Komatsu D475A-5E0 Brochure

STANDARD EQUIPMENT
● Air conditioner with heater and defroster ● Hinged underguard with front pull hook
● Air-suspension seat ● Hydraulic track adjusters
● Alternator, 100 A/24 V ● Lighting system (including four front
● Auto-priming system
and two rear lights)
● Back-up alarm ● Lockup torque converter
● Batteries, 200 Ah/4 x 12 V ● Mirror
● Blower fan ● Mirror, rearview
● Decelerator pedal ● Muffler with rain cap
● Dry-type air cleaner with dust evacuator ● Perforated front mask
● Radiator reserve tank
and dust indicator
● Eight-roller track frames ● ROPS brackets
● Final drive case wear guard ● Seat belt
● Segmented sprockets
ROPS*:
Weight . . . . . . . . . . . . . . . . 940 kg 2,070 lb
Dimension:
Width . . . . . . . . . . . . . . . . . . 1940 mm 6'4"
*Meets ISO 3471, SAE J1040 APR88, ROPS
standards.
OPTIONAL EQUIPMENT
Variable giant ripper:
Variable, parallelogram single-shank ripper
ideal for ripping up tough material. Ripping
angle is variable. Ripping depth is adjustable
in four stages by a hydraulically controlled
pin puller.
Weight (including hydraulic
control unit) . . . . . . . . 7360 kg 16,230 lb
Beam length . . . . . . . . . . . . 1477 mm 4'10"
Maximum lift above ground . 1196 mm 3'11"
Maximum digging depth . . . . 1744 mm 5'9"
● Hydraulics for ripper
● Additional cab heater
● Lattice front mask
● Battery isolator
● Light for ripper
● Coal dozer
● Orbcomm
● Counterweight
● Prelubrication
● Double wiper
● Push plate
● Dual tilt dozer
● Radio-AM/FM cassette
● Fast fuel fill
● Safety glass
● Fire extinguisher
www.Komatsu.com
Materials and specifications are subject to change without notice.
CEN00075-02
● Shoes, 710 mm 28" extreme service,
single-grouser
● Starting motors, 2 x 7.5 kW/24 V
● Steel cab
● Steering control
● Sun visor
● TORQFLOW transmission
● Track roller guards
● VHMS (without orbcomm)
● Warning horn
● Water separator
● Wet steering clutches
Steel cab**:
Weight . . . . . . . . . . . . . . . . 455 kg 1,000 lb
Dimension:
Length. . . . . . . . . . . . . . . 1790 mm 5'10"
Width . . . . . . . . . . . . . . . . 1455 mm 4'9"
Height from compartment
floor to ceiling . . . . . . . . 1530 mm 5'0"
**Meets ISO 3449 FOPS standard.
Multi-shank ripper:
Hydraulically controlled parallelogram ripper
with three shanks. Ripping angle variable
and depth adjustable in two stages.
Weight (including hydraulic
control unit) . . . . . . . . 9720 kg 21,430 lb
Beam length . . . . . . . . . . . . 3085 mm 10'1"
Maximum lift above ground . 1196 mm 3'11"
Maximum digging depth . . . . 1124 mm 3'8"
● Shoes:
—810 mm 32"
—910 mm 36"
● Spill guards
● Strengthened Semi-U blade
● Strengthened U blade
● Track shoe slip control system
Printed in Japan 200801 IP.AD (10)
is a trademark of Komatsu Ltd. Japan.
D475A
-5E0
HORSEPOWER
Gross: 671 kW 899 HP @ 2000 rpm
Net: 664 kW 890 HP @ 2000 rpm
OPERATING WEIGHT
108390 kg 238,960 lb
Photo may include optional equipment.
