NAPCO MAGNUM ALERT 3000 FIRE ALARM Basic Operating Instructions

BASIC OPERATING INSTRUCTIONS FOR THE MA3000 FIRE CONTROL PANEL
Note: Text in quotes indicates a displayed message; messages preceded and followed by asterisks indicate additional
related message(s) to follow. Buttons markings are shown in brackets ( [ ] ).
Note: This system uses a "smart" menu-driven keypad; that is,
when scrolled, the keypad will display only those options that
are relevant to the existing condtion.
STANDBY
This is the normal mode. The keypad will read "NORMAL'; no
reminders ("DISABLE"; "FIRE/TEL"; "SYS TEL") will display; the
green AC-POWER light will be on.
FIRE ALARM
Signal deviceswill sound. The keypad will display " FIRE ",
followed by the number and description of the zone in alarm,
then " FIRE STATUS ", then "FIRE ALARM". The "FIRE/TBL"
reminder and the ALARM light will come on.
SILENCING A FIRE ALARM
Enter code and press [SILENCE] to silence the signal devices
and keypad sounder. The keypad will display "FIRE SI-
LENCED, followed by " FIRE STATUS ", "FIRE ALARM",
then "FIRE SILENCED". Another alarm will sound the signals
again.
FIRE ALARM RESET
Enter code and press [INFO]. Press [NO] to continue to scroll
options or [YES] to select option.
FIRE TROUBLE
The keypad will display "FIRE TROUBLE" followed by the
number and description of the zone in trouble, then " FIRE
STATUS ", then "FIRE TROUBLE". The "FIRE/TBL" reminder
will flash.
FIRE TROUBLE RESET
Enter code and press [INFO]. The keypad will display options
one at a time. Press [NO] to continue to scroll options or [YES]
to select option.
SUPERVISORY ALARM
The keypad will sound and display " SUPV ALARM " fol-
lowed by the number and description of the fire supervisory
zone in alarm, then " FIRE STATUS ", then "SPRINK SUPV
ALARM". This indicates that a device designed to monitor the
fire alarm system is in alarm.
SUPERVISORY TROUBLE
The keypad will sound and display " SUPV TROUBLE "
followed by the number and description of the supervisory zone
in trouble, then " FIRE STATUS ", then
TRBL".
SUPERVISORY ALARM/TROUBLE RESET
Enter code and press [INFO].The keypad will display options
one at a time. Press [NO] to continue to scroll options or [YES]
to select option.
Local Service Representative: ________________________________________________________
Address: _________________________________________________________________________
Telephone Number: ________________________________________________________________
Note: (1) Test system weekly! (2) If panel sounder is on, call for service. (3) A complete functional checkout of the control unit is required
following any programming or reprogramming. (4) This page is to be framed and mounted adjacent to the control unit.
WITH THE CF3000LCD KEYPAD.
FIRE ALARM/TROUBLE CONDITIONS
The keypad will constantly display the alarm/trouble condi-
tions still present on the system. " FIRE STATUS " will dis-
play followed by the condition(s). To determine the particular
zone(s) respansible for the condition(s), enter code and press
[INFO]. The keypad will display options one at a time. Press
[NO] to continue to scroll options or [YES] to select option.
DISABLE/ENABLE ZONE BUTTON
For installer's use only.
ALARM TEST
Operate an initiating device. Signal devices will sound and the
keypad will display an alarm. Silence the alarm and reset the
device.
FIRE DRILL TEST
Enter code and press [INFO]. Press [NO] until "FIRE DRILL?
(YES/NO)" appears, Press [YES]. The fire signal devices
should sound. To terminate the test, enter code, then press
[SILENCE]. The keypad will display "NOT NORMAL", indicating
that the fire bell is active.
SYSTEM TEST
To test the keypad, hold down the[*] and [3] keys simul-
taneously. The three reminders ("DISABLE"; "FIRE/TEL"; "SYS
TBL") will display and all screen characters will appear black.
Holding the [ ] key depressed, press [3] to view different
characters on the display. Press [RESET] to terminate the test.
To test fire alarm signal devices, enter code and press
[INFO]. Press [NO] until "TEST ALARMS? (YES/NO)" appears.
Press [YES]. Fire signal devices should sound for 2 seconds.
SYSTEM TROUBLE
When a system trouble is detected, the "SYS TBL" reminder
will flash, the screen will display the system trouble, and the
keypad sounder will pulse. To acknowledge the system trouble,
enter code, then press [RESETI. The keypad will silence and
the system trouble descrIption will clear. However If the system
trouble still exists, the "SYS TEL" reminder will remain on and
the screen will display "NOT NORMAL".
"SPRINK SUPV
To determine the particular condition responsible for the
system trouble, enter code, then press [INFO]. Press [No] until
"DISP SYS TRBL? (YES/NO)" appears, then press [YES].
WI658C 08/99
