FILE: 091-9-2000.P65
DATE: 4-23-2000
REV. A
INSTRUCTION MANUAL
AUTO CHARGE
2000
PUMP-PLUS
AIR COMPRESSOR / BATTERY CHARGER
MODEL #091-9-2000
NOTE :
This charger is designed for
vehicles with dual batteries
and negative ground.
INPUT :120 volt, 50/60 Hz, 3.5 amps
OUTPUT: 18 AMPERES
1 YEAR WARRANTY ON AIR COMPRESSOR
3 YEAR WARRANTY ON CHARGER
.
KUSSMAUL ELECTRONICS CO., INC
170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796
TEL: in NY 631-567-0314
TOLL FREE: 800-346-0857
FAX: 631-567-5826
Advertisement
Related Manuals for KUSSMAUL 091-9-2000
Summary of Contents for KUSSMAUL 091-9-2000
- Page 1 INPUT :120 volt, 50/60 Hz, 3.5 amps OUTPUT: 18 AMPERES 1 YEAR WARRANTY ON AIR COMPRESSOR 3 YEAR WARRANTY ON CHARGER KUSSMAUL ELECTRONICS CO., INC 170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796 TEL: in NY 631-567-0314 TOLL FREE: 800-346-0857 FAX: 631-567-5826...
- Page 2 INTRODUCTION The AUTO CHARGE 2000 is a compact, completely automatic, dual channel battery charger designed for vehicles with two batteries. The charger is rugge- dized to withstand the shock and vibration encountered by vehicle mounted equipment. The Auto Charge 2000 Pump Plus operates an 091-9 air compressor. With the selector switch in the AC position the compressor runs only when the AC power is applied.
- Page 3 Battery Saver & Indicator A 3 ampere BATTERY SAVER is built into the charger. When connected as shown in the installation wiring diagram, loads on battery #1 such as radios and rechargeable hand lights are automatically switched to the BATTERY SAVER when power is applied to the charger.
- Page 5 Installation Wiring Diagram IMPORTANT : Wire size is WIRE SIZE CHART for a maximum length of 10 CONNECTION ITEM DEFINITION WIRE SIZE BATTERY NEGATIVE CHARGING LEAD 12 AWG feet. If wiring is to be longer, COMMON FOR CHARGING BATTERIES AND BATTERY SAVER LOAD larger wiring is required.
- Page 6 Specifications: Input: 120 volt, 50/60 Hz, 3.5 amperes Input Fuse: 6 amperes, fast acting Output: 12 volts D.C. 15 amperes Max., total both outputs Remote Sensing: Electronic, sense wires not required Number of Charger Outputs: 2 Number of Battery Saver Outputs: 1 Battery Saver Output: 12 volts D.C., 3 amperes Max.
-
Page 7: Indicator Installation
INDICATOR INSTALLATION 1. Locate Indicator in a convenient place on the vehicle. 2. Place the template in position and center punch in 4 places. 3. Drill holes as shown. 5. Cut out square hole. 6. Connect wiring to charger using butt connector supplied. 7. -
Page 8: Warranty
Kussmaul Electronics Company, Inc. shall have no liability for dam- ages of any kind to associated equipment arising from the installation and /or use of the Kussmaul Electronics Company, Inc. products. The pur- chaser, by the acceptance of the equipment, assumes all liability for any...
