Using the stretch massage
Warning
• Make sure there are no people or pets behind the unit when the arm stretch function is turned "on."
Failure to observe this precaution may result in accident or injury.
Caution
• Do not use with any pre-existing condition of shoulder injury.
Doing so may result in injury.
• When Pre-Program and Quick Massage are selected, the leg stretch is turned on and the arm stretch is turned off, respectively.
• When Self-Program and Manual Operation are selected, the stretch massage for all parts is turned off.
1
Open the left cover.
2
Press the or
To execute the stretch massage only
After turning on the power by pressing the
press the (stretch legs) or
arm) buttons.
• The power will turn off automatically if no operation is
executed for 3 minutes.
Operations of the leg stretch
1. After grasping the legs with air, the
legs are stretched as the legrest is
lowered approximately 10 degrees
from the massage position.
Lowered by
approximately
10 degrees
Operations of the arm stretch
1. The backrest will come fully up.
One arm will inflate to firmly secure
the arm/hand in place.
buttons to turn the functions off or on.
The display will indicate if the stretch function is turned
on or off.
button,
(The lamp is turned on: [ON], the lamp is turned off: [OFF])
(stretch
2. Once the legrest returns to the original
angle, the legrest is then lowered
approximately 30 degrees to stretch
the legs further.
Lowered by
approximately
30 degrees
2. After the backrest reclines
approximately 20 degrees to stretch
the arm, the backrest will come back
up 5 degrees.
Display
Arm stretch
Leg stretch
3. When the operation is complete, the
legrest will return to the angle at the
time before the operation.
3. Then, the backrest will recline approximately
10 degrees to stretch the shoulders and
arms further. When the operation is
complete, the backrest will return to the
angle at the time before the operation.
