A compact, solid state,
four channel field recorder.
Pro quality four channels recordings
to large capacity SDHC cards.
The Edirol R-44 is designed for professional use
within a very conveniently sized package. Capture up
to 4 channels of uncompressed audio with selectable
bit depths (16-bit or 24-bit) and sampling frequencies
(44.1kHz/48kHz/88.2kHz/96kHz). R-44 employs SD
cards or large capacity SDHC
cards as the recording media.
No moving parts enables the
most silent and reliable
operation possible.
Built-in stereo microphones
and monitor speakers.
Although the R-44 is compact, all the necessary
functions are included. Built-in high quality
microphones and speakers make recording and
monitoring without external devices possible.
Built-in limiter, low-cut filter
and studio class effects.
An on-board limiter helps suppress sudden peaks in
sound from an input source. A low-cut filter is
included to help prevent things like wind noise or mic
handling noise. Studio class effects such as 3-Band
EQ, 6-Band GEQ, Enhancer or DeEsser can be used
as tools to greatly improve audio quality. Effects can
be applied while recording or simply for monitoring/
playback.
■ Bulit-In Effects
3-band parametric EQ ; allows precise equalization with
3-Band EQ
high/low shelving and peaking
6-Band Graphic EQ
6 point frequency band equalization; ideal for recording
Minimizes noise during low audio levels, cuts low
Noise Gate
frequency noise
Enhancer
Cleary defines and enhances sound; good for dialogue
Cuts hissing, smoothens the sound, makes audio level
Comp & DeEsser
uniform
Generates stereo mix with specified spread from inputs
MS Mic Mixing
of Mid-Side Microphones
* Effects can be applied on both input and output
* Effects are not available while sample rate is set to 192kHz
Pre-Record function ensures you never
miss that important moment again.
The Pre-Record function buffers input signals for a
certain amount of time. When the REC button is
pressed, the material from the previous few seconds
(selectable) is included. This also helps reduce sound
bites at the beginning of a recording by not having to
start the recorder too early.
Combo type analog jacks and digital output
enables connection with a variety of devices.
The combo input jacks (4)
supports the connection of both
XLR and 1/4 inch plugs.
XLR inputs are equipped with
phantom power. Eleven steps
of input sensitivity enable the
connection of various devices
with a variety of inputs levels
