IMMUNITY TEST REPORT
APPLICANT: Belkin Corporation
LAB LOCATION: No.47 14th Ling, Chia Pau Tsuen, Linkou
This test report consists of 29 pages in total. It may be duplicated completely for legal use with the
approval of the applicant. It should not be reproduced except in full, without the written approval of
our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S.
government agencies. The test results in the report only apply to the tested sample.
Report No.: RM920221R04A
Reference No.: RM920221R04
REPORT NO.: RM920221R04A
MODEL NO.: F5D7000
RECEIVED: Feb. 21, 2003
TESTED: Feb. 27 ~ Mar. 7, 2003
501 WEST WALNUT STREET COMPTON,
ADDRESS:
CA 90220
ISSUED BY: Advance Data Technology Corporation
Hsiang, Taipei, Taiwan, R.O.C.
1
0528
ILAC MRA
Issued: Mar. 14, 2003

Advertisement

Table of Contents
loading

Related Manuals for Belkin F5D7000CE2

Summary of Contents for Belkin F5D7000CE2

  • Page 1 IMMUNITY TEST REPORT REPORT NO.: RM920221R04A MODEL NO.: F5D7000 RECEIVED: Feb. 21, 2003 TESTED: Feb. 27 ~ Mar. 7, 2003 APPLICANT: Belkin Corporation 501 WEST WALNUT STREET COMPTON, ADDRESS: CA 90220 ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No.47 14th Ling, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C.

  • Page 2: Table Of Contents

    Table of Contents CERTIFICATION ........................3 SUMMARY OF TEST RESULTS .................... 4 GENERAL INFORMATION ..................... 5 GENERAL DESCRIPTION OF EUT ..................5 DESCRIPTION OF TEST MODE.....................6 GENERAL DESCRIPTION OF APPLIED STANDARD ............6 DESCRIPTION OF SUPPORT UNIT..................7 EMISSION TEST........................8 CONDUCTED EMISSION MEASUREMENT ................8 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............8 4.1.2...

  • Page 3: Certification

    1 CERTIFICATION PRODUCT: 2.4GHz wireless PCI MODEL NO: F5D7000 BRAND NAME: Belkin APPLICANT: Belkin Corporation STANDARDS: EN 301 489-1 (09-2001), EN 301 489-17 (09-2000) EN 55022:1998, Class B EN 61000-4-2:1995 EN 61000-4-3:1995 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility from Feb.

  • Page 4: Summary Of Test Results

    2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: EMISSION Standard Test Type Result Remarks Meet the requirement of limit EN 55022:1998, Conducted Test PASS Minimum passing margin is –23.49dBuV/m at 0.255MHz Class B (Conducted Emission) NOT APPLICABLE Radiated Test...

  • Page 5: General Information

    GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT 2.4GHz wireless PCI MODEL NO. F5D7000 POWER SUPPLY 3.3VDC from host equipment MODULATION TYPE DSSS, OFDM TRANSFER RATE Up to 54Mbps OPERATING 2.412GHz ~ 2.472GHz FREQUENCY NUMBER OF CHANNEL CHANNEL SPACING 5 MHz RATED RF OUTPUT 18.69dBm (Measured Max.

  • Page 6: Description Of Test Mode

    3.2 DESCRIPTION OF TEST MODE The EUT was tested under following conditions: CONDITION CONFIGURATION REMARKS Transmission Standby 3.3 GENERAL DESCRIPTION OF APPLIED STANDARD The EUT is a kind of computer peripheral with wireless data transmission function. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: EN 301 489-1 (09-2001), EN 301 489-17 (09-2001) EN 55022:1998, Class B (Conducted Emission)

  • Page 7: Description Of Support Unit

    3.4 DESCRIPTION OF SUPPORT UNIT The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. For Conducted Emission PRODUCT BRAND MODEL NO.

  • Page 8: Emission Test

    EMISSION TEST 4.1 CONDUCTED EMISSION MEASUREMENT 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT Class A (dBuV) Class B (dBuV) FREQUENCY (MHz) Quasi-peak Average Quasi-peak Average 0.15 - 0.5 66 - 56 56 - 46 0.50 - 5.0 5.0 - 30.0 NOTE: (1) The lower limit shall apply at the transition frequencies.

  • Page 9: Test Procedures

    4.1.3 TEST PROCEDURES a. The EUT was placed 0.4 meters from the conducting wall of the shielded room with EUT being connected to the power mains through a line impedance stabilization network (LISN). Other support units were connected to the power mains through another LISN.

  • Page 10: Test Setup

    4.1.5 TEST SETUP For the actual test configuration, please refer to the related item – Photographs of the Test Configuration. 4.1.6 EUT OPERATING CONDITIONS a. Connected the EUT to a computer system placed on a testing table. b. The computer system ran a test program to enable EUT under transmission/receiving condition continuously at specific channel frequency.

  • Page 11: Test Results

    4.1.7 TEST RESULTS 2.4GHz wireless PCI Model F5D7000 6dB BANDWIDTH 10 kHz INPUT POWER 230Vac, 50 Hz PHASE Line (L) ENVIRONMENTAL 22 deg. C, 68 % RH, TESTED BY: Cody Chang CONDITIONS 1005 hPa Emission Freq. Corr. Reading Value Limit Margin Level Factor...
  • Page 12 2.4GHz wireless PCI Model F5D7000 6dB BANDWIDTH 10 kHz INPUT POWER 230Vac, 50 Hz PHASE Neutral (N) ENVIRONMENTAL 22 deg. C, 68 % RH, TESTED BY: Cody Chang CONDITIONS 1005 hPa Emission Freq. Corr. Reading Value Limit Margin Level Factor [dB (uV)] [dB (uV)] [dB (uV)]...

  • Page 13: Immunity Test

    5 IMMUNITY TEST 5.1 GENERAL DESCRIPTION Product EN 301 489-1 (09-2001), EN 301 489-17 (09-2000) Standard EN 61000-4-2 Electrostatic Discharge – ESD: 8kV air discharge, 4kV Contact discharge, Basic Standard, Performance Criterion B Specification, and EN 61000-4-3 Radio-Frequency Electromagnetic Field Performance Susceptibility Test –...
  • Page 14 The phenomena allowed during and after test in each criterion are clearly stated in the following table Performance criteria Criteria During test After test Shall operate as intended. Shall operate as intended. May show degradation of Shall be no degradation of performance (see note1).

  • Page 15: Eut Operating Condition

    5.3 EUT OPERATING CONDITION 1. Connected the EUT to a computer system placed on a testing table. 2. The computer system ran a test program to enable all functions of EUT. 3. Prepared the access point and placed it outside of testing area to act as communication partner for EUT.

  • Page 16: Electrostatic Discharge Immunity Test (Esd)

    5.4 ELECTROSTATIC DISCHARGE IMMUNITY TEST (ESD) 5.4.1 TEST SPECIFICATION Basic Standard: EN 61000-4-2 Discharge Impedance: 330 ohm / 150 pF Discharge Voltage: Air Discharge - 8 kV (Direct) Contact Discharge – 4kV (Direct/Indirect) Polarity: Positive & Negative Number of Discharge: Minimum 20 times at each test point Discharge Mode: Single Discharge...

  • Page 17: Test Procedure

    5.4.3 TEST PROCEDURE a. Electrostatic discharges were applied only to those points and surfaces of the EUT that are accessible to users during normal operation. b. The test was performed with at least ten single discharges on the pre-selected points in the most sensitive polarity. c.

  • Page 18: Test Setup

    5.4.5 TEST SETUP 0.1m Vertical coupling plane 0.5mm Isolation Support Generator 470k Nearest Wall 80cm Horizontal coupling plane Reference Ground Plane For the actual test configuration, please refer to the related item – Photographs of the Test Configuration. NOTE: TABLE-TOP EQUIPMENT The configuration consisted of a wooden table 0.8 meters high standing on the Ground Reference Plane.

  • Page 19: Test Result

    5.4.6 TEST RESULT 2.4GHz wireless PCI MODEL NO. F5D7000 INPUT POWER 230Vac, 50 Hz MODE Transmission (SYSTEM) ENVIRONMENTAL 23 deg.C, 47 % RH TESTED BY: Cody Chang CONDITIONS 1005 hPa TEST RESULTS OF DIRECT APPLICATION Polarity Discharge Contact Performance Test Point Air Discharge Level (kV) Discharge...
  • Page 20 2.4GHz wireless PCI MODEL NO. F5D7000 INPUT POWER 230Vac, 50 Hz MODE Standby (SYSTEM) ENVIRONMENTAL TESTED BY: Cody Chang 23 deg.C, 47 % RH CONDITIONS 1005 hPa TEST RESULTS OF DIRECT APPLICATION Polarity Discharge Contact Performance Test Point Air Discharge Level (kV) Discharge Criterion...

  • Page 21: Radiated, Radio-Frequency, Electromagnetic Field Immunity Test (Rs)

    5.5 RADIATED, RADIO-FREQUENCY, ELECTROMAGNETIC FIELD IMMUNITY TEST (RS) 5.5.1 TEST SPECIFICATION Basic Standard: EN 61000-4-3 Frequency Range: 80 MHz - 1000 / 1400 - 2000 MHz Field Strength: 3 Vrms Modulation: 1kHz Sine Wave, 80%, AM Modulation Frequency Step: 1 % of momentary frequency Polarity of Antenna: Horizontal and Vertical Test Distance: 3 m Antenna Height: 1.5m...

  • Page 22: Test Procedure

    5.5.3 TEST PROCEDURE The test procedure was in accordance with EN 61000-4-3 a. The testing was performed in a fully-anechoic chamber. The transmit antenna was located at a distance of 3 meters from the EUT. b. The frequency range is swept from 80 MHz to 1000 MHz / 1400 MHz to 2000 MHz, with the signal 80% amplitude modulated with a 1kHz sinewave.

  • Page 23: Test Setup

    5.5.5 TEST SETUP 3m measurement distance in a Full Anechoic Chamber RF Amplifier RF Generator Monitoring system control system For the actual test configuration, please refer to the related item – Photographs of the Test Configuration. NOTE: TABLETOP EQUIPMENT The EUT installed in a representative system as described in section 7 of EN 61000- 4-3:1996 was placed on a non-conductive table 0.8 meters in height.

  • Page 24: Test Result

    5.5.6 TEST RESULT 2.4GHz wireless PCI MODEL NO. F5D7000 INPUT POWER 230Vac, 50 Hz MODE Transmission (SYSTEM) ENVIRONMENTAL 22 deg.C, 56 % RH TESTED BY: Cody Chang CONDITIONS 1005 hPa Field Performance Frequency Obser- Result Polarity Azimuth Strength Criterion (MHz) vation (V/m) 80 -1000...
  • Page 25 2.4GHz wireless PCI MODEL NO. F5D7000 INPUT POWER 230Vac, 50 Hz MODE Standby (SYSTEM) ENVIRONMENTAL 22 deg.C, 56 % RH TESTED BY: Cody Chang CONDITIONS 1005 hPa Field Performance Frequency Obser- Result Polarity Azimuth Strength Criterion (MHz) vation (V/m) 80 –1000 PASS V&H 80 –1000...

  • Page 26: Photographs Of The Test Configuration

    PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: RM920221R04A Issued: Mar. 14, 2003 Reference No.: RM920221R04...
  • Page 27 ESD TEST Report No.: RM920221R04A Issued: Mar. 14, 2003 Reference No.: RM920221R04...
  • Page 28 RS TEST Report No.: RM920221R04A Issued: Mar. 14, 2003 Reference No.: RM920221R04...

  • Page 29: Appendix - Information On The Testing Laboratories

    APPENDIX - INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited and approved by the following approval agencies according to ISO/IEC 17025, Guide 25 or EN 45001: FCC, NVLAP, UL Germany TUV Rheinland...
