Lexicon PCM 80 - QUICK REFERENCE GUIDE REV 1 Quick Reference Manual page 2

Audition the Programs
P0
Matrix
Location Preset Type
0.0-1.9 Multi Effects
2.0-3.5 Modulation Effects
3.6-4.9 Special Effects
Each preset has one or more
parameters patched to the
ADJUST knob.
Edit
The PCM 80 offers two levels of editing control: Go mode and Pro mode.
Go mode gives you access to a specific set of as many as 10
parameters for each of the 200 presets. We have designed
each set of parameters to allow you to make changes to the
effect without losing the character of the sound.
Pro mode gives you access to the full effect edit matrix
whenever you press Edit. The edit matrix contains all effect
parameters, as well as Patching and Modulation controls.
The PCM 80 is shipped in Go mode. To change the Edit mode,
press Control, use SELECT and Up and Down to locate
matrix position 1.0. Turn ADJUST to select Go or Pro.
Store
Press Store. The current
program name will appear
with a flashing cursor over
the first letter of the name.
Turn ADJUST to select a new
character. Press Up or Down
to select a new type of char-
acter (upper or lower case,
numeric, symbolic, or blank).
Turn SELECT to move the
cursor to a new character.
Press Program Banks to cycle through four banks of 50 presets.
Turn SELECT to view all of the presets in the selected bank.
Press Load/ to load any displayed effect.
P1
Matrix
Location Preset Type
P0
0.0-3.6 Rhythmic Echo and
Delay Effects
3.7-4.9 Ambience Effects
Turn ADJUST to display the
name and the current value
of the patch.
Press Load/ to display the
name currently assigned to
the ADJUST knob patch.
Use the same procedure for
entering a new name.
Note: The PCM 80 will not perform a store instruction if the
Memory Protection option is on. To turn Memory Protection off,
press Control. Use Up and Down and SELECT to locate matrix
position 1.5. Turn ADJUST to display Off.
In addition to these easy plug and play techniques, the PCM 80 provides extensive
system control via front panel patching or MIDI. For complete details on these and other
features, read the PCM 80 Owner's Manual.
3 Oak Park • Bedford MA 01730-1441 • Tel: (781) 280-0300 • Fax: (781)280-0490
PCM 80 Quick Reference Guide
P2
Matrix
Location Preset Type
0.0-1.0 EQ Effects
1.1-2..4 Spatial Effects
2.5-4.0 Gain Effects
4.1-4.9 Resonant Chord
Effects
Continue turning ADJUST to
change the value of the patch
along its entire range. The
screen will return to its nor-
mal display when you stop
turning ADJUST.
In Go mode, press Edit to
access the most useful pre-
set parameters for the cur-
rently running effect.
Turn SELECT to view the
available parameters.
Turn ADJUST to change the
value of any displayed pa-
rameter.
Press Load/ twice to
move the to the Register
ID number in the lower left
corner of the display. Use
ADJUST or SELECT to
choose the register where
you want the effect saved.
P3
Matrix
Location Preset Type
0.0-2.8 Reverb Effects
2.9-3.9 Processed Reverb
Effects
4.0-4.9 Remix Effects
Compare
When you turn ADJUST, or
perform any other param-
eter edits, the front panel
Compare light will go on to
indicate that the program
has been modified since it
was last stored. Press Com-
pare to hear the unedited
version. Press again to re-
turn to your edited program.
Bypass
Press Bypass to mute the
input signal. A Bypass Mode
parameter at Control mode
1.3 allows you to select input
muting, output muting, input
and output muting, or bypass
as alternatives. You can also
assign the bypass function to
an external controller.
When the display shows the
register number you want,
press Store. Press Store in
response to the "Are you
sure?" message to save your
new effect to the displayed
register location.
Copyright © 1997 Lexicon Inc. All rights reserved.
