Dvs Group; Keyer Group - Yaesu FT-2000 - MENU MODE LIST Manual

DISPLAY G
014 diSP QMB MKR
Function: Enables/Disables the QMB Marker (White ar-
row " ") to display on the Spectrum Band Scope when
the optional DMU-2000 Data Management Unit is con-
nected.
Available Values: On / OFF
Default Setting: On
A :
DVICE
If the optional DMU-2000 Data Management Unit is not
connected, this adjustment has no effect.
015 diSP LVL IND
Function: Enables/Disables the Sub band (VFO-B) fre-
quency display to show each frequency or value while each
of the enabled knob is turned.
Available Values: PI (PITCH) / SP (SPEED) / CO (CON-
TOUR) / nO (NOTCH) / dn (DNR) / Cd (CW DELAY) /
Ud (VOX DEALAY) / rP (RF POWER) / nG (MIC GAIN) /
Pr (PROCESSOR GAIN) / SH (IF SHIFT) / UI (IF
WIDTH)
To disable the "function," rotate the [ SUB VFO-B ] knob
to recall the "function" to be disabled, then press the [ ENT ]
key to change this setting to "OFF" (a "E E E E E " notation will
replace the "d d d d d " notation). Repeat the same procedures to
enable a function (setting it to "ON" ("E E E E E " notation ap-
pears)").
DVS G
016 dUS RX LVL
Function: Sets the audio output level from the voice
memory.
Available Values: 0 ~ 100
Default: 50
017 dUS TX LVL
Function: Sets the microphone input level to the voice
memory
Available Values: 0 ~ 100
Default: 50
FT-2000 O
PERATING
ROUP
ROUP
M
ANUAL
M
KEYER G
018 tEy BEACON
Function: Sets the interval time between repeats of the
beacon message.
Available Values: OFF / 1 ~ 255 sec
Default Setting: OFF
019 tEy NUM STL
Function: Selects the Contest Number "Cut" format for
an imbedded contest number.
Available Values: 1290 / AunO / Aunt / A2nO / A2nt /
12nO / 12nt
Default Setting: 1290
1290: Does not abbreviate the Contest Number
AunO: Abbreviates to "A" for "One," "U" for "Two,"
"N" for "Nine," and "O" for "Zero."
Aunt: Abbreviates to "A" for "One," "U" for "Two,"
"N" for "Nine," and "T" for "Zero."
A2nO: Abbreviates to "A" for "One," "N" for "Nine,"
and "O" for "Zero."
A2nt: Abbreviates to "A" for "One," "N" for "Nine,"
and "T" for "Zero."
12nO: Abbreviates to "N" for "Nine," and "O" for
"Zero."
12nt: Abbreviates to "N" for "Nine," and "T" for
"Zero."
020 tEy CONTEST
Function: Enters the initial contest number that will in-
crement/decrement after sending during contest QSOs.
Available Values: 1 ~ 9999
Default Setting: 1
A :
DVICE
Press the [ CLEAR ] button to reset the contest number to
"1."
021 tEy CW MEM1
Function: Permits entry of the CW message for message
register 1.
Available Values: tyP1 / tyP2
Default Setting: tyP2
tyP1: You may enter the CW message from the front
panel's Function Keys.
tyP2: You may enter the CW message from the CW
keyer.
022 tEy CW MEM2
Function: Permits entry of the CW message for message
register 2.
Available Values: tyP1 / tyP2
Default Setting: tyP2
tyP1: You may enter the CW message from the front
panel's Function Keys.
tyP2: You may enter the CW message from the CW
keyer.
M
ENU ODE
ROUP
Page 113
