Chapter 3. Reference information

This section contains monitor specifications, instructions to manually install the
monitor drover, troubleshooting information, and service information.

Monitor specifications

Table 3-1. Monitor specifications for type-model 4422-Hx6
Dimensions
Stand
VESA mount
Power input
Power consumption
Note: Power consumption figures
Video input (Analog)
Video input (Digital)
Communications
Altitude Test
Supported Display Modes
(VESA Standard modes between
noted ranges)
Temperature
Copyright Lenovo 2008.
are for the monitor and the
power supply combined.
Height
Depth
Width
Tilt range
Swivel
Lift
Pivot
Supported
Viewable image size
Maximum height
Maximum width
Pixel pitch
Supply voltage
Max supply current
Normal operation
Standby/Suspend
Off
Input signal
Horizontal addressability
Vertical addressability
Clock frequency
Interface
Input signal
Horizontal addressability
Vertical addressability
Clock frequency
VESA DDC
Operation
Horizontal frequency
Vertical frequency
Native Resolution
Operating
Storage
Shipping
378.78 mm (14.913 in)
241.07 mm (9.491 in)
510.30 mm (20.091 in)
Range: 0°/+30°
Range: -45°, +45°
Range: 110.0 mm
Yes (clock wise 90 degree)
100 mm (3.94 in)
433.44 mm (17.06 in)
270.90 mm (10.67 in)
433.44 mm (17.06 in)
0.258 mm (0.010 in) (V)
100-240 VAC, 60/50 3 Hz
1.5 A
≤ 32 W
< 2 W
< 1 W
Analog Direct Drive, 75 ohm 0.7 V
1680 pixels (max)
1050 lines (max)
205 MHz
DVI
VESA TMDS (Panel Link™)
1680 pixels (max)
1050 lines (max)
165 MHz
CI
8,000 ft
VAG: 30 kHz – 83 kHz
DVI: 30 kHz – 75 kHz
50 Hz – 75 Hz
1680 x 1050 at 60 Hz
0° to 40°C (32° to 104° F)
-20° to 60°C (-4° to 140° F)
-20° to 60°C (-4° to 140° F)
