) is located in the engine compartment. This module contains fuses and relays. Integrated Power Module CAUTION! When installing the integrated power module cover, it is important to ensure the cover is prop- erly positioned and fully latched.
Page 375 Cavity Car- Mini- Description tridge Fuse Fuse — 15 Amp Washer Motor Blue — 25 Amp Powertrain Control Neutral Module (PCM) — 25 Amp Ignition Run/Start Neutral — 25 Amp Alternator Neutral — — — — 25 Amp Ignition Coils/Injectors Neutral —...
Page 376: Rear Power Distribution Center
374 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description tridge Fuse Fuse — — — — — — — — — Rear Power Distribution Center There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays.
Page 377 MAINTAINING YOUR VEHICLE 375 CAUTION! When installing the power distribution center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the power distribution center and possibly result in an electrical system failure.
Page 378 376 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description tridge Fuse Fuse 60 Amp — Ignition Off Draw (IOD) Yellow 40 Amp — Integrated Power Mod- Green ule (IPM) — — — 40 Amp — Integrated Power Mod- Green ule (IPM) 30 Amp —...
Page 379 Cavity Car- Mini- Description tridge Fuse Fuse — 20 Amp Cluster Yellow — 20 Amp Selectable Power Outlet Yellow — 10 Amp Stop Lights — — — — — — — — — — — — — — — — —...
Page 380 378 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description tridge Fuse Fuse — 5 Amp Antenna Module - if Orange equipped/Power Mir- rors — 20 Amp Hands-Free Phone - if Yellow equipped/Video Moni- tor - if equipped/Radio — 15 Amp Transmission Blue —...
Page 381: Vehicle Storage
fused by the 25-amp circuit breaker in cavity 11. The passenger seat switch is fused by the 25-amp circuit breaker in cavity 12. The door modules, the driver power window switch, and the passenger power window switch are fused by the 25-amp circuit breaker in cavity 13.
Page 382: Bulb Replacement
380 MAINTAINING YOUR VEHICLE Exterior Low Beam Headlight (Standard Halogen) ..9006 Low Beam Headlight – High Intensity Discharge (HID) ....... . D1S (Serviced at Authorized Dealer) High Beam Headlight.
Page 383 CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. 3. Disconnect the bulb from the socket assembly and install the replacement bulb.
Page 384 382 MAINTAINING YOUR VEHICLE 3 — Park/Turn Light Bulb 4 — Side Marker Light Bulb...
Page 385: Low Beam Headlight, High Beam Headlight, And Park/Turn Light - Models With High Intensity Discharge Headlights (Hid)
Low Beam Headlight, High Beam Headlight, and Park/Turn Light — Models with High Intensity Discharge Headlights (HID) HID Headlights The headlights are a type of high voltage discharge tube. High voltage can remain in the circuit even with the HEADLIGHT switch off and the key removed. Because of this, you should not attempt to service a headlight bulb yourself.
Page 386: Backup Light, Side Marker Light, Tail/Turn Light, And Tail/Stop Light
384 MAINTAINING YOUR VEHICLE Backup Light, Side Marker Light, Tail/Turn Light, and Tail/Stop Light 1. Open the Trunk. 2. Remove two fasteners from the back of the tail light assembly. 3. Pull back the trunk liner. 4. Remove the remaining fastener from the back of the tail light assembly.
Page 387 MAINTAINING YOUR VEHICLE 385 8. Turn the appropriate bulb and socket assembly coun- terclockwise to remove it from the tail light assembly. 2 — Side Marker Light Bulb 1 — Backup Light Bulb...
Page 388 386 MAINTAINING YOUR VEHICLE 3 — Tail/Turn Light Bulb 4 — Tail/Stop Light Bulb...
Page 389: License Light
9. Disconnect the bulb from the socket assembly and install the replacement bulb. 10. Reinstall the bulb and socket assembly into the tail light assembly, and then turn it clockwise. 11. Reinstall the tail light assembly, fasteners, electrical connector, and trunk liner. 12.
Page 390: Fluids And Capacities
388 MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Fuel (Approximate) Engine Oil with Filter 6.1 Liter Engine (SAE 0W-40) Cooling System * 6.1 Liter Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent * Includes heater and coolant recovery bottle filled to MAX level. U.S.
Page 391: Fluids, Lubricants, And Genuine Parts
FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (6.1L Engine) Oil Filter (6.1L Engine) Spark Plugs (6.1L Engine) Fuel Selection (6.1L Engine) Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of SM or SM/CF, and...
Page 392: Chassis
390 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Brake Master Cylinder Power Steering Reservoir Rear Axle Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid MOPAR DOT 3 and SAE J1703 should be used or equivalent. If DOT 3 brake fluid is not available, then DOT 4 is acceptable.
Page 393 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..392 Maintenance Schedule ....392 Required Maintenance Intervals ..394...
Page 394 392 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type, must be done at the times or mileages specified to ensure the continued proper functioning of the Emissions Con- trol System. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 395 NOTE: The oil change indicator message will not monitor the time since the last oil change. Change your vehicle’s oil if it has been six months since your last oil change, even if the oil change indicator message is NOT illuminated.
Page 396 394 MAINTENANCE SCHEDULES Once a Month Check tire pressure and look for unusual wear or damage. Inspect the battery, and clean and tighten the terminals as required. Check the fluid levels of coolant reservoir, brake master cylinder, power steering, and transmission, and add as needed.
Page 397 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule Change the engine oil and engine oil filter.
Page 398 396 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Inspect the rear axle fluid. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 24,000 Miles (40,000 km) or 24 Months Maintenance Service Schedule Change the engine oil and engine oil filter.
Page 399: Service Schedule
30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Adjust parking brake on vehicles equipped with four-wheel disc brakes. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 36,000 Miles (60,000 km) or...
Page 400 398 MAINTENANCE SCHEDULES 48,000 Miles (80,000 km) or 48 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter.
Page 401 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Adjust parking brake on vehicles equipped with four-wheel disc brakes. Inspect the CV joints.
Page 402 400 MAINTENANCE SCHEDULES 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter.
Page 403 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter.
Page 404 402 MAINTENANCE SCHEDULES 96,000 Miles (160,000 km) or 96 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter.
Page 405 108,000 Miles (180,000 km) or 108 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter.
Page 406 404 MAINTENANCE SCHEDULES 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Adjust parking brake on vehicles equipped with four-wheel disc brakes.
Page 407 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter.
Page 408 406 MAINTENANCE SCHEDULES 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter.
Page 409 * This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 411: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......411 Prepare For The Appointment .
Page 412 410 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Quality Grades ......417 Treadwear ......417 Traction Grades .
Page 413: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 414: Chrysler Llc Customer Center
412 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 415: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 416: Warranty Information (U.s. Vehicles Only)
414 IF YOU NEED CONSUMER ASSISTANCE the ownership experience. You’ll be pleased with their sincere efforts to resolve any warranty issues or related concerns. WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain, or emit, chemicals known to the State of California to cause cancer and birth defects, or other reproductive harm.
Page 417: In Canada
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.
Page 418 416 IF YOU NEED CONSUMER ASSISTANCE Service Manuals These comprehensive Service Manuals provide the information that students and professional technicians need in diagnosing/troubleshooting, problem solving, maintaining, servicing, and repairing Chrysler LLC vehicles. A complete working knowledge of the ve- hicle, system, and/or components is written in straightforward language with illustrations, diagrams, and charts.
Page 419 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 420 418 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 421 INDEX...
Page 422 420 INDEX About Your Brakes ....277,279 ABS (Anti-Lock Brake System) ... . 279,282 Adding Engine Coolant (Antifreeze) .
Page 423 Automatic Door Locks ..... 29 Automatic Headlights ....126 Automatic Temperature Control (ATC) .
Page 424 422 INDEX Brake/Transmission Interlock ....266 Break-In Recommendations, New Vehicle ..73 Brightness, Interior Lights ....131 Bulb Replacement .
Page 425 Computer, Trip/Travel ....178 Connector UCI ....... . 230 Universal Consumer Interface (UCI) .
Page 426 424 INDEX Power Steering ......277 Disabled Vehicle Towing ....339 Disposal Antifreeze (Engine Coolant) .
Page 427 Cooling ......358 Exhaust Gas Caution ....74,320 Fails to Start .
Page 428 426 INDEX Fluid, Brake ......390 Fluid Capacities ......388 Fluid Leaks .
Page 429 Gauges Coolant Temperature ....166 Fuel ....... . 165 Speedometer .
Page 430 428 INDEX Hood Release ......124 Ignition ....... 14 Key .
Page 431 Leaks, Fluid ......76 Life of Tires ......302 Light Bulbs .
Page 432 430 INDEX Passing ......129 Reading ......130,140 Seat Belt Reminder .
Page 433 Automatic Dimming ..... 82 Electric Powered ..... . . 84 Electric Remote .
Page 434 432 INDEX Outside Rearview Mirrors ....82 Overhead Console ..... . . 140 Overheating, Engine .
Page 435 Radio, Satellite ..... . . 235,241 Rear Cupholder ......153 Rear Seat, Folding .
Page 436 434 INDEX Satellite Radio Antenna ....236 Schedule, Maintenance ....392 Seat Belt Maintenance .
Page 437 Setting the Clock ....192,207,210,219 Settings, Personal ......187 Shifting .
Page 438 436 INDEX Storing Your Vehicle ..... . 379 Stuck, Freeing ......338 Sun Roof .
Page 439 Safety ......288,297 Sizes ....... 290 Snow Tires .
Page 440 438 INDEX Universal Transmitter ..... 141 Unleaded Gasoline ..... . . 317 Untwisting Procedure, Seat Belt .
Page 441 INDEX 439 Windshield Wiper Blades ....354 Windshield Wipers ..... . . 132 Wiper Blade Replacement .
Page 442 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
Page 443 Chrysler LLC 81-226-0921 First Edition Printed in U.S.A.

This manual is also suitable for:

2009 dx-48 charger srt8 2009 lx-48 charger srt8

Dodge 2009 Charger SRT8 Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding the Features of Your Vehicle 113

138 Understanding the Features of Your Vehicle

Understanding the Features of Your Vehicle 147

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

Quick Links

Chapters

Related Manuals for Dodge 2009 Charger SRT8

Summary of Contents for Dodge 2009 Charger SRT8
