NAIM ND5 XS Dimensions

AUDIO INPUTS
S/PDIF 1x BNC, 1x RCA, 1x optical,
sample rates up to 192kHz/24bit
USB type A Front panel socket for iPod, iPhone,
iPad and memory sticks
UPnP TM Wired Ethernet (RJ45) or Wi-Fi
Antenna inputs DAB/FM, Wi-Fi (802.11 g or n at 2.4GHz)
Tuning range DAB (Band lll and L Band),
FM 87.5-108MHz
(FM/DAB version only)
AUDIO OUTPUTS
Analogue outputs DIN and RCA, 2.1V rms at 1kHz
at full level (Fixed)
Output impendence 32Ω maximum
Minimum load impedance 10kΩ
Frequency response 10Hz – 20kHz, +0.1/-0.5dB
THD+N <0.02%, 10Hz to 20kHz at full level
Phase response Linear phase, absolute phase correct
Digital outputs (type) S/PDIF, 75Ω BNC
UPGRADES
Power supply options XPS, 555 PS
Other DAC, Hi-Line, Power-Line,
long-range WA5 antenna
CONNECTIVITY
Infrared RC5
Remote input 3.5mm jack on rear (RC5)
Remote output 3.5mm jack on rear (RC5) x2
Rear USB For updates only (USB mini-B)
Windows Media™ is a trademark of Microsoft Corporation.
UPnP™ is a trademark of the UPnP™ forum.
iPod, iPhone and Mac are trademarks of Apple Inc, registered in the U.S. and other countries.
Please note information provided relating to specification is subject to change.
NAIM AUDIO LIMITED
Southampton Road • Salisbury • England • SP1 2LN
Tel: +44 (0) 1722 426600 • Fax: +44 (0) 871 230 1012
www.naimaudio.com
FORMATS
Audio Files Supported WAV and AIFF (up to 32bit/192kHz)
FLAC (up to 24bit/192kHz)
ALAC (up to 24bit/96kHz)
Windows Media-formatted content
(up to 16bit/48kHz) must be WMA 9.2
Ogg Vorbis (up to 16bit/48kHz)
MP3 and M4a (up to 320kbit/s)
iRadio service provider vTuner 5* full service
Internet radio (Windows Media-formatted
content, MP3 streams, MMS, Ogg Vorbis)
USER CONTROL INTERFACES
Front panel Yes
Handheld Remote handset included and optional
n-Stream app for iPod, iPhone and iPad
devices, downloadable from App Store
AMX & Crestron Installer-customisable reference apps available
POWER
Supply voltage 100V or 115V or 230V; 50 to 60Hz
Power consumption (maximum) 60VA
PRODUCT CERTIFICATIONS & LICENSES
Certifications Apple (made for iPhone), vTuner Premium
Licenses MP3, AAC, DAB, Windows Media
PHYSICAL
Dimensions (mm) 70 x 432 x 301mm (H x W x D)
Weight 6.5Kg
ND5 XS Network Player
