- Page 1 ExtEndEd RangE USB WiRElESS n adaptER SURF N300 XR User Manual F9L1004 8820xx00894xx Rev. A00 English...
-
Page 2: Table Of Contents
European Compliance Statement: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Belkin International, Inc ., Limited 2-Year Product Warranty . . . . . . . . 35... -
Page 3: Introduction
INtroductIoN Thank you for purchasing the Belkin N300 High Gain Wireless USB Adapter. With its adjustable high-gain antenna, you can connect farther and faster than standard adapters. Now you can take advantage of this great new technology and gain the freedom to network your home and office computers wirelessly. This Adapter allows you to connect a notebook or desktop computer to your network. -
Page 4: Advantages Of A Wireless Network
• Flexibility – set up and access printers, computers, and other networking devices from anywhere in your home • E asy expansion – the wide range of Belkin networking products let you expand your network to include devices such as printers and gaming consoles • No cabling required –... -
Page 5: Optimal Performance
10 feet from the wireless router (or access point) in order to see if distance is the problem. If difficulties persist even at close range, please contact Belkin Technical Support. Note: While some of the items listed below can affect network performance, they will not prohibit your wireless network from... - Page 6 To achieve the best wireless network coverage for your “wireless • Refrigerators clients,” (i.e., computers enabled by Belkin Adapters or Cards): • Washers and/or dryers • E nsure that your wireless router’s (or access point’s) antennas are parallel to each other, and are positioned • Metal cabinets...
- Page 7 Use the • T ry moving cordless phones away from the wireless router Site Survey capabilities of your Belkin Wireless Networking (or access point) and your wireless-enabled computers. Utility to locate any other wireless networks, and move your wireless router (or access point) and computers to a • U nplug and remove the battery from any cordless phone that...
- Page 8 Secure connections include: For more information regarding our networking products, • V irtual Private Network (VPN) connections, often visit our website at www.belkin.com/networking used to connect remotely to an office network or call Belkin Technical Support. • T he “Bring Your Own Access” program from America Online (AOL), which lets you use AOL through broadband provided by another cable or DSL service • Most online banking websites • M any commercial websites that require a user name and password to access your account Secure connections can be interrupted by a computer’s power...
-
Page 9: Overview
Overview Product Features The Adapter complies with the IEEE 802.11n specification to communicate with other 802.11n-compliant wireless devices at up to 300Mbps*. The Adapter is also compatible with 802.11g devices at 54Mbps as well as 802.11b products at 11Mbps. The Adapter operates on the same 2.4GHz frequency band as 802.11b/g Wi-Fi products. -
Page 10: Applications And Advantages
Overview Applications and Advantages • W ireless roaming with a laptop around the home or office Offers the freedom of networking without cables • Connection rates of up to 300Mbps* Provides immediate high-speed wireless connectivity at home, work, and hotspot locations without compromising the use of existing 802.11b/g products • Compatibility with 802.11b/g products The Adapter is backward-compatible with existing Wi-Fi (IEEE 802.11b/g) products • Difficult-to-wire environments Enables networking in buildings with solid or finished walls, or open areas where wiring is difficult to install • Frequently changing environments Adapts easily in offices or environments that frequently rearrange or change locations • SOHO (Small Office/Home Office) networking needs P rovides the easy and quick, small network installation SOHO users need • Micro Enclosure The Adapter has been designed to fit neatly into... -
Page 11: Product Specifications
Overview Product Specifications Host Interface: USB 2.0 Operating Temperature: 32–104 degrees F (0–40 degrees C) Storage Temperature: -4–158 degrees F (-20–70 degrees C) Humidity: Max. 90% (non-condensing) Typical Operating Range: Up to 1,200 ft.** *NOTE: The standard transmission rate—300Mbps—is the physical data rate. Actual data throughput will be lower. **Wireless performance may vary depending on the networking environment. (a) USB Connector Part of the Adapter that fits into your computer’s USB port. -
Page 12: System Requirements
Overview System Requirements • PC-compatible laptop with one available USB 2.0 bus-power port • Windows XP with SP2 or later, Windows Vista , or Windows 7 ® ® Package Contents • SURF N300 XR Extended Range USB Wireless N Adapter • Quick Installation Guide • CD with Installation Software and User Manual... -
Page 13: Installing And Setting Up The Adapter
A.1 Insert the Installation Software CD into your CD-ROM drive. A.2 Click “Next” to begin the installation process. Note: If the Belkin Wireless Card Installer screen does not appear within 20 seconds, access your CD-ROM by double-clicking on the “My Computer” icon; then double-click on the CD-ROM drive into which the installation CD has been placed. - Page 14 INsTAllINg ANd sETTINg uP ThE AdAPTER A.3 The InstallShield Wizard will start the installation process. A.4 A window may appear showing the message, “Windows can’t verify the publisher of this driver software”. This DOES NOT indicate a problem. Our software has been fully tested and is compatible with this operating system.
- Page 15 INsTAllINg ANd sETTINg uP ThE AdAPTER A.5 When prompted, plug in your Adapter. A.7 Click “Finish” to restart your computer. A.6 When the installation completes, you will see the following pop-up message on your Windows taskbar.
- Page 16 INsTAllINg ANd sETTINg uP ThE AdAPTER A.8 To connect to the Internet, open the Network and Sharing Center A.9 In the Control Panel, click on “View network status and tasks”. by first opening the Control Panel from the “Start” menu.
- Page 17 INsTAllINg ANd sETTINg uP ThE AdAPTER A.10 In the Network and Sharing Center, click A.11 In the next screen, select an available on “Connect to a network”. wireless network and click “Connect”.
- Page 18 INsTAllINg ANd sETTINg uP ThE AdAPTER A.12 Your Adapter will attempt to connect to the selected network. A.13 Depending on the security settings of your wireless network, you may be prompted to enter a network security key or a passphrase. Click “Connect” after you have done so.
- Page 19 INsTAllINg ANd sETTINg uP ThE AdAPTER A.14 After connecting to the network, you can choose A.15 The Network and Sharing Center now indicates the network to save this network and connect automatically connection that you have just made. The links on the left of when your Adapter is in range.
-
Page 20: B - Installation Process For Windows Xp
20 seconds. Click “Install Software” or “Next” to start the installation. Note: If the Belkin Wireless Adapter Installer screen does not appear within 20 seconds, access your CD-ROM by double- clicking on the “My Computer” icon; then double-click on the CD-ROM drive into which the installation CD has been placed. - Page 21 INsTAllINg ANd sETTINg uP ThE AdAPTER B.3 Select a destination folder for the software installation by clicking B.4 A Setup Status screen lets you know where “Browse”; or, simply click “Next” to install to the default location. you are in the setup process.
- Page 22 INsTAllINg ANd sETTINg uP ThE AdAPTER B.5 A window may appear showing the message, “The software B.6 When prompted, plug in your Adapter. you are installing…” This DOES NOT indicate a problem. Our software has been fully tested and is compatible with this operating system.
- Page 23 INsTAllINg ANd sETTINg uP ThE AdAPTER B.7 The Found New Hardware Wizard might appear in B.8 Click “Finish” to restart your computer. 3–15 seconds. If it does, select “Install the software automatically” and click “Next” to install the software.
-
Page 24: Connecting To A Secure Wi-Fi Network
INsTAllINg ANd sETTINg uP ThE AdAPTER Connecting to a secure Wi-Fi Network ® If you choose to connect to a secure network, determine the type of security (WPA/WPA2 or WEP) and use the appropriate field in the dialog box. Wireless Equivalent Privacy (WEP) is a less secure, but more widely adopted wireless security protocol. -
Page 25: Troubleshooting
Belkin Wireless Router, the lights should be as follows: Computer” icon on your desktop. Choose “Properties” and navigate to the “Device Manager” and see if your USB Adapter is listed without • The “router” light should be on and not blinking. any errors. If an error is indicated, contact Belkin Technical Support. If this is NOT the case, make sure: • The router’s power cord is plugged in. • All cables are connected between the router and the modem. • A ll the modem’s LEDs are functioning correctly. If not, see your modem’s user manual. • Reboot the router. • Reboot the modem. If you continue to have issues, please contact Belkin Technical Support. If you are not using a Belkin Wireless Router, consult that router manufacturer’s user guide. - Page 26 Check the WEP, WPA, or WPA2 key settings to see if they match. network name (SSID) settings in your wireless network properties. The key is case-sensitive and the spelling on each computer and wireless router (or access point) must be exactly the same in order Check the SSID settings to see if they match. The SSID for the Adapter to connect to the router. For more information about is case-sensitive and the spelling on each computer encryption, see the “Connecting to a Secure Wi-Fi Network” section. must be exactly the same in order for the Adapter to connect to the wireless router (or access point). If issues persist even at close range, please contact Belkin Technical Support. Note: To check the SSID settings or look for an available network, double-click the Signal Indicator icon to bring up the “Wireless Networks” screen. Click “Add” if you do not see the network you are trying to connect to and type in the SSID. For more information about setting up an SSID, please reference your router manufacturer’s user manual. If issues persist even at close range, please contact Belkin Technical Support.
- Page 27 100 to 200 feet. Note also that connection speed may decrease as you move farther from the wireless router (or access point). In order to determine if wireless issues are related to range, we suggest temporarily moving the computer, if possible, to five to 10 feet away from the wireless router (or access point). Please see the section titled, “Placement of your Wireless Networking Hardware for Optimal Performance.” If issues persist even at close range, please contact Belkin Technical Support.
- Page 28 Changing the wireless channel – Depending on local wireless transmission rates should be acceptable for browsing the Internet. traffic and interference, switching the wireless channel of your For more assistance, see your wireless card’s literature. If issues network can improve performance and reliability. The default channel persist even at close range, please contact Belkin Technical Support. the router is shipped with is channel 6. You may choose from several other channels depending on your region; see your router’s (or access point’s) user manual for instructions on how to choose other channels.
- Page 29 The Adapter does not perform or connection is slow when computer has a second built-in wireless network when computer has a built-in wired ethernet card. card (such as a mini PCI or Intel Centrino ® ™ This condition occurs if your computer has an active Ethernet This condition occurs if your computer has a built-in card while your Adapter is also active. This happens because wireless card while your Belkin Enhanced Wireless USB Windows must now handle two active network connections. Adapter is also active. This happens because Windows You must disable the Ethernet card from your computer must now handle two active wireless connections. under “Network Adapters” in the Device Manager. You must disable the built-in wireless card from your computer under “Network Adapters” in the Device Manager.
- Page 30 TrOubleshOOTINg What’s the difference between 802.11g and 802.11n? Currently there are three commonly used wireless networking standards, which transmit data at very different maximum speeds. Each is based on the designation for certifying network standards. The most common wireless networking standard, 802.11g, can transmit information up to 54Mbps; 802.11a also supports up to 54Mbps, but in the 5GHz frequency; and 802.11n specification can connect at up to 300Mbps. See the following chart for more detailed information. belkin Wireless Comparison Chart Wireless N150 N300 MIMO N600 Dual-Band MIMO Technology (802.11g) (1x1 802.11n) 802.11n 802.11n Speed/Data Rate* Up to 54Mbps* Up to 150Mbps* Up to 300Mbps*...
-
Page 31: Technical Support
TrOubleshOOTINg Country number Internet adress AUSTRIA 0820 200766 www.belkin.com/de/networking/ Technical support www.belkin.com/nl/networking/ BELGIUM 07 07 00 073 www.belkin.com/fr/networking/ 239 000 406 www.belkin.com/uk/networking/ CZECH REPUBLIC DENMARK 701 22 403 www.belkin.com/uk/networking/ http://www.belkin.com/support FINLAND 0972519123 www.belkin.com/uk/networking/ FRANCE 08 - 25 54 00 26 www.belkin.com/fr/networking/ GERMANY 0180 - 500 57 09 www.belkin.com/de/networking/ http://www.belkin.com/uk/support GREECE 00800 - 44 14 23 90 www.belkin.com/uk/networking/ Australia HUNGARY 06 - 17 77 49 06 www.belkin.com/uk/networking/ http://www.belkin.com/au/support ICELAND 800 8534 www.belkin.com/uk/networking/... -
Page 32: Information
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. We, Belkin International, Inc., of 12045 E. Waterfront Drive, Playa Vista, CA 90094, declare under our sole responsibility that the This equipment generates, uses, and can radiate radio frequency product, F9L1004, to which this declaration relates, complies with energy. - Page 33 The firmware setting is not accessible by the end user. Modifications The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved by Belkin International, Inc., may void the user’s authority to operate the equipment.
-
Page 34: European Compliance Statement
INFORMATION European Compliance Statement: Belkin International hereby declares that this F9L1004 Extended Range USB Wireless N Adapter is in compliance with the essential requirements and other revelant provisions of the RTT&E Directive 1999/5/EC, the EMC Directive 2004/108/ EC, and the Low Voltage Directive 2006/5/EC. Conformity was assessed using a Technical Construction File. -
Page 35: Belkin International, Inc., Limited 2-Year Product Warranty
Belkin product that the product shall be free of defects in design, assembly, material, or workmanship. All above warranties are null and void if the Belkin product is not provided to Belkin for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin determines that What the period of coverage is. - Page 36 INFORMATION How to get service. How state law relates to the warranty. To get service for your Belkin product you must take the following steps: THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN. THERE ARE NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED BY LAW, IMPLIED, INCLUDING 1.
- Page 37 © 2011 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. F9L1103 8820xx00781uk Belkin Ltd.
