DENON AVR/AVC control protocol
Application model : AVR-4802R
Application terminal : RS-232C
Connector specification
Connector type : DB-9pin female type, slave straight connection (DCE type)
( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )
Communication format :
Synchronous system
communication system
Communication speed
Character length
Parity control
Start bit
Stop bit
Communication procedure
Communication data length
: Tone step synchronization
: A half duplex
: 9600bps
: 8 bits
: None
: 1 bit
: 1 bit
: Non procedural
: 135 bytes (maximum)
- 1 -
Ver. 3.7
