  6. Set up and operating instructions manual

Central Hydraulics 99887 Set Up And Operating Instructions Manual

High position motorcycle lift
Hide thumbs
Table of Contents

Advertisement

Quick Links

MOTORCYCLE LIFT
SET uP aNd OPERaTING INSTRuCTIONS
distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SaVE THIS MaNuaL.
©
Copyright
2008 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
HIGH POSITION
3491 Mission Oaks Blvd., Camarillo, CA 93011
®
. All rights reserved. No portion of this manual or any artwork
99887
®
.

Advertisement

Table of Contents
loading

Related Manuals for Central Hydraulics 99887

Summary of Contents for Central Hydraulics 99887

  • Page 1 HIGH POSITION MOTORCYCLE LIFT 99887 SET uP aNd OPERaTING INSTRuCTIONS ® distributed exclusively by Harbor Freight Tools 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our website at: http://www.harborfreight.com Read this material before using this product. Failure to do so can result in serious injury.

  • Page 2: Important Safety Information

    Safety equipment not avoided, could result in such as non-skid safety shoes will minor or moderate injury. reduce personal injuries. SKU 99887 For technical questions, please call 1-800-444-3353. Page 2...

  • Page 3: Specific Safety Warnings

    Lift, its load, and any and any other condition that may additional tools and accessories. affect the unit’s operation. If dam- aged, have the Lift repaired before SKU 99887 For technical questions, please call 1-800-444-3353. Page 3...

  • Page 4: Specifications

    Avoid rapid load descent. Turn the subheadings therein before set Release Valve slowly. up or use of this product. SKU 99887 For technical questions, please call 1-800-444-3353. Page 4...
  • Page 5 Attach the Jack Bracket (3) to the and one Nut (14). (See Figure B.) Lower Linkage (5) using one Shaft (22) and one Nut (14). (See Figure d, next page.) SKU 99887 For technical questions, please call 1-800-444-3353. Page 5...
  • Page 6 Continue pumping until no more air (See Figure F.) bubbles appear in the Oil Filler Re- ceptacle. Fill to the top of the Oil Filler Recep- tacle with hydraulic oil. Replace the Oil Plug (38A). SKU 99887 For technical questions, please call 1-800-444-3353. Page 6...

  • Page 7: Product Features

    Then turn the Release Valve STRaP RELEaSE clockwise until it stops. LEVER (See Figure G.) (24) Slide the Arm Lift (13) under the mo- torcycle, making sure the Arm Lift is SKU 99887 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8 Transport the Motorcycle Lift to a aLWaYS lock the clean, dry, safe storage location out arm Lift (13) in of reach of children and other unau- place with the Position Pin (17) thorized persons. SKU 99887 For technical questions, please call 1-800-444-3353. Page 8...

  • Page 9: Maintenance And Servicing

    REPLACEMENT PARTS THERETO, (See pages 6 thru 7.) OR ARISING OUT OF HIS OR HER If the Lift fails to INSTALLATION OF REPLACEMENT operate properly PARTS THERETO. SKU 99887 For technical questions, please call 1-800-444-3353. Page 9...

  • Page 10: Troubleshooting

    Arm Lift assembly. Position Pin not removed. Remove Position Pin. Follow all safety precautions whenever diagnosing or servicing the tool. Remove any load on Motorcycle Lift before service. SKU 99887 For technical questions, please call 1-800-444-3353. Page 10...

  • Page 11: Parts List & Assembly Diagram

    Clip Ring (#12) Shaft Spring Washer (#12) Release Valve Bolt (M12x65) Strap Release Lever Base Leg Strap w/Hook Arm Lift Strap Release Lever (24) not shown. Straps with Hooks (25) not shown. SKU 99887 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12 Ball #6 Wire Ring (16x1.6) Small Copper Washer Seal Pump Cylinder Cup Seal Spring Seat O Ring 36x2.4 Spring Big Copper Washer Spring cover Oil Tube Cotter Pin 3.2x16 Oil Plug SKU 99887 For technical questions, please call 1-800-444-3353. Page 12...

  • Page 13: Limited 1 Year / 90 Day Warranty

    Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not avail- able individually as replacement parts. SKU 99887 For technical questions, please call 1-800-444-3353. Page 13...
