HD4MDIP
EQUIP ® SERIES 720P TRUE DAY/NIGHT
RUGGED INDOOR/OUTDOOR DOME NETWORK CAMERA
Honeywell's latest addition to the EQUIP
high definition, True Day/Night rugged indoor/outdoor fixed mini-dome camera. This ultra
compact and vandal-resistant camera provides extremely crisp images at minimal
bandwidth. The HD4MDIP provides 720p resolution at full frame rate. Progressive scan
technology and 2D edge enhancement provide outstanding clarity and definition. Digital
Noise Reduction results in significant storage savings without sacrificing image quality in low
light. The ¼" progressive scan CMOS sensor offers the latest in digital video surveillance
technology with accurate color rendition through a wide variety of lighting conditions.
The HD4MDIP integrates a camera and lens in an ultra compact, single piece, tamper proof
unit for fast and easy installation in any application. The camera comes complete with
surface and flush mounting options (compatible with a 4S electrical box), and optional wall
and pendant mount kits are available.
In addition to the low light color performance, the camera will automatically switch to black
and white. In this mode, lighting can be complemented with infrared for discreet/covert low
light surveillance with exceptional monochrome images.
A 3-D axis gimbal capable of 360° of pan, 180° of tilt and 360° of horizontal rotation
simplifies mechanical camera adjustment. The Vari-focal Auto Iris lens allows the field of
view to be adjusted to suit the scene requirements, and an on-board analog output allows
the installer to connect a local test monitor while adjusting the scene.
A powerful and intuitive web client allows fine tuning of the camera. This can also be
performed from most DVR/NVR setup utilities.
The HD4MDIP supports dual video streams and multiple compression formats with rates up
to 30 frames per second (25 fps for PAL systems). The digital compression parameters for
the two video streams are independently configurable. A third analog stream can be utilized
for failover and local viewing, and is also valuable when retrofitting onto an existing analog
input DVR or encoder (full resolution not available).
With built-in low current Power over Ethernet (IEEE 802.3af), Class 1, power is supplied to
the camera using standard network cabling, eliminating the need for a separate power
supply and associated wiring. In retrofit situations where PoE switching does not exist, the
unit can also be powered directly from 24 VAC.
Market Opportunities
The HD4MDIP is perfect for installations where excellent picture clarity at minimal bandwidth
is required. At three times the resolution of standard analog cameras, yet with similar
bandwidth requirements, the HD4MDIP can be retrofitted on many existing DVR/NVR
installations without requiring additional storage. Its discreet, vandal-resistant, outdoor
design provides maximum protection against dust, dirt, and water, and is also impact
resistant. This provides optimum performance for both indoor and outdoor applications.
Features
• Outstanding image quality,
720p (1280 X 720) resolution
• 30 fps (25 fps PAL)
progressive scan
• True Day/Night, 3.3-12 mm VFAI lens
with removable IR cut filter
• Camera tamper detection
• Video motion detection
• Wall and pendant mount kit available
® Series of IP-based products, the HD4MDIP is a
• Selectable compression formats
• Dual digital video streams
simultaneously, independently
configurable
• Remote firmware update
• Supports both dynamic and static IP
address assignment
• Includes advanced IP locator software
to make system setup easy
www.honeywellvideo.com
• Web server for remote setup of
camera video and network parameters
• Choice of 24 VAC or PoE IEEE 802.3af
class 1 power inputs
• Supports input and output alarm
contacts
• Supports bidirectional audio
• Rugged polycarbonate dome
