APPLICANT: Belkin Corporation
LAB LOCATION: No. 47 14th Ling, Chia Pau Tsuen, Linkou
This test report consists of 54 pages in total. It may be duplicated completely for legal use
with the approval of the applicant. It should not be reproduced except in full, without the
written approval of our laboratory. The client should not use it to claim product endorsement
by NVLAP or any U.S. government agencies. The test results in the report only apply to the
tested sample.
Report No.: RE920221R04A
Reference No.: RE920221R04
RADIO TEST REPORT
REPORT NO.: RE920221R04A
MODEL NO.: F5D7000
RECEIVED: Feb. 21, 2003
TESTED: Feb. 20~ Feb. 24, 2003
501 WEST WALNUT STREET COMPTON,
ADDRESS:
CA 90220
ISSUED BY: Advance Data Technology Corporation
Hsiang, Taipei, Taiwan, R.O.C.
1
0528
ILAC MRA
Issued: Mar. 14, 2003
