Part names and functions

Main unit
1 Legrest
2 Leg/Sole massage section
• Includes air massage function
Sole Reflexology Plates
• Removable
• Position adjustment possible
3 Legrest Slide Lever
• Extendable length to approx. 5 in.
(12 cm)
4 Control Panel
See page 7 to 8
5
3 4
2
5 Seat/Thigh Side Massage section
Seat/Thigh Soft Massage Plates
(integrated)
• Position adjustment possible
6 Retracted position of massage
heads
7 Back Cushion
8 Pillow
9 Backrest
• Includes integrated massage
heads
10 Seat
• Includes integrated air massage
function
11 Armrest
Front
5 6 7
10 11 12 13
8 9
14
12 Hand/Arm massage section
• Includes integrated air massage
function
13 Control Panel Stand Covers
• On both the left and right sides
14 Outer Shoulder massage section
• Includes integrated air massage
function
Shoulder Plates
• Removable
• Position adjustment possible
