Bontrager NODE 1 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

NODE
1 & NODE
2
™
™
Owner's Manual.
ENGLISH

Advertisement

Table of Contents
loading

Related Manuals for Bontrager NODE 1

Summary of Contents for Bontrager NODE 1

  • Page 1 NODE 1 & NODE ™ ™ Owner’s Manual. ENGLISH...
  • Page 2 We hope this computer gives you miles (or kilometers) of pleasure. Please read this manual carefully. If you do not understand the information, or you have a question that this manual does not cover, consult your Bontrager dealer or contact us.
  • Page 3 Safety When Riding When riding your bicycle, do not stare at the computer for a long time (Figure 1). If you do not watch the road, you could hit an obstacle, which may cause you to lose control and fall. Terms Used Press a button continuously for about three Hold...

  • Page 4: Screen Elements And Abbreviations

    Screen Elements and Abbreviations There are two models of NODE computer: · NODE 1 · NODE 2 CLOCK ALARM TEMPERATURE BIKE SELECTION Either model can be used on two bicycles with different wheel sizes, yet still bike1 bike2 calculate all the data correctly. You must set the wheel sizes and choose the bike setting that is appropriate for that bike before you start riding.

  • Page 5: Trip Data/Screen Terms

    Trip Data (can be restarted to 0 without affecting the total) • Cadence AVG and MAX • Distance (TRP) • Heart Rate AVG, MIN, and MAX; plus Zones 1 through 5 • Power AVG, MIN, and MAX • Speed AVG and MAX •...

  • Page 6: Modes

    Modes The NODE computer has two modes: · Ride · Setting Ride This is the mode you will use when riding your bike. Ride mode (Figure 3) displays the functions, the information gathered by the computer. This Figure 3. Ride Mode. information can be the current data (your current speed, the current temperature, or data from other functions), or for some functions the NODE can display your average, total, or minimum/maximum data.

  • Page 7: Sensors

    If the battery loses power, the sensor will no longer send is appropriately equipped, you can purchase a combination speed/cadence signals to the computer. sensor. You can also customize your computer by purchasing additional Bontrager NODE sensors or a power sensing system of your choice from your Bontrager dealer.

  • Page 8: Pairing Procedure/Force Pair

    Before Your First Ride Pairing (Pair) Procedure Before the NODE can display any data, it must identify each radio signal sent by the sensors (Figure 6). This process, which takes about one minute, is called “Pairing” (Pair). After the NODE creates a Pair, it remembers the signals, so normally this only occurs once (during the initial set up).

  • Page 9: Connecting Procedure/Force Connect

    Connecting (Connect) Procedure Each time you switch on the NODE, it automatically tries to Connect (lock on) to the signals it remembers from the Pairing procedure. Just like during Pairing, for the NODE to Connect to signals you must activate the sensors (make them send a signal).
  • Page 10 Switching Sensors to OFF or ON Hold for three seconds to go to Setting mode. When BIKES appears, scroll to SENS. Press (3 sec) To change Cadence to ON or OFF, press To select, press (or) To change Power to ON or OFF, press To select, press (or)
  • Page 11 To change Heart Rate to ON or OFF, press Press (or) To save and exit, press To go to Ride mode, hold for three seconds.

  • Page 12: Automatic Setup

    Automatic Setup When you switch the NODE to On the fi rst time (or replace the batteries or perform the Reset procedure), the computer will automatically go through the Pairing and Connecting procedures and set the units for one bike. Before starting this procedure, place the NODE within 5 feet (1.5 m) of all NOTE sensors, and be ready to activate the sensors as explained in Pairing.
  • Page 13 Repeat Step 4 to change and select the other digits, then press To change to MPH or KMH, press To select, press (or) To change to °C or °F, press To select, press (or) To change to 12hr or 24hr, press To select, press (or)
  • Page 14 To change the underlined digit, press To select, press Repeat step 9 to change and select the other digits. If you selected the 12hr clock, you also must select AM or PM. (or) When PAIR appears, make the sensor(s) send a signal (spin the wheel, turn the crank, etc.).
  • Page 15 Advanced Setup This section explains how to perform setup for a second bike or set a custom wheel size. To Perform Setup for a Second Bike Hold for three seconds to go to Setting mode. (or) When BIKES appears, press (3 sec) To change from bike1 or bike2, press To select, press...
  • Page 16 Setting a Custom Wheel Size Measure the roll-out (Figure 9). Roll-out is the distance your bicycle travels in exactly one revolution of the wheel. NOTE If one wheel on your bicycle is bigger, measure the wheel with the magnet. With the valve stem of the wheel directly over the fl oor, sit on the bike.
  • Page 17 To select, press Scroll to CUSTOM. Press (or) To change the underlined digit, press To select, press Repeat step 5 for the other digits. (or) To save and exit, press To go to Ride mode, hold for three seconds.

  • Page 18: To Restart/To Select The Bike

    Every Ride After the First To switch the NODE to “On,” simply push any button or send the NODE speed or cadence data: spin the crankarm or roll the wheel. The Connecting procedure will begin immediately. To Restart (Change Trip Data to 0) In Ride mode, hold for three seconds.
  • Page 19 Understanding Your NODE’s Functions SPEED Speed is a measurement of how fast your bike is moving. Features of Speed Function In Ride mode, speed always displays (Figure 10). The NODE can also display your current (CUR), average (AVG), and maximum (MAX) speed. The NODE can do this for two bicycles, bike1 and bike2.
  • Page 20 CADENCE (CAD) Cadence is how fast you are pedaling, counted as the number of complete revolutions per minute (RPM) of the crankset. Features of Cadence Function When displaying the cadence function, the lower section of the screen displays CAD (Figure 11). The NODE can display Current (CUR), Average (AVG), and Maximum (MAX) cadence.
  • Page 21 The NODE can receive signals from a variety of power meters (sensors) that work with the ANT+ protocol. However, Bontrager does not make a power meter. The sensor must be switched to ON and send a signal (spin the crank).
  • Page 22 Calibrating Power To get the most accurate data, you should calibrate the power function before every ride. In Ride Mode, scroll to PWR. Press CALIB? (Calibrate?) appears. To calibrate, press As the NODE calibrates, the 0 (zero) of speed fl ashes each segment in a circular pattern.
  • Page 23 HEART RATE (HR) Heart rate is a measurement of the number of times your heart beats in a minute. Features of Heart Rate Function If heart rate data is sent to the NODE, the lower section of the screen displays HR (Figure 13).
  • Page 24 Viewing Heart Rate CUR AVG MAX In Ride Mode, scroll to HR. Scroll CUR changes to AVG, which changes to MAX. If you have set the heart rate zones, a number will display beside the CUR heart rate. This number is the current heart rate zone.
  • Page 25 Zone 1 appears, showing the time spent in Zone 1 since the last Trip Restart. Scroll to see Zones 1 through 5. To return to HR, press Setting Heart Rate Zones Hold for three seconds to go to Setting mode. When BIKES appears, scroll to HR.
  • Page 26 To go to MAX, press To change the MAX number, press To change the underlined digit, press To select, press Repeat step 8 for the other digits. (or) To save and exit, press To go to Ride mode, hold for three seconds.
  • Page 27 CALORIE OUTPUT (CAL) This feature estimates the calories you are burning based on work and body weight (Figure 15). CAL is based on heart rate, so the sensor must be switched to ON and send a signal. Figure 15. Calorie Output Function. To View Calorie Output In Ride Mode, scroll to HR.
  • Page 28 Setting Calorie Output Hold for three seconds to go to Setting mode. When BIKES appears, scroll to CAL. Press (or) (3 sec) To change M (male) or F (female), press To select, press To change WGT kg or lb, press (or) (or) To select, press...
  • Page 29 INTERVALS (INT) Intervals are periods of time of a set length, separated by set periods of time. Interval Clock The interval clock runs separately from the Time function, so you can still use the stopwatch function and scroll through standard functions without stopping the interval clock.
  • Page 30 To Start the Interval Clock, or Restart at 0 In Ride Mode, scroll to INT. To start the clock from its current state, press (or) To restart the clock at 00:00, hold for three seconds. To Stop the Interval Clock In Ride Mode, scroll to INT.
  • Page 31 To Set Intervals Setting intervals has four sections: · ON/OFF (On/Off) · TIME (the length of time of the interval) · REST (the length of time between intervals) · REPS (the number of repetitions) Hold for three seconds to go to Setting mode. (or) When BIKES appears, scroll to INT.
  • Page 32 To change the Rest time, press To skip to REPS, press and go to step 13. To change the underlined digit, press To select, press Repeat step 9 for the other digits. (or) To go to REPS, press To change the number of repetitions, press To change the underlined digit, press To select, press Repeat step 12 for the other digits.
  • Page 33 TRIP (TRP) Trip is the distance you have traveled since the last Trip Restart. Odometer is the distance since the last Reset (erase of settings). The NODE adds distance values of Trip and Odometer from bike1 to those of bike2. Features of Trip Function In Trip, the lower section of the screen displays TRP (Figure 17).
  • Page 34 Setting the Odometer Hold for three seconds to go to Setting mode. When BIKES appears, scroll to SYSTEM. Press (3 sec) When ODO appears, press To change the underlined digit, press To select, press Repeat step 5 for the other digits. (or) To go to Ride mode, hold for three seconds.
  • Page 35 ALTITUDE (ALT) The NODE 2 can calculate ALT, or altitude. Altitude is the height above sea level. The NODE adds altitude values from bike1 to those of bike2. Features of Altitude Function The altitude function can calculate changes in altitude during a ride, including loss, gain, and total change (Figure 18).
  • Page 36 To see the gain (+) or loss (–) in Trip or Total, scroll to that feature and toggle When % appears, toggle to see current (CUR) and maximum (MAX). Setting Current Altitude The altimeter measures your altitude based on air pressure and temperature. Air pressure changes with the weather, so for the best accuracy you should set the current altitude before your fi rst use and again whenever you are near a point of reference of known altitude.
  • Page 37 When ODO appears, scroll to ALT. Press To change from FT or MT, press (or) To select, press To change from + or –, press To select, press (or) To change the underlined digit, press To select, press (or) Repeat step 8 for the other digits. To go to Ride mode, hold for three seconds.
  • Page 38 DUAL VIEW (DV) Dual View splits the lower screen to show two of the secondary functions simultaneously (Figure 19). Speed, the primary function, always displays in Ride mode. With Dual View, in addition to Speed, your NODE can also display, for example, Power and Heart Rate.
  • Page 39 To change to ON or OFF, push To select, press To change the function on the left, scroll (or) To change the function on the right, scroll To save and exit, press To go to Ride mode, hold for three seconds. To View Dual View (DV) In Ride mode, scroll...
  • Page 40 TIME The NODE works with time in two ways: · Time of Day (clock) HH:MM hours and minutes · Ride time (stopwatch) HH:MM:SS, hours, minutes, and seconds In Ride mode, the time function always displays (Figure 20). Ride time data is erased in a Trip Restart, but the Clock setting is not. When the Ride Time clock goes past 9:59:59, the fi rst digit changes to show an H along with hours and minutes (H:00:00).
  • Page 41 Setting Time Hold for three seconds to go to Setting mode. When BIKES appears, scroll to SYSTEM. Press (or) (3 sec) When ODO appears, scroll to CLOCK. To change, press To change 12hr or 24hr, press To select, press (or)
  • Page 42 To change the underlined digit, press To select, press Repeat step 7 for the other digits. If you selected the 12hr clock, you also must select AM or PM. (or) To save and exit, press To go to Ride mode, hold for three seconds.
  • Page 43 NUTRITION TIMER The nutrition alarm displays an alarm bell (Figure 21) to remind you to eat at intervals you select. The intervals are based on the ride time clock, not the time of day, so the nutrition timer shows time as hours and minutes (HH:MM). Figure 21.
  • Page 44 To change ON or OFF, press To select, press Press again. (or) To change the underlined digit, press To select, press Repeat step 5 for the other digits. To go to Ride mode, hold for three seconds. (or)
  • Page 45 BACKLIGHT The NODE 2 has a screen backlight. The backlight provides a light source behind the screen so that the numbers are more visible. To Switch the Backlight to ON In Ride mode, hold for three seconds. To save battery life, the backlight automatically switches to Off after fi ve seconds. (3 sec)

  • Page 46: Installation

    Installation This section explains how to attach the computer to the handlebar and attach the sensors and magnets to their locations. There are no wires. Tools Required • Screwdriver, small slot type • Screwdriver, small phillips type • 2.5mm allen key (if installing a SpeedTrap or DuoTrap sensor) To Attach the Computer to the Handlebar Determine the diameter of your handlebar (25.4 mm, 26.0 mm, or 31.8 mm).
  • Page 47 To Attach the Computer to the Stem Insert the rubber pad with logo into the back of the computer base. Position the base on the stem. Secure the base to stem using zip-ties. Slide the computer head into the base (Figure 25). To Install the Speed Magnet With the logo facing away from the wheel (Figure 26), wrap the magnet around a spoke.
  • Page 48 To Install the Cadence Magnet Remove the left pedal. Slide the cadence magnet (Figure 30) onto the crankarm with the magnet to the inside. Reinstall the pedal. Align the magnet with the cadence sensor. To Install the Sensor(s) Figure 30. Crank Magnet on Crank Arm. Figure 31.
  • Page 49 Battery Maintenance Reset There is a battery in the computer, and also in each of the sensors. If you use the You can erase all settings and programming. Push the Reset button (Figure 36). NODE for one hour every day, the batteries should last about 10 months. The NODE goes to the procedure for Automatic Setup.
  • Page 50 Troubleshooting If your NODE computer has problems, use this guide to fix it. If you cannot fix it, take your computer—with the bicycle—to your dealer. Symptom Possible Causes Solution Erratic data Magnet misaligned or too far away Readjust magnet and sensor placement Sensor battery power is low Replace battery No current speed...
  • Page 51 Bontrager & Bontrager B-Dot are registered trademarks of Trek Bicycle Corporation. ©2009 Trek Bicycle Corporation, Waterloo, Wisconsin 53594 USA. All rights reserved. Part Number 304105...

This manual is also suitable for:

Node 2
