Samsung SCP-2120 Specifications

SCP - 2120
600TVL
Ø120 (4.72")
FIRST PRINT 03-2010
12x
0.2 24VAC
Lux
Unit : mm (inch)
Ø147.5 (5.79")
SCP-2120N
ELECTRICAL
24V AC
Input Voltage
Max. 12W
Power Consumption
VIDEO
Imaging Device 1/4" Super HAD CCD
Total Pixels 811(H) x 508(V)
Effective Pixels 768(H) x 494(V)
Scanning System 2 : 1 Interlace
Internal / AC line lock
Synchronization
Frequency H : 15.734KHz / V : 59.94Hz
Horizontal Resolution Color : 600TV lines (Min.) / B/W : 700TV lines (Min.)
Color : 0.2Lux (50 IRE@F1.67), 0.0004Lux (Sens-up, 512x)
Min. Illumination
B/W : 0.004Lux (50 IRE@F1.67)
S / N (Y signal) 52dB
CVBS : 1.0Vp-p / 75 composite
Video Output
LENS
Zoom Ratio 12x (Optical), 16x (Digital)
Focal Length 3.9 ~ 46mm (F1.67 ~ 1.88)
Max. Aperture Ratio 1 : 1.67(Wide) ~ 1.88(Tele)
Min. Object Distance 1.8m (5.91ft)
Angular Field of View H : 25.77°(Wide) ~ 2.55°(Tele) / V : 19.64°(Wide) ~ 1.69°(Tele)
Auto / Manual / One-push
Focus
Zoom Movement Speed 1.9sec
Iris Control Auto / Manual
PAN / TILT
Pan Range 360° Endless
Pan Speed Preset : 650°/sec / Manual : 0.05°/sec ~ 120°/sec (Proportional zoom ratio)
-5° ~ 185°
Tilt Range
Preset : 650°/sec / Manual : 0.05°/sec ~ 120°/sec (Proportional zoom ratio)
Tilt Speed
Preset Positions 255
Preset Accuracy ±0.1°
PTZ Mode Preset, Swing, Group, Tour
OPERATIONAL
Korean, English, Japanese,
On Screen Display
Spanish, French, Portuguese, Taiwanese
Camera Title On / Off (Displayed 15 characters)
Day & Night Auto (ICR) / Color / B/W
SSDR On / Off (Level adjustable)
Backlight Compensation BLC / HLC / Off
Motion Detection On / Off (8 programmable zones)
On / Off
Digital Image Stabilization
On / Off (8 programmable zones)
Privacy Masking
2D+3D Noise Filter (SSNRIII) On / Off (Level adjustable)
Sens-up (Frame Integration) Auto / Off (Selectable 2x ~ 512x)
Gain Control Low / High / Off
White Balance AWC / Manual / Indoor / Outdoor / ATW (1,700°K ~ 11,000°K)
Auto (NTSC : 1/60 ~ 1/120,000sec, PAL : 1/50 ~ 1/120,000) / Manual / A.FLK
Electronic Shutter Speed
Communication RS-485/422, Coaxial control
Protocol Samsung-T, Pelco-D, Pelco-P, Pelco Coaxitron, Panasonic, Honeywell, AD, Vicon, BOSCH, GE
Alarm 2 In, 2 Out
Auto Digital Flip On / Off
ENVIRONMENTAL
Operating Temperature / Humidity -10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 90% RH
-20°C ~ +60°C (-4°F ~ +140°F) / 20% ~ 95% RH
Storage Temperature / Humidity
MECHANICAL
Dimension (WxH) Ø147.5 x 150mm (Ø5.79" x 5.91")
Weight 1.065Kg (2.35 lb)
Certifications FCC (Class A), UL/cUL listed
SCP-2120P
795(H) x 596(V)
752(H) x 582(V)
H : 15.625KHz / V : 50Hz
English, French, German, Spanish, Italian, Chinese, Russian,
Polish, Czech, Romanian, Serbian, Swedish, Danish, Turkish, Portuguese
CE (Class A), UL/cUL listed
SAMSUNG SECURITY SOLUTIONS_46
