- Page 1 SIMPLY CLE VER ŠkodaOctavia SUPPLEMENT TO THE OWNER'S MANUAL Technical Changes 11/2010...
-
Page 2: Seat Heaters
Introduction Introduction Seat heaters* This supplement replaces the Owner's manual OCTAVIA Edition 05.10 referred to in the following as the Owner's manual. The information given in this supplement takes preference over the information in the Owner's manual. Special equipment is marked with the symbol *. We wish you a good journey Škoda Auto a.s. - Page 3 “START - STOP”* In the start-stop mode, the engine automatically switches to the vehicle's idle phase, The minimum engine temperature is reached. e.g. when stopped at traffic lights. The charge state of the vehicle battery is sufficient. Information regarding the current state of the “START-STOP” system is indicated in the The vehicle is not on a slope or on a downhill section.
-
Page 4: Charging The Vehicle Battery
Charging the vehicle battery Messages in the instrument cluster display (valid for vehicles without MAXIDOT If the air conditioning Climatronic* is running in automatic mode, under certain info display*) conditions, the engine may not switch off automatically. ERROR START STOP Charging the vehicle battery Error in the START-STOP system START STOP NOT POSSIBLE... - Page 5 Climatic* Climatic Setting Fig. 4 Climatic: Control elements Recommended settings for the Climatic control elements: Switch positions Button adjusting Air outlet vents 3 Open and adjust the flow of Defrost function, windscreen To the right up to Switched off Do not switch on air in direction of the side and side windows...
- Page 6 Tyre repair kit* Switch positions Button adjusting Air outlet vents 3 To the left up to the briefly 4, then Quickest-possible cooling Activated briefly switched on Opening stop 2 or 3 Open and adjust the flow of Desired tempera- ...
- Page 7 Tyre repair kit* Valve remover WARNING (continued) Sticker with speed designation “max. 80 km/h”/“max. 50 mph” Check the tyre inflation pressure after driving 10 minutes. Inflation hose with plug Sealant is hazardous to heath. Remove immediately if it comes into contact Compressor with the skin.
- Page 8 Tyre repair kit* – Unscrew the valve cap. – If you cannot reach an air pressure of 2.0 – 2.5 bar, unscrew the tyre inflation hose from the tyre valve. – Use the screwdriver to remove the valve core and place it down on a clean surface.
- Page 9 Tow-starting and towing vehicle Check after driving for 10 minutes Fuse assignment in the dash panel Check the tyre inflation pressure after driving 10 minutes. Power consumer Amperes If the tyre inflation pressure is 1.3 bar or less: Heating, air conditioning, reversing lights, interior rear view mirror dimming, telephone preinstallation, START –...
- Page 10 Technical Data Technical Data Petrol engines OCTAVIA COMBI 970/1000 970/1010 Weight 1,6 l/75 kW - EU4, EU2 (AG6) (940/1110) (940/1130) The indicated unloaded weight is for orientation purposes only. It is for the basic 1,8 l/118 kW TSI - EU5, EU2 DDK 1010/990 1010/1010 equipping of the vehicle not including special features or accessories.
- Page 11 Technical Data OCTAVIA RS COMBI RS 1010/930 1010/950 2,0 I/147 kW TSI EU5 (M6) (980/1060) (970/1080) 1010/920 1030/940 2,0 I/147 kW TSI EU5 (DQ6) (1000/1060) (1000/1070) 1030/940 1030/960 2,0 I/125 kW TDI CR EU5 (M6) (1000/1070) (1000/1090) 1060/930 1060/950 2,0 I/125 kW TDI CR EU5 (DQ6) (1030/1070) (1020/1080) Vehicles of category N1.
- Page 12 Technical Data 1.4 ltr./59 kW - EU5 Engine Power output kW per rpm 59/5000 Maximum torque Nm per rpm 132/3800 4/1390 Number of cylinders/Displacement (cm Performances OCTAVIA COMBI Maximum speed km/h Acceleration 0 - 100 km/h 14,3 14,4 Fuel consumption (in ltr./100 km) and CO emission (in g/km) OCTAVIA COMBI...
- Page 13 Technical Data Weight (in kg) OCTAVIA COMBI Permissible gross weight 1750 1755 Unloaden weight ready for work 1255 1270 Loading capacity Loading capacity when using the TLC Max. permissible gross weight per axle (in kg) - front axle Max. permissible gross weight per axle (in kg) - rear axle Permissible trailer loads, trailer braked 1100 1100...
- Page 14 Technical Data 1,6 l/77 kW TDI CR - EU5 Performances OCTAVIA M5 COMBI M5 OCTAVIA M5 OCTAVIA M5 OCTAVIA DQ7 COMBI M5 COMBI DQ7 Technology Technology GreenLine Maximum speed km/h Acceleration 0 - 100 km/h 11,3 11,4 11,3 11,4 11,4 11,4 11,5 Fuel consumption (in ltr./100 km) and CO...
- Page 15 Technical Data Weight (in kg) OCTAVIA M5 COMBI M5 OCTAVIA M5 Technology Technology GreenLine Permissible gross weight 1990 1960 1975 Unladen weight ready for operation 1390 1360 1375 Loading capacity Loading capacity when using the TLC 1030/990 1020/1000 Max. permissible gross weight per axle (in kg) - front/rear axle 1003/988 (1000/1100) (990/1120)
- Page 16 Technical Data 2.0 ltr./81 kW TDI CR - EU4 Engine Power output kW per rpm 81/4200 Maximum torque Nm per rpm 250/1500-2500 4/1968 Number of cylinders/Displacement (cm Engine oil specifications 507 00 Performances OCTAVIA COMBI Maximum speed km/h Acceleration 0 - 100 km/h 11,0 11,1 Fuel consumption (in ltr./100 km) and CO...
- Page 17 Technical Data Capacities (in litre) Engine oil Cooling system of the vehicle Oil capacity with oil filter change. Inspect oil level when filling; do not fill up too much. The oil level must be between the markings. On vehicles which are fitted with an independent auxiliary heating and ventilation, the volume of the coolant is greater by approx. 1 ltr. Weight (in kg) OCTAVIA COMBI...
- Page 18 Technical Data 2.0 ltr./103 kW TDI CR - EU4, EU5 Performances COMBI 4x4 SCOUT Maximum speed km/h Acceleration 0 - 100 km/h 10,2 Fuel consumption (in ltr./100 km) and CO emission (in g/km) COMBI COMBI 4x4 SCOUT Urban Ex-urban combined emissions combined...
- Page 19 Technical Data Weight (in kg) COMBI 4x4 COMBI 4x4 SCOUT Permissible gross weight 2100 2120 2175 Unladen weight ready for operation 1500 1520 1575 Loading capacity Loading capacity when using the TLC 1060/1080 1080/1070 1090/1100 Max. permissible gross weight per axle (in kg) - front/rear axle (1020/1190) (1040/1190) (1030/1210)
- Page 21 Škoda Auto pursues a policy of constant product and model development. We trust Reprinting, reproduction or translation, either in whole or in part, is not permitted that you will understand that changes to models in terms of shape, equipment and without the written consent of Škoda Auto.
- Page 22 Dodatek Návodu k obsluze Octavia anglicky 11.10 S64.5612.23.20 1Z0 012 026 CN...
