Setup Manual
TA770E/TA770XE/TA790XE BIOS Manual
BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2 Advanced Menu.......................................................................................7
3 PCIPnP Menu........................................................................................16
4 Boot Menu..............................................................................................19
5 Chipset Menu.........................................................................................21
6 T-S eries Menu........................................................................................27
7 Exit Menu...............................................................................................39
i
Advertisement
Table of Contents
Related Manuals for Biostar TA770E - BIOS
Summary of Contents for Biostar TA770E - BIOS
- Page 1 TA770E/TA770XE/TA790XE BIOS Manual BIOS Setup ....................1 1 Main Menu....................3 2 Advanced Menu..................7 3 PCIPnP Menu..................16 4 Boot Menu....................19 5 Chipset Menu..................21 6 T-S eries Menu..................27 7 Exit Menu....................39...
-
Page 2: Bios Setup
TA770E/TA770XE/TA790XE BIOS Manual BIOS Setup Introduction T he purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. T he power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off. -
Page 3: Pci Bus Support
TA770E/TA770XE/TA790XE BIOS Manual PCI Bus Support T his AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconn ect) local bus speci fication. DRAM S upport DDR2 SDRAM (Double Data Rate II Synchronous DRAM) is supported. Supported CP Us T his AMI BIOS supports the AMD CPU . -
Page 4: System Memory
TA770E/TA770XE/TA790XE BIOS Manual 1 Main Menu Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system inform ation. BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et T-Series Exit Syste m Overview... -
Page 5: Ide Configuration
TA770E/TA770XE/TA790XE BIOS Manual Floppy A Select the type of floppy disk drive installed in your system. Options: 360K, 5.25 in / 1.2M, 5.25 in / 720K, 3.5 in / 1.44M, 3.5 in / 2.88M, 3.5 in / None IDE Configuration T he BIOS will automatically detect the presence of ID E/SAT A devices. - Page 6 TA770E/TA770XE/TA790XE BIOS Manual Primary IDE Master/Slav e ; SATA 1/2/3/4/5/6 Dev ice BIOS SETUP UTILITY Main Primary IDE Master Select the type of device connected Device to the system. Type [Auto] LBA/Large Mode [Auto] Block (Multi-Sector Transfer)[Auto] PIO Mode [Auto] DMA Mode [Auto] S.M.A.R.T...
-
Page 7: Hard Disk Write Protect
TA770E/TA770XE/TA790XE BIOS Manual 32Bit Data Transfer Enable or disable 32-bit data transfer. Options: Enabled (Default) / Disabled Hard Disk Write Protect Disable or enable device write protection. T his will be effective only if the device is accessed through BIOS. Options: Disabled (Default) / Enabled IDE Detect Time Out (Sec) -
Page 8: Advanced Menu
TA770E/TA770XE/TA790XE BIOS Manual 2 Advanced Menu T he Advanced Menu allows you to configu re the settings of CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. - Page 9 TA770E/TA770XE/TA790XE BIOS Manual Secure Virtual Machine Mode Virtualization T echnology can virtually separate your system resou rce into several parts, thus enhance the performance when running virtual machines or multi interf ace systems. Options: Enabled (Default) / Disabled PowerNow T his item allows you to enable or disable the PowerNow power saving technology. Options: Enabled (Default) / Disabled ACPI SRAT Table...
-
Page 10: Super Io Configuration
TA770E/TA770XE/TA790XE BIOS Manual SuperIO Configuration BIOS S ETUP UTILITY Advanced Confi gure ITE8718 Super IO Chi pset Allo ws BIOS to E nable or D isable Flopp y Onboa rd Floppy Con troller [ Enabled] Cont roller Keybo ard PowerOn [ Disabled] Mouse PowerOn [ Disabled]... -
Page 11: Smart Fan Configuration
TA770E/TA770XE/TA790XE BIOS Manual Mouse PowerOn T his item allows you to control the mouse power on function. Options: Disabled (Default) / Enabled Restore on AC Power Loss T his setting specifies how your system should behave after a power fail or interrupts occurs. -
Page 12: Hardware Health Configuration
TA770E/TA770XE/TA790XE BIOS Manual Control Mode T his item provides several operation modes of the fan. Options: Quiet / Performan ce / Manual Fan Ctrl OFF(℃ ) If the CPU/System T emperature is lower than the set value, FAN will turn off. 0~127 (℃) Options: Fan Ctrl On(℃... -
Page 13: Power Configuration
TA770E/TA770XE/TA790XE BIOS Manual H/W Health Function If with a monitoring system, the system will show PC health status during POST stage. Options: Enabled (Default) / Disabled Shutdow n Temperature T his item allows you to set up the CPU shutdown T emperature. This item is only effective under Windows 98 ACPI mode. - Page 14 TA770E/TA770XE/TA790XE BIOS Manual ACPI APIC support T his item is used to enable or disable the motherboard's APIC (Advan ced Programmable Interrupt Controller). The APIC provides multiprocessor support, more IRQs and faster interrupt handling. Options: Enabled (Default) / Disabled AMI OEMB table Set this value to allow the ACPI BIOS to add a pointer to an OEMB table in the Root System Description T able (RSD T ) table.
-
Page 15: Usb Configuration
TA770E/TA770XE/TA790XE BIOS Manual Wake Up by PCI Enable / Disable PCI to generate a wake ev ent. Options: Disabled (Default) / Enabled USB Configuration T his item shows the USB controller and using USB device information. BIOS S ETUP UTILITY Advanced USB C onfiguration Enab les support for... - Page 16 TA770E/TA770XE/TA790XE BIOS Manual USB Mass Storage Dev ice Configuration BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 Sec] USB mass storage device after start Device # unit command.
-
Page 17: Pcipnp Menu
TA770E/TA770XE/TA790XE BIOS Manual 3 PCIPnP Menu T his section describes con figuring the PCI bus system. PCI, or Personal Computer Interconn ect, is a system which allows I/O devices to operate at speeds nearing the speed o f the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. -
Page 18: Pci Latency Timer
TA770E/TA770XE/TA790XE BIOS Manual PCI Latency Timer T his item controls how long a PCI device can hold the PCI bus bef ore another takes over. T he longer the latency, the longer the PCI device can retain control of the bus before handing it over to another PCI device. -
Page 19: Reserved Memory Size
TA770E/TA770XE/TA790XE BIOS Manual IRQ3/4/5/7/9/10/11/14/15 T hese items will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. T he option “Available” means the IRQ is going to assign automatically. Options: Available (Default) / Reserved DMA Channel 0/1/3/5/6/7 T hese items will allow you to assign each DMA channel a type, depending on the type of device using the channel. -
Page 20: Boot Device Priority
TA770E/TA770XE/TA790XE BIOS Manual 4 Boot Menu T his menu allows you to setup the system boot options. BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et T-Series Exit Boot Settings Conf iguration Spec ifies the Boot Device Prio rity sequenc e. >... -
Page 21: Quick Boot
TA770E/TA770XE/TA790XE BIOS Manual CD/DV D Drives T he BIOS will attempt to arrange the CD/DVD drive boot sequence automatically. You can also change the booting sequence. The number of device items that appears on the screen depends on the number of devices installed in the system. Options: Pri. -
Page 22: Chipset Menu
TA770E/TA770XE/TA790XE BIOS Manual 5 Chipset Menu T his submenu allows you to configure the speci fic features of the chipset installed on your system. T his chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. BIOS S ETUP UTILITY Main Advanced... -
Page 23: Onchip Sata Channel
TA770E/TA770XE/TA790XE BIOS Manual SB Azalia Audio Configuration BIOS S ETUP UTILITY Chips et HD Au dio Azalia De vice [ Enabled] Options Azali a Clock Gatin g [ Disabled] Auto Disa bled Enab led S elect Screen S elect Item C hange Option G eneral Help F1 0... -
Page 24: Power Saving Features
TA770E/TA770XE/TA790XE BIOS Manual Option ROM POST Delay Options: Disabled (Default) / 1 ~ 7 Seconds SATA IDE Combined Mode T his option controls the SAT A/PAT A combined mode. Options: Enabled (Default) / Disabled Power Saving Features Disable / Enable power saving featu res in SB. Generally, this f eature should be disabled for desktop and enabl ed fo r mobile. - Page 25 TA770E/TA770XE/TA790XE BIOS Manual PCI Express Configuration BIOS S ETUP UTILITY Chips et PCI E xpress Config uration Options Peer- to-Peer among GFX/GFX2 [ Disabled] Enab led GPP S lots Power Li mit, W [ 25 ] Disa bled > Por t #02 Feature s >...
-
Page 26: Primary Video Controller
TA770E/TA770XE/TA790XE BIOS Manual Link ASPM Options: Disabled (Default) / L0s / L1 / L0x & L1 Link Width Options: Auto (Default) / x1 / x2 / x4 / x8 / x16 Slot Power Limit, W Options: 75 (Default) / 0-255 NB-SB Port Features BIOS S ETUP UTILITY Chips et... -
Page 27: Onboard Peripherals Configuration
TA770E/TA770XE/TA790XE BIOS Manual OnBoard Peripherals Configuration BIOS S ETUP UTILITY Chips et MAC I D Information Enab le/Disable Realt ek PCIE NIC [ Enable] Onbo ard Realtek Real tek Option RO M [ Disabled] PCIE Network Cont roller S elect Screen S elect Item C hange Option G eneral Help... -
Page 28: Overclock Navigator
OverClock Navigator OverClock .Navigator is designed for beginners in overclock field. Based on many test and experiments from Biostar Engineer Team, OverClock Navigator provid es 3 default overclo ck con figurations that are able to raise the system perfo rmance. - Page 29 TA770E/TA770XE/TA790XE BIOS Manual Auto OverClock S ystem BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et T-Series Exit T-Ser ies Settings Options WARNI NG: Pl ease Clear C MOS if syste m no display Norm al af ter overcloc king. Auto mate OverClo ck Manu al OverClock OverC lock Navigato r...
-
Page 30: Over-Voltage Configuration
TA770E/TA770XE/TA790XE BIOS Manual Manual Overclock System (M.O.S.) BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et T-Series Exit T-Ser ies Settings Options WARNI NG: Pl ease Clear C MOS if syste m no display Norm al af ter overcloc king. Auto mate OverClo ck Manu al OverClock OverC lock Navigato r... -
Page 31: Cpu Nb Voltage
TA770E/TA770XE/TA790XE BIOS Manual Memory Over Voltage T his item allows you to select DDR Over Voltage Control. Options: 1.950V (Default) / 1.970V ~ 2.950V (Interval: 0.02V) Chipset Over Voltage T his item allows you to select chipset Voltage Control. Options: Auto (Default) / 1.160V ~ 2.340V (Interval: 0.02V) CPU NB Voltage T his item allows you to select CPU NB Over Voltage Control. -
Page 32: Phase Control
TA770E/TA770XE/TA790XE BIOS Manual G.P.U Phase Control BIOS S ETUP UTILITY T-Series G.P.U Phase Contro l Options Phase Status Auto CPU V core: Curre nt CPU Power : Effic iency G.P.U Phase Mode [ Auto] S elect Screen S elect Item C hange Option G eneral Help F1 0... - Page 33 TA770E/TA770XE/TA790XE BIOS Manual Processor Multiplier T his item allows you to select multiplier of CPU. Options: Auto (Default) / x4.0 800MHz ~ x13.0 2600MHz (Differed by CPU) Processor Voltage T his item allows you to select voltage of CPU. Options: Auto (Default) / 0.800V ~ 1.550V (Differed by CPU) Custom P-States (AM2+ CPU Only) T his item allows you to select the P-States controlling.
-
Page 34: Dram Timing Configuration
TA770E/TA770XE/TA790XE BIOS Manual DRAM Timing Configuration BIOS S ETUP UTILITY T-Series DRAM Timing Config uration Sele ct the DRAM Freq uency progra mming Memor y Clock Mode [ Auto] meth od. If Auto, DRAM Timing Mode [ Auto] the DRAM speed w ill be b ased on SPDs . - Page 35 TA770E/TA770XE/TA790XE BIOS Manual CAS Latency (CL) Options: Auto (Default) / 3~6 CLK 2T Command Options: Auto (Default) / 1T / 2T TR CD Options: Auto (Default) / 3~6 CLK Options: Auto (Default) / 3~6 CLK tR TP Options: Auto (Default) / 2~4 CLK TR AS Options: Auto (Default) / 5~18 CLK...
-
Page 36: Hyper Transport Configuration
TA770E/TA770XE/TA790XE BIOS Manual tWRRD Options: Auto (Default) / 0~3 CLK tWTR Options: Auto (Default) / 1~3 CLK tWRWR Options: Auto (Default) / 1~3 CLK tRDRD Options: Auto (Default) / 2~5 CLK tRFC0 / tRFC1 / tRFC2 / tRFC3 Options: Auto (Default) / 75ns / 105ns / 127.5ns / 195ns / 327.5ns Hyper Transport Configuration BIOS SETU P U TILITY T-Series... -
Page 37: Memory Configuration
TA770E/TA770XE/TA790XE BIOS Manual Memory Configuration BIOS S ETUP UTILITY T-Series Memor y Configurati on Enab le Bank Memo ry Inte rleaving Bank Interleaving [ Auto] Enabl e Clock to Al l DIMMs [ Disabled] MemCl k Tristate C3 /ATLVID [ Disabled] Memor y Hole Remapp ing [ Enabled] Power Down Enable... -
Page 38: Ecc Configuration
TA770E/TA770XE/TA790XE BIOS Manual DC T Unganged Mode T his item controls the DRAM controller ganged (128bit*1) / unganged (64bit*2) dual-chann el operation mode. If two DRAM modules with different size are installed, using unganged mode can still make it run in dual-channel operation. Options: Always (Default) / Auto Power Dow n Enable... - Page 39 TA770E/TA770XE/TA790XE BIOS Manual Integrated Memory Test Integrat ed Memory T est allows users to test memory module compatibilities without additional device or sof tw are. Step 1: T his item is disabled on default; change it to “ Enable” to precede memory test. BIOS S ETUP UTILITY Main Advanced...
-
Page 40: Save Changes And Exit
TA770E/TA770XE/TA790XE BIOS Manual 7 Exit Menu T his menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset T-Series Exit Exit Options Exit system setup after saving the... -
Page 41: Cmos Backup Function
TA770E/TA770XE/TA790XE BIOS Manual CMOS Backup Function It allows users to save different CMOS settings into BIOS-ROM and reload any saved CMOS setting for customizing system configurations. Moreover, users are able to save an ideal overclock setting during overclock operation. T here are 10 sets o f record address es in total, and users are able to nam e the CMOS data acco rding to personal preference. - Page 42 TA770E/TA770XE/TA790XE BIOS Manual Change Supervisor Passw ord Setting the supervisor password will prohibit everyone except the supervisor from making changes using the CMOS Setup Utility. You will be prompted with to enter a password. User Acess Level T his item allows supervisor to set the user level. Options: Full Access (Default) / No Access / View Only / Limited Change User Password...
