TA790GX A3+Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Biostar TA790GX A3 PLUS
Summary of Contents for Biostar TA790GX A3 PLUS
- Page 1 TA790GX A3+Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Introduction ............1 Before You Start ................1 Package Checklist ................1 Motherboard Features..............2 Rear Panel Connectors ..............3 Motherboard Layout................. 4 Chapter 2: Hardware Installation ..........5 Installing Central Processing Unit (CPU)........5 FAN Headers.................. -
Page 3: Chapter 1: Introduction
TA790GX A3+ CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation. -
Page 4: Motherboard Features
Motherboard Manual OTHERBOARD EATURES SPEC AMD 64 Architecture enables 32 and 64 bit Socket AM3 computing AMD Phenom II processors Supports Hyper Transport 3.0 and PowerNow Support HyperTransport 3.0 Supports up to 5.2 GT/s Bandwidth AMD 790GX Chipset AMD SB750 ITE 8718 Environment Control initiatives, Provides the most commonly used legacy... -
Page 5: Rear Panel Connectors
Provide Audio-In/Out and microphone connection Board Size 244 mm (W) x 305 mm (L) Biostar reserves the right to add or remove support OS Support Windows XP / Vista 32 / Vista 64 for any OS With or without notice. -
Page 6: Motherboard Layout
Motherboard Manual OTHERBOARD AYOUT JKBMS1 JCFAN1 JATX PWR3 J1394_US1 JATXPW R2 JUSBLAN1 JAUDIO2 790GX JATX PWR1 PHASE1_LED PHASE2_LED PHASE3_LED LED_D1 JCDIN1 PHASE4_LED LED_D2 JNFA N1 PEX16_2 SATA5-6 PEX1_1 BAT1 SB750 PEX1_2 SATA3-4 PEX16_1 SATA1-2 PCI1 Super I/O Codec BIOS JSFAN1 PCI2 JCMOS1 JSPDIF_OUT1... -
Page 7: Chapter 2: Hardware Installation
TA790GX A3+ CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Step 1: Remove the socket protection cap. Step 2: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle. Step 3: Look for the white triangle on socket, and the gold triangle on CPU should point towards this white triangle. - Page 8 Motherboard Manual Step 3: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 4: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the JCFAN1. This completes the installation.
-
Page 9: Fan Headers
TA790GX A3+ FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. -
Page 10: Installing System Memory
Motherboard Manual NSTALLING YSTEM EMORY A. DDR3 Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated. - Page 11 TA790GX A3+ B. Memory Capacity DIMM Socket Total Memory DDR3 Module Location Size DDR3_A1 256MB/512MB/1GB/2GB/4GB DDR3_B1 256MB/512MB/1GB/2GB/4GB Max is 16GB. DDR3_A2 256MB/512MB/1GB/2GB/4GB DDR3_B2 256MB/512MB/1GB/2GB/4GB C. Dual Channel Memory installation Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table.
-
Page 12: Connectors And Slots
Motherboard Manual ONNECTORS AND LOTS FDD1: Floppy Disk Connector The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the provided floppy drive ribbon cables. IDE1: IDE/ATAPI Connector The motherboard has a 32-bit Enhanced IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 functionality. - Page 13 TA790GX A3+ PEX16_1: PCI-Express Gen2 x16 Slot (x16/x8 Speed) PCI-Express 2.0 compliant. PCI-Express Gen2 supports a raw bit-rate of 5.0Gb/s on the data pins. 2X bandwidth over the PCI-Express 1.1 architecture. x16 Speed Mode: Maximum theoretical realized bandwidth of 8GB/s simultaneously per direction, for an aggregate of 16GB/s totally.
- Page 14 Motherboard Manual PEX1_1/PEX1_2: PCI-Express Gen2 x1 Slots PCI-Express 2.0 compliant. Data transfer bandwidth up to 500MB/s per direction; 1GB/s in total. PCI-Express Gen2 supports a raw bit-rate of 5.0Gb/s on the data pins. 2X bandwidth over the PCI-Express 1.1 architecture. PEX1_1 PEX1_2 PCI1~PCI2: Peripheral Component Interconnect Slots...
-
Page 15: Chapter 3: Headers & Jumpers Setup
TA790GX A3+ CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened Pin closed Pin1-2 closed... - Page 16 Motherboard Manual JATXPWR2: ATX Power Source Connector This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V Ground +3.3V JATXPWR3: ATX Power Source Connector...
-
Page 17: Clear Cmos Procedures
TA790GX A3+ JATXPWR1: Auxiliary Power for Graphics This connector is an auxiliary power connection for graphics cards. Exclusive power for the graphics card provides better graphics performance. Assignment +12V Ground Ground JCMOS1: Clear CMOS Header By placing the jumper on pin2-3, it allows user to restore the BIOS safe setting and the CMOS data, please carefully follow the procedures to avoid damaging the motherboard. - Page 18 Motherboard Manual SATA1-2/SATA3-4/SATA5-6: Serial ATA Connectors The motherboard has a PCI to SATA Controller with 6 channels SATA interface, it satisfies the SATA 2.0 spec and with transfer rate of 3.0Gb/s. SATA1 -2 SATA3-4 SATA5 -6 JUSB3~JUSB5: Headers for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC front panel, and also can be connected with internal USB devices, like USB card reader.
- Page 19 TA790GX A3+ JAUDIOF1: Front Panel Audio Header This header allows user to connect the front audio output cable with the PC front panel. This header allows only HD audio front panel connector; AC’97 connector is not acceptable. Assignment Mic Left in Ground Mic Right in GPIO...
- Page 20 Motherboard Manual On-Board LED Indicators There are 6 LED indicators showing system status. PHASE1_LED PHASE2_LED PHASE3_LED PHASE4_LED LED_D2 LED_D1 LED1 & LED2: Debug Indicators PH1 ~ PH4: Power Status Indicators Please refer to the tables below for specific messages: LED1 LED2 Message Normal...
-
Page 21: Chapter 4: (Hybrid) Crossfirex Function
TA790GX A3+ CHAPTER 4: (HYBRID) CROSSFIREX FUNCTION ROSS EQUIREMENTS Only Windows XP/Vista supports CrossFireX (Dual Video) function. A pair of graphics cards with Radeon HD3650/HD3850/HD3870/HD4850/ HD4870/HD4670/HD4650/HD4350/HD4550/HD4830 GPU. The graphics card driver should support CrossFireX technology. The power supply unit must provide at least the minimum power required by the system, or the system will be unstable. -
Page 22: Hybrid Crossfirex Requirements
Motherboard Manual YBRID ROSS EQUIREMENTS Only Windows Vista supports Hybrid CrossFireX function. A graphics card with Radeon HD3450/HD3470 GPU. The graphics card driver should support Hybrid CrossFireX technology. The power supply unit must provide at least the minimum power required by the system, or the system will be unstable. -
Page 23: Operation Modes Supporting List
TA790GX A3+ PERATION ODES UPPORTING Operation Mode Single Card CrossFireX Hybrid CrossFireX Model Radeon HD3650 Radeon HD3850 Radeon HD3870 Radeon HD4850 Radeon HD4870 Radeon HD3450 Radeon HD3470 Radeon HD3870X2 (O means Supported, X means Not Supported.) -
Page 24: Chapter 5: Raid Functions
Motherboard Manual CHAPTER 5: RAID FUNCTIONS PERATING YSTEM Supports Windows XP and Windows VISTA. RRAYS RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications. - Page 25 TA790GX A3+ RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array.
- Page 26 Motherboard Manual RAID 1+0: RAID 1 drives can be stripped using RAID 0 techniques. Resulting in a RAID 1+0 solution for improved resiliency, performance and rebuild performance. Features and Benefits Drives: Minimum 4, and maximum is 6 or 8, depending on the platform. ...
- Page 27 TA790GX A3+ RAID 5: RAID 5 stripes both data and parity information across three or more drives. It writes data and parity blocks across all the drives in the array. Fault tolerance is maintained by ensuring that the parity information for any given block of data is placed on a different drive from those used to store the data itself.
-
Page 28: Chapter 6: T-Series Bios & Software
Motherboard Manual CHAPTER 6: T-SERIES BIOS & SOFTWARE BIOS ERIES T-Series BIOS Features Overclocking Navigator Engine (O.N.E.) Memory Integration Test (M.I.T., under Overclock Navigator Engine) BIO-Flasher: Update BIOS file from USB Flash Drive or FDD Self Recovery System (S.R.S) Smart Fan Function CMOS Reloading Program !! WARNING !! For better system performance, the BIOS firmware is being... -
Page 29: Cpu Configuration
TA790GX A3+ Manual Overclock System (M.O.S.) MOS is designed for experienced overclock users. It allows users to customize personal overclock settings. BIOS SETUP UTILITY PCIPnP Boot Main Advanced Chipset T-Series Exit T-Series Settings Options WARNING: Setting wrong values in below sections Normal may cause system to malfunction. - Page 30 Motherboard Manual CPU FID/VID Control Enter this function for more advanced CPU settings. Voltage Configuration Enter this function for more advanced voltage settings. DRAM Timing Configuration Enter this function for more advanced DRAM clock settings. Hyper Transport Configuration Enter this function for more advanced Hyper Transport settings. Memory Configuration Enter this function for more advanced memory settings.
- Page 31 TA790GX A3+ V6 Tech Engine This engine will make a good over-clock performance. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Chipset T-Series Exit T-Series Settings Options WARNING: Setting wrong values in below sections V6-Tech Engine may cause system to malfunction. V8-Tech Engine V12-Tech Engine OverClock Navigator...
- Page 32 Motherboard Manual Notices: Not all types of AMD CPU perform above overclock setting ideally; the difference will be based on the selected CPU model. B. Memory Integration Test (M.I.T.) This function is under “Overclocking Navigator Engine” item. MIT allows users to test memory compatibilities, and no extra devices or software are needed.
- Page 33 TA790GX A3+ C. BIO-Flasher BIO-Flasher is a BIOS flashing utility providing you an easy and simple way to update your BIOS via USB pen drive or floppy disk. The BIO-Flasher is built in the BIOS chip. To enter the utility, press <F12> during the Power-On Self Tests (POST) procedure while booting up.
- Page 34 Motherboard Manual D. Self Recovery System (S.R.S.) This function can’t be seen under BIOS setup; and is always on whenever the system starts up. However, it can prevent system hang-up due to inappropriate overclock actions. When the system hangs up, S.R.S. will automatically log in the default BIOS setting, and all overclock settings will be re-configured.
- Page 35 TA790GX A3+ Smart Fan Calibration Choose this item and then the BIOS will automatically test and detect the CPU/System fan functions and show CPU/System fan speed. Control Mode This item provides several operation modes of the fan. Fan Ctrl OFF(℃) If the CPU/System temperature is lower than the set value, the CPU/ System fan will turn off.
-
Page 36: T-Series Software
Motherboard Manual ERIES OFTWARE Installing T-Series Software 1. Insert the Setup CD to the optical drive. The drivers installation program would appear if the Auto-run function has been enabled. 2. Select Software Installation, and then click on the respective software title. - Page 37 TA790GX A3+ Over Clock Panel Restore Default Settings AUTO Over-Clock V3/V6/V9 Engine Real-time Ove r-clock Manual Adjust CPU Clock Test & Apply Manual Setting s AUTO User can click this button and the utility will set the best and stable performance and frequency automatically.
- Page 38 Motherboard Manual Then the utility will execute a series of testing until system fail. Then system will do fail-safe reboot by using Watchdog function. After reboot, launch the utility again and the utility will load the previously verified best and stable frequency. V3 / V6 / V9 Provide user the ability to do real-time over-clock adjustment.
- Page 39 TA790GX A3+ Over Voltage Panel Manual Adjust CPU/Memo ry/Chipset/FSB Voltage CPU Voltage This function allows user to adjust CPU voltage. Click on “+” to increase or “-“ to decrease the CPU voltage. Memory Voltage This function allows user to adjust Memory voltage. Click on “+” to increase or “-“...
-
Page 40: Hardware Monitor
Motherboard Manual About Panel In this panel, you can get model name and other system information that may related to over-clocking. You can also get the version number of this software. Note Because the Over Clock and Over Voltage features are controlled by several separate chipset, the utility divides these features to separate panels. - Page 41 TA790GX A3+ eHot-Line (Optional) eHot-Line is a convenient utility that helps you to contact with our Tech-Support system. This utility will collect the system information which is useful for analyzing the problem you may have encountered, and then send these information to our tech-support department to help you fix the problem. Before you use this utility, please set Outlook Express as your default e-mail client application program.
- Page 42 If you are not using Outlook Express as your default e-mail client application, you may need to save the system information to a .txt file and send the file to our tech support with other e-mail application. Go to the following web http://www.biostar.com.tw/app/en-us/about/contact.php for getting our contact information.
-
Page 43: Bios Update
TA790GX A3+ BIOS Update BIOS Update is a convenient utility which allows you to update your motherboard BIOS under Windows system. Show current BIOS information AWARD BIOS AMI BIOS Online Update function Clear CMOS function (Only for AMI BIOS) (Only for AWARD BIOS) Save current BIOS to a .bin file Update BIOS... - Page 44 Motherboard Manual <Update BIOS> Before doing this, please download the proper BIOS file from the website. For AWARD BIOS, update BIOS procedure should be run with Clear CMOS function, so please check on Clear CMOS first. Then click Update BIOS button, a dialog will show for asking you backup current BIOS.
- Page 45 TA790GX A3+ <Online Update> (for AMI BIOS only) Automatically download and update the latest BIOS via internet; make sure that the computer is connected to the internet before using this function. After clicking on the Online Update button, the utility will search for the latest BIOS from internet.
-
Page 46: Chapter 7: Useful Help
Motherboard Manual CHAPTER 7: USEFUL HELP RIVER NSTALLATION After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system. -
Page 47: Extra Information
TA790GX A3+ XTRA NFORMATION CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again. -
Page 48: Ami Bios Beep Code
Motherboard Manual AMI BIOS B Boot Block Beep Codes Number of Beeps Description No media present. (Insert diskette in floppy drive A:) “AMIBOOT.ROM” file not found in root directory of diskette in Insert next diskette if multiple diskettes are used for recovery Flash Programming successful File read error No Flash EPROM detected... -
Page 49: Troubleshooting
TA790GX A3+ ROUBLESHOOTING Probable Solution There is no power in the system. Make sure power cable is Power LED does not shine; the securely plugged in. fan of the power supply does not Replace cable. work Contact technical support. Indicator light on keyboard does not shine. -
Page 50: Appendix: Spec In Other Languages
Motherboard Manual APPENDIX: SPEC IN OTHER LANGUAGES ERMAN Spezifikationen Die AMD 64-Architektur unterstützt eine 32-Bit- und Sockel AM3 64-Bit-Datenverarbeitung AMD Phenom II Prozessoren Unterstützt Hyper Transport 3.0 und PowerNow Unterstützt HyperTransport 3.0 mit einer Bandbreite von bis zu 5.2 GT/s AMD 790GX Chipsatz AMD SB750... - Page 51 VGA-Anschluss DVI-D-Anschluss LAN-Anschluss USB-Anschluss Audioanschluss Platinengröße 244 mm (B) X 305 mm (L) Biostar behält sich das Recht vor, ohne Ankündigung OS-Unterstüt Windows XP / Vista 32 / Vista 64 die Unterstützung für ein Betriebssystem zung hinzuzufügen oder zu entfernen.
-
Page 52: French
Motherboard Manual RENCH SPEC Socket AM3 L'architecture AMD 64 permet le calcul 32 et 64 bits Processeurs AMD Phenom II Prend en charge Hyper Transport 3.0 et PowerNow Prend en charge Hyper Transport 3.0 jusqu'à Bus frontal une bande passante de 5.2 GT/s AMD 790GX Chipset AMD SB750... - Page 53 Fiche audio Dimensions 244 mm (l) X 305 mm (H) de la carte Biostar se réserve le droit d'ajouter ou de supprimer Support SE Windows XP / Vista 32 / Vista 64 le support de SE avec ou sans préavis.
-
Page 54: Italian
Motherboard Manual TALIAN SPECIFICA L’architettura AMD 64 abilita la co mputazione 32 Socket AM3 e 64 bit Processori AMD Phenom II Supporto di Hyper Transport 3.0 e PowerNow Supporto di HyperTransport 3.0 fino a 5.2 GT/s di larghezza di banda AMD 790GX Chipset AMD SB750... - Page 55 Connettore audio Dimension 244 mm (larghezza) x 305 mm i scheda (altezza) Sistemi Biostar si riserva il diritto di aggiungere o operativi Windows XP / Vista 32 / Vista 64 rimuovere il supporto di qualsiasi sistema supportati operativo senza preavviso.
-
Page 56: Spanish
Motherboard Manual PANISH Especificación La arquitectura AMD 64 permite el procesado de 32 y Conector AM3 64 bits Procesadores AMD Phenom II Soporta las tecnologías Hyper Transport 3.0 y PowerNow Admite HyperTransport 3.0 con un ancho de banda de hasta 5.2 GT/s Conjunto de AMD 790GX chips... - Page 57 Tamaño de 244 mm. (A) X 305 mm. (H) la placa Soporte de Biostar se reserva el derecho de añadir o retirar el sistema Windows XP / Vista 32 / Vista 64 soporte de cualquier SO con o sin aviso previo.
-
Page 58: Portuguese
Motherboard Manual ORTUGUESE ESPECIFICAÇÕES A arquitectura AMD 64 permite uma computação de 32 Socket AM3 e 64 bits Processadores AMD Phenom II Suporta as tecnologias Hyper Transport 3.0 e PowerNow Suporta a tecnologia HyperTransport 3.0 com uma largura de banda até 5.2 GT/s AMD 790GX Chipset AMD SB750... - Page 59 Tomada de áudio Tamanho 244 mm (L) X 305 mm (A) da placa Sistemas A Biostar reserva-se o direito de adicionar ou remover Windows XP / Vista 32 / Vista 64 operativos suporte para qualquer sistema operativo com ou sem suportados...
-
