Lexicon Performance ALEX Brochure page 4

an intimate club. Exclusive Randomizer feature (Reflex
only) reduces coloration and enhances long reverb tails,
with dual early reflections for added realism.
Inverse – Similar to gated reverb, except that the
reverberation envelope is sharply tilted to provide a long
rising attack, followed by a sharp cutoff. Gate Provides a
very dense field with a sudden cutoff, rather than the
smoothly decaying envelope normally associated with
reverberation.
Plate – All of the sonic traits of a metal plate. The pre-
sets provide classic plate effects for drums and other percus-
sive instruments, as well as for a variety of broadband audio
sources.
Flanger – A stereo flange that can be used to create
different effects from left and right outputs. Individual
Audio Inputs (2)
Level: –30dBu minimum
Impedance: Stereo/50kΩ unbalanced
mono/25kΩ unbalanced
Audio Outputs (2)
Level: –2dBu nominal; +8dBu maximum
Impedance: 75Ω unbalanced
Footswitch Tip/Ring/Sleeve phone jack for
bypass and register step
MIDI Connectors (Reflex only) 5-pin DIN connectors for MIDI
IN and MIDI OUT or THRU
(selectable via internal jumper)
Frequency Response
Wet: 20Hz to 15kHz, +1, –3dB
Dry: 20Hz to 20kHz, ±0.5dB
THD plus Noise
Wet: <0.05% @1kHz
Dry: <0.025% @1kHz
*All specifications apply to both Alex and Reflex unless otherwise indicated, and are subject to change without notice. All products indicated by a trademark or registration symbol
are trademarked and/or registered by their respective manufacturers.
Alex Rear Panel Connections
Reflex Rear Panel Connections
3 Oak Park, Bedford, MA 01730-1441 Tel: (617) 280-0300 Fax: (617) 280-0490 Email: info@lexicon.com Web: www.lexicon.com
delays of as much as 1 second, with separate feedback con-
trols are provided, as well as rate and shape controls for the
flange ("feedback" and "shape" available on Reflex only).
Chorus – 6-voice stereo chorus with both chorusing
and delay effects. Lets you create single recirculating echo
effects and slap echoes, or make use of longer delays (1.5
seconds). In Reflex, delay times can be driven by MIDI.
Single-Tap – A recirculating echo to 1.5 seconds.
Multi-Taps – A 4-tap bouncing delay with the bounce
going back and forth between the left and right outputs.
Reflex allows delay times to be driven by MIDI.
Resonator (Reflex only) – Simulates the acoustic
effects of multi-stringed instruments. A series of resonators
tuned to a chromatic scale is provided, with controls for
tuning and damping.
SPECIFICATIONS *
Dynamic Range
Conversion
Power Requirements
Dimensions
Weight
Environment
Operating Temperature:
HEARD IN ALL THE RIGHT PLACES
85dB typical
20Hz to 20kHz bandwidth
16-bit linear PCM encoding;
31.25kHz sampling rate
9VAC, 1A wall transformer
provided
19.0" W x 1.75"H x4.0" D
(483 x 45 x 102mm)
2 lbs, 11 oz (1.22 kg)
32˚ to 104˚ F (0˚ to 40˚ C)
Relative Humidity:
95%, non-condensing
Studio Photo: Tom Gatlin; Courtesy of Recording Arts, Nashville,TN.
0497
©1994,1997 Lexicon
