RocketFish RF-WHTIB User Manual

Universal wireless rear speaker kit
Hide thumbs Also See for RF-WHTIB:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Universal Wireless Rear Speaker
Kit
RF-WHTIB
User Guide

Advertisement

Table of Contents
loading

Related Manuals for RocketFish RF-WHTIB

Summary of Contents for RocketFish RF-WHTIB

  • Page 1 Universal Wireless Rear Speaker RF-WHTIB User Guide...

  • Page 2: Table Of Contents

    One-Year Limited Warranty..........17 Introduction Congratulations on your purchase of a Rocketfish RF-WHTIB Universal Wireless Rear Speaker Kit. Your RF-WHTIB represents the state of the art in wireless speaker kit design, and is designed for reliable and trouble-free performance. This manual explains how to correctly install, operate, and get the best performance from your universal wireless rear speaker kit.

  • Page 3: Safety Information

    9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or RF-WHTIB...

  • Page 4: Features

    the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

  • Page 5: Package Contents

    Package contents Examine the contents of the box for your RF-WHTIB Universal Wireless Rear Speaker Kit. The box should contain: • A sender unit • A receiver unit • A holder for the receiver unit • An AC power adapter (for the sender unit) •...

  • Page 6: Receiver Unit

    Receiver unit The receiver unit receives the 2.4 GHz audio signals from the sender. Front view Back view Bottom view Feature Power indicator LED Power button Volume control knob Manual connect button Left surround sound speaker output terminal Right surround sound speaker output terminal Hanging holes for wall mounting the receiver (by using 3 ×...

  • Page 7: Setting Up Your Universal Wireless Rear Speaker Kit

    Note: If you need to mount the receiver, make sure that the left and right speaker cords are correctly connected to the speaker terminals of the receiver by checking the labels on the rear panel of the receiver. Receiver RF-WHTIB...

  • Page 8: Connecting The Sender

    Connecting the sender Connecting the sender to the amplifier Surround speaker outputs Sender back panel Press and hold Release Caution: Turn off your amplifier while connecting the units. To connect the amplifier to the sender: Using the 2-foot speaker cords (provided), connect the right surround speaker terminals of your amplifier to the right speaker terminals of the sender by connecting the red wire to the Red (+) terminals, and the black wire to the Black (-) terminals.
  • Page 9 Connecting the receiver to your surround speakers Left Right surround surround speaker speaker To connect the surround speakers to the receiver: Connect the right speaker to the right speaker terminals of the receiver, and the left speaker to the left speaker terminals. RF-WHTIB...
  • Page 10 If the speakers have wires instead of terminals, connect the positive (+) wire from the right speaker to the Red (+) terminal for the right speaker on the receiver and the negative (-) wire from the right speaker to the Black (-) terminal for the right speaker on the receiver.
  • Page 11 (provided), or mounted on a wall, using the mounting holes on the bottom. Warning: This stand is intended for the RF-WHTIB receiver only. Use with other equipment can result in instability and may cause injury. Note: If you need to mount the receiver on a wall, install it against the wall so that cool air can travel through the ventilation slots in the unit and come out the top.

  • Page 12: Establishing Communications Between Sender/Receiver

    Using your universal wireless rear speaker Establishing communications between the sender and receiver To turn on the System: Press the (power) button on the back panel of the sender. The LED indicator blinks to indicate that the sender is plugged in and in Standby mode.

  • Page 13: To Adjust Volume Balance

    You can leave both units on when not in use. Optimizing your surround sound The RocketFish Universal Wireless Rear Speaker Kit uses state-of-the-art 2.4 GHz technology to digitally send audio data from the sender to the receiver. Wireless links create a small latency...

  • Page 14: Troubleshooting

    Troubleshooting Please read this User Guide carefully before using your universal wireless rear speaker kit. Check this list for a possible troubleshooting solution before calling for service. Problem Solution No sound • Make sure that the AC adapter is connected to the sender and the power cord is connected to the AC supply for the receiver.

  • Page 15: Specifications

    This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF-WHTIB...
  • Page 16 FCC Rules could void the user’s authority to operate this equipment. Copyright © 2008 Rocketfish. Rocketfish and the Rocketfish logo are trademarks of Best Buy Enterprise Services, Inc. Other brands and product names are trademarks or registered trademarks of their respective holders.

  • Page 17: One-Year Limited Warranty

    Product is determined to be defective by an authorized Rocketfish repair center or store personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you.
  • Page 18 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2008 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 19 RF-WHTIB...
