Komatsu D275A-5 Brochure

STANDARD EQUIPMENT
● Alternator 75 ampere/24V ● Hydraulic track adjusters
● Backup alarm ● Lighting system (including four front
● Batteries 170 Ah/2 x 12V
and two rear lights)
● Blower fan ● Torque converter
● Decelerator pedal ● Muffler with rain cap
● Dry-type air cleaner with dust evacuator ● Palm lever steering control
● Radiator reserve tank
and dust indicator
● Final drive case wear guard ● ROPS brackets
● Hinged front mask ● Segmented sprockets
● Hinged underguard with front pull hook
OPTIONAL EQUIPMENT
● Air conditioner with heater and defroster ● Mirror, rearview
● Alternator 90 ampere/24 V ● Panel cover
● Batteries 200 Ah/2 x 12V ● Perforated side covers
● Car stereo ● Perforated single radiator mask
● Counterweight ● Pusher plate
● Dual tilt dozer ● Seat belt
● Fire extinguisher ● Shoes:
● Hitch
—710 mm 28"
● Hydraulics for ripper
—760 mm 30"
● Light for ripper point ● Spill guard for semi-U dozer
ROPS canopy:* Multi-shank ripper:
Weight . . . . . . . . . . . . . . . . 650 kg 1,430 lb Hydraulically controlled parallelogram ripper
Roof dimensions with three shanks. Ripping angle available
Length . . . . . . . . . . . . . . . 1405 mm 4'7" stepless adjustable.
Width . . . . . . . . . . . . . . . . 2035 mm 6'8"
Weight (including hydraulic
Height from
control unit) . . . . . . . . . 4462 kg 9,840 lb
compartment floor . . . . . . . 1830 mm 6'0"
Beam length . . . . . . . . . . . . . 2495 mm 8'2"
*Meets ISO 3471 and SAE J1040 APR88, ROPS
Maximum lift above ground . . . 955 mm 3'2"
standards, as well as ISO 3449 FOPS standard
Maximum digging depth . . . . 900 mm 2'11"
Additional ground
Additional ground
pressure . . 9.8 kPa 0.10 kg/cm
pressure . . 2.0 kPa 0.02 kg/cm 2 0.28 psi
Steel Cab:
Weight. . . . . . . . . . . . . . . . . . 415 kg 910 lb
Dimensions:
Length. . . . . . . . . . . . . . . 1790 mm 5'10"
Width . . . . . . . . . . . . . . . . 1455 mm 4'9"
Height from compartment
floor to ceiling . . . . . . . . . . 1530 mm 5'0"
Additional ground
pressure . . 1.0 kPa 0.01 kg/cm 2 0.14 psi
CEN00024-01
www.Komatsu.com
● Shoes, 610 mm 24" extreme service,
single-grouser
● Seven-roller track frames
● Starting motor 11 kW/24 V
● Suspension seat, synthetic leather
● TORQFLOW transmission
● Track roller guards
● Warning horn
● Wet steering clutches/brakes
● Spill guard for U-dozer
● Sun visor
● Suspension seat
—Fabric seat
—Fabric seat, high backrest
● Strengthened Semi-U blade
● Strengthened U blade
● Track shoe slip control system
● Vandalism protection kit
Variable giant ripper:
Variable, parallelogram single-shank ripper
ideal for ripping up tough material. Ripping
angle is variable. Ripping depth is adjustable
in three stages by a hydraulically controlled
pin puller.
Weight (including hydraulic
control unit) . . . . . . . . . 3600 kg 7,940 lb
Beam length . . . . . . . . . . . . . 1252 mm 4'1"
Maximum lift above ground . 1195 mm 3'11"
2 1.42 psi Maximum digging depth . . . . 1420 mm 4'8"
Additional ground
pressure . . 7.8 kPa 0.88 kg/cm
Printed in Japan 200807 IP.AD (10)
Materials and specifications are subject to change without notice
is a trademark of Komatsu Ltd. Japan
D275A-5
2 1.14 psi
NET HORSEPOWER
306 kW 410 HP
OPERATING WEIGHT
49850 kg 109,900 lb
D
275
Photo may include optional equipment
