F1PG200ENau – Belkin Analogue Telephone Adapter (ATA)
Firmware release notes
1. Voice over IP registration indicator and error codes
2. Error '482 loop detected' fixed. This error is caused if the modem loses DSL sync and
the ATA will then try to connect to the next available SIP server, obviously connection
will fail as there is no DSL sync. Once the DSL becomes active again the ATA no
longer sits waiting for user intervention to re-connect and the ATA will gauge DSL
sync and re-establish connectivity to the SIP server. -
http://www.ietf.org/rfc/rfc2782.txt
3. OOB signalling – default is set to info (RFC 2976) for support for touch tone menu
options.
Introduction
From time to time Belkin releases new firmware which has enhancements or fixes to
the previous releases of firmware. Firmware resides on the networking product in
question and acts similar to an operating system on a computer.
This guide will explain the changes to the latest release of firmware for the ATA and
will also explain how to perform an upgrade in step by step format.
Advertisement
Related Manuals for Belkin F1PG200ENAU
Summary of Contents for Belkin F1PG200ENAU
- Page 1 3. OOB signalling – default is set to info (RFC 2976) for support for touch tone menu options. Introduction From time to time Belkin releases new firmware which has enhancements or fixes to the previous releases of firmware. Firmware resides on the networking product in question and acts similar to an operating system on a computer.
- Page 2 Before you begin: You will need: Belkin ATA VoIP unit Power cable Network cable PC with network card Discovery tool – this was included on the supplied CDROM – if you do not have this software please download from the following link: http://www.belkin.com/support/download/download.asp?download=F1PG200ENau&l...
- Page 3 3) The Login page will appear. Type in your current password (or the default password of admin) then click LOGIN 4) On the left hand side of the screen click Advanced Setup 5) You will now be presented with more options in the menu on the left. Click Utilities then choose Firmware Update 6) Click the browse button, located in the centre of the screen 7) You will now be asked to browse for the file you downloaded earlier.
- Page 4 NB – Progress bar will indicate the progress at the bottom of the screen in percentage. 9) Once the Firmware Update process has completed, you will need to restart the ATA by clicking the Restart ATA button When the prompt asks you to restart please click yes. The ATA will restart and take you back to the Login page.
- Page 5 Finally you will need to perform a factory reset of your ATA so you can continue using the ATA with the newer firmware. Before conducting a factory reset ensure that you have your VoIP phone number and password handy – write this information below to assist you later: VoIP phone number ______________________ VoIP Password __________________________ To perform a factory reset follow these steps:...
- Page 6 ATA and wait for 1 hour before turning the ATA back on – if after a few minutes the ATA Line 1 or 2 light does not illuminate please contact Belkin technical support on 1800 235546.
