Chorus - Lexicon REFLEX - REV 1 User Manual

Delay 3
Delay 2
Delay 1
Feedback
APM Parameter
Setting Name
1 Feedback
2 Delay 1
3 Effects Level
4 High Frequency Cutoff
5 Delay 2 Spread
6 Delay 3 Spread
7 – –
8 Diffusion
9 Chorus Rate
10 Echo Rhythm
*See Page 30 for a map of knob positions vs. note values.
Diffusion HF Cut

Chorus

Rate
Diffusion HF Cut
Display Range
-128 to +128 -99 to +99%
1 to 120 0-1500ms
1 to 128 0-100%
1 to 16 321Hz-13.8kHz
1 to 128 0-1000ms
1 to 128 0-1000ms
– – – –
1 to 128 0-100 (arbitrary units)
1 to 16 0-15 (arbitrary units)
1 to 14* 1/64th note-whole note
Effects
Level
Actual Range
29
Chorus
This algorithm is a 6-voice stereo chorus
with both chorusing and delay effects. It lets
you create single, recirculating echo effects
and slap echoes or make use of long (1.5
seconds max) delay times. Delay times can
be tempo-driven by MIDI.
This algorithm has three separate delay
pairs. Feedback routes the audio back to
Delay 1, as well as feeding Delays 2 and 3.
All three of the delay pairs are sent to the
Rate control which adjusts the overall
amount of random chorus generation.
Both the Chorus and Canyon Presets
(13-14) were created from this algorithm.
When controlling Delay 1 via MIDI, refer to
Dynamic MIDI Patching: Special Notes on
MIDI Programming for important information
about this parameter.
A8
