Universal Remote Control Complete Control MRF-260 Specification

MRF-260
Optimizing Narrow Band Reception
with Complete Control Remotes
Whole House Control
The MRF-260 base station is an "addressable" base station. RF
Addressing gives you the ability to control as many as 60 identical
components throughout a house. To enable better range and reliability
the MRF-260 is equipped with Narrow Band RF reception.
1. Your URC Complete Control remote sends radio waves in
every direction, so you enjoy "No More Pointing" operation!
Interference Rejection and
Extended Range via Narrow Band
The MRF-260 receives RF (radio frequency) signals via its integrated
RF receiver and antenna. The MRF-260 displays RF interference via a
bright red Status LED which flickers when interference is present if the
ID is set to 0. Simply relocate the MRF-260 should interference occur.
COMPLETE COMPLETE
CONTROL
Base Station
The MRF-260 shown
on left is actual size.
2. The MRF-260's integrated Narrow
Band RF receiver receives commands
from any URC Complete Control remote.
3. The MRF-260's
built-in Front Blaster
sends commands to
components in the
same cabinet space
as the MRF-260.
4. Self-adhesive "Flashers" affix to the
front panels of your components (over
the built-in IR sensor). The Flashers
relay commands to components out of
sight of the MRF-260's Front Blaster.
The flashers plug in to the MRF-260's
rear flasher line outputs via their 10 foot
cables. Uniquely, the MRF-260 can also
connect to rear panel IR Inputs via its
two adjustable Outputs.
The Pioneer in Control Technology
