- Page 1 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA 201-10813-01 March 2006...
-
Page 2: Publication Version 1.0, March
In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. - Page 3 EN 55 022 Declaration of Conformance This is to certify that the NETGEAR ProSafe 24-Port 10/100/1000 L3 managed Stackable Switch with 4 High-speed I/O Module Bays GSM7328S is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a.
- Page 4 Refer to the Support Information Card that shipped with your Managed Stackable Layer 3 Fast Ethernet Switch. World Wide Web NETGEAR maintains a World Wide Web home page that you can access at the universal resource locator (URL) http://www.netgear.com. A direct connection to the Internet and a Web browser such as Internet Explorer or Netscape are required.
-
Page 5: Table Of Contents
Contents Chapter 1 About This Manual Audience, Scope, Conventions, and Formats ..............1-1 Chapter 2 Introduction GSM7328S Front Panel and LEDs .................2-1 GSM7328S Rear Panel ....................2-4 GSM7352S Front Panel and LEDs .................2-4 GSM7352S Rear Panel ....................2-6 Safety Instructions ......................2-7 Chapter 3 Hardware Installation Package Contents ......................3-1 Protecting Against Electrostatic Discharge ..............3-2... - Page 6 Chapter 4 Troubleshooting Troubleshooting Chart ....................4-1 Additional Troubleshooting Suggestions ..............4-2 Appendix A Technical Specifications ......................A1 Appendix B Default Configuration Settings ....................B1 Publication Version 1.0, March 2006...
-
Page 7: About This Manual
Chapter 1 About This Manual The Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide describes installation and basic troubleshoting for the NETGEAR ® GSM7328S and GSM7352S switches. Audience, Conventions, Formats, and Scope This information in this guide is intended for network managers familiar with network management concepts and terminology. - Page 8 Switch with 4 Gigabit Ports GSM7328S • ProSafe 48-Port 10/100 L3 managed Stackable Switch with 4 Gigabit Ports GSM7352S Manual Publication Date March 2006 Note: Product updates are available on the NETGEAR, Inc. Web site at http://kbserver.netgear.com. About This Manual v1.0, March 2006...
-
Page 9: Introduction
Chapter 2 Introduction The NETGEAR Layer 3 Managed Stackable Fast Ethernet Switch is a state-of- the-art, high-performance, IEEE-compliant network solution. It includes powerful management features that you can use to eliminate bottlenecks, boost performance, and increase productivity. This guide describes hardware installation and basic troubleshooting for the following NETGEAR switches: •... - Page 10 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide The module bays support any combination of either the ProSafe 24-Gigabit Stackable Module (AX742) or the ProSafe 10-Gigabit Ethernet XFP Adapter (AX741). See “High-Speed I/O Module Bays” in Chapter 3. RJ-45 jacks Copper/fiber Stacking/XFP...
- Page 11 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Table 2-1. LED Descriptions for GSM7328S (continued) Description M1, M2, M3, M4 XFP Module present or Stacking Adapter present and ACT LED: High-Speed I/O XFP Module present LED /ACT Modules •...
-
Page 12: Gsm7328S Rear Panel
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide GSM7328S Rear Panel The rear panel has two module bays, a console port, redundant power supply connector, and a standard AC power receptacle for the supplied power cord. The module bays support any combination of either the ProSafe 10-Gigabit Ethernet XFP Adapter (AX741) or the ProSafe 24-Gigabit Stackable Module (AX742). - Page 13 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide The table below describes the GSM7352S LEDs on the front of the switch. Table 2-2. GSM7352S LED Description Description This is the stack member ID (1–8) that the software assigns to the switch.
-
Page 14: Gsm7352S Rear Panel
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Table 2-2. GSM7352S LED Description (continued) Description M1, M2, M3, M4 XFP Module present or Stacking Adapter present and ACT LED High-Speed I/O XFP Module present LED /ACT Modules •... -
Page 15: Safety Instructions
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Safety Instructions Use the following safety guidelines to ensure your own personal safety and to help protect your system from potential damage. To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the following precautions. - Page 16 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide • To help avoid damaging your system, be sure that the voltage selection switch (if provided) on the power supply is set to match the power available at your location: –...
-
Page 17: Hardware Installation
Rubber caps for the SFP sockets • Rack-mounting kit • Null-modem serial cable (RS-232) with 9-pin connectors • NETGEAR CD: The CD contains – Configuration software – Documentation including the Command Line Interface Reference for the ProSafe 7300S Series Layer-3 Stackable Switches, the Administration... -
Page 18: Protecting Against Electrostatic Discharge
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Protecting Against Electrostatic Discharge Warning: Static electricity can harm delicate components inside your system. To prevent static damage, discharge static electricity from your body before you touch any of the electronic components, such as the microprocessor. -
Page 19: Installation
4. Make sure that all items are present. See “Package Contents” on page 3-1. Note: If any item is found missing or damaged, contact your local NETGEAR reseller for replacement. 5. Inspect the products and accessories for damage. Report any damage immediately. -
Page 20: Select A Location
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Select a Location The switch can be mounted in a standard 19-inch (48.26-centimeter) rack, wall- mounted, or left freestanding (placed on a tabletop). The site where you install the switch may greatly affect its performance. Before installing the switch or switches, make sure that the chosen installation location meets the following site requirements. -
Page 21: Install The Switch
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Install the Switch You can install the switch on a flat surface or in a standard 19-inch rack. Installing the Switch on a Flat Surface The switch ships with four self-adhesive rubber footpads. Stick one rubber footpad on each of the four concave spaces on the bottom of the switch. -
Page 22: Check The Installation
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide 4. Align the bracket and rack holes. Use two pan-head screws with nylon washers to fasten each bracket to the rack. 5. Tighten the screws with a No. 2 Phillips screwdriver to secure the switch in the rack. -
Page 23: High-Speed I/O Module Bays
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide High-Speed I/O Module Bays The High-Speed I/O Module Bays can be used for inter-switch stacking or to install XFP 10-Gigabit Ethernet modules. If you want to do both, you can stack the switch using two 24-Gigabit Stackable Modules (AX742), and then use the remaining module bays for 10-Gigabit Ethernet XFP Adapters (AX741). - Page 24 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide To install additional Gigabit Ethernet modules, repeat step 1. High-Speed I/O Module Installation The High-Speed I/O Module Bays support ProSafe 10-Gigabit Ethernet XFP Adapter (AX741) or ProSafe 24-Gigabit Stackable Modules (AX742). AX741 adapter Figure 3-3 When the ProSafe 10-Gigabit Ethernet XFP Adapter (AX741) is in place, you can...
-
Page 25: Stacking
For information about working with the CLI, see the Command Line Interface Reference for the ProSafe 7300S Series Layer-3 Stackable Switches on the NETGEAR CD that shipped with your product. Hardware Installation v1.0, March 2006... -
Page 26: Connecting A Redundant Power Supply
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Connecting a Redundant Power Supply Each switch has a redundant power supply (RPS) connector at the rear of the switch next to the power receptacle. Power receptacle Redundant power supply connector Figure 3-6 You can connect an external DC-to-DC power supply unit to the switch to provide... -
Page 27: Connecting A Console To The Switch
Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Connecting a Console to the Switch After you install the switch and apply power, you can connect to it with a terminal or workstation. You can use the Command Line Interface (CLI) to identify the IP address. - Page 28 The following documents are provided for this purpose: • Quick Install Guide: Explains basic setup and configuration (provided as both a print document and in PDF format on the NETGEAR CD). • Command Line Interface Reference for the ProSafe 7300S Series Layer-3 Stackable Switches: Gives detailed examples of how to use the CLI, and is located on the NETGEAR CD.
-
Page 29: Troubleshooting
Chapter 4 Troubleshooting Troubleshooting Chart The following table lists symptoms, causes, and solutions of possible problems. Table 4-1. Troubleshooting Problem Cause Solution Power LED is off. No power is received Check the power cord connections for the switch at the switch and the connected device. -
Page 30: Additional Troubleshooting Suggestions
You can verify the integrity of the switch by resetting the switch. To reset the switch, use the Tools> Reset command or remove AC power from the switch and then reapply AC power. If the problem continues, contact NETGEAR technical support. - Page 31 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Auto-Negotiation The copper 10/100/1000 Mbps ports negotiate the correct duplex mode and speed if the device at the other end of the link supports auto-negotiation. If the device does not support auto-negotiation, the switch only determines the speed correctly and the duplex mode defaults to half-duplex.
- Page 32 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Troubleshooting v1.0, March 2006...
- Page 33 Appendix A Technical Specifications This appendix provides technical specifications for the switches. Table A-1. Technical Specifications Feature GSM7328S GSM7352S IEEE Network Protocol 802.3 10BASE-T and Standards 802.3u 100BASE-TX compatibility 802.3z 1000BASE-SX 802.3z 1000BASE-LX 802.3ab 1000BASE-T 802.3ae 10000BASE-LR 802.3ae 10000BASE-SR 802.3x flow control Switch management •...
- Page 34 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Table A-1. Technical Specifications Feature GSM7328S GSM7352S Layer 2 Services • 802.1Q Static VLAN (Up to 4k) • 802.1p Class of Service (CoS) • 802.1D Spanning Tree Protocol (STP) •...
- Page 35 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Table A-1. Technical Specifications Feature GSM7328S GSM7352S Environment • Operating temperature: 32° to 122°F (0° to 50°C) • Storage temperature: – 4° to 158°F (–20° to 70°C) • Operating humidity: 90% maximum relative humidity, noncondensing •...
- Page 36 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Technical Specifications v1.0, March 2006...
-
Page 37: Default Configuration Settings
Appendix B Default Configuration Settings This appendix provides the default settings for the NETGEAR Model GSM7328S and GSM7352S switches. Table B-1. Default Configuration Settings Features Default Setting Port speed Auto-negotiation Port duplex Auto-negotiation Flow control (half duplex) Enabled Flow control (full duplex) - Page 38 Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide Table B-1. Default Configuration Settings (continued) Features Default Setting IP routing Disabled Disabled MAC address aging 300 seconds OSPF Disabled SNMP community public (read-only access), private (read/write access) DHCP Server Disabled VLAN Ingress filtering Enabled...
